Spring Web Service to Securely Transfer SOAP Request and Response Call

In this article, I will explain the steps to transfer a SOAP Request and Response call securely with a 256-bit key.

I have used the Spring framework with JAXws and AES algorithms for encryption and decryption.

I hope this article will help you to understand this secure way of transferring SOAP calls using a public key as shown in below figure.

Sample Soap UI output

Web.xml

<web-app xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns="http://java.sun.com/xml/ns/javaee"
xsi:schemaLocation="http://java.sun.com/xml/ns/javaee
http://java.sun.com/xml/ns/javaee/web-app_3_0.xsd"
id="WebApp_ID" version="3.0">

<display-name>Spring Web Service with AES Encryption </display-name>

<servlet>
  <servlet-name>dispatcher</servlet-name>
  <servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class>
  <load-on-startup>1</load-on-startup>
</servlet>

<servlet-mapping>
<servlet-name>dispatcher</servlet-name>
<url-pattern>/</url-pattern>
</servlet-mapping>

<servlet>
<servlet-name>wsservice</servlet-name>
<servlet-class>com.sun.xml.ws.transport.http.servlet.WSSpringServlet</servlet-class>
<load-on-startup>2</load-on-startup>
</servlet>

<servlet-mapping>
  <servlet-name>wsservice</servlet-name>
  <url-pattern>/AESWS</url-pattern>
</servlet-mapping>

<listener>
  <listener-class>
  org.springframework.web.context.ContextLoaderListener
  </listener-class>
</listener>

<session-config>
<session-timeout>5</session-timeout>
</session-config>

</web-app>

Dispatcher-servlet.xml

The Config.properties files are configured in the property-placeholder. The AES Key is configured in these properties files.

Below is the AES encrypted Java file to marshal and unmarshal the data.

<beans xmlns="http://www.springframework.org/schema/beans"
xmlns:context="http://www.springframework.org/schema/context"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xmlns:mvc="http://www.springframework.org/schema/mvc"
xmlns:p="http://www.springframework.org/schema/p"
xmlns:c="http://www.springframework.org/schema/c"
xmlns:tx="http://www.springframework.org/schema/tx"
xsi:schemaLocation="
        http://www.springframework.org/schema/beans
        http://www.springframework.org/schema/beans/spring-beans-3.2.xsd
        http://www.springframework.org/schema/mvc
        http://www.springframework.org/schema/mvc/spring-mvc-3.2.xsd
        http://www.springframework.org/schema/context
        http://www.springframework.org/schema/context/spring-context-3.2.xsd
        http://www.springframework.org/schema/tx
        http://www.springframework.org/schema/tx/spring-tx-3.2.xsd">

    <context:annotation-config />

<context:component-scan base-package="com.shri" />

<bean class="org.springframework.web.servlet.view.InternalResourceViewResolver">
  <property name="prefix">
  <value>/WEB-INF/views/</value>
  </property>
  <property name="suffix">
    <value>.jsp</value>
  </property>
</bean>

<mvc:resources mapping="/resources/**" location="/resources/" />

<bean id="messageSource"
class="org.springframework.context.support.ResourceBundleMessageSource">
<property name="basename" value="message" />
</bean>

<context:property-placeholder location="classpath:config.properties, classpath:message.properties"
ignore-unresolvable="true"/>

<mvc:annotation-driven />

<!-- AWS Encryption starts -->
<bean id="encrypt" class="com.shri.ws.shared.AESEncrypted" >
<constructor-arg value="${aes_key}" type="String"></constructor-arg>
</bean>
<!-- AWS Encryption end-->

</beans>

application-context.xml

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:ws="http://jax-ws.dev.java.net/spring/core"
xmlns:wss="http://jax-ws.dev.java.net/spring/servlet" xmlns:tx="http://www.springframework.org/schema/tx"
xsi:schemaLocation="http://www.springframework.org/schema/beans
       http://www.springframework.org/schema/beans/spring-beans-2.5.xsd
       http://jax-ws.dev.java.net/spring/core
   http://jax-ws.dev.java.net/spring/core.xsd
   http://jax-ws.dev.java.net/spring/servlet
   http://jax-ws.dev.java.net/spring/servlet.xsd">

<import resource="dispatcher-servlet.xml" />

<!-- Web service binding status -->
<wss:binding url="/AESWS">
  <wss:service>
  <ws:service bean="#shriAESWS" />
  </wss:service>
</wss:binding>
<!-- Web service binding status ends -->

<!-- Web service methods bean Declaration -->

<!-- Service -->
<bean id="shriAESWS" class="com.shri.ws.service.WSAppService">
<property name="enqObjectImpl" ref="enqObjectImpl"></property>
</bean>
<!-- Service Ends -->

<!-- Implementation Object -->
<bean id="enqObjectImpl" class="com.shri.ws.impl.EnqObjectImpl" />
<!-- Implementation Object Ends -->
<!-- Web service methods bean Declaration Ends -->

</beans>

config.properties file

This is the public AES 256-bit key used for Encryption and Decryption.

aes_key= x!A%D*G-KaPdSgVkYp3s6v8y/B?E(H+M

The WSAppService extends SpringBeanAutowiringSupport.

