REST API Testing With Spring Cloud Feign Clients

DZone's Guide to

REST API Testing With Spring Cloud Feign Clients

Looking to make the job of testing your REST API easier and more relevant? Then this post is for you. Read on for details.

· Integration Zone ·
Free Resource

SnapLogic is the leading self-service enterprise-grade integration platform. Download the 2018 GartnerMagic Quadrant for Enterprise iPaaS or play around on the platform, risk free, for 30 days.

What Is Spring Cloud Feign?

Spring Cloud Feign is a convenient way to test your application’s API, focused on creating tests to verify business logic instead of spending time on the technical implementation of web services clients.

You only need to describe how to reach the remote API service by providing details such as the URL, request and response body, accepted headers, etc. The Feign Client will take care of the implementation details.

In this blog post, you will be taken through a step-by-step guide describing the process of creating a comprehensive framework for testing RESTful APIs. Spring Feign doesn’t stand alone but rather works closely with other Spring Framework components like Spring Web and Spring IoC container. To understand Feign, we need to have a closer look at these two components.

What Is Spring IoC and How Does It Interact With Feign for Rest API Testing?

Spring IoC implements the dependency injection principle when all the object dependencies are loaded (injected) by another object. This means that for any object, you only need to define all the objects it depends on, without taking care of the initialization details. This is why it’s called inversion of control (IoC). This approach makes your code more flexible and independent of the implementation of the objects it depends on.

In Spring, the object that injects dependencies is called a Spring container. The container implements the ApplicationContext interface (which itself extends the BeanFactory interface by adding more enterprise-specific functionalities) and is responsible for installing, configuring, and assembling beans in the application. ApplicationContext itself is a central interface to provide configuration for an application. It has many features, but, within this blog post, we will need only bean factory methods to access application context and methods to load file resources.

Spring Feign uses ApplicationContext to create an ensemble of components to send requests to a remote service endpoint described by the Feign Client specification. We will use ApplicationContext to create beans of Feign Clients and also to create beans of almost all types within the test framework. To read more about Spring IoC refer to the documentation.

We will use Spring Web components that access resources, like the @RequestMapping annotation, to describe API interfaces.

What Do I Need to Get Started?

Feign Clients use instruments from the Spring Web package to describe remote services endpoints. Later, I will show you how to use those instruments to create a REST service client.

So, to build up the framework, we will use the following libraries and technologies:

  1. Java 1.8 or higher. You can download it from the official site.
  2. Spring Boot. You may notice that I didn’t previously use the term ‘Spring Boot,' but only used Spring. While Spring has many useful features like the IoC container and the MVC framework, to use it you still need to set up a lengthy framework configuration, define how the Spring components should work together, and so on. On the other hand, Spring Boot bootstraps your applications in a few steps while taking care of configuration, the installation of dependencies, and the auto-configuration of components. It also helps assemble components that should work together. To learn more about Spring Boot, refer to the official site. This is why we will use Spring Boot as the application framework on top of Spring.
  3. Since we are going to create an automated testing framework that tests other applications, we need to choose a testing framework. TestNG will be the perfect match here. It’s not only the framework that allows you to create any type of tests (unit, component, end-to-end, etc.) in a fast and easy fashion, it also supports integration with Spring Boot, which gives us more flexibility and explicit support in using Spring Feign with the help of Spring Boot. To learn more about TestNG, refer to its documentation.
  4. Maven as a build tool. To download Maven, follow this link. Maven is a project management tool that helps you build your project and manage documentation and resources. In terms of this project, we will use Maven to compile the Java code, and download all the libraries that the test framework depends on.

Right now you may be wondering why we need to use these “heavy” libraries and technologies to create a test framework for RESTful API testing when there are already lightweight web service clients. However, once the framework is built, you will notice how elegant it is: all the interfaces have clear boundaries and functional purposes, there is no mixing between the layers and low-level details and configuration is handled by the Spring Boot application.

As automated test engineers, we need to focus only on business logic instead of the implementation of infrastructure. Extending such frameworks is also very easy.

Creating a New Feign Client Project in Your IDE

Let’s start with creating a new project. We chose the IntelliJ IDEA IDE, but you can use any IDE of your choice. There will not be any specific action that requires only using this IDE, so the code in this blog post can easily be exported to any IDE.

To create a project in IntelliJ Idea select: File -> New -> Project. Select Maven. Click on Next.

