Getting Started with Hibernate Search

The Key to Effective ORM

Written by

John Griffin Senior Developer, Overstock.com

Explains Hibernate Search installation and configuration, Mapping entities, bridges, building indexes, querying indexes, and examining their contents.

Free PDF
Section 1

Google Your Database!

Hibernate Search complements Hibernate Core by enabling full-text search queries on persistent domain models, and brings Lucene search features to the Hibernate world. Hibernate Search depends on Apache Lucene, a powerful full-text search engine library (and a de facto standard solution in Java) hosted at the Apache Software Foundation (http://www.apache.org/). This refcard explains installation and configuration, and covers Mapping entities, bridges, building indexes, querying them and examining their contents. Table 1 shows links to documentation.

Topic URL
Lucene http://lucene.apache.org/java/docs/
Hibernate Search http://www.hibernate.org/410.html
Mailing lists http://www.hibernate.org/20.html
JIRA http://opensource.atlassian.com/projects/hibernate/secure/Dashboard.jspa

Table 1 Documentation Links

Section 2

Getting Started

In order to use Hibernate Search you should understand the basics of Hibernate, and be familiar with the object manipulation APIs from the Hibernate Session or the Java Persistence EntityManager as well as the query APIs. You should also be familiar with associ-ation mappings and the concept of bidirectional relationships.

Download Hibernate Search at http://www.hibernate.org or use the JBoss Maven repository (http://repository.jboss.org/maven2/org/hibernate/hibernate-search). It is interesting to download the Apache Lucene distribution as well, available at http://lucene.apache.org/java/. It contains both documentation and a contri-bution section containing various add-ons not included in Hibernate Search. Make sure to use the same Lucene version Hibernate Search is based on. You can find the correct version in the Hibernate Search distribution in lib/readme.txt.

Hibernate Search requires three JARs – all available in the Hibernate Search distribution:

  • hibernate-search.jar: the core API and engine of
  • Hibernate Search
  • lucene-core.jar: Apache Lucene engine
  • hibernate-commons-annotations.jar: some common utilities for the Hibernate project

You can also add the optional support for modular analyzers by adding: apache-solr-analyzer.jar. This JAR (available in the Hibernate Search distribution), is a subset of the SOLR distribution that contains various analyzers. While optional, it is recommended to add this JAR to your classpath as it greatly simplifies the use of analyzers.

Hot Tip

The apache-solr-analyzer.jar capabilities are only available in Hibernate Search 3.1+.

Hibernate Search is not compatible with all versions of Hibernate Core and Hibernate Annotations. Refer to Table 2 for compati-bility requirements. The latest version is available on the Hibernate download page at http://www.hibernate.org/6.html.

Package Version Core Annotations Entity
Hibernate Core 3.2.6 GA 3.2.x, 3.3.x 3.2.x, 3.3.x 3.0.x
3.3.0 SP1 3.4.x 3.4.x 3.1.x
Hibernate Annotations 3.3.1 GA 3.2.x 3.3.x 3.0.x
3.4.0 GA 3.3.x 3.4.x 3.1.x
Hibernate EntityManager 3.3.2 GA 3.2.x 3.3.x 3.0.x
3.4.0 GA 3.3.x 3.4.x 3.1.x
Hibernate Validator 3.0.0 GA 3.2.x 3.3.x 3.3.x 3.0.x
3.1.0 GA 3.3.x 3.4.x 3.4.x 3.1.x
Hibernate Search 3.0.1 GA >= 3.2.2
(better if >= 3.2.6)
(better if >= 3.3.1 )
3.1.0 Beta1 3.3 3.4 3.4 -
Hibernate Shards 3.0.0 Beta2 3.2.x 3.3.x Not compatible 3.0.x
Hibernate Tools 3.2.2 3.2.x 3.2.x and 3.3.x 3.2.x and 3.3.x (3.2.0)

Table 2: Compatibility Matrix.

Hot Tip

Dependencies needed to build and initially test Hibernate Search are included in the Hibernate Search distribution or can be found in the Maven dependency file (POM) which is included with the Hibernate Search download.

Configuration Parameters

Configuration parameters can be provided in three ways:

  • In a hibernate.cfg.xml file
  • In a /hibernate.properties file
  • Through the configuration API and specifically configuration.setProperty(String, String)
Listing 1: An example hibernate.cfg.xml file.

