Build a Microservices Architecture With Spring Boot and Spring Cloud Config Using JHipster

Java and Spring Boot is becoming a very popular combination to develop a microservice architecture. If you don’t believe me, just look at all the similar frameworks that have popped up throughout the years like Quarkus, Micronaut, and MicroProfile.

Spring Boot provided Java Developers with “starters” that have pre-configured beans with default settings. This meant that Java developers could write less code with the ability to override any of the settings through an application.properties file.

In a previous tutorial on Java Microservices with Spring Boot and Spring Cloud, I showed how you can use OAuth 2.0 and OpenID Connect to secure everything. One of the problems with this example is that you have to configure the OIDC properties in each application. This can be a real pain if you have hundreds of microservices. Yes, you could define them as environment variables and this would solve the problem. However, if you have different microservices stacks using different OIDC client IDs, this approach will be difficult.

Java Microservices with Spring Cloud Config

Spring Cloud Config is a project that provides externalized configuration for distributed systems. Spring Cloud Config has server and client components. You can configure the server to read its configuration from the file system or a source code repository, like Git. On the client, you configure things in a bootstrap configuration file to get configuration data from the server. In a microservices environment, this provides an elegant way to configure all your microservices from a central location.

Today I’d like to show you how this works and demo it using one of the hippest microservice solutions I’ve ever worked with.

Use JHipster to Generate a Java Microservices Architecture

JHipster is a development platform to generate, develop, and deploy Spring Boot + { Angular or React or Vue } applications. In addition, it supports creating Spring-based microservice architectures. In fact, if you create microservices projects and choose OAuth 2.0 / OIDC for authentication, you’ll be using code that’s very similar to the aforementioned example.

To use JHipster, you’ll need to have Node.js installed. You can also use start.jhipster.tech, which is similar to start.spring.io.

The most common way to install JHipster is using npm:

npm install -g generator-jhipster@6.0.1

In a terminal, create a directory to hold all the projects you’re about to create. For example, jhipster.

Create an apps.jh file in this directory and put the following code into it.

application {
  config {
    baseName gateway,
    packageName com.okta.developer.gateway,
    applicationType gateway,
    authenticationType oauth2,
    prodDatabaseType postgresql,
    serviceDiscoveryType eureka,
    testFrameworks [protractor]
  }
  entities Blog, Post, Tag, Product
}

application {
  config {
    baseName blog,
    packageName com.okta.developer.blog,
    applicationType microservice,
    authenticationType oauth2,
    prodDatabaseType postgresql,
    serverPort 8081,
    serviceDiscoveryType eureka
  }
  entities Blog, Post, Tag
}

application {
  config {
    baseName store,
    packageName com.okta.developer.store,
    applicationType microservice,
    authenticationType oauth2,
    databaseType mongodb,
    devDatabaseType mongodb,
    prodDatabaseType mongodb,
    enableHibernateCache false,
    serverPort 8082,
    serviceDiscoveryType eureka
  }
  entities Product
}

entity Blog {
  name String required minlength(3),
  handle String required minlength(2)
}

entity Post {
  title String required,
  content TextBlob required,
  date Instant required
}

entity Tag {
  name String required minlength(2)
}

entity Product {
  title String required,
  price BigDecimal required min(0),
  image ImageBlob
}

relationship ManyToOne {
  Blog{user(login)} to User,
  Post{blog(name)} to Blog
}

relationship ManyToMany {
  Post{tag(name)} to Tag{post}
}

paginate Post, Tag with infinite-scroll
paginate Product with pagination

microservice Product with store
microservice Blog, Post, Tag with blog

// will be created under 'docker-compose' folder
deployment {
  deploymentType docker-compose
  appsFolders [gateway, blog, store]
  dockerRepositoryName "jmicro"
  consoleOptions [zipkin]
}

This code is JDL (JHipster Domain Language) and you can use it to define your app, its entities, and even deployment settings. You can learn more about JDL in JHipster’s JDL documentation. Below is a screenshot of JDL Studio, which can be used to edit JDL and see how entities related to each other.

The JDL you just put in apps.jh defines three applications:

• gateway: a single entry point to your microservices, that will include the UI components.
• blog: a blog service that talks to PostgreSQL.
• store: a store service that uses MongoDB.

Run the following command to create these projects in your jhipster folder.

jhipster import-jdl apps.jh

Create Docker Images for Microservice Apps

When the configuration is generated for Docker Compose, a warning is spat out to the console.