Image title

Now, specify a unique group id (consider a group as a tree of folders for your project), an artifactId (project name) and a version.

Once the project is created, the next step will be to define all the required dependencies in the pom.xml file that is in the project root.

Created from a template, the initial pom.xml looks like this:

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
     xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
     xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
<modelVersion>4.0.0</modelVersion>

<groupId>com.blazemeter.api</groupId>
<artifactId>SpringFeignClientsTests</artifactId>
<version>1.0-SNAPSHOT</version>

</project>

To add dependencies to the project, add them within the <dependencies></dependencies> block.

Declaring a dependency from Spring feign:

<dependency>

<groupId>org.springframework.cloud</groupId>

<artifactId>spring-cloud-starter-feign</artifactId>

<version>1.4.3.RELEASE</version>

</dependency>

Spring Boot dependency:

<dependency>

<groupId>org.springframework.boot</groupId>

<artifactId>spring-boot-starter</artifactId>

<version>2.0.0.RELEASE</version>

</dependency>

TestNG dependency:

<dependency>

<groupId>org.testng</groupId>

<artifactId>testng</artifactId>

<version>6.11</version>

</dependency>

Summarizing, the complete dependencies will look like this:

<dependencies>

<dependency>

    <groupId>org.springframework.cloud</groupId>

    <artifactId>spring-cloud-starter-feign</artifactId>

    <version>1.4.3.RELEASE</version>

</dependency>

<dependency>

    <groupId>org.springframework.boot</groupId>

    <artifactId>spring-boot-starter</artifactId>

    <version>2.0.0.RELEASE</version>

</dependency>

<dependency>

    <groupId>org.testng</groupId>

    <artifactId>testng</artifactId>

    <version>6.11</version>

</dependency>

</dependencies>

We have defined all the required dependencies to start creating feign clients to a remote server.

To configure the remote web service that is going to be used in this blog post please refer to the readme of the project on GitHub.

Creating Spring Cloud Feign Clients

Before proceeding further first set up a mock for the RESTful service Feign Client that will be created as described in the GitHub repo of this demo.

To look at the Feign Client, refer to the code snippet from the src/main/java/com/blazemeter/blog/api/client package

@FeignClient(name = "bookStoreClient", url = "http://" + "${host}" + ":${port}", configuration = BookClientConfiguration.class)
public interface BookStoreClient {

@RequestMapping(method = RequestMethod.GET, path = "getBooks")

public List<Book> getBooks();




@RequestMapping(method = RequestMethod.POST, path = "buyBook")

@Headers("Content-Type: application/json")

public Book buyBook(@RequestBody Book book);

}

The Feign Client should be created as a Java interface without any implementation of the methods as this is how Feign clients should work. All the implementations should be handled by the Spring framework.

The annotation @FeignClient tells Spring that this interface should be used as Feign. In “FeignClient” properties, we have added a unique name and URL. The URL variable tells “FeignClient” where to send all the requests associated with the client. As you can see, it’s composed from the “http://” prefix with the host and port values attached from the application context by reading corresponding properties from the “application.properties” file. Also, we set up the configuration class to Feign, but this will be explained later when I explain POST request mapping.

Method List<Book> getBooks() helps to send the GET request to the “/getBooks” request of the service. To indicate that it is the method that should send web requests, we’ve used the @RequestMapping annotation of the “Spring Web” package with the appropriate properties: the request method GET and the path getBooks. As a response, the method accepts a list of books.

The same applies to the buyBook method but in terms of sending the POST request to buyBook endpoint. We use the annotation @RequestBody to indicate that the passed parameter book should be recognized as the request body of the request. The @Headers  annotation is used to send the request header with the content-type of the request’s body.

The Feign Client doesn’t make any conversion of the requests bodies and parameters, but, rather, uses the Encoder and Decoder for that instead. Configured earlier, the web service, with the help of MockServerManager, consumes and produces the body in JSON format. To convert the buyBook method parameter book of the type Book to a JSON string, we need to specify the custom Encoder to Feign Client.

This is done in the BookClientConfiguration class as follows:

public class BookClientConfiguration {




public Encoder feignEncoder() {

    HttpMessageConverter jacksonConverter = new MappingJackson2HttpMessageConverter();

    ObjectFactory<HttpMessageConverters> objectFactory = () -> new HttpMessageConverters(jacksonConverter);

    return new SpringEncoder(objectFactory);

}

}

Starting the Spring Boot Application

The HttpMessageConverter is defined as MappingJackson2HttpMessageConverter and passed within the ObjectFactory to a new Encoder entity.

