What Are Istio Virtual Services and Destination Rules?

Virtual services and destination rules are two Kubernetes objects that form the core of traffic management in Istio. Learn what they are and how they work.

By
Anas T user avatar
Anas T
·
Jul. 18, 23 · Analysis
Likes (8)
Comment
Save
Tweet
Share
9.3K Views

Join the DZone community and get the full member experience.

Join For Free

It makes sense for DevOps engineers and architects to perform canary deployments in their CI/CD workflows. They cannot skip testing a release for the sake of adhering to continuous delivery practices, can they?

In canary deployments, the new version, called canary, is tested with limited live traffic at first. Ops teams and SREs then observe and analyze the performance and customer experience of the canary before gradually rolling it out for the larger audience in case of no issues.

The crucial part of a canary deployment is to split the live traffic and route a small portion of it to the canary. Architects and DevOps teams need the best tool to carry out such traffic splitting between services. Of course, API gateways can do it. But it is difficult to split traffic between internal services or subsets with API gateways.

This is where the open-source Istio service mesh comes in. Istio provides five traffic management API resources to handle traffic from the edge and also between service subsets:

  • Virtual services
  • Destination rules
  • Gateways
  • Service entries
  • Sidecars

Out of all the above resources, virtual services and destination rules form the core of Istio’s traffic routing features. Canary deployment is just one of the use cases they provide. Let us explore the resources, like what virtual services and destination rules are, and how they work.

But before we begin, let us understand how Istio routes and load balance traffic by default.

A Quick Introduction to Istio Envoy Proxy Load Balancing

Istio uses Envoy proxy as its data plane. Envoy proxy runs as a sidecar container with each application pod and intercepts the traffic going in and out of the pod, as shown in the image below.

Istio’s Envoy proxy uses the least requests model to load balance traffic by default. That means two random service instances (pods) are selected from a service’s load balancing pool (or replicas), and the traffic is routed to the pod that has fewer active requests to serve. This prevents service instances or pods from request overloading and ensures effective utilization of resources.

Istio works fine with the default load-balancing model. However, there are circumstances where you want to configure certain rules. For example, consider the below scenarios:

  • You want to change the default routing policy into a weighted or round-robin model.
  • You want to limit the number of simultaneous connections or requests to upstream services.
  • You want to set an outlier detection policy to eject unhealthy pods for a certain amount of time to keep the infrastructure resilient.
  • You would like to A/B test between two versions of services — split traffic and route a certain percentage of them to the new version.

These are some instances where DevOps and cloud architects can use VirtualServices and DestinationRules.

What Are Istio Virtual Services?

Istio virtual service is a Kubernetes custom resource definition (CRD) that defines the routing rules for traffic within a mesh. Virtual service routes requests to respective destinations if they meet the matching criteria defined in the VirtualService YAML file.

The matching conditions can be applied to any parameters in the HTTP messages, such as URIs, traffic ports, header fields, etc. Istio virtual service resource supports HTTP/1.1, HTTP2, and gRPC traffic.

Sample VirtualService YAML

The below VirtualService YAML will route traffic with the URIs /istio-support and /istio-implementation addressing the host imeshi.ai, to istio-support and istio-implementation services, respectively.

YAML

apiVersion: networking.istio.io/v1beta1
kind: VirtualService
metadata:
  name: imesh-route
spec:
  hosts:
    - imesh.ai
  http:
  - match:
    - uri:
        prefix: /istio-support
    route:
    - destination:
        host: istio-support
  - match:
    - uri:
        prefix: /istio-implementation
    route:
    - destination:
        host: istio-implementation


Below are some parameters for virtual service resources to create the rules for runtime traffic:

  • hosts: In YAML, hosts field is the destination host (DNS name, IP address, or FQDN) that the routing rules apply to. The hosts is set to imesh.ai in the above example, so the VirtualService will only apply to requests addressing that host.
  • http: The http section defines the virtual service’s routing rules for traffic to hosts. It contains the match conditions and the destination where the traffic should go based on those conditions. Apart from HTTP, virtual services can route TCP and unterminated TLS traffic.
  • match: The match field sets conditions that the incoming request has to satisfy for it to be routed to the destination service. This can be based on URIs, HTTP headers, methods, source IP addresses, etc. Here, the match has uri subfields with prefix attributes that match the URIs of incoming requests, which are /istio-support and /istio-implementation respectively.
  • destination: The destination defined under the route section specifies the actual destination for traffic that matches the respective conditions. For effective traffic distribution, the destination service should exist in Istio’s service registry, either by default (Envoy proxy) or added using a service entry. The destination can also be a service subset.

