One Agent, Two Runtimes: Defining State Ownership Between Temporal and LangGraph

Combining Temporal and LangGraph creates a deceptively simple question: which runtime owns the state of the agent? Both preserve execution progress, but they preserve different kinds of progress. Temporal reconstructs Workflow state from Event History and reuses recorded Activity results during replay. LangGraph persists thread-scoped graph state as checkpoints and resumes from super-step boundaries. Treating those mechanisms as interchangeable creates ambiguous recovery semantics. Production integration therefore needs explicit authority for business progress, agent working state, and the handoff between them. Deployment language, storage backend, model provider, and hosting topology remain unspecified assumptions.

The current Temporal LangGraph integration narrows the problem. Its public-preview Python plugin can run LangGraph nodes as Temporal Activities or deterministic Workflow code, while Temporal provides durability; the documentation recommends an in-memory LangGraph checkpointer rather than a separate PostgreSQL or Redis checkpointer. Continue-As-New can carry cached task results into the next Workflow Run.

The harder two-runtime problem appears when LangGraph retains an independent persistent checkpointer while Temporal separately orchestrates the business lifecycle. That case needs an application-level consistency contract.

Ownership and Handoff

The cleanest ownership rule is semantic. Temporal should own business lifecycle state: whether an execution is open, waiting for approval, canceled, timed out, compensated, or complete. LangGraph should own agent working state: messages, retrieved evidence, tentative plans, tool proposals, and graph position. External systems should remain authoritative for effects in their own domains. A payment processor owns whether a charge occurred; a deployment service owns whether a release exists. Temporal and LangGraph may retain receipts, but neither should invent contradictory domain truth. This matches their native models: Event History records Workflow progress, while LangGraph checkpointers persist thread state.

The handoff should be modeled as a command protocol. A business execution ID identifies the long-lived application process and can map to a stable Temporal Workflow ID. A graph thread ID identifies checkpoint lineage. A command ID identifies one requested graph advance, while a monotonically increasing application revision identifies the state version against which that command was accepted. Temporal Run ID should not become the business identifier because Continue-As-New preserves Workflow ID while creating a new Run ID. LangGraph uses thread_id to load checkpoint history. Stable application identities must therefore outlive either runtime’s individual run instance.

A graph-advance Activity can enforce that contract without exposing persistence details to Workflow code:

def advance_agent(cmd):
    receipt = receipts.get(cmd.command_id)
    if receipt and receipt.status == "completed":
        return receipt.result

    state = threads.acquire(
        cmd.thread_id,
        fencing_token=cmd.revision,
    )
    if state.revision != cmd.expected_revision:
        raise StaleCommand(cmd.command_id)

    result = graph.invoke(
        cmd.input,
        {"configurable": {"thread_id": cmd.thread_id}},
        durability="sync",
    )
    return receipts.complete(cmd, result)

The key property is the admission rule. The same command ID must never become new input merely because an Activity retried. A command accepted at revision 17 remains command 17 across worker crashes and timeouts. A genuinely new turn receives a new command ID and expected revision. LangGraph’s synchronous durability mode persists each checkpoint before the next step starts, reducing checkpoint-loss risk, but it does not create a transaction with Temporal Event History.

Failure and Re-Execution

The critical failure window begins after LangGraph commits a checkpoint and before Temporal records Activity completion. Temporal documents the analogous edge directly: an Activity can finish, the worker can crash before reporting completion, and the Activity can then execute again. Completed Activities are not re-executed during Workflow replay, but an unrecorded completion is indistinguishable from unfinished work at the orchestration boundary. Blindly injecting the same graph input on retry can therefore advance the agent twice for one logical transition.

A durable command receipt closes that ambiguity. It records command ID, thread ID, expected revision, resulting revision, checkpoint reference, status, and result reference. When checkpoint and receipt records share a database, a custom persistence adapter can commit command acceptance and checkpoint metadata in one local transaction. When stores cannot share a transaction, recovery can reconstruct a missing receipt from checkpoint metadata containing the command ID and resulting revision. That reconstruction is an application-level inference based on LangGraph checkpoint metadata and lookup capabilities. A separate receipt written only after graph completion leaves another crash window.