<?xml version=”1.0” encoding=”UTF-8”?> hibernate.cfg.xml file
<!DOCTYPE hibernate-configuration PUBLIC
   “-//Hibernate/Hibernate Configuration DTD 3.0//EN”
<!-- hibernate.cfg.xml -->
        <session-factory name=”dvdstore-catalog”>

        <!-- regular Hibernate Core configuration -->
        <property name=”hibernate.dialect”>
        <property name=”hibernate.connection.datasource”>

        <!-- Hibernate Search configuration -->
        <property name=”hibernate.search.default.indexBase”>

        <!-- mapping classes -->
        <mapping class=”com.manning.dvdstore.model.Item”/>
        list additional entities

Parameter Description
hibernate.search.autoregister_listeners Enable listeners auto registration in Hibernate Annotations and Entity-Manager. Default to true.
hibernate.search.indexing_strategy Defines the indexing strategy, default to event. Other option is manual.
hibernate.search.analyzer The default Lucene analyzer class.
hibernate.search.similarity The default Lucene similarity class.
hibernate.search.worker.batch_size Has been deprecated in favor of this explicit API
hibernate.search.worker.backend Out of the box support for the Apache Lucene backend and the JMS back end. Defaults to lucene. Other option is jms.
hibernate.search.worker.execution Supports synchronous and asynchronous execution. Defaults to sync. Other option is async.
hibernate.search.worker.thread_pool.size Defines the number of threads in the pool. Useful only for asynchronous execution. Default to 1.
hibernate.search.worker.buffer_queue.max Defines the maximal number of work queue if the thread poll is starved. Useful only for asynchronous execution. Default to infinite. If the limit is reached, the work is done by the main thread.
hibernate.search.worker.jndi.* Defines the JNDI properties to initiate the InitialContext (if needed). JNDI is only used by the JMS back end.
hibernate.search.worker.jms.connection_factory Mandatory for the JMS back end. Defines the JNDI name to lookup the JMS con- nection factory from. (java:/Connect ionFactory by default in JBoss AS)
hibernate.search.worker.jms.queue Mandatory for the JMS back end. Defines the JNDI name to lookup the JMS queue from. The queue will be used to post work messages.
hibernate.search.reader.strategy Defines the reader strategy used. Defaults to shared. Other option is not-shared.
hibernate.search.filter.cache_strategy The filter caching strategy class (must have a no-arg constructor and implement FilterCachingStrategy).
hibernate.search.filter.cache_bit_results.size The hard ref count of our Caching WrapperFilter. Defaults to 5.

Table 3: Hibernate Search configuration parameters.

Section 3

Mapping Entities

Figure 1

Figure 1: Basic entity mapping.

Section 4


Bridges fulfill several needs in the Hibernate Search architecture.

  • Converts an object instance into a Lucene consumable representation (commonly a String) and adds it to a Lucene document.
  • Reads information from the Lucene document and builds back the object representation.

Bridges that support both the conversion object to Lucene and Lucene to object are called two-way bridges. Table 4 lists all out-of-the-box Hibernate Search bridges.

Java Type Build-in Bridge Description
String StringBridge no-op
short / Short ShortBridge Use toString(), not comparable
int / Integer IntegerBridge Use toString(), not comparable
long / Long LongBridge Use toString(), not comparable
float / Float FloatBridge Use toString(), not comparable
double / Double DoubleBridge Use toString(), not comparable
BigDecimal BigDecimalBridge Use toString(), not comparable
BigInteger BigIntegerBridge Use toString(), not comparable
boolean / Boolean BooleanBridge String value: “true” / “false”
Class ClassBridge Allows manipulation of any combination of different fields.
Enum EnumBridge Use enum.name()
URL UrlBridge Converts to the String representation
URI UriBridge Converts to the String representation
Date DateBridge The string representation depends on @DateBridge. Converting Date into string and back is not guaranteed to be idempotent

Table 4: List of standard Hibernate Search bridges.

Custom bridges allow for converting unexpected data types. The @FieldBridge annotation is placed on a property (field or getter) that needs to be processed by a custom bridge. An example, including parameter passing, is given in Listing 2.

Listing 2: A custom bridge example with parameters.

public class Item {
  // property marked to use a custom bridge
    // declare the custom bridge implementation
    // optionally provide parameters
    params= {
      @Parameter(name=”pad”, value=”3”),
      @Parameter(name=”round”, value=”5”) }
private double price;

Embeddable Objects

Embedded objects in Java Persistence (they are called comp-onents in Hibernate) are objects whose life cycle entirely depends on the owning entity. When the owning entity is deleted, the embedded object is deleted as well.

