Java and GraphQL: A Guide

It is quite difficult to design REST APIs as they need to serve multiple clients efficiently. Each client has their own needs, and therefore requires different parameters around data filtering and searching, which is where a traditional rest API comes in. Clients can navigate the single version, picking and choosing the data they want.

Developed by Facebook to overcome the shortcomings of REST API, GraphQL acts as a query language for APIs, as well as a runtime for fulfilling those queries with your extant data. When you provide a complete and clear description of the data in your API, clients can utilize that to ask for exactly what they need. When you expose your schema, the evolution of APIs becomes much easier. Clients can still navigate the schema to fit their needs, even if you add more fields and relations over time.

In this article, I will be walking you through the process of using Java and Spring Boot to build a GraphQL API. In addition, I will also go through the steps to test your GraphQL API using Java’s most popular testing library: JUnit 5.

If you would rather watch a video or follow along with the audio, you can watch this tutorial as a screencast.

Create a GraphQL API With Java and Spring Boot

Let’s start with an initialized app by going to Spring Initializr and defining your app data as follows:

• Project: Maven Project
• Language: Java
• Spring Boot: 2.2.2
• Project Metadata:
  • Group: com.oktadeveloper
  • Artifact: graphqldemo
• Dependencies:
  • Add Spring Web
  • Add Spring Data JPA
  • Add H2 Database

You may also follow this link, it will take you to a pre-configured Spring Initializr page.

Expand the downloaded package and add GraphQL SPQR as a dependency to your pom.xml:

<dependency>

    <groupId>io.leangen.graphql</groupId>

    <artifactId>graphql-spqr-spring-boot-starter</artifactId>

    <version>0.0.4</version>

</dependency>

Then create a Food entity class:

xxxxxxxxxx

package com.oktadeveloper.graphqldemo;

import io.leangen.graphql.annotations.GraphQLQuery;

import javax.persistence.Id;

import javax.persistence.GeneratedValue;

import javax.persistence.Entity;

@Entity

public class Food {

    @Id @GeneratedValue

    @GraphQLQuery(name = "id", description = "A food's id")

    private Long id;

    @GraphQLQuery(name = "name", description = "A food's name")

    private String name;

    public Long getId() {

        return id;

    }

    public void setId(Long id) {

        this.id = id;

    }

    public String getName() {

        return name;

    }

    public void setName(String name) {

        this.name = name;

    }

    @Override

    public String toString() {

        return "Food{" +

            "id=" + id +

            ", name='" + name + '\'' +

            '}';

    }

}

Notice that you are already using GraphQL SPQR (GraphQL Schema Publisher & Query Resolver, pronounced like speaker) annotations (i.e. @GraphQLQuery) on the entity. This is how it will know to expose those entities in the API.

Create the respective repository:

xxxxxxxxxx

package com.oktadeveloper.graphqldemo;

import org.springframework.data.jpa.repository.JpaRepository;

import org.springframework.stereotype.Repository;

@Repository

interface FoodRepository extends JpaRepository<Food, Long> {

}

In GraphQL you can either define a query which will only load data, or define a mutation which will also change the underlying data that feeds the API. For this sample app, you will define the basic read, save and delete functionality for food entities. For that, create a service class:

xxxxxxxxxx

package com.oktadeveloper.graphqldemo;

import io.leangen.graphql.annotations.GraphQLArgument;

import io.leangen.graphql.annotations.GraphQLContext;

import io.leangen.graphql.annotations.GraphQLMutation;

import io.leangen.graphql.annotations.GraphQLQuery;

import io.leangen.graphql.spqr.spring.annotations.GraphQLApi;

import org.springframework.stereotype.Service;

import java.util.Arrays;

import java.util.List;

import java.util.Optional;

@Service

@GraphQLApi

public class FoodService {

    private final FoodRepository foodRepository;

    public FoodService(FoodRepository foodRepository) {

        this.foodRepository = foodRepository;

    }

    @GraphQLQuery(name = "foods") // READ ALL

    public List<Food> getFoods() {

        return foodRepository.findAll();

    }

    @GraphQLQuery(name = "food") // READ BY ID

    public Optional<Food> getFoodById(@GraphQLArgument(name = "id") Long id) {

        return foodRepository.findById(id);