WARNING! Docker Compose configuration generated, but no Jib cache found
If you forgot to generate the Docker image for this application, please run:
To generate the missing Docker image(s), please run:
  ./mvnw -Pprod verify jib:dockerBuild in /Users/mraible/java-microservices-examples/jhipster/gateway
  ./mvnw -Pprod verify jib:dockerBuild in /Users/mraible/java-microservices-examples/jhipster/blog
  ./mvnw -Pprod verify jib:dockerBuild in /Users/mraible/java-microservices-examples/jhipster/store

To make it easier to create Docker images with one command, create an aggregator pom.xml in the jhipster root directory.

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <groupId>com.okta.developer</groupId>
    <artifactId>jhipster-parent</artifactId>
    <version>1.0.0-SNAPSHOT</version>
    <packaging>pom</packaging>
    <name>jhipster-parent</name>
    <modules>
        <module>gateway</module>
        <module>blog</module>
        <module>store</module>
    </modules>
</project>

Then "just jib it" using Jib.

mvn -Pprod verify com.google.cloud.tools:jib-maven-plugin:dockerBuild

[INFO] Skipping containerization because packaging is 'pom'...
[INFO] ------------------------------------------------------------------------
[INFO] Reactor Summary:
[INFO]
[INFO] Gateway 0.0.1-SNAPSHOT ............................. SUCCESS [02:44 min]
[INFO] Blog 0.0.1-SNAPSHOT ................................ SUCCESS [ 34.391 s]
[INFO] Store 0.0.1-SNAPSHOT ............................... SUCCESS [ 28.589 s]
[INFO] jhipster-parent 1.0.0-SNAPSHOT ..................... SUCCESS [  1.096 s]
[INFO] ------------------------------------------------------------------------
[INFO] BUILD SUCCESS
[INFO] ------------------------------------------------------------------------
[INFO] Total time: 03:49 min
[INFO] Finished at: 2019-05-17T07:44:39-06:00
[INFO] ------------------------------------------------------------------------
Execution time: 3 min. 50 s.

Run Your Java Microservices Stack with Docker Compose

Once everything has finished building, cd into the docker-compose directory and start all your containers.

cd docker-compose
docker-compose up -d

It will take several minutes to start all eight of your containers. You can use Kitematic to monitor their startup progress if you like.

Creating docker-compose_gateway-app_1                ... done
Creating docker-compose_gateway-postgresql_1         ... done
Creating docker-compose_blog-app_1                   ... done
Creating docker-compose_store-mongodb_1              ... done
Creating docker-compose_keycloak_1                   ... done
Creating docker-compose_blog-postgresql_1            ... done
Creating docker-compose_jhipster-registry_1          ... done
Creating docker-compose_store-app_1                  ... done

JHipster Registry for Service Discovery with Java Microservices

This microservices stack uses Eureka for service discovery, just like the bare-bones Spring Boot + Spring Cloud example. This was determined by the following line for each app in the JDL.

serviceDiscoveryType eureka

When you select eureka for service discovery, JHipster Registry is used. This application is very similar to Eureka Server, except it has an Angular UI and includes Spring Cloud Config, among other features.

Because you chose OAuth 2.0/OIDC for authentication, you’ll need to create an entry in your hosts file (/etc/hosts on Linux/Mac, C:\Windows\System32\Drivers\etc\hosts on Windows) for Keycloak.

127.0.0.1  keycloak

This is because the Docker network recognizes keycloak as a registered hostname, but it also redirects you to keycloak. Your browser is not aware of that hostname without the hosts entry.

Open your browser and navigate to http://localhost:8761. You’ll be redirected to Keycloak to login. Enter admin/admin for credentials and you’ll be redirected back to JHipster Registry. You’ll see all your microservice instances have been registered.

Navigate to http://localhost:8080, click sign in, and you’ll be logged in to the gateway. You can go to Entities > Blog and add a blog.

Go to Entities > Product and you can add a product too.

Pretty slick, don’t you think?!