Listing 3: Embeddable Object example.

public class Rating {
        // mark properties for indexing
        @Field(index=Index.UN_TOKENIZED) private Integer overall;
        @Field(index=Index.UN_TOKENIZED) private Integer scenario;
        @Field(index=Index.UN_TOKENIZED) private Integer soundtrack;
        @Field(index=Index.UN_TOKENIZED) private Integer picture;
public class Item {
        // mark the association for indexing
        @IndexedEmbedded private Rating rating;

@IndexedEmbedded marks the association as embedded: the Lucene document contains rating.overall, rating,scenario, rating.soundtrack, rating.picture. When Item is deleted the embedded Rating object is also deleted.


Associations between objects are similar to embeddable objects except that an associated object’s life time is not dependent on the owning entity. Below is an example association mapping.

Figure 2

Figure 2: An example association.

Associations, Continued

Listing 4 shows that @ContainedIn is paired to an @IndexedEmbedded annotation on the other side of the bi-directional relationship.

Listing 4: Figure 2 in code.

@Entity @Indexed
public class Item {
        private Set<Actor> actors; // embed actors when indexing
        private Director director; // embed director when indexing
@Entity @Indexed
public class Actor {
        @Field private String name;
        @ContainedIn actor is contained in item index (1)
        private Set<Item> items;
@Entity @Indexed
public class Director {
        @Id @GeneratedValue @DocumentId private Integer id;
        @Field private String name;
        @ContainedIn director is contained in item index
        private Set<Item> items;

Hot Tip

The @IndexEmbedded depth setting (e.g. @IndexEmbedded(depth=3)) controls the maximum number of embeddings allowed per association.
Section 5


Analyzers are responsible for taking text as input, chunking it into individual words (tokens) and optionally applying some operations (filters) on the tokens. A filter can alter the stream of tokens as it pleases. It can remove, change, and add words.

In addition to the SOLR analyzers mentioned previously, Lucene’s org.apache.lucene.analysis package contains additional analyzers and many filters. Listing 5 is an example of defining an analyzer on an entity.

Listing 5

@Entity @Indexed
  name=”applicationanalyzer”, // analyzer definition name
  tokenizer =
     // tokenizer factory
  @TokenizerDef(factory = StandardTokenizerFactory.
  class ),
     filters = {
                // list of filters to apply
                @TokenFilterDef(factory = StopFilterFactory.
                // parameters passed to the filter factory
                params = {
                @Parameter(name=”ignoreCase”, value=”true”)
         } )
} )
// Use the pre defined analyzer
public class Item {

Section 6

Initial Indexing of Entities


First you need an instance of either a FullTextEntityManager or a FullTextSession depending on whether or not you are using an EntityManager.

Listing 6: Manually indexing data.

SessionFactory factory =
   new AnnotationConfiguration().buildSessionFactory();
Session session = factory.openSession();
FullTextSession fts =
for (Item item : items) {
   fts.index(item); //manually index an item instance
fts.getTransaction().commit(); //index is written at commit time
EntityManagerFactory factory =
EntityManager em = factory.createEntityManager();
FullTextEntityManager ftem =
for (Item item : items) {
   ftem.index(item); //manually index an item instance
//index is written at commit time

Hot Tip

getFullTextSession and getFullTextEntityManager were named createFullTextSession and createFullTextEntityManager in Hibernate Search 3.0.

From a Dataset

Listing 7: Initial indexing of a dataset.

// disable flush operations
// disable 2nd level cache operations

Transaction tx = session.beginTransaction();
// read the data from the database
// scrollable results will avoid loading too many objects
// in memory
// ensure forward only result set
ScrollableResults results = session.createCriteria(Item.class)
   .scroll( ScrollMode.FORWARD_ONLY );

int index = 0;
while( results.next() ) {
   session.index( results.get(0) ); index entities (4)
   if (index % BATCH_SIZE == 0) {
      session.flushToIndexes(); apply changes to the index (5)
      session.clear(); clear the session releasing memory
tx.commit(); apply the remaining index changes

Updates, additions and deletions to indexes are handled auto-matically by Hibernate Search via entity listeners. If you are using Hibernate Annotations these listeners are automatically wired for you. If you are not using the annotations then you have to wire the listeners manually as shown in Listing 8.

From a Dataset, Continued

Listing 8: Wiring listeners when not using annotations.

     <event type=”post-update”>
        <listener class= “org.hibernate.search.event
     <event type=”post-insert”>
        <listener class= “org.hibernate.search.event
     <event type=”post-delete”>
                <listener class= “org.hibernate.search.event
     <event type=”post-collection-recreate”>
                <listener class= “org.hibernate.search.event
     <event type=”post-collection-remove”>
                <listener class= “org.hibernate.search.event
     <event type=”post-collection-update”>
                <listener class= “org.hibernate.search.event

For versions of Hibernate Search prior to 3.1.x the configuration is slightly different as shown in Listing 9.

