Time and Related Data Types in PostgreSQL

We here at Cockroach Labs have been busy getting CockroachDB (CRDB) more in line with PostgreSQL for v20.1. This allows you to be able to use Cockroach as a drop-in replacement for PostgreSQL (whilst using your favourite existing ORM or driver), but with the powerful, scalable backend we provide.

Time, Timestamp and TimestampTZ have been three data types Cockroach has supported, but were not well matched with PostgreSQL functionality. We were also missing the TimeTZ datatype, as well as precision for time and interval types. Even worse, our results did not match PostgreSQL in some cases for the existing data types we do support.

We've spent a lot of the v20.1 release mastering time data types, fixing what was broken through ORM tests and community reports whilst adding new features to bridge that gap. A significant amount of time was spent scratching our heads as we figured out why existing time-related ORM tests were failing against CRDB. We've found a lot of devils in the details, with knowledge over these edge cases sparsely located over old SQL mailing lists and StackOverflow.

In this blog post, we'll explore some of the intricacies of time in PostgreSQL and look at how we reproduce these features using Go and its ecosystem. We'll share our recommendations for using time along the way.

Are you excited to learn about time in the PostgreSQL world? Join us as a companion in our TARDIS (Time and Related Data Types In SQL...blog post) and hop into an adventure into the world of time. Allons-y!

Session Time Zones

When you open a connection to Postgres/CRDB, you will have a session between you (the client) and the database (the server). The session will contain a time zone, which you can set with the SET TIME ZONE command for both PostgreSQL and CRDB.

When connecting using the shell, the PostgreSQL shell (psql) will try to connect and set the session to the local time zone as defined by your computer settings, whereas CRDB will default to UTC. We can observe this with CURRENT_TIMESTAMP, which returns the current timestamp in the default session time zone:

You can specify your time zone to be a location (which is daylight savings aware), or a UTC offset. This will change the CURRENT_TIMESTAMP to be in the time zone your session is set to:

In the above example, CRDB and psql now output the same data as SET TIME ZONE is explicitly set to the same things.

Note your ORM or driver may have different default behaviour than the psql shell or the CRDB shell, but should allow you to set a default time zone.

Setting your session time zone will affect some time operations in some fun and exciting ways (which is not necessarily what you want as a developer) which we'll explore soon.

POSIX Time Offsets

In the above examples, we have used SET TIME ZONE with an integer offset (-11) or a location (Australia/Sydney). However, Postgres also supports the syntax for SET TIME ZONE to have GMT or UTC at the front, e.g. SET TIME ZONE 'UTC+3'. Let's see how it behaves:

Hold on a second, why does it have a time zone of -3 when setting the time zone to UTC+3?

It turns out that this is because having UTC or GMT in front uses the POSIX definition for time zones, which defines zones to be hours west of the GMT line. In essence, the sign is reversed from the time zone structure we know and love, where positive integers represent that the timestamp is east of the GMT line (also known as ISO8601 standard). Note that the POSIX standard also applies if you just add colon separators to the offset in SET TIME ZONE:

The takeaway here is that integers are treated as ISO8601 format, locations do what you expect and anything else is POSIX standard.

Thinking this is a little weird? We've got another surprise with this coming later!

TIMESTAMP and TIMESTAMPTZ

The TIMESTAMP (also known as TIMESTAMP WITHOUT TIME ZONE) and TIMESTAMPTZ (also known as TIMESTAMP WITH TIME ZONE) types stored as a 64-bit integer as a microsecond offset since 1970-01-01 in CRDB and as a 64-bit integer microsecond offset since 2000-01-01 in PostgreSQL (by default).

As both data types are stored using only 64-bit integers, it is important to note that neither store any time zone information.  So where does TIMESTAMPTZ get the time zone from? That's right — the session time zone. As a corollary, that means storing the TIMESTAMPTZ and fetching the results from a different session time zone results in a different printed result, with the same equivalent UTC offset underneath.

Let's compare storing a TIMESTAMP / TIMESTAMPTZ and fetching it from a different time zone:

In the psql shell, the time we've inserted these entries as 2020-05-13 14:05:23.801845with offset -07. The TIMESTAMP column does not regard the time zone, so drops that information. When we switched time zones to UTC-3, only the ttz column will change its result by transforming the time into the +3 offset, which is 10 hours ahead, hence now displaying 2020-05-13 18:05:23.801845-03.