    }

    @GraphQLMutation(name = "saveFood") // CREATE

    public Food saveFood(@GraphQLArgument(name = "food") Food food) {

        return foodRepository.save(food);

    }

    @GraphQLMutation(name = "deleteFood") // DELETE

    public void deleteFood(@GraphQLArgument(name = "id") Long id) {

        foodRepository.deleteById(id);

    }

    @GraphQLQuery(name = "isGood") // Calculated property of Food

    public boolean isGood(@GraphQLContext Food food) {

        return !Arrays.asList("Avocado", "Spam").contains(food.getName());

    }

}

Notice that you are also able to define calculated properties to entities. In the above class, you declared the method isGood() as a property that can be queried for each food. You will see ahead that you can read it just like you read the food’s id and name fields.

To initialize the app with sample data, add an ApplicationRunner bean definition in GraphqldemoApplication:

xxxxxxxxxx

@Bean

ApplicationRunner init(FoodService foodService) {

    return args -> {

        Stream.of("Pizza", "Spam", "Eggs", "Avocado").forEach(name -> {

            Food food = new Food();

            food.setName(name);

            foodService.saveFood(food);

        });

        foodService.getFoods().forEach(System.out::println);

    };

}

Also, add the following line to application.properties to enable the web UI to test the GraphQL API:

xxxxxxxxxx

graphql.spqr.gui.enabled=true

Run Your Java GraphQL API

Run the project with ./mvnw spring-boot:run. Head over to http://localhost:8080/gui and you should see a web UI to test your GraphQL API. Run a sample query by typing on the left-side panel:

xxxxxxxxxx

{

  foods {

    id

    name

    isGood

  }

}

Click the play button and you should see a result similar to this:

xxxxxxxxxx

{

  "data": {

    "foods": [

      {

        "id": 1,

        "name": "Pizza",

        "isGood": true

      },

      {

        "id": 2,

        "name": "Spam",

        "isGood": false

      },

      {

        "id": 3,

        "name": "Eggs",

        "isGood": true

      },

      {

        "id": 4,

        "name": "Avocado",

        "isGood": false

      }

    ]

  }

}

You can also find a specific food by ID using a query like the following:

xxxxxxxxxx

{ food(id: 1) { name } }

And seeing that result:

xxxxxxxxxx

{

  "data": {

    "food": {

      "name": "Pizza"

    }

  }

}

Notice that you are able to manipulate the response. On that last query, you asked only for the name of the food and the API didn’t return the id nor the isGood property.

Create a new food by running the saveFood() mutation:

xxxxxxxxxx

mutation {

  saveFood(food: { name: "Pasta" }) {

    id

    isGood

  }

}

And you will see a result like:

xxxxxxxxxx

{

  "data": {

    "saveFood": {

      "id": 5,

      "isGood": true

    }

  }

}

If you query all the foods again you should see the newly added “Pasta” there.

Test Your Java GraphQL API with JUnit 5

You can write tests for your API with JUnit 5 and Spring Mock MVC. To do this, you can call your API via HTTP, wrap the query in a JSON object with a single property called "query", and the response should be similar to what you were seeing in the web UI. For example, the following class tests that you can retrieve all registered foods:

xxxxxxxxxx

package com.oktadeveloper.graphqldemo;

import org.junit.jupiter.api.Test;

import org.springframework.beans.factory.annotation.Autowired;

import org.springframework.boot.test.autoconfigure.web.servlet.AutoConfigureMockMvc;

import org.springframework.boot.test.context.SpringBootTest;

import org.springframework.http.MediaType;

import org.springframework.test.web.servlet.MockMvc;

import org.springframework.test.web.servlet.request.MockMvcRequestBuilders;

import static org.springframework.test.web.servlet.result.MockMvcResultMatchers.content;

import static org.springframework.test.web.servlet.result.MockMvcResultMatchers.status;

@SpringBootTest

@AutoConfigureMockMvc

class GraphqldemoApplicationTests {

    @Autowired

    MockMvc mockMvc;