Include your DAO Process once the request contains a valid file.

Create additional request using the autowired @WebMethod (operationName="User_DEFINE") in the method.

@WebService(serviceName = "WSAppService", portName = "WSAppServicePort",
targetNamespace = "http://example.org/AESWS")
public class WSAppService extends SpringBeanAutowiringSupport {

@Resource
private WebServiceContext wsctx;

static Logger log = Logger.getLogger(WSAppService.class.getName());

private EnqObjectImpl enqObjectImpl;

@WebMethod(exclude = true)
public void setEnqObjectImpl(EnqObjectImpl enqObjectImpl) {
this.enqObjectImpl = enqObjectImpl;
}

//WebService
@WebMethod(operationName = "WS")
@WebResult(name = "OUTBOUND")
@XmlJavaTypeAdapter(AESEncrypted.class) //Used to encrypt and decrypt
public String startProcess(
@WebParam(name = "INBOUND") @XmlJavaTypeAdapter(AESEncrypted.class) String request ){

    log.info(" Request : " + request);
    String response; // response
    Outbound outbound = new Outbound();

    try{
    log.info(request);
    //Validate the request
    if(request.trim().length()>0 && !request.trim().equalsIgnoreCase("?"))

        //After unmarsel the header request tag, validate the request by XSD schema
        //Step1
        XmlToObject xmlToObject = new XmlToObject();

        //Step2
        //Convert request string to object
        Inbound inbound = (Inbound)XmlToObject.convert(Inbound.class, request, outbound);

        if (outbound.getStatus() == "failure") {
          response = outbound.toString(); // Outbound XML tag
          return response;
        }else{
          //Do your DAO process here
          log.info(inbound.getName());
          log.info(inbound.getAddress());
          //Move to service and start DAO Process
          outbound = enqObjectImpl.startProcess(inbound, outbound);
          outbound.setStatus("success");
        }

    }else{
    outbound.setStatus("failure");
    }

  }catch(Exception err){
    log.info(err.toString());
    outbound.setStatus("failure");
  }
  response = outbound.toString();
  return response;
}

}

XmlToObject

Convert XML code to an Object by using JAXB; validation is also enabled in this process. If we want, we can push through the response with a valid failure message.

public class XmlToObject {

static Logger log = Logger.getLogger(XmlToObject.class.getName());

public static Object convert (Class entityClass,String xml, Outbound outbound) throws SAXException{

  log.info("Entity class "+ entityClass.getName());
  //XML Validation
  ValidationEventCollector vec = new ValidationEventCollector();

  Object  inbound = null;
  try {
  //It generate the URL entityClass.getResource() for the folder
  URL xsdURL = entityClass.getResource("schema.xsd");

  SchemaFactory sf = SchemaFactory.newInstance(XMLConstants.W3C_XML_SCHEMA_NS_URI);
  Schema schema = sf.newSchema(xsdURL);
  JAXBContext jaxbContext = JAXBContext.newInstance(entityClass);

  Unmarshaller unmarshaller = jaxbContext.createUnmarshaller();
  unmarshaller.setSchema(schema);
  unmarshaller.setEventHandler(vec);
  StringReader reader = new StringReader(xml);
  inbound = (Object)unmarshaller.unmarshal(reader);

  } catch (JAXBException err) {
  if (vec != null && vec.hasEvents()) {
          for (ValidationEvent ve : vec.getEvents()) {

              String msg = ve.getMessage();
              ValidationEventLocator vel = ve.getLocator();
              int numLigne = vel.getLineNumber();
              int numColonne = vel.getColumnNumber();

              log.info("Error validation xml" + "Error : " + numLigne + "." + numColonne + ": " + msg +" : "+ ve.getSeverity());
              }
          }
    outbound.setStatus("failure");
    if (err.getLinkedException () == null){
           log.debug(err.toString());
          //Add This message to your response by adding additional datatype in Outdata file
    }else{
           log.debug(err.getLinkedException().getMessage());
    }
  }

  return inbound;
  }
}

AESEncrypted.java

This file helps to encrypt and decrypt the data and it overwrites it with @Service org.springframework.stereotype.Service.

I used base64 code with an Apache common codec jar.