In the CRDB shell, things look largely the same. However, the TIMESTAMP column has an extraneous +00:00 at the front. This is a UX quirk of using the Go driver lib/pq (which is not related to the C library libpq) that powers the CRDB shell — it always displays a time zone when representing any time object since it uses the same format string for all time related types. We're looking to fix this UX issue in a future release — but have comfort that it represents the same value underneath.

If you're still confused, don't worry — it's confusing to us too. Here is a summary:

• TIMESTAMP is an absolute value time offset. It does not store time zones, or change based on the session time zone. Another way to think about it is that it is always in UTC.
• TIMESTAMPTZ is also an absolute value time offset with no time zone metadata set, but it displays timestamps and performs operations in the session time zone. You've seen the "displays timestamp" bit already — we'll get to the "performs operations" component later.

We'll omit CRDB shell output for the remainder of this section to avoid duplicate information — but it is worth noting we've had bugs in all aspects in areas below which is how we got to explaining it.

Parsing

Let's parse the opening ceremony of the Sydney Olympics in PostgreSQL with a fresh new psql shell in California:

So parsing a timestamp string without any time zone information in the string will automatically default to the current time zone for TIMESTAMPTZ.

Let's append Sydney's time zone in September (+11:00) into the string before we cast:

As we see above:

• For TIMESTAMPs, we've got 19:00 — same as the input but we've ignored the time zone offset. This can be significant for us as 19:00-07 is different to the value it is stored as — 19:00+00.
• For TIMESTAMPTZ, we've got 01:00, which looks way off. Remember — TIMESTAMPTZ is a UTC offset, which displays in the session time zone. We've parsed TIMESTAMPTZ with +11:00 (which is parsed as ISO8601 format unlike SET TIME ZONE) but we are displaying TIMESTAMPTZ in the time zone -07:00 as we are in California. With an 18 hour time difference, that places the opening ceremony at 1am local time in California, as you can see from the output. American readers, youse must have been tired watching the Olympics in 2000.

Of course, explicitly changing the session time zone with the same strings will change the output for TIMESTAMPTZ:

Again, the time zone when parsing TIMESTAMP is completely ignored, but for Tokyo's time zone of +09:00, we've had to rewind the clock from 19:00 to 17:00 to display correctly in the session time zone.

Casting

Let's look at a few casts between TIMESTAMP and TIMESTAMPTZ with the time one of the greatest cricket test match finishes of all time:

When we cast from a TIMESTAMP to a TIMESTAMPTZ in Case 1, we have to set the time zone of +10:30. However, this actually changes the UTC time, as "displaying it correctly" in the current session time zone involves subtracting 10:30 from the underlying offset value.

Conversely, when we convert from TIMESTAMPTZ to TIMESTAMP in Case 2, TIMESTAMP represents an absolute UTC value but without the time zone information. As such, we would have to add 10:30 to the underlying offset value for the correct equivalent value to make this equal to the value 17:00.

This behaviour gets tricky, especially when the data is stored and fetched in a session with another session time zone whilst expecting the cast to TIMESTAMP to give you the same result:

In the above example, we changed the time zone above from +10:30 to Chicago's -06:00, so we have a 16:30 time difference. Since we cast to TIMESTAMP using the TIMESTAMPTZ data type, we evaluate it as of the session time zone at the point of evaluation, hence getting 2006-12-05 00:30:00 when casting it in America/Chicago. Note if you want a result to always evaluate to the same TIMESTAMP no matter the session time zone, use the AT TIME ZONE syntax discussed below.

For many of these operations, we need to move timestamps to a different time zone but whilst keeping the same timestamp underneath. Go does not natively do this, as time.In only changes the location, but has the same UTC offset underneath. This means that something at 10:00 cast to a +3 time zone  without any offset changes would report as 13:00+3 instead of 10:00+3. This was a source of quite a few of our time bugs!

To do this correctly, we have to do an awkward dance: read the second argument from Zone to get the zone offset in seconds from the timezones before and after and then use time.Add to subtract that duration offset to the new time value.

Example code:

func KeepTimeOffsetInNewZone(t time.Time, loc *time.Location) time.Time {
    afterTime := t.In(loc)
    _, beforeOffsetSecs := t.Zone()
    _, afterOffsetSecs := afterTime.Zone()
    timeDifference := afterOffsetSecs — beforeOffsetSecs
    return afterTime.Add(-time.Duration(timeDifference) * time.Second)
}

Precision

TIMESTAMP and TIMESTAMPTZ supports microsecond precision. However, there is an option for "rounding" of fractional digits for the seconds component.

