Using Apache MiniFi on Edge Devices: Part 1

DZone's Guide to

Using Apache MiniFi on Edge Devices: Part 1

Apache MiniFi lets you safely ingest data on Raspberry Pi and other devices. Learn how to set up a NiFi flow in part 1 of this tutorial.

· IoT Zone
Free Resource

Address your IoT software testing needs – improve quality, security, safety, and compliance across the development lifecycle.

MiniFi enables you to use a small device like a Raspberry Pi, ASUS Ticker board or BeagleBone Black to ingest data in a safe, controlled manner and allow for full chain of custody of data.

This is a great update over my previous methods of just using Python to send MQTT messages.

We build a flow in Apache NiFi and then export the template. Using the MiniFi tool we convert this into a config.yaml file and send it to our device via SCP. You can see this in Part 1. This simple flow calls a shell script that will run a Python script to get our sensor data. This flow will then send the data to our NiFi server via S2S over HTTP.

What I have added in this part is the use of the new Record and Schema paradigms and also the ability to SQL queries against incoming flow files using QueryRecord. This requires building an AVRO schema for our data, which is dead easy JSON definition.

We set out port to connect the MiniFi agent to our server.

Data quickly starts coming in.

Receive the JSON Messages in NiFi via S2S


Top Steps to Ingest Sensor Day in a Few Hours

  • Connect to the port.
  • Set a schema to pull from the registry; also set a mime-type for JSON.
  • Query the flow file and just take ones over 65 degrees Fahrenheit via Apache Calcite processed SQL. These produces an AVRO file using the AvoRecordSetWriter and the schema from the AvroSchemaRegistry.
  • Store the AVRO file produced to HDFS.
  • Store the raw JSON file sent into HDFS.
  • Convert the AVRO file to ORC.
  • Store the ORC files to HDFS.
  • Grab the autogenerated hive.ddl to create the external tables.
  • Query the sensor data in Zeppelin.

hive.ddl Automagically Generated Hive Schema

      CREATE EXTERNAL TABLE IF NOT EXISTS sensor (tempf FLOAT, cputemp FLOAT, ts STRING, pressure FLOAT, host STRING, pitch FLOAT, ipaddress STRING, temp FLOAT, diskfree STRING, yaw FLOAT, humidity FLOAT, memory FLOAT, y FLOAT, x FLOAT, z FLOAT, roll FLOAT) STORED AS ORC

I grab the HDFS location and add that to the DDL: LOCATION '/sensor'.

For the AVRO and JSON versions of the data, I make similar tables.

      ROW FORMAT SERDE 'org.apache.hive.hcatalog.data.JsonSerDe'    LOCATION '/jsonsensor';         ROW FORMAT SERDE 'org.apache.hadoop.hive.serde2.avro.AvroSerDe'    STORED AS AVRO    LOCATION '/avrosensor';

Install Libraries (See Part 1 for MiniFi Install)

      pip install --upgrade sense-hat<br>pip install --upgrade pillow<br>pip install rtimulib    pip install psutil    sudo apt-get install oracle-java8-jdk

Shell Script

      python /opt/demo/rpi-sensehat-mqtt-nifi/sense2.py

Python Script

      from sense_hat import SenseHat    import json    import sys, socket    import os    import psutil    import subprocess    import time    import datetime    from time import sleep    from time import gmtime, strftime    # get data    #current_milli_time = lambda: int(round(time.time() * 1000))    # yyyy-mm-dd hh:mm:ss    currenttime= strftime("%Y-%m-%d %H:%M:%S",gmtime())    host = os.uname()[1]    rasp = ('armv' in os.uname()[4])    cpu = psutil.cpu_percent(interval=1)    if rasp:        f = open('/sys/class/thermal/thermal_zone0/temp', 'r')        l = f.readline()        ctemp = 1.0 * float(l)/1000    usage = psutil.disk_usage("/")    mem = psutil.virtual_memory()    diskrootfree =  "{:.1f} MB".format(float(usage.free) / 1024 / 1024)    mempercent = mem.percent    external_IP_and_port = ('198.41.0.4', 53)  # a.root-servers.net    socket_family = socket.AF_INET    #p = subprocess.Popen(['/opt/vc/bin/vcgencmd','measure_temp'], stdout=subprocess.PIPE,    #    stderr=subprocess.PIPE)    #out, err = p.communicate()    def IP_address():            try:                s = socket.socket(socket_family, socket.SOCK_DGRAM)                s.connect(external_IP_and_port)                answer = s.getsockname()                s.close()                return answer[0] if answer else None            except socket.error:                return None    ipaddress = IP_address()    sense = SenseHat()    sense.clear()    temp = sense.get_temperature()    temp = round(temp, 2)    humidity = sense.get_humidity()    humidity = round(humidity, 1)    pressure = sense.get_pressure()    pressure = round(pressure, 1)    orientation = sense.get_orientation()    pitch = orientation['pitch']    roll = orientation['roll']    yaw = orientation['yaw']    acceleration = sense.get_accelerometer_raw()    x = acceleration['x']    y = acceleration['y']    z = acceleration['z']    #cputemp = out    x=round(x, 0)    y=round(y, 0)    z=round(z, 0)    pitch=round(pitch,0)    roll=round(roll,0)    yaw=round(yaw,0)    row =  { 'ts': currenttime, 'host': host, 'memory': mempercent, 'diskfree': diskrootfree, 'cputemp': round(ctemp,2), 'ipaddress': ipaddress, 'temp': temp, 'tempf': round(((temp * 1.8) + 12),2), 'humidity': humidity, 'pressure': pressure, 'pitch': pitch, 'roll': roll, 'yaw': yaw, 'x': x, 'y': y, 'z': z }    json_string = json.dumps(row)    print(json_string)