    @Test

    void listFoods() throws Exception {

        String expectedResponse = "{\"data\":{\"foods\":[" +

                "{\"id\":1,\"name\":\"Pizza\",\"isGood\":true}," +

                "{\"id\":2,\"name\":\"Spam\",\"isGood\":false}," +

                "{\"id\":3,\"name\":\"Eggs\",\"isGood\":true}," +

                "{\"id\":4,\"name\":\"Avocado\",\"isGood\":false}" +

                "]}}";

        mockMvc.perform(MockMvcRequestBuilders.post("/graphql")

                .content("{\"query\":\"{ foods { id name isGood } }\"}")

                .contentType(MediaType.APPLICATION_JSON)

                .accept(MediaType.APPLICATION_JSON))

                .andExpect(status().isOk())

                .andExpect(content().json(expectedResponse))

                .andReturn();

    }

}

You can replace src/test/java/com/.../GraphqldemoApplicationTests.java with the code above and run ./mvnw test to see it in action.

xxxxxxxxxx

[INFO] Results:

[INFO]

[INFO] Tests run: 1, Failures: 0, Errors: 0, Skipped: 0

[INFO]

[INFO] ------------------------------------------------------------------------

[INFO] BUILD SUCCESS

[INFO] ------------------------------------------------------------------------

For a client to use your GraphQL API, it just needs to call it as a standard HTTP API: send a POST request with the query or mutation and parse the result as JSON.

Secure Your Java GraphQL API

So far, your API is open to whoever has its endpoint URI. Let’s change that by adding proper security.

Okta offers a very handy Maven plugin to set up your app’s security quickly and easily. First, add Okta as a dependency in pom.xml. While you’re at it, add Spring Security’s testing library.

xxxxxxxxxx

<dependency>

    <groupId>com.okta.spring</groupId>

    <artifactId>okta-spring-boot-starter</artifactId>

    <version>1.3.0</version>

</dependency>

<dependency>

    <groupId>org.springframework.security</groupId>

    <artifactId>spring-security-test</artifactId>

    <scope>test</scope>

</dependency>

Then run the Okta Maven plugin from your app’s folder:

xxxxxxxxxx

./mvnw com.okta:okta-maven-plugin:register

Answer a few questions (name, email, and company), and it will generate a new Okta developer account for you.

Run the following command to register a new OIDC application, and add the correct properties into your application.properties file.

xxxxxxxxxx

./mvnw com.okta:okta-maven-plugin:spring-boot

If you start your app again, you’ll notice that you can’t run GraphQL queries anymore. That’s because you’re not authenticated.

To authenticate and see your access token (required to use the API), create a very simple controller that displays the access token. Add the following class to your project:

xxxxxxxxxx

package com.oktadeveloper.graphqldemo;

import org.springframework.beans.factory.annotation.Autowired;

import org.springframework.security.oauth2.client.OAuth2AuthorizedClient;

import org.springframework.security.oauth2.client.OAuth2AuthorizedClientService;

import org.springframework.security.oauth2.client.authentication.OAuth2AuthenticationToken;

import org.springframework.web.bind.annotation.RequestMapping;

import org.springframework.web.bind.annotation.RestController;

import java.security.Principal;

@RestController

class MyAccessTokenController {

    @Autowired

    private OAuth2AuthorizedClientService clientService;

    @RequestMapping("/my-access-token")

    String home(Principal user) {

        OAuth2AuthenticationToken token = (OAuth2AuthenticationToken) user;

        String authorizedClientRegistrationId = token.getAuthorizedClientRegistrationId();

        String name = user.getName();

        OAuth2AuthorizedClient client = clientService.loadAuthorizedClient(authorizedClientRegistrationId, name);

        return "token: " + client.getAccessToken().getTokenValue();

    }

}

Start your app again and go to http://localhost:8080/my-access-token. If you are not authenticated, it will present you with a login form. After authenticating, you will see your token displayed on the web page. Copy the token value as you will use it next.

If you want to use the web UI (http://localhost:8080/gui), click on HTTP HEADERS at the bottom left and add the following, replacing <your_access_token> with the actual value of your access token that you got in the previous step:

xxxxxxxxxx

{ "Authorization": "Bearer <your_access_token>" }

If you are calling the API directly through HTTP, simply add the Authorization header with value Bearer <your_access_token>. You can click the Copy CURL button in the top right of the web UI to see an example.

xxxxxxxxxx

curl 'http://localhost:8080/graphql' -H 'Accept-Encoding: gzip, deflate, br' -H 'Content-Type: application/json' -H 'Accept: application/json' -H 'Connection: keep-alive' -H 'DNT: 1' -H 'Origin: http://localhost:8080' -H 'Authorization: Bearer <your_access_token>' --data-binary '{"query":"{\n  foods {\n    id\n    name\n  }\n}"}' --compressed

Or you can use HTTPie:

xxxxxxxxxx

http POST http://localhost:8080/graphql query='{foods{id,name}}' 'Authorization: <your_access_token>'

Now you have a fully secured GraphQL API!