To do this, we can specify a number between 0 and 6 inclusive in parenthesis after TIMESTAMP and TIMESTAMPTZ, e.g. TIMESTAMP(3) for TIMESTAMP in millisecond precision allowing 3 fractional digits, or TIMESTAMPTZ(0) for TIMESTAMPTZ with no fractional digits. This will get the datums rounded to the specified precision.

Let's look at examples using the time when Super Over rules were unfair:

The equivalent functionality in Go is available using time.Round in the time library.

Functions and Operators

Functions (e.g. extract, date_trunc) and Operators (e.g. =, +, -, >) are fairly easy to comprehend with TIMESTAMP. However they are a little nuanced with TIMESTAMPTZ, causing a variety of bugs internally in CRDB. As we alluded to earlier, it's important to remember that TIMESTAMPTZ performs operations in the session time zone.

Let's look at some time operators, with timestamps around the release of the movie Crocodile Dundee:

Remember — in all cases, the TIMESTAMP is converted to the TIMESTAMPTZ of the current session time zone, which is '1986-09-26 10:00-04' in New York. Taking a look at each case:

• Case 1: the added -04 for TIMESTAMP when converting to TIMESTAMPTZ means this result is true.
• Case 2: they are both internally the same time offset, and hence they are equal.
• Case 3: 10:00-05 can be thought of as 11:00-04, which is strictly higher, hence returning true.
• Case 4: adding an interval of 1 day changes the date to be incremented by 1.

For builtins, let's look at extract:

From the above:

• Case 1: The hour can be extracted as "10" directly.
• Case 2: As the timestamp provided is in the same time zone as the session time zone, the calculation does not need any time zone conversions, but the underlying UTC offset has a different hour. Thankfully, Go's time.Hour operator (and Minute, Second, Month, etc.) takes into account what location the time is in, so extracting the hour is straightforward.
• Case 3: What happened here? Remember — TIMESTAMPTZ performs operations in the session time zone. If we were to run SELECT '1986-09-26 10:00-06'::TIMESTAMPTZ, we'd see 1986-09-26 12:00-04 as -04 is the session time zone.  As such, when moving it to from -02 to -04, the time becomes 12:00 — and since we perform the operation in the session time zone — extract will hence return 12.

AT TIME ZONE

AT TIME ZONE will convert a TIMESTAMPTZ to a TIMESTAMP at a given time zone, or a TIMESTAMP to a TIMESTAMPTZ at a given time zone (which will be transposed into the session time zone). It is worth noting that TIMESTAMP AT TIME ZONE <zone> and TIMESTAMPTZ AT TIME ZONE <zone> are inverses of each other.

This can be useful if you expect users to cast from TIMESTAMPTZ to TIMESTAMP or vice versa from different session time zones but you need consistent offsets from the epoch time (see "Casting" for an example for how this could be a problem).

Confusing? Let's look at the real examples using the release date of the song Friday:

From the above:

• Case 1: we are switching from Australia/Sydney time to Asia/Tokyo time, which is 2 hours behind. This involves moving from 10am to 8am, but underneath removing the UTC time zone offset to the absolute "TIMESTAMP" value of 8am.
• Case 2: we have a TIMESTAMP which we wish to convert to Sydney time. This is straightforward -- add the UTC offset to the time, which when we display in the session time zone of 'Australia/Sydney' will still be 10am.
• Case 3: Case 3 gets interesting. We've added the Asia/Tokyo time zone offset to the underlying offset, but remember we display this offset at the session time zone. With the two hour time difference, that means we see 12pm in the afternoon when displaying this operation with a session time zone of Australia/Sydney.

POSIX Standard strikes again

Remember the surprise earlier with the POSIX standard being used for strings when using SET TIME ZONE? In AT TIME ZONE, omitting the UTC/GMT prefix and having just a bare integer offset (e.g. +3, -3, 3) also behaves as POSIX timestamp (unlike SET TIME ZONE where integers were special and behave as ISO8601):

We would expect the above case to be 2011-03-14 10:00:00+03:00 if it were ISO8601 when using AT TIME ZONE. However, as +3 is POSIX for AT TIME ZONE, it really means "at time zone 3 hours west of GMT", to be displayed as "3 hours east of UTC", hence adding 6 hours to the result.

Daylight Savings

Now you may be wondering when to use a location versus when to use an absolute offset. Offsets already seem tricky given how it uses POSIX style offsets.

This may help you decide — locations can infer changing time zone information. Let's look at a dates which traverse time zones in Chicago:

With the daylight savings boundary change, we can see that the time zone offset changes. That's neat, isn't it?