One Record (JSON)

      {"tempf": 75.14, "temp": 35.08, "pitch": 1.0, "diskfree": "1211.8 MB", "yaw": 55.0, "cputemp": 52.08, "ts": "2017-06-16 17:39:08", "humidity": 41.5, "pressure": 0.0, "host": "picroft", "memory": 23.0, "y": 0.0, "x": -1.0, "z": 1.0, "ipaddress": "192.168.1.156", "roll": 1.0}

AVRO Schema (JSON Format)

      {"type":"record","namespace":"hortonworks.hdp.refapp.sensehat","name":"sensehat","fields":[{"name": "tempf", "type": "float"},{ "name": "cputemp", "type": "float"},{"name":"ts","type":"string"},{ "name": "pressure","type": "float"},{ "name": "host","type": "string"},{ "name": "pitch","type": "float"},{"name": "ipaddress","type": "string"},{"name": "temp","type": "float"},{ "name": "diskfree","type": "string"},{ "name": "yaw","type": "float" },{"name": "humidity","type": "float"},{"name": "memory","type": "float"},{"name": "y", "type": "float"},{"name": "x", "type": "float" },{"name": "z","type": "float"},{"name": "roll", "type": "float"}]}

config.yml

      MiNiFi Config Version: 2    Flow Controller:      name: sense hat      comment: sense hat 2017    Core Properties:      flow controller graceful shutdown period: 10 sec      flow service write delay interval: 500 ms      administrative yield duration: 30 sec      bored yield duration: 10 millis      max concurrent threads: 1    FlowFile Repository:      partitions: 256      checkpoint interval: 2 mins      always sync: false      Swap:        threshold: 20000        in period: 5 sec        in threads: 1        out period: 5 sec        out threads: 4    Content Repository:      content claim max appendable size: 10 MB      content claim max flow files: 100      always sync: false    Provenance Repository:      provenance rollover time: 1 min    Component Status Repository:      buffer size: 1440      snapshot frequency: 1 min    Security Properties:      keystore: ''      keystore type: ''      keystore password: ''      key password: ''      truststore: ''      truststore type: ''      truststore password: ''      ssl protocol: ''      Sensitive Props:        key:        algorithm: PBEWITHMD5AND256BITAES-CBC-OPENSSL        provider: BC    Processors:    - id: db6fbd3b-ddf4-3041-0000-000000000000      name: ExecuteProcess      class: org.apache.nifi.processors.standard.ExecuteProcess      max concurrent tasks: 1      scheduling strategy: TIMER_DRIVEN      scheduling period: 60 sec      penalization period: 30 sec      yield period: 1 sec      run duration nanos: 0      auto-terminated relationships list: []      Properties:        Argument Delimiter: ' '        Batch Duration:        Command: /opt/demo/rpi-sensehat-mqtt-nifi/sense2.sh        Command Arguments:        Redirect Error Stream: 'true'    Process Groups: []    Input Ports: []    Output Ports: []    Funnels: []    Connections:    - id: 5635290a-4cb6-3da7-0000-000000000000      name: minifiSenseHat      source id: db6fbd3b-ddf4-3041-0000-000000000000      source relationship names:      - success      destination id: 166616e3-1962-1660-2b7c-2f824584b23a      max work queue size: 10000      max work queue data size: 1 GB      flowfile expiration: 0 sec      queue prioritizer class: ''    Remote Process Groups:    - id: fdc45649-84be-374b-0000-000000000000      name: ''      url: http://hw13125.local:8080/nifi      comment: ''      timeout: 30 sec      yield period: 10 sec      transport protocol: HTTP      Input Ports:      - id: 166616e3-1962-1660-2b7c-2f824584b23a        name: MiniFi SenseHat        comment: ''        max concurrent tasks: 1        use compression: false

Build Our MiniFi Configuration File From the sensorminif.xml

      minifi-toolkit-1.0.2.1.4.0-5/bin/config.sh transform sensorminifi.xml config.yml

Then, just SCP to your device.