If you try running your tests (./mvnw test), you will notice they are failing because the API will now answer with 403 Forbidden instead of 200 OK:

xxxxxxxxxx

$ ./mvnw test

...

[INFO] Results:

[INFO]

[ERROR] Failures:

[ERROR]   GraphqldemoApplicationTests.listFoods:34 Status expected:<200> but was:<403>

[INFO]

[ERROR] Tests run: 1, Failures: 1, Errors: 0, Skipped: 0

...

That happens because your tests are not security-aware. To fix that, you need to add the method call .with(SecurityMockMvcRequestPostProcessors.jwt()) to each of your mockMvc.perform() chains, for example:

xxxxxxxxxx

mockMvc.perform(MockMvcRequestBuilders.post("/graphql")

        .with(SecurityMockMvcRequestPostProcessors.jwt()) // <- ADD THIS LINE

        .content("{\"query\":\"{ foods { id name isGood } }\"}")

        .contentType(MediaType.APPLICATION_JSON)

        .accept(MediaType.APPLICATION_JSON))

        .andExpect(status().isOk())

        .andExpect(content().json(expectedResponse))

        .andReturn();

Both MockMvcRequestBuilders.post() and SecurityMockMvcRequestPostProcessors.jwt() can be static imports, so you can make this code a bit easier to read. Add the imports:

xxxxxxxxxx

import static org.springframework.security.test.web.servlet.request.SecurityMockMvcRequestPostProcessors.jwt;

import static org.springframework.test.web.servlet.request.MockMvcRequestBuilders.post;

Then remove the class names from the test:

xxxxxxxxxx

mockMvc.perform(post("/graphql")

        .with(jwt())

        ...

The jwt() method instructs the test to inject a JWT authentication and act accordingly as if a user is authenticated.

Below is a full test class that verifies the GraphQL API you wrote works as expected:

xxxxxxxxxx

package com.oktadeveloper.graphqldemo;

import org.junit.jupiter.api.MethodOrderer;

import org.junit.jupiter.api.Order;

import org.junit.jupiter.api.Test;

import org.junit.jupiter.api.TestMethodOrder;

import org.springframework.beans.factory.annotation.Autowired;

import org.springframework.boot.test.autoconfigure.web.servlet.AutoConfigureMockMvc;

import org.springframework.boot.test.context.SpringBootTest;

import org.springframework.http.MediaType;

import org.springframework.test.web.servlet.MockMvc;

import static org.springframework.security.test.web.servlet.request.SecurityMockMvcRequestPostProcessors.jwt;

import static org.springframework.test.web.servlet.request.MockMvcRequestBuilders.post;

import static org.springframework.test.web.servlet.result.MockMvcResultMatchers.content;

import static org.springframework.test.web.servlet.result.MockMvcResultMatchers.status;

@SpringBootTest

@AutoConfigureMockMvc

@TestMethodOrder(MethodOrderer.OrderAnnotation.class)

class GraphqldemoApplicationTests {

    @Autowired

    MockMvc mockMvc;

    @Test

    @Order(0)

    void listFoods() throws Exception {

        String expectedResponse = "{\"data\":{\"foods\":[" +

                "{\"id\":1,\"name\":\"Pizza\",\"isGood\":true}," +

                "{\"id\":2,\"name\":\"Spam\",\"isGood\":false}," +

                "{\"id\":3,\"name\":\"Eggs\",\"isGood\":true}," +

                "{\"id\":4,\"name\":\"Avocado\",\"isGood\":false}" +

                "]}}";

        mockMvc.perform(post("/graphql")

                .with(jwt())

                .content("{\"query\":\"{ foods { id name isGood } }\"}")

                .contentType(MediaType.APPLICATION_JSON)