@Service
public class AESEncrypted extends XmlAdapter<String, String>{

    //Secret Key values set from properties files
    private static SecretKeySpec secretKey;

private static Cipher cipher;

static Logger log = Logger.getLogger(AESEncrypted.class.getName());

public AESEncrypted(){}

//Value set from dispatcher Servlet constructor INJECTION
public AESEncrypted(String awsKey){
  try {
  secretKey = new SecretKeySpec(awsKey.getBytes(), "AES");
    cipher = Cipher.getInstance("AES/ECB/PKCS5PADDING");
  } catch (Exception e) {
  log.info("Secrate Key Loading issue !! " );
  }
}

/**
 * Encrypts the value to be placed back in XML
 */
@Override
public String marshal(String plaintext)   {
  try{
         cipher.init(Cipher.ENCRYPT_MODE, secretKey);
         byte[] cipherText = cipher.doFinal(plaintext.getBytes("UTF8"));
         String encryptedString = new String(Base64.encodeBase64(cipherText),"UTF-8");
         return encryptedString;
  }catch(Exception err){
  log.info(err.getMessage());
      return "";
   }
}
/**
 * Decrypts the string value
 */
@Override
public String unmarshal(String encryptedText)  {
    try{
      cipher.init(Cipher.DECRYPT_MODE, secretKey);
      byte[] cipherText = Base64.decodeBase64(encryptedText.getBytes("UTF8"));
      String decryptedString = new String(cipher.doFinal(cipherText), "UTF-8");
      return decryptedString;
    }catch(Exception err){
     log.info(err.getMessage());
      return "";
     }
 }
}

Inbound.java

Here, we request an XML data file.

I converted the below Java file to an XSD file with the simple steps below.

1. location> schemagen Program.java

package com.shri.ws.vo;

import javax.xml.bind.annotation.XmlElement;
import javax.xml.bind.annotation.XmlRootElement;
import javax.xml.bind.annotation.XmlType;
import javax.xml.bind.annotation.adapters.CollapsedStringAdapter;
import javax.xml.bind.annotation.adapters.XmlJavaTypeAdapter;

/**
 * @author shrisowdhaman
 * Nov 15, 2017
 */
@XmlType(name = "REQ",propOrder={"name","address"})
@XmlRootElement(name ="REQ")
public class Inbound {

  private String name;

  private String address;

  @XmlJavaTypeAdapter(CollapsedStringAdapter.class)
  @XmlElement(name="NAME",required=true, nillable=false)
  public String getName() {
  return name;
  }

  public void setName(String name) {
  this.name = name;
  }

  @XmlJavaTypeAdapter(CollapsedStringAdapter.class)
  @XmlElement(name="ADDRESS",required=true, nillable=false)
  public String getAddress() {
  return address;
  }
  public void setAddress(String address) {
  this.address = address;
  }
}

Schema.xsd

Used to validate the request file with a schema. Validation code available in XmlToObject.java

<?xml version="1.0" encoding="UTF-8" standalone="yes"?>
<xs:schema version="1.0" xmlns:xs="http://www.w3.org/2001/XMLSchema">

  <xs:element name="REQ" nillable="true" type="xs:anyType"/>

  <xs:complexType name="REQ">
    <xs:sequence>
      <xs:element name="NAME" type="xs:string"/>
      <xs:element name="ADDRESS" type="xs:string"/>
    </xs:sequence>
  </xs:complexType>


</xs:schema>

EnqObject.java

public interface EnqObject {

public Outbound startProcess(Inbound inbound,Outbound outbound);
}

EnqObjectImpl.java

@Service
public class EnqObjectImpl implements EnqObject{

static Logger log = Logger.getLogger(EnqObjectImpl.class.getName());

public Outbound startProcess(Inbound inbound, Outbound outbound) {

if (inbound != null) {
    try {
    //Call DAO Area and save the values in database
    log.info("Inside Inbond");
    } catch (Exception err) {
    outbound.setStatus("failure");
    }
  }  else {
  outbound.setStatus("failure");
  }

  return outbound;
  }

}

You can check my Source Code here.

Java, by default, supports 128-bit keys. If you want to use a 256-bit key, follow the below steps.

Update the Java Cryptography Extension (JCE) to Unlimited Strength Jurisdiction Policy Files to support a 256-bit key.

1. Download the java policy files for Java 7 or Java 8.
2. Locate the jre\lib\security directory for the Java instance that the Atom is using.
For example, this location might be:
C:\Program Files\Java\jre1.8.0_144\lib\security.
C:\Program Files\Java\jdk1.8.0_144\jre\lib\security
3.Replace the following .jar files directory: local_policy.jar and US_export_policy.jar.
4.Stop and restart the eclipse/server.

Check AES Encryption code here.