The above fields show only the gist of routing rules that DevOps and cloud engineers can configure with virtual services. To see the comprehensive list, head to Istio / Virtual Service.

What Are Istio Destination Rules?

The Istio destination rule is another Kubernetes CRD that defines rules for the traffic routed after evaluating virtual service configurations. In other words, DestinationRule defines what happens to the traffic routed to a given destination. Destination rules let users customize the following traffic policies of Envoy proxy:

  • Load balancing model
  • Connection pool size from the sidecar
  • Outlier detection settings
  • TLS security mode
  • Circuit breaking settings

Sample DestinationRule YAML

We configured the above VirtualService to route requests to imesh.ai/istio-support to istio-support service. Assuming that we have two subsets of istio-support deployed, then this is how the DestinationRule YAML would look like:

YAML

apiVersion: networking.istio.io/v1beta1
kind: DestinationRule
metadata:
  name: istio-support-destination
spec:
  host: istio-support
  subsets:
  - name: istio-support-v1
	labels:
  	  version: v1
  - name: istio-support-v2
	labels:
  	  version: v2
  trafficPolicy:
      loadBalancer:
        simple: ROUND_ROBIN


The traffic to istio-support service will load balance between the two subsets (istio-support-v1 and istio-support-v2) using the round-robin algorithm, given that they are mentioned in the corresponding VirtualService since the routing is defined there.

Typically, both virtual services and destination rules work together to apply policies and send traffic to their respective destinations. But sometimes, they do not need each other:

  • If the service has only one version and there are no granular routing requirements such as load balancing policy, connection pool settings, etc., VirtualService alone will be enough.
  • DestinationRule independently is sufficient if you only need to apply traffic policies like load balancing policy or circuit breaking to specific services.

How Do Virtual Services and Destination Rules Work?

The control plane component of Istio, called istiod, applies virtual services and destination rules to all data plane proxies by default. However, note that it is the Envoy proxy at the source which controls the routing rules and not the one at the destination.

For example, if the traffic coming from UI service (pod A) to product service (pod 2) needs to have retry logic configured (refer to the image below), the proxy of pod A controls this configured behavior, not the proxy of pod 2.

Many DevOps and cloud engineers who try to understand virtual services and destination rules fall into the trap of believing that they are controlled by the destination proxy. But if you look at why it is not the case, it is all very logical:

  • The sidecar proxy of pod 2 is only aware of its own application container, pod 2. It is not aware of the containers of pod 1 or pod 3. So if the request to pod 2 keeps on failing, pod 1 or pod 3 still will not serve that request.

    In the case of UI service, it sits outside product service’s cluster and is fully aware of the services (pod 1, pod 2, pod 3) in the cluster. (Note that cluster here means a set of similar services, not Kubernetes cluster.) So, UI service’s proxy can route traffic to pod 1 or pod 3 when a request to pod 2 fails.
  • Almost similar is the case if you configure traffic splitting between services. For example, if you want 25% of the traffic from the UI to go to pod 1 and 10% to pod 2, Envoy proxies of the UI pods control that rule.

    The proxy of pod 2 cannot do anything because it is the destination and the traffic has already reached there. It cannot forward the traffic to other service instances. At the same time, UI service’s pods that sit outside can see and control the behavior of traffic to the cluster, including forwarding requests based on weights.
  • The same happens with routing to subsets (in the least-request load balancing model, for example) using DestinationRule. To send traffic to subsets with the least active requests, the proxy needs to monitor traffic to the pods in the cluster. And it can only be done by the proxy outside the cluster.
  • Now, assume that there is a new service called reviews. It is not deployed in an Istio-enabled namespace and thus does not have a sidecar proxy. If reviews sends traffic to an Istio-enabled service, you cannot configure any routing rules on the requests since the source does not have the proxy to apply virtual services or destination rules.

Always remember: Envoy proxy at the source controls the routing rules, not the one at the destination.

Features and Use Cases of Istio Virtual Services and Destination Rules

Virtual services and destination rules help in applying granular routing rules. Besides, they provide features to test and ensure network resiliency so that applications operate reliably.

Below are some features and use cases of virtual services and destination rules:

  • Canary deployments
  • Blue/green deployments
  • Timeouts
  • Retries
  • Fault injection
  • Circuit breakers
  • Failover/mirroring

In the article, Traffic Management and Network Resiliency With Istio Service Mesh, you can learn more about each of them in detail.