External effects require a second deduplication boundary. Temporal recommends idempotent Activities because Activity execution may happen more than once, and idempotency keys must ultimately be enforced by the called service. The graph should therefore propose an effect before performing it. An interrupt can expose the proposal, allowing Temporal to own approval, deadlines, and cancellation while a dedicated Activity performs the mutation with a stable operation ID. LangGraph documents that an interrupted node restarts from its beginning when resumed, so code before interrupt() executes again and pre-interrupt effects must be safe to repeat.

def await_effect(state):
    receipt = interrupt({
        "operation_id": state["operation_id"],
        "proposal": state["proposal"],
        "revision": state["revision"],
    })

    if receipt["operation_id"] != state["operation_id"]:
        raise ValueError("effect receipt mismatch")

    return {"effect_receipt": receipt}

This arrangement also clarifies replay. Temporal replay re-executes Workflow code while matching Commands against Event History; recorded Activity results are reused. LangGraph replay from an older checkpoint instead re-executes nodes after that checkpoint, including LLM calls, API requests, and interrupts. A LangGraph fork is therefore a new computational branch, not restoration of external reality. Previously completed business effects remain attached to their original operation receipts, while newly proposed effects require fresh authorization.

Operational Semantics

Concurrency control must prevent overlapping Activity attempts from advancing one thread simultaneously. A lease alone is insufficient if an expired holder can still write. A monotonically increasing fencing token tied to the accepted application revision provides a stronger rule: persistence rejects writes from an older token after a newer command is admitted. This is an integration pattern rather than a built-in Temporal or LangGraph guarantee. Administrative retries, manual resumes, and human approvals should pass through the same admission path. Temporal’s documented retry model establishes the underlying reason for such protection: Activity execution can occur more than once even though successful completion is observed once by the Workflow.

Retry policy should remain layered. Temporal should own Activity retry delivery, while LangGraph-level retries should remain narrowly scoped to graph operations whose repetition is safe. Independent retry loops at both layers can multiply attempts and obscure the failure budget. Cancellation also needs explicit semantics. Temporal delivers cancellation to heartbeat-enabled Activities through heartbeats, but cancellation of orchestration does not prove that an already accepted remote effect was reversed. Ambiguous operations therefore require reconciliation with the authoritative downstream system.

Continue-As-New changes run identity but not business identity. Temporal starts a fresh Event History with the same Workflow ID and a different Run ID, carrying selected state forward. In a dual-runtime design, the business execution ID, graph thread ID, latest revision, outstanding commands, and unresolved effect receipts must cross that boundary. Temporal scopes Update-ID deduplication to a Workflow Run, so deduplication that must survive Continue-As-New cannot rely solely on server-side Update identity. The official LangGraph integration similarly carries serialized cached results across Continue-As-New.

Operational tests should target boundaries rather than happy paths. Worker termination immediately after checkpoint commit, after an external service accepts an operation, and before Activity acknowledgment exposes duplicate-execution defects. Concurrent retries should prove that stale fencing tokens cannot write. Stale approvals should prove that proposal revision checks reject obsolete decisions. Continue-As-New tests should prove that logical identities and deduplication records survive the run transition. Temporal provides test hooks for exercising Continue-As-New, while LangGraph checkpoint history and replay make recovery assertions observable.

Conclusion

A Temporal-and-LangGraph agent becomes reliable only when durability is subordinate to ownership. Temporal should decide business progress, LangGraph should preserve agent working state, and external systems should remain authoritative for real-world effects. The handoff needs stable business, thread, command, and revision identities; durable receipts; idempotent effect execution; explicit replay semantics; fenced concurrency; and continuity across Continue-As-New. The official Temporal LangGraph plugin can collapse much of this complexity by making Temporal the durable execution substrate. When independent persistence remains on both sides, however, two durable runtimes do not become one consistent runtime automatically. A precise state-ownership protocol is what turns duplicated durability into controlled recovery.