Configure JHipster Microservices to Use Okta for Identity

One of the problems you saw in the bare-bones Spring Boot + Spring Cloud setup is you have to configure okta.oauth2.* properties in every microservice. JHipster doesn’t use the Okta Spring Boot starter. It uses oauth2-client and oauth2-resource-server Spring Boot starters instead. The configuration for OAuth 2.0 is contained in each app’s src/main/resources/config/application.yml file.

spring:
  ...
  security:
    oauth2:
      client:
        provider:
          oidc:
            issuer-uri: http://localhost:9080/auth/realms/jhipster
        registration:
          oidc:
            client-id: internal
            client-secret: internal

Why Okta?

You might be wondering why you should use Okta instead of Keycloak? Keycloak works great for development and testing, and especially well if you’re on a plane with no wi-fi. However, in production, you want a system that’s always on. That’s where Okta comes in. To begin, you’ll need to create an Okta account and an application with it.

Create a Web Application in Okta

Log in to your Okta Developer account (or sign up if you don’t have an account).

1. From the Applications page, choose Add Application.
2. On the Create New Application page, select Web.
3. Give your app a memorable name, add http://localhost:8080/login/oauth2/code/oidc as a Login redirect URI, select Refresh Token (in addition to Authorization Code), and click Done.
4. To configure Logout to work in JHipster, Edit your app, add http://localhost:8080 as a Logout redirect URI, then click Save.

Configure Your OpenID Connect Settings with Spring Cloud Config

Rather than modifying each of your apps for Okta, you can use Spring Cloud Config in JHipster Registry to do it. Open docker-compose/central-server-config/application.yml and add your Okta settings.

The client ID and secret are available on your app settings page. You can find the issuer under API > Authorization Servers.

spring:
  security:
    oauth2:
      client:
        provider:
          oidc:
            issuer-uri: https://okta.okta.com/oauth2/default
        registration:
          oidc:
            client-id: {yourClientId}
            client-secret: {yourClientSecret}

The registry, gateway, blog, and store applications are all configured to read this configuration on startup.

Restart all your containers for this configuration to take effect.

docker-compose restart

Before you can log in, you’ll need to add redirect URIs for JHipster Registry, ensure your user is in a ROLE_ADMIN group and that groups are included in the ID token.

Log in to your Okta dashboard, edit your OIDC app, and add the following Login redirect URI:

• http://localhost:8761/login/oauth2/code/oidc

You’ll also need to add a Logout redirect URI:

• http://localhost:8761

Then, click Save.

Create Groups and Add Them as Claims to the ID Token

JHipster is configured by default to work with two types of users: administrators and users. Keycloak has configured with users and groups automatically, but you need to do some one-time configuration for your Okta organization.

Create a ROLE_ADMIN group (Users > Groups > Add Group) and add your user to it. Navigate to API > Authorization Servers, and click on the default server. Click the Claims tab and Add Claim. Name it groups, and include it in the ID Token. Set the value type to Groups and set the filter to be a Regex of .*. Click Create.

Now when you hit http://localhost:8761 or http://localhost:8080, you’ll be prompted to log in with Okta!

It’s pretty nifty how you can configure your service registry and all your microservices in one place with Spring Cloud Config, don’t you think?!

Configuring Spring Cloud Config with Git

JHipster Registry and its Spring Cloud Config server support two kinds of configuration sources: native and git. Which one is used is determined by a spring.cloud.config.server.composite property. If you look in docker-compose/jhipster-registry.yml, you’ll see that native is enabled and git is commented out.

You can see the default configuration for Git at @jhipster/jhipster-registry/central-config/application.yml. You can learn more about application configuration with Spring Cloud Config in JHipster Registry’s documentation. It includes a section on encrypting configuration values.

What About Kotlin Microservices?

In the first post of this series, I told you why I wrote this post in Java:

I wrote this post with Java because it’s the most popular language in the Java ecosystem. However, Kotlin is on the rise, according to RedMonk’s programming language rankings from January 2019.

Spring has excellent support for Kotlin, and you can choose it as a language on start.spring.io. JHipster has support for Kotlin too with its Kotlin Blueprint! A new release was published a few months ago that allows you to create Kotlin-based JHipster apps with khipster.

If you’d like to see us write more posts using Kotlin, please let us know in the comments!

Learn More about Spring Cloud Config, Java Microservices, and JHipster

I hope you enjoyed learning how to build Java microservice architectures with JHipster and configure them with Spring Cloud Config. You learned how to generate everything from a single JDL file, package your apps in Docker containers, run them with Docker Compose, and authenticate with OIDC using Keycloak and Okta.

You can find all the code shown in this tutorial on GitHub in the jhipster directory.