You may now be wondering — how are these time zone changes encoded? IANA maintains a database of daylight savings changes for each time zone (some of which date back a very long time). But which version of this database do we use? Well:

• CRDB will use a copy of this database that is installed within your computer. This is the default behaviour of Go.
• PostgreSQL ships out its own copy of tzdata every release.

This means that time and daylight savings behaviours can change between computers when using CRDB if a newer version of the IANA database is on your system. This is currently tracked for a fix, and is one of the reasons we recommend always using UTC as your session time zone.

Interval Math with Daylight Savings

Let's look at how daylight savings impacts interval math:

Huh — are there not 24 hours in a day? Intervals in Postgres are represented as "months", "days" and "seconds", which plays a role in what we see here. Let's see how this applies to the cases above:

• Case 1: When adding "seconds" to TIMESTAMPs (which is represented by units that are not days, i.e. 24 hours still uses seconds until it overflows), we add real world seconds. This is done in Go by using time.Add.
• Case 2: When adding "days", we're just putting any math straight into the date fields, preserving the same time even as we cross daylight savings barriers. This is handled in Go by time.AddDate.
• Case 3: Similar to case 2, but we add months instead of days.

The Y2K38 Problem

Does 2038-01-19 03:14:07 spark any Y2K vibes? This is the time is 2147483647 (max int32) seconds after the unix offset of 1970-01-01, known as the Y2K38 date. This was an issue in Go when handling tzdata past 2038 which has only just been resolved.

As Go 1.13 does not understand the "extended" format of tzdata which handles time zones past Y2K38, our handling of daylight savings is broken after the Y2K38 date in v20.1 (which ships with Go 1.13). We cannot easily parse it ourselves either, as the Go Location struct is not an interface, and the relevant variables to change are private and inaccessible without forking Go's time library.

As such, if we pass Y2K38, the time zone in CRDB will be the same as the daylight savings in your current time zone, as that is what it is evaluated to in Go. This can be a problem if using a session time zone that has daylight savings:

This is tracked for a future fix.

As a side note — if you're curious about tzdata, it makes for an interesting read. Check out some of the weird offsets such as America/Chicago pre-1900 with a time offset of -5:50:36.

Time Twister

Feeling confident about time? Feeling you may be turning half human, half time lord?

Let's see — can you explain the following behaviour:

The answer is near the end of this blog post.

What do we recommend?

Like many others, CRDB recommends usage of TIMESTAMPTZ as encoding time zone data is valuable. However, we recommend always setting the session time zone to UTC. This allows the user to not worry about not losing time zone information whilst parsing, whilst allaying concerns that if a user decides to use session time zones that they perform with intended daylight-savings aware behaviour.

TIME and TIMETZ

TIME (also known as TIME WITHOUT TIME ZONE) and TIMETZ (also known as TIME WITH TIME ZONE) both only store the time of day component of a TIMESTAMP. But:

• TIME is still encoded with 8 bytes, representing microseconds since midnight.
• TIMETZ is encoded with 12 bytes, with 8 bytes representing microseconds since midnight and 4 bytes for storing the time zone offset in seconds west of UTC (again, the opposite of what we're used to when talking time zones). Unlike TIMESTAMPTZ, the current session time zone is not taken into account (except for parsing) and since it only stores time zone offsets and not locations, it does not encode daylight savings information.

Let's look at using CURRENT_TIME (the equivalent of CURRENT_TIMESTAMP) in psql (with California time as default) and CRDB:

As you can see, changing the time zone does not affect table results. Since TimeTZ stores the offset, they stay the same between session time zones shifts.

It is worth noting here that CRDB outputs an extra "0000-01-01" for time types, as well as an extraneous "+00:00" for the time type. This data has no meaning and is the way our driver lib/pq for the CRDB shell displays this data. This is tracked for a future fix.

When performing interval math with time, times past 23:59:59.999999, automatically overflows back to 00:00:00 as there is no "date" component.

Parsing

Parsing TIME and TIMETZ largely behaves the same as the parsing for TIMESTAMP and TIMESTAMPTZ:

• With TIME, any time zone offsets are ignored.
• With TIMETZ, the current session time zone appended to TIMETZ if none is specified (which changes based on daylight savings).  However, If a time zone offset is specified for TIMETZ, it will use that instead. The time zone offsets use the familiar ISO8601 standard.

