Spring Boot Application Connect to LDAP Userstore

DZone's Guide to

Spring Boot Application Connect to LDAP Userstore

There are detailed instructions on connecting Java Spring Boot applications to LDAP and an example using Apache Directory Studio.

· Web Dev Zone ·
Free Resource

Deploying code to production can be filled with uncertainty. Reduce the risks, and deploy earlier and more often. Download this free guide to learn more. Brought to you in partnership with Rollbar.

In this blog post, we are going to connect a sample spring boot application with LDAP-based userstore to do the authentication.

First, create an LDAP server. I've created a sample server using Apache Directory Studio.

Then create a sample spring-boot application with the following dependencies.

<parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>1.3.3.RELEASE</version>
        <relativePath/>
    </parent>
    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-devtools</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-security</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.security</groupId>
            <artifactId>spring-security-ldap</artifactId>
        </dependency>
        <dependency>
            <groupId>org.apache.directory.server</groupId>
            <artifactId>apacheds-server-jndi</artifactId>
            <version>1.5.5</version>
        </dependency>
    </dependencies>

Then in your sample application extend the WebSecurityConfigurerAdapter class and override the below two methods. Provide the connection details as per the LDAP server created above.

@Configuration
@EnableWebSecurity
public class LdapSecurity extends WebSecurityConfigurerAdapter {

    @Override
    protected void configure(HttpSecurity httpSecurity) throws Exception {
        httpSecurity.httpBasic().and().authorizeRequests().anyRequest().authenticated().and().csrf().disable();

    }

    @Override
    protected void configure(AuthenticationManagerBuilder authenticationManagerBuilder) throws Exception {
        authenticationManagerBuilder.ldapAuthentication()
                .contextSource().url("ldap://localhost:10389/dc=example,dc=com")
                .managerDn("uid=admin,ou=system").managerPassword("secret")
                .and()
                .userSearchBase("ou=users")
                .userSearchFilter("(cn={0})");
    }
}

That's it the spring will engage basic authenticate your requests to the webapp.
Now start the app using mvn spring-boot:run or using the java -jar spring-boot-ldap-sample.jar, Access the webapp using http://localhost:8080/ and provide the credentials of a user in the LDAP user base. You'll see the authenticated user's details after a successful authentication.


 Full source to the sample can be found here.