Listing 9: Wiring listeners prior to Hibernate Search version 3.1.x.

        <event type=”post-update”>
          <listener class=”org.hibernate.search.event
        <event type=”post-insert”>
          <listener class=”org.hibernate.search.event
        <event type=”post-delete”>
          <listener class=”org.hibernate.search.event
        <!-- collection listener is different -->
        <event type=”post-collection-recreate”>
          <listener class=”org.hibernate.search.event
        <event type=”post-collection-remove”>
          <listener class= org.hibernate.search.event
        <event type=”post-collection-update”>
          <listener class=”org.hibernate.search.event

Section 7

Querying Indexes

Table 5 shows the three ways to obtain results.

Method Call Description
query.list() List<Item> items = query.list(); All matching objects are loaded eagerly as opposed to lazily.
query.iterate() Iterator<Item> items = query.iterate(); while ( items.hasNext() ) { Item item = items.next(); } All object identifiers are extracted from the Lucene index but objects are not loaded until iterator.next() is called

ScrollableResults items = query.scroll();
// process results
ScrollableResults must be closed when processing is finished to free resources.

Table 5: Querying indexes, continued.

Listing 10: A FullTextQuery example.

SessionFactory factory =
   new AnnotationConfiguration().buildSessionFactory();
Session session = factory.openSession();
FullTextSession fts =
// create a Term for the description field
Term term = new Term(“description”, “salesman”);
TermQuery query = new TermQuery(term);
// generate a FullTextQuery and obtain a result list
org.hibernate.search.FullTextQuery hibQuery =
   s.createFullTextQuery(query, Dvd.class);
List<Dvd> results = hibQuery.list();

Basic Query Types

Table 6 presents the basic query types. Consult the Lucene API documentation at http://lucene.apache.org/java/2_4_0/api/index.html for a complete listing, specifically the org.apache.lucene.search package.

Query Description
TermQuery This is the basic building block of queries. It searches for a single term in a single field. Many other query types are reduced to one or more of these.
WildcardQuery Queries with the help of two wildcard symbols '*' (multiple characters) and '?' (single character). These wildcard symbols allow queries to match any combination of characters.
PrefixQuery A WildcardQuery that starts with characters and ends with the '*' symbol.
PhraseQuery Also known as a proximity search, this queries for multiple terms enclosed by quotes.
FuzzyQuery Queries using the Levenshtein distance between terms. Requires a minimum similarity float value that expands or contracts the distance.
RangeQuery Allows you to search for results between two values. Values can be inclusive or exclusive but not mixed.
BooleanQuery Holds every possible combination of any of the other query types including other BooleanQuerys. Boolean queries combine individual queries as SHOULD, MUST or MUST_NOT.
MatchAllDocsQuery Returns all documents contained in a specified index.

Table 6: Basic query types.

Section 8

Hibernate Search Annotations

Table 7 is a complete listing of all Hibernate Search annotations.

Annotation Description
@Analyzer Define an Analyzer for a given entity, method, attribute or Field. The order of precedence is: @Field, attribute/ method, entity, default. Able to reference an implementation or an @AnalyzerDef definition.
@AnalyzerDef Reusable analyzer definition. An analyzer definition defines: one tokenizer and, optionally, some filters. Filters are applied in the order they are defined.
@Boost Apply a boost factor to a field or an entire entity.
@ClassBridge Allows a user to manipulate a Lucene document based on an entity change in any manner the user wishes.
@ClassBridges Allows multiple @ClassBridge declarations per document.
@ContainedIn Marks the owning entity as being part of the associ-ated entity’s index (to be more accurate, being part of the indexed object graph). This is only necessary when an entity is used as a @IndexedEmbedded target class. @ContainedIn must mark the property pointing back to the @IndexedEmbedded owning Entity. Not necessary if the class is an embeddable class.
@DateBridge Defines the temporal resolution of a given property. Dates are stored as a String in GMT.
@DocumentId Declare a property as the document id.
@Factory Marks a method of a filter factory class as a Filter implementation provider. A factory method is called whenever a new instance of a filter is requested.
@Field Marks a property as indexed. Contains field options for storage, tokenization, whether or not to store TermVector information, a specific analyzer and a Field-Bridge.
@FieldBridge Specifies a field bridge implementation class. A field bridge converts (sometimes back and forth) a property value into a string representation or a representation stored in the Lucene Document.
@Fields Marks a property as indexed into different fields. Useful if the field is used for sorting and searching or if different analyzers are used.
@FullTextFilterDef Defines a full-text filter that can be optionally applied to full-text queries. While not related to a specific indexed entity, the annotation must be set on one of them.
@FullTextFilterDefs Allows multiple @FullTextFilterDef per FullTextQuery.
@Indexed Specifies that an entity is to be indexed. The index name defaulted to the fully qualified class name can be overridden using the name attribute.
@IndexedEmbedded Specifies that an association (@*To*, @Embedded, @CollectionOfEmbedded) is to be indexed in the root entity index. It allows queries involving associated objects restrictions.