Precision

Similar to TIMESTAMP/TIMESTAMPTZ, you can specify precision in parenthesis for TIME/TIMETZ types, which round to specified precision of fractional digits for the seconds component:

Casting

When casting TIME to TIMETZ, the TIME will get promoted to the time zone of your current session. However, when casting TIMETZ to TIME, we will lose time zone offset:

Losing the time zone offset and reinterpreting it in the session time zone can be surprising, as casting that TIME back to TIMETZ will give you a different result. In other words, casting the inverse of the inverse does not yield the identity. You can see an example of this below:

Here, our +03 in our TIMETZ has been reinterpreted in the session time zone of +11 after casting it to TIME, which represents a wholly different result. If you need inverses to match, AT TIME ZONE between TIME and TIMETZ will yield the desired effects.

Comparators and Ordering of TIMETZ

Consider the comparison of these two equivalent times (10:00+03 and 11:00+04), one in the same time zone and one in a different time zone:

That's interesting — they're the same time in the real world, aren't they? Well not in the realm of TimeTZ. Recall that TimeTZ stores both microsecond offset AND offset representing seconds west of UTC. If the microsecond offset is the same, then we compare seconds WEST of UTC (i.e. the negative of the offset we see above). As such:

• Case 1 demonstrates that the same UTC offset AND time zone offset being equal means the result is equal, as expected.
• Case 2 demonstrates that despite having the same UTC offset, the results are NOT equal since the offset TIME ZONE is not the same
• Case 3 demonstrates that timezones "more west" (has a higher POSIX offset) have precedence.
• Case 4 demonstrates that UTC offsets take precedence, since 11:01+04 is one minute higher relative to UTC compared to 10:00+03.

24:00 in TIME/TIMETZ

An interesting feature that is only supported for TIME and TIMETZ is 24:00:00 time. This is a time that can be parsed, but you cannot use arithmetic to achieve the value. Adding to 24:00:00 overflows the value back to 00:00:00.

Unfortunately, Go's time.Parse does not handle 24:00 — so our TIME string parsers all have wrappers to regex match and handle the 24:00 case.

Parsing and displaying 24:00 time with the Go time library is also a challenge, as can be demonstrated in the lib/pq driver. Unfortunately, the lib/pq driver we use displays the 24:00 with the exact same representation as 00:00:

We have submitted a PR as a fix, but until then, 24:00 time is broken in the lib/pq driver, even against PostgreSQL.

What do we recommend?

Whilst TIME and TIMETZ store only the time component, TIME takes the same amount of space — and even more for TimeTZ. Furthermore, TIMETZ also does not keep track of location with time offsets. 24:00 time is an interesting case that is handled but may have limited practical uses.

It is worth also noting that PostgreSQL advises against using the TIMETZ data type. TIMETZ was originally implemented to follow the SQL standard. See the note just above section 8.1 in PostgreSQL's own documentation.

So our recommendation is to use … neither! If you need time, you are most likely better off using TIMESTAMPTZ which takes care of these shortfalls in all these cases. If time zone information is required, use a separate column to encode that information.

Time Twister — Answer

The session time zone is set at -9. This means 1947-12-13 13:00+11 would be translated to 1947-12-12 17:00:00-09.

Now UTC+3 is POSIX standard, meaning it really means 3 hours west of UTC ("-3" in ISO8601). This is six hours ahead of the session time zone of "-9", hence translating to 23:00:00. Since AT TIME ZONE translates a TIMESTAMPTZ to a TIMESTAMP, the time zone data is gone.

(And if you are curious, 1947-12-13 is the date of the infamous Mankad incident.)

Conclusion

Each of the time types have interesting nuances:

• TIMESTAMP is a type with date and time that has no time zone information and is absolute. It disregards time zones when parsing, which can be unexpected. Alternatively, think of it as "always UTC time".
• TIMESTAMPTZ is a type with date and time that has time zone behaviour dependent on your session time zone and is conscious of daylight savings. If you want to be safe, always use UTC with it.
• TIME is a type with time of day info only.
• TIMETZ is a type with time of day and fixed time zone offsets. It does not depend on the session time zone for computation, and is not daylight savings aware.

As mentioned above, our advice is to always use TIMESTAMPTZ with your session time zone set to UTC. If you need time zone information, use a separate column to store this information. At the end of the day, make sure what you pick works for you.

Whew, that was confusing. Maybe I should write a strongly worded letter. In any case, working with time data types is indeed interesting — and we haven't even touched intervals and leap seconds!

Did you enjoy our adventures and deep dive into the internals and nuances of databases? As always, Cockroach Labs is hiring!
