Publish and Deploy Angular and .NET Core Applications as a Single Unit

DZone 's Guide to

Publish and Deploy Angular and .NET Core Applications as a Single Unit

In this post I will talk about the basics of publishing and deploying Angular and .Net Core Web applications as a single unit.

· Web Dev Zone ·
Free Resource

In this post I will talk about the basics of publishing and deploying Angular and .Net Core Web applications as a single Unit.

In this scenario, I already have a web application built using .Net Core, Angular and Entity Framework and I will use this application for deployment purposes. You can instead use your own application if u like. The .NET Core web application is also serving an Angular application as well.

Lets see how can we publish and deploy this application.

We can break-down the process in two steps as follows:

  • Building and Publishing the Application
  • Deploying and Running the Application

Building and Publishing the Applications

Building the Angular App

As our Angular application will be hosted inside .NET Core web application, we can build our Angular application first using the following command. The output of the build process will be placed inside wwwroot directory which is a default directory for delivering static contents for .NET Core web applications (I set this path in angular.json file for build-output path).

Building Angular


Build & Publish .NET Core Application

Microsoft has great resources available to describe a step by step approach. However, for quick reference, I’ll show you how to do this step which requires running following power-shell command.

With our Angular build part already done, let's execute following command to build and publish the .NET Core web application.

Building .NET Core app


Command will create a publish folder in your project’s bin directory as follows:

Creating a publish folder

Now this folder is the output we can take and deploy. I am going to copy it on a different location and rename the folder to AccountingApp as well.

AccountingApp folder

Database Deployment

There are many different ways you can deploy the database. However, in my case, the application is using Entity Framework migration strategy and if needed we can simply run those migrations against a target database or can also generate script to be deployed in another way.

Deploying and Running the Application

So, we have a self-contained deployment folder for our web-application. The simplest thing we can do is to run it with Kestrel. Kestrel is a cross-platform web server for ASP.NET Core and it is included by default in ASP.NET Core project templates.

Running Using Kestrel

You can use Kestrel by itself or with a reverse proxy server, such as Internet Information Services (IIS), Nginx, or Apache. A reverse proxy server receives HTTP requests from the network and forwards them to Kestrel.

I have copied the publish folder to a different location and renamed it to AccountingApp as follows:

Copied publish folder

Now open a PowerShelld prompt inside this folder and execute following command to run the web application using Kestrel:

Run web application


Now browse to this URL using a web browser and we have our published web-app shows up:

Published web app


Using a Reverse Proxy

The use of reverse proxy can help in many ways. For example, it can limit the exposed public surface area of the apps that it hosts. Also, it can provide an additional layer of configuration and defense and might integrate better with existing infrastructure. There are many other benefits you can look at Microsoft website and in the following section how can be use IIS to deploy our published web application.

Enable IIS Features

Based on your OS, you might need to enable IIS feature as shown below. Microsoft has great information about this process in details.

Enable IIS

You will need to install Hosting Bundle which is needed to host .NET Core Applications under IIS. You can download that from Microsoft website.

Hosting Bundle

Deploy to IIS

Once the feature is installed, you can run it from the Start menu as shown below:

Run from start menu

The IIS Screen will show up with a default website.

Default website

Right-click on Sites-node in the left section and add a new website as follows:

Add new website

For physical path value, I select the same folder where copied the published output earlier. So location is same, we are just delegating its management to IIS.

Configure Applications Pool

Creating a website in IIS also created an application pool and we just need to set it as follows:

Application Pool

Adjusting Folder Security

You might need to adjust security permissions as follows for the AccountingApp folder.

Adjusting folder security


Add a new user as follows:

Add new user


With all this in place, open up the browser and access the application and you will see a familiar dashboard but this time application is being served by IIS.

Dashboard


Summary

Deploying .Net Core web applications is not that difficult. I have shown you two very common ways to delivery your application. Similar approach is used if you want to deploy to cloud services or you can take one step further and deliver it via docker containers.

You can use any .NET core based application for deployment purposes and if you want to know more details about above shown application, you can check its link in the references section.

References

Build Accounting Application Using .NET Core, Angular and Entity-Framework.
https://www.amazon.com/dp/B08D8PLN6T
