Spring Boot/Batch Tutorial: Integration With HBASE REST API and Data Ingestion

Before reading this article you need some basic knowledge on REST, Spring Boot, and Spring Batch.

This article is focused on how to ingest data using Spring Boot/Batch and the HBase REST API. As Spring for Apache Hadoop project will reach End-Of-Life status on April 5th, 2019, using the REST API with Spring Batch helps us to interact with HBase directly from a Windows environment, so you don't need to deploy your jar to a Unix/Linux environment where your HBase is running.

For data ingestion using HBase's REST API, we need to use Base64 encoding for ingesting and fetching as well. First, we need to start HBase's REST API using the following commands:

The screenshot below shows what happens when these commands are run:

Now we are ready and have HBase's REST API up and running. Let's create a sprinboot-batch project and create our classes for file ingestion.

This use case covers the three concepts:

1. Reading and writing multiple files with Spring Batch.

2. Integrating REST APIs in an item writer.

3. Invoking HBase's REST API for ingestion.

Here we are going to ingest each file as a single column in an HBase table and file name as row-key of that HBase table. First, create a Java bean to define the file details that we'll use across the project.

Now let's build the job config class with a reader, processor, and writer:

package com.damu.hbase.test.ingest;

import java.io.ByteArrayOutputStream;

import java.io.File;

import java.io.FileInputStream;

import java.io.IOException;

import java.nio.file.Files;

import java.nio.file.Path;

import java.nio.file.Paths;

import java.security.KeyManagementException;

import java.security.KeyStoreException;

import java.security.NoSuchAlgorithmException;

import java.security.cert.X509Certificate;

import java.time.Instant;

import java.util.Base64;

import java.util.List;

import java.util.stream.Collectors;

import javax.net.ssl.SSLContext;

import org.apache.http.conn.ssl.SSLConnectionSocketFactory;

import org.apache.http.conn.ssl.TrustStrategy;

import org.apache.http.impl.client.CloseableHttpClient;

import org.apache.http.impl.client.HttpClients;

import org.springframework.batch.core.Job;

import org.springframework.batch.core.Step;

import org.springframework.batch.core.configuration.annotation.EnableBatchProcessing;

import org.springframework.batch.core.configuration.annotation.JobBuilderFactory;

import org.springframework.batch.core.configuration.annotation.StepBuilderFactory;

import org.springframework.batch.core.launch.support.RunIdIncrementer;

import org.springframework.batch.item.ItemWriter;

import org.springframework.batch.item.support.PassThroughItemProcessor;

import org.springframework.beans.factory.annotation.Autowired;

import org.springframework.context.annotation.Bean;

import org.springframework.context.annotation.Configuration;

import org.springframework.http.HttpEntity;

import org.springframework.http.HttpHeaders;

import org.springframework.http.HttpMethod;

import org.springframework.http.ResponseEntity;

import org.springframework.http.client.HttpComponentsClientHttpRequestFactory;

import org.springframework.scheduling.annotation.EnableScheduling;

import org.springframework.web.client.RestTemplate;

@Configuration

@EnableBatchProcessing

@EnableScheduling

public class ReadMultiFileJob {

 @Autowired

 private JobBuilderFactory jobBuilderFactory;

 @Autowired

 private StepBuilderFactory stepBuilderFactory;

 @Bean

 public Job readFiles() throws IOException {

  return jobBuilderFactory.get(“readFiles”).incrementer(new RunIdIncrementer()).

  flow(step1()).end().build();

 }

 @Bean

 public Step step1() throws IOException {

  return stepBuilderFactory.get(“step1”). < JSONFileBatchBean, JSONFileBatchBean > chunk(10)

   .reader(multiResourceItemReader()).writer(writer()).build();

 }

 @Bean

 public PassThroughItemProcessor < JSONFileBatchBean > processor() {

  return new PassThroughItemProcessor < JSONFileBatchBean > ();

 }

 @Bean

 public FileReader multiResourceItemReader() throws IOException {

  List < File > jsonFiles = Files.walk(Paths.get(“C: \\DAMU\\ XML\\ multi”))

   .filter(Files::isRegularFile)

   .map(Path::toFile)

   .collect(Collectors.toList());

  System.out.println(“inside file reader === === === === === = ”);

  return new FileReader(jsonFiles);

 }

 @Bean

 public RestTemplate restTemplate() {

  TrustStrategy acceptingTrustStrategy = (X509Certificate[] chain, String authType) -> true;

  SSLContext sslContext = null;

  try {

   sslContext = org.apache.http.ssl.SSLContexts.custom().loadTrustMaterial(null, acceptingTrustStrategy)

    .build();

  } catch (KeyManagementException e) {

   e.printStackTrace();

  } catch (NoSuchAlgorithmException e) {

   e.printStackTrace();

  } catch (KeyStoreException e) {

   e.printStackTrace();

