Calling Stored Procedures From Spring Data JPA

DZone's Guide to

Calling Stored Procedures From Spring Data JPA

It is a common requirement to JPA connect to stored procedures or database functions. This article looks at how you can do this using Spring Data JPA.

· Java Zone ·
Free Resource

Verify, standardize, and correct the Big 4 + more– name, email, phone and global addresses – try our Data Quality APIs now at Melissa Developer Portal!

Consider the following stored procedure:

   PROCEDURE in_only_test (inParam1 IN VARCHAR2);
   PROCEDURE in_and_out_test (inParam1 IN VARCHAR2, outParam1 OUT VARCHAR2);
END test_pkg;

   PROCEDURE in_only_test(inParam1 IN VARCHAR2) AS
   END in_only_test;

   PROCEDURE in_and_out_test(inParam1 IN VARCHAR2, outParam1 OUT VARCHAR2) AS
      outParam1 := 'Woohoo Im an outparam, and this is my inparam ' || inParam1;
   END in_and_out_test;
END test_pkg;

Here we have two different procedures:

  • in_only_test - takes an input parameter(inParam1), but doesn't return a value.

  • in_and_out_test - takes an input parameter(inParam1), and returns a value(outParam1).

We can then call the stored procedures using the @NamedStoredProcedureQueries annotation:

@Table(name = "MYTABLE")
   @NamedStoredProcedureQuery(name = "in_only_test",
                              procedureName = "test_pkg.in_only_test",
                              parameters = {
                                 @StoredProcedureParameter(mode = ParameterMode.IN, name = "inParam1", type = String.class)
   @NamedStoredProcedureQuery(name = "in_and_out_test",
                              procedureName = "test_pkg.in_and_out_test",
                              parameters = {
                                 @StoredProcedureParameter(mode = ParameterMode.IN, name = "inParam1", type = String.class),
                                 @StoredProcedureParameter(mode = ParameterMode.OUT, name = "outParam1", type = String.class)
public class MyTable implements Serializable {

The key points are:

  •  The Stored Procedure uses the annotation @NamedStoredProcedureQuery and is bound to a JPA table.

  • procedureName – This is the name of the stored procedure.

  • name – This is the name of the StoredProcedure in the JPA ecosystem.

  • Define the IN/OUT parameter using @StoredProcedureParameter.

We then create the Spring Data JPA repository:

 public interface MyTableRepository extends CrudRepository<MyTable, Long> {
    @Procedure(name = "in_only_test")
    void inOnlyTest(@Param("inParam1") String inParam1);

    @Procedure(name = "in_and_out_test")
    String inAndOutTest(@Param("inParam1") String inParam1);

The key points are:

  • @Procedure – the name parameter must match the name on @NamedStoredProcedureQuery

  • @Param – Must match @StoredProcedureParameter name parameter

  • Return types must match - so in_only_test is void, and in_and_out_test returns String

We can then call them:

 // This version shows how a param can go in an be returned from a stored procedure
 String inParam = "Hi Im an inputParam";
 String outParam = myTableRepository.inAndOutTest(inParam);
 Assert.assertEquals(outParam, "Woohoo Im an outparam, and this is my inparam Hi Im an inputParam");

 // This version shows how to call a Stored Procedure which doesnt return any parameter -

Other Tricks

The wide range of possiblities for stored procedures has resulted in a few occasions when the above approach hasnt worked. I've solved these problems by defining a custom repository to call the stored procedures as a native query.
This is done by defining a custom repository:

 public interface MyTableRepositoryCustom {
    void inOnlyTest(String inParam1);

We then make sure our main repository extends this interface:

 public interface MyTableRepository extends CrudRepository<MyTable, Long>, MyTableRepositoryCustom {

We then create our custom repository implementation:

public class MyTableRepositoryImpl implements MyTableRepositoryCustom {

   private EntityManager em;

   public void inOnlyTest(String inParam1) {
      this.em.createNativeQuery("BEGIN in_only_test(:inParam1); END;")
          .setParameter("inParam1", inParam1)


This can then be called in the normal way:

MyTableRepository myTableRepository;

// And to call the method -