OK, now we are done with configuring the web service and client and are ready to start our Spring Boot application.

This is achieved with the Java application run class (with public static as the main method) where the Spring Boot application is started via the Spring runner.

@EnableFeignClients

@SpringBootApplication

public class BookStoreApplication {




public static void main(String[] args) {

    SpringApplication.run(BookStoreApplication.class, args);

}

}

BookStoreApplicationis marked with @SpringBootApplication to indicate that this is a Spring Boot application, the @EnableFeignClients annotation tells Spring Boot that we are going to use FeignClients and hence our application needs to search for interfaces with the @FeignClient annotation.

Now, we have fully configured the application to test web services.

Creating Your First Test in the Test Package

Let’s create our first test in the test package of the project:

@SpringBootTest

public class WebServiceTest extends AbstractTestNGSpringContextTests {







@Autowired

private MockServerManager serverManager;




@Autowired

private BookStoreClient bookStoreClient;







@BeforeClass

public void startServer() {

    serverManager.start();

}




@AfterClass

public void shutDown() {

    serverManager.shutDown();

}




@Test

public void testService() {

List<Book> books = bookStoreClient.getBooks();

assert !books.isEmpty();

Book bookToBuy = books.get(0);

Book boughtBook = bookStoreClient.buyBook(books.get(0));

assert bookToBuy.equals(boughtBook);

}
}

The test class is marked with the @SpringBootTest annotation, which runs tests for the Spring Boot application deployed earlier. There is one important note here: test classes marked as @SpringBootTest must reside in the same package tree as the Spring Boot Application class.

Extending from AbstractTestNGSpringContextTests gives us access to the Spring Boot application context. From the application context, we inject MockServerManager and BookStoreClient, which are created automatically by the Spring Boot application with help of the @Autowired annotation.

To use those features, additional dependencies need to be added to pom.xml:

<dependency>

<groupId>org.springframework.boot</groupId>

<artifactId>spring-boot-test</artifactId>

<version>1.5.8.RELEASE</version>

<scope>test</scope>

</dependency>

<dependency>

<groupId>org.springframework</groupId>

<artifactId>spring-test</artifactId>

<version>4.3.8.RELEASE</version>

<scope>test</scope>







@Autowired

private MockServerManager serverManager;




@Autowired

private BookStoreClient bookStoreClient;







@BeforeClass

public void startServer() {

    serverManager.start();

}




@AfterClass

public void shutDown() {

    serverManager.shutDown();

}




@Test

public void testService() {

List<Book> books = bookStoreClient.getBooks();

assert !books.isEmpty();

Book bookToBuy = books.get(0);

Book boughtBook = bookStoreClient.buyBook(books.get(0));

assert bookToBuy.equals(boughtBook);

}
}

Please note that the above dependencies have a scope test and will be available only under the test package.

The test itself does the following:

Before any test starts, the web service needs to be deployed and configured. This is done by calling the start() method of the Mock Server Manager, serverManager.

@BeforeClass
public void startServer() {
    serverManager.start();
}

In the test, we get the list of available books by calling the appropriate method of the web service client. Then we check if there is at least 1 book available. By calling the method buyBook, we buy the first available book and validate if the returned book is the book we were intending to buy. To compare two different books, we need to override the Object’s equals method for Book objects:

@Override

public boolean equals(Object o) {

Book compareTo = (Book)o;

return title.equals(compareTo.getTitle())

        && author.equals(compareTo.getAuthor())

        &&price == compareTo.getPrice();

}

That’s it, now we can run our test.

All tests that are under project test package can be executed by the Maven test command mvn test.

A single test can be started with the command mvn -Dtest=WebServiceTest test. The test results can be viewed as an HTML report in the build output directory/surefire-reports/index.html file.

Why You Should Use Spring Boot

So why should you use Spring Boot if it needs so much configuration? Yes, you still need to make some changes, but it’s not intensive compared to the amount of time and effort you will spend configuring a comprehensive framework for a RESTful web service. You will only need to configure Spring Boot once and then you can reuse it over and over in other projects if needed. In return, you will receive a well-built framework with clear functional boundaries where the Feign Client takes care of all the low-level details and you can focus on business level targets! So, go ahead, try this approach yourself, and you will see how elegant the solution is!