Source Repository

https://github.com/tspannhw/rpi-sensehat-minifi-python

Example MiniFi Log

      dResourceClaim[id=1497645887239-1, container=default, section=1], offset=2501, length=278],offset=0,name=13917785142443,size=278]] (278 bytes) to http://HW13125.local:8080/nifi-api in 116 milliseconds at a rate of 2.32 KB/sec    2017-06-16 20:54:41,827 INFO [Provenance Maintenance Thread-1] o.a.n.p.MiNiFiPersistentProvenanceRepository Created new Provenance Event Writers for events starting with ID 3162    2017-06-16 20:54:41,844 INFO [Provenance Repository Rollover Thread-1] o.a.n.p.MiNiFiPersistentProvenanceRepository Successfully merged 16 journal files (3 records) into single Provenance Log File provenance_repository/3159.prov in 33 milliseconds    2017-06-16 20:54:41,846 INFO [Provenance Repository Rollover Thread-1] o.a.n.p.MiNiFiPersistentProvenanceRepository Successfully Rolled over Provenance Event file containing 5 records    2017-06-16 20:54:43,288 INFO [Write-Ahead Local State Provider Maintenance] org.wali.MinimalLockingWriteAheadLog org.wali.MinimalLockingWriteAheadLog@87eb01 checkpointed with 0 Records and 0 Swap Files in 100 milliseconds (Stop-the-world time = 13 milliseconds, Clear Edit Logs time = 10 millis), max Transaction ID -1    2017-06-16 20:54:48,429 INFO [pool-23-thread-1] o.a.n.c.r.WriteAheadFlowFileRepository Initiating checkpoint of FlowFile Repository    2017-06-16 20:54:48,890 INFO [pool-23-thread-1] org.wali.MinimalLockingWriteAheadLog org.wali.MinimalLockingWriteAheadLog@17461db checkpointed with 0 Records and 0 Swap Files in 460 milliseconds (Stop-the-world time = 190 milliseconds, Clear Edit Logs time = 77 millis), max Transaction ID 2107    2017-06-16 20:54:48,891 INFO [pool-23-thread-1] o.a.n.c.r.WriteAheadFlowFileRepository Successfully checkpointed FlowFile Repository with 0 records in 461 milliseconds    2017-06-16 20:54:51,482 INFO [Http Site-to-Site PeerSelector] o.apache.nifi.remote.client.PeerSelector org.apache.nifi.remote.client.PeerSelector@f69f9d Successfully refreshed Peer Status; remote instance consists of 1 peers    2017-06-16 20:55:07,621 INFO [Timer-Driven Process Thread-9] o.apache.nifi.remote.client.PeerSelector New Weighted Distribution of Nodes:    PeerStatus[hostname=HW13125.local,port=8080,secure=false,flowFileCount=0] will receive 100.0% of data    2017-06-16 20:55:07,957 INFO [Timer-Driven Process Thread-9] o.a.nifi.remote.StandardRemoteGroupPort RemoteGroupPort[name=MiniFi SenseHat,target=http://hw13125.local:8080/nifi] Successfully sent [StandardFlowFileRecord[uuid=b3bcd211-7425-4750-9e4c-ba2d477b9cc1,claim=StandardContentClaim [resourceClaim=StandardResourceClaim[id=1497645887239-1, container=default, section=1], offset=2779, length=278],offset=0,name=13979556432846,size=278]] (278 bytes) to http://HW13125.local:8080/nifi-api in 114 milliseconds at a rate of 2.38 KB/sec

Check the Status of MiniFi

      root@picroft:/opt/demo/minifi-1.0.2.1.4.0-5# bin/minifi.sh flowStatus processor:db6fbd3b-ddf4-3041-0000-000000000000:health,stats,bulletins    minifi.sh: JAVA_HOME not set; results may vary    Bootstrap Classpath: /opt/demo/minifi-1.0.2.1.4.0-5/conf:/opt/demo/minifi-1.0.2.1.4.0-5/lib/bootstrap/*:/opt/demo/minifi-1.0.2.1.4.0-5/lib/*    Java home:    MiNiFi home: /opt/demo/minifi-1.0.2.1.4.0-5    Bootstrap Config File: /opt/demo/minifi-1.0.2.1.4.0-5/conf/bootstrap.conf         FlowStatusReport{controllerServiceStatusList=null, processorStatusList=[{name='ExecuteProcess', processorHealth={runStatus='Running', hasBulletins=false, validationErrorList=[]}, processorStats={activeThreads=0, flowfilesReceived=0, bytesRead=0, bytesWritten=1390, flowfilesSent=0, invocations=5, processingNanos=9290051632}, bulletinList=[]}], connectionStatusList=null, remoteProcessGroupStatusList=null, instanceStatus=null, systemDiagnosticsStatus=null, reportingTaskStatusList=null, errorsGeneratingReport=[]}

Output Displayed in Apache Zeppelin Workbook

Using the DDL generated by Apache NiFi, we can create external Hive tables for the raw JSON data, the ORC cleaned up version of the data, and also an AVRO version of the data.

We can then query our datasets.