                .accept(MediaType.APPLICATION_JSON))

                .andExpect(status().isOk())

                .andExpect(content().json(expectedResponse))

                .andReturn();

    }

    @Test

    @Order(1)

    void addAndRemoveFood() throws Exception {

        String expectedResponseBefore = "{\"data\":{\"foods\":[" +

                "{\"id\":1,\"name\":\"Pizza\"}," +

                "{\"id\":2,\"name\":\"Spam\"}," +

                "{\"id\":3,\"name\":\"Eggs\"}," +

                "{\"id\":4,\"name\":\"Avocado\"}" +

                "]}}";

        String expectedResponseAfter = "{\"data\":{\"foods\":[" +

                "{\"id\":1,\"name\":\"Pizza\"}," +

                "{\"id\":2,\"name\":\"Spam\"}," +

                "{\"id\":3,\"name\":\"Eggs\"}," +

                "{\"id\":4,\"name\":\"Avocado\"}," +

                "{\"id\":5,\"name\":\"Pasta\"}" +

                "]}}";

        // List foods, expect 'New Food' to not be there

        mockMvc.perform(post("/graphql")

                .with(jwt())

                .content("{\"query\":\"{ foods { id name } }\"}")

                .contentType(MediaType.APPLICATION_JSON)

                .accept(MediaType.APPLICATION_JSON))

                .andExpect(status().isOk())

                .andExpect(content().json(expectedResponseBefore))

                .andReturn();

        // Add 'New Food'

        mockMvc.perform(post("/graphql")

                .with(jwt())

                .content("{\"query\":\"mutation { saveFood(food: { name: \\\"Pasta\\\" }) { id name } }\"}")

                .contentType(MediaType.APPLICATION_JSON)

                .accept(MediaType.APPLICATION_JSON))

                .andExpect(status().isOk())

                .andExpect(content().json("{\"data\":{\"saveFood\":{\"id\":5,\"name\":\"Pasta\"}}}"))

                .andReturn();

        // List foods, expect 'New Food' to be there

        mockMvc.perform(post("/graphql")

                .with(jwt())

                .content("{\"query\":\"{ foods { id name } }\"}")

                .contentType(MediaType.APPLICATION_JSON)

                .accept(MediaType.APPLICATION_JSON))

                .andExpect(status().isOk())

                .andExpect(content().json(expectedResponseAfter))

                .andReturn();

        // Remove 'New Food'

        mockMvc.perform(post("/graphql")

                .with(jwt())

                .content("{\"query\":\"mutation { deleteFood(id: 5) }\"}")

                .contentType(MediaType.APPLICATION_JSON)

                .accept(MediaType.APPLICATION_JSON))

                .andExpect(status().isOk())

                .andReturn();

        // List foods, expect 'New Food' to not be there

        mockMvc.perform(post("/graphql")

                .with(jwt())

                .content("{\"query\":\"{ foods { id name } }\"}")

                .contentType(MediaType.APPLICATION_JSON)

                .accept(MediaType.APPLICATION_JSON))

                .andExpect(status().isOk())

                .andExpect(content().json(expectedResponseBefore))

                .andReturn();

    }

}

Further Reading on GraphQL and Java

In this tutorial, you learned how to create your GraphQL API in Java with Spring Boot. But you are not limited to Spring Boot for that. You can use the GraphQL SPQR in pretty much any Java environment, even with Micronaut.

If you are using Quarkus and natively compiling your code, GraphQL SPQR wouldn’t work as it depends on reflection. But on that environment (and others) you could use the less-magic GraphQL Java, it’s a bit more verbose as you need to manually declare your schema, but it gets the job done as well as GraphQL SPQR. And don’t worry, we have a tutorial for GraphQL Java as well:

• Build a Secure API with Spring Boot and GraphQL

If you want to keep reading about Java, Security, and Spring, here are some other links for you:

• Build a Java REST API with Java EE and OIDC
• Java + Spring Tutorials
• 10 Myths About Java in 2019
• Use React and Spring Boot to Build a Simple CRUD App

The source code for this post is available on GitHub in the oktadeveloper/okta-graphql-java-example repository.

If you have any questions about this post, please add a comment below. For more awesome content, follow @oktadev on Twitter, like us on Facebook, or subscribe to our YouTube channel.