  }

  SSLConnectionSocketFactory csf = new SSLConnectionSocketFactory(sslContext);

  CloseableHttpClient httpClient = HttpClients.custom().setSSLSocketFactory(csf).build();

  HttpComponentsClientHttpRequestFactory requestFactory = new HttpComponentsClientHttpRequestFactory();

  requestFactory.setHttpClient(httpClient);

  RestTemplate restTemplate = new RestTemplate(requestFactory);

  return restTemplate;

 }

 @Bean

 public ItemWriter < JSONFileBatchBean > writer() {

  return items -> {

   for (JSONFileBatchBean bean: items)

   {

    System.err.println(bean.getFileName());

    //System.err.println(“bean.toString() — -”+bean.getJsonFile().createNewFile());

    FileInputStream in = new FileInputStream(bean.getJsonFile());

    ByteArrayOutputStream bos = new ByteArrayOutputStream();

    byte[] buf = new byte[1024];

    for (int readNum;
     (readNum = in .read(buf)) != -1;) {

     bos.write(buf, 0, readNum);

    }

    byte[] byteArray = bos.toByteArray();

    Instant instant = Instant.now();

    long timeStampMillis = instant.toEpochMilli();

    String rowKey = bean.getFileName();

    HttpHeaders headers = new HttpHeaders();

    headers.set(“Accept”, “application / json”);

    headers.set(“content - type”, “application / json”);

    String fileName = bean.getFileName();

    String rowKeyHash = Base64.getEncoder().encodeToString(bean.getFileName().getBytes(“utf - 8”));

    String URL = ”http: //localhost:8157/FILE_DATA/"+rowKeyHash;

     String jsonPaylod = ” {
      \”
      Row\”: [{
       \”
       key\”: “+“\””

        +rowKeyHash

        +
        “\”,
       \”Cell\”: [{
        \”
        column\”: \””

         +“RGF0YUNGOnRlc3R4bWw = ” //XML test

         +“\”,
        \””

        +“timestamp\”: ”

         +“\”” +timeStampMillis + ”\””

         +“,
        \”$\”: \””+Base64.getEncoder().encodeToString(byteArray)

         +
         “\”
       }]
      }]
     }”;

    System.out.println(“byteArray === ”+byteArray);

    System.out.println(“jsonPaylod === ”+jsonPaylod);

    HttpEntity < String > entity = new HttpEntity < > (jsonPaylod, headers);

    ResponseEntity < String > response = restTemplate().exchange(URL, HttpMethod.POST, entity, String.class);

    System.out.println(“Response: “+response);

    in .close();

   }

  };

 }

}

ow let's see how we are calling HBase API

Here are the table structure and URL details.

After running the  Spring Boot application console logger, we get the following:

TEST_JSON.json

byteArray===[B@30871dc5

jsonPaylod==={“Row”: [{“key”: “VEVTVF9KU09OLmpzb24=”,”Cell”: [{“column”: “RGF0YUNGOnRlc3R4bWw=”, “timestamp”:”1554230585299",”$”: “ew0KICAibmFtZSI6ICJKdW5nbGUgR3ltIiwNCiAgImFnZSI6IDI1LA0KICAiZmF2b3JpdGVfY29sb3IiOiAiI2ZmYTUwMCIsDQogICJnZW5kZXIiOiAibWFsZSIsDQogICJsb2NhdGlvbiI6IHsNCiAgICAiY2l0eSI6ICJTZWF0dGxlIiwNCiAgICAic3RhdGUiOiAiV0EiLA0KICAgICJjaXR5c3RhdGUiOiAiU2VhdHRsZSwgV0EiDQogIH0sDQogICJwZXRzIjogWw0KICAgIHsNCiAgICAgICJ0eXBlIjogImRvZyIsDQogICAgICAibmFtZSI6ICJGb28iDQogICAgfSwNCiAgICB7DQogICAgICAidHlwZSI6ICJjYXQiLA0KICAgICAgIm5hbWUiOiAiQmFyIg0KICAgIH0NCiAgXQ0KfQ==”}]}]}

Response: <200,{}>

TEST_TEXT.txt

byteArray===[B@7d4d62d1

jsonPaylod==={“Row”: [{“key”: “VEVTVF9URVhULnR4dA==”,”Cell”: [{“column”: “RGF0YUNGOnRlc3R4bWw=”, “timestamp”:”1554230585637",”$”: “SGVsbG8gdGhpcyBzaW1wbGUgaGFic2UgaW50ZWdyYXRpb24=”}]}]}

Response: <200,{}>

TEST_XML.xml

byteArray===[B@6df13b6a

2019-Apr-02 11:43:06.292 INFO [restartedMain] o.s.b.c.l.s.SimpleJobLauncher — Job: [FlowJob: [name=readFiles]] completed with the following parameters: [{run.id=14}] and the following status: [COMPLETED]

We can use the HBase GET API to see the ingested data:
