MUnit is a Mule Application Testing Framework that allows you to easily build automated tests for your Integration and APIs. It provides a full suite of integration and unit test capabilities, and it is fully integrated with Maven.

MUnit is fully integrated with Anypoint Studio and allows you to create, design, and test your MUnit tests just like you would Mule Applications.

With MUnit, you can:

  • Create your test by writing Mule code

  • Enable or ignore a particular test

  • Check visual coverage in the studio

  • Generate coverage reports

In this article, I'll show you how to create and run an MUnit test. I am performing this example in Mule 4. MUnit version 2.0, works with all mule version since 4.0

How to Create MUnit Test for Mule Flow

Create a project in Anypoint Studio. The flow looks like, as shown below:

Image title


<?xml version="1.0" encoding="UTF-8"?>

<mule xmlns:http="http://www.mulesoft.org/schema/mule/http" xmlns="http://www.mulesoft.org/schema/mule/core"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:schemaLocation="http://www.mulesoft.org/schema/mule/core http://www.mulesoft.org/schema/mule/core/current/mule.xsd
http://www.mulesoft.org/schema/mule/http http://www.mulesoft.org/schema/mule/http/current/mule-http.xsd">
<http:listener-config name="HTTP_Listener_config" doc:name="HTTP Listener config" doc:id="89ac8a6f-ce64-4726-927f-679b06e56aec" >
<http:listener-connection host="" port="8081" />
<flow name="munitFlow" doc:id="24f8fe4d-2476-4112-9188-8ebc81458030" >
<http:listener doc:name="Listener" doc:id="986cdf76-9129-4aa9-8f36-a5bde486398c" config-ref="HTTP_Listener_config" path="/test"/>
<set-variable value="test" doc:name="Set Variable" doc:id="276e0ebb-2711-4725-a548-78dada3f0f1b" variableName="code"/>
<set-payload value="#[vars.code]" doc:name="Set Payload" doc:id="c48a4a9b-0b0f-4924-925e-40cbaa97d744" />
<logger level="INFO" doc:name="Logger" doc:id="bd82f51a-9c2e-4652-992d-599a35ae3c86" message="#[payload]"/>
  • Right-click on the flow created. Select MUnit -> Create new MUnit.xml suite.

Image title

This will create an MUnit test suite, which will be present in src/test/munit.

Search for the assert that in the mule palette. Drag and drop it in the validation section of the munit-test-suite flow.

In the properties section of assert that, set the values for the EXPRESSION, IS, and MESSAGE.

Image title


<?xml version="1.0" encoding="UTF-8"?>

<mule xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:munit="http://www.mulesoft.org/schema/mule/munit" xmlns:munit-tools="http://www.mulesoft.org/schema/mule/munit-tools"
xmlns="http://www.mulesoft.org/schema/mule/core" xmlns:doc="http://www.mulesoft.org/schema/mule/documentation"
http://www.mulesoft.org/schema/mule/core http://www.mulesoft.org/schema/mule/core/current/mule.xsd
http://www.mulesoft.org/schema/mule/munit http://www.mulesoft.org/schema/mule/munit/current/mule-munit.xsd
http://www.mulesoft.org/schema/mule/munit-tools  http://www.mulesoft.org/schema/mule/munit-tools/current/mule-munit-tools.xsd">
<munit:config name="munit-test-suite.xml" />
<munit:test name="munit-test-suite-munitFlowTest" description="Test" doc:id="77a653f8-0adf-47e1-84db-6b0914db7cd7" >
<munit:execution >
<flow-ref doc:name="Flow-ref to munitFlow" doc:id="c163902a-d303-4fba-a75b-15486d590553" name="munitFlow"/>
<munit:validation >
<munit-tools:assert-that doc:name="Assert that" doc:id="b5c1f3e3-e06f-41ba-a253-9ac09fb0ebd9" expression="#[payload]" is="#[MunitTools::notNullValue()]"/>

Run the MUnit Test

  • Right-click on flow or canvas of MUnit test flow.   Select Run MUnit Suite.

  • After runningMUnit suite, it will provide test result, errors, failures (if any) and other details on the console in Anypoint Studio.

Image title

Once the test is complete, you will get a green color horizontal line of the left side of the studio below the package explorer. This means that your test case has been complete, successfully executed, and passed.

                                            RUN: 1/1                      ERRORS: 0             FAILURE: 1

integration ,mule 4 ,munit ,tutorial ,munit testing