Marks a method of a filter factory class as a Filter key provider. A key is an object that uniquely identifies a filter instance associated with a given set of parameters.

The key object must implement equals and hashcode so that 2 keys are equals if and only if the given target object types are the same and the set of parameters are the same. The key object is used in the filter cache implementation.

@Parameter Basically a key/value descriptor. Used in @ClassBridge, @FieldBridge, TokenFilterDef and @TokenizerDef.
@ProvidedId Objects whose identifier is provided externally, as opposed to being a part of the object state, should be marked with this annotation. This annotation should not be used in conjunction with @DocumentId. This annotation is primarily used in the JBoss Cache Searchable project. http://www.jboss.org/jbosscache and http://wiki.jboss.org/wiki/JBossCacheSearchable
@Similarity Specifies a similarity implementation to use in scoring calculations.

Ex. @Entity
@Similarity(impl = BookSpecificSimilarity.public class Book {

@TokenFilterDef Specifies a TokenFilterFactory and its parameters inside a @AnalyzerDef.
@TokenizerDef Defines a TokenizerFactory and its parameters inside a @AnalyzerDef

Table 7: Hibernate Search Annotations.

Section 9


The most indispensable utility you can have in your arsenal of index troubleshooting tools (in fact it may be the only one you really need) is Luke, shown in Figure 3. With Luke you can examine any facet of an index you can imagine. Some of its capabilities are:

  • view individual documents
  • execute a search, and browse the results
  • selectively delete documents from the index
  • examine term frequency, and many more...

The Luke author, Andrzej Bialecki, actively maintains Luke to keep up with the latest Lucene version. Luke is available for download, in several different formats, at http://www.getopt.org/luke/. The most current version of the Java WebStart JNLP direct download is the easiest to retrieve.

Figure 3

Figure 3: The search window of the Luke utility for Lucene indexes.


  • Featured
  • Latest
  • Popular
Getting Started With Docker
Teaches you typical Docker workflows, building images, creating Dockerfiles, and includes helpful commands to easily automate infrastructure and contain your distributed application.
10.3k 7,449
Getting Started With Real User Monitoring
Teaches you how to use new web standards—like W3C’s Beacon API—to see how your site is performing for actual users, letting you better understand how to improve overall user experience.
4,492 3,749
Core Java
Gives you an overview of key aspects of the Java language and references on the core library, commonly used tools, and new Java 8 features.
104.2k 264.3k
JavaFX 8
Gives you what you need to start using the powerful JavaFX 8 UI and graphics tool with code snippets and visual examples of shapes and controls.
6,829 9,071
Continuous Delivery With Jenkins Workflow
Provides an introduction to the Jenkins Workflow plugin, a tool that extends the popular CD application to manage even the most complex software pipelines and help you continuously deliver more efficiently.
8,722 9,902
Functional Programming in JavaScript
Explains functions, data types, and techniques to demonstrate the functional paradigm through the familiar JavaScript language.
12k 8,797
Java Caching
Explores the building blocks of JCache and other caching APIs, as well as multiple strategies for implementing temporary data storage in your application.
10.5k 10.7k
Getting Started With Microservices
Still re-deploying your entire application for one small update? Microservices deploy modular updates and increase the speed of application deployments.
13.8k 14.3k
Getting Started With MQTT
Explores the fundamentals of MQTT, including message types, QoS levels, and security.
6,098 7,234
Monitoring NGINX
Overcome dropped connections, server errors, and more by efficiently monitoring your NGINX web server.
4,889 3,862
Getting Started With Apache Tomcat
Learn Apache Tomcat, a pure Java open-source web server that implements the Java Servlet, JavaServer Pages, and Expression Language specifications.
8,896 7,380
IntelliJ IDEA Essentials
Helps Java developers navigate the various facets of this world-class IDE, with tips, tricks, shortcuts, and quick tutorials on editor basics, navigation, and more.
20.4k 91.1k
{{ card.title }}
{{card.downloads | formatCount }} {{card.views | formatCount }}

{{ parent.title || parent.header.title}}

{{ parent.tldr }}

{{ parent.urlSource.name }}
