Code Splitting With Vue.js and Webpack

Learn how Vue.js and Webpack can be used to split a single page app into more optimally sized files that can be dynamically loaded.

Anthony Gore user avatar by
Anthony Gore
CORE ·
Feb. 04, 20 · Tutorial
Like (7)
Save
Tweet
Share
13.98K Views

Join the DZone community and get the full member experience.

Join For Free

one possible downside to bundling your single page app with webpack is that you can end up with a really big bundle file, sometimes several megabytes in size!

bundle size

 bundle size


the problem with this is that a user must download the whole file and run it  before  they can see anything on the screen. if the user is on a mobile device with a poor connection this process could take quite some time.

 code splitting  is the idea that a bundle can be fragmented into smaller files allowing the user to only download what code they need, when they need it.

for example, looking at this simple web page, we can identify portions of the app that we don't need on the initial load:

components required for initial page load

 components required for initial page load


what if we delayed loading these parts of the code until after the initial render? it would allow a user to see and interact with the page much quicker.

in this article, i'll show you how vue.js and webpack can be used to split a single page app into more optimally sized files that can be dynamically loaded.

you may also like:  what's new in vue?

async components

the key to code splitting a vue.js app is  async components  . these are components where the component definition (including its template, data, methods, etc) is loaded asynchronously.

let's say you're declaring a component using the  component  api, i.e.  vue.component(name, definition)  . rather than having a definition object as the second argument, async components have a function. this function has two notable features:

  1. it's an  executor  for a promise, i.e. it has a  resolve  argument.
  2. it's a  factory function,  i.e. it returns an object (in this case, the component definition).
javascript





 x



1
vue.component('async-component', (resolve) => {
2
  resolve({
3
    template: '<div>async component</div>',
4
    props: [ 'myprop' ]
5
  });
6
});



async components are the first step for code splitting because we now have a mechanism for abstracting sections of our app's code.

dynamic module loading

we'll also need webpack's help. say we abstract our component definition into an es6 module file:

 asynccomponent.js

javascript





xxxxxxxxxx
1



1
export default {
2
  template: '<div>async component</div>',
3
  props: [ 'myprop' ]
4
}



how could we get our vue.js app to load this? you may be tempted to try something like this:

javascript





xxxxxxxxxx
1



1
import asynccomponent from './asynccomponent.js'`;
2
vue.component('async-component', asynccomponent);



however, this is  static  and is resolved at compile-time. what we need is a way to  dynamically  load this in a running app if we want to get the benefits of code splitting.

import()

currently, it's not possible to dynamically load a module file with javascript. there is, however, a dynamic module loading function  currently under proposal  for ecmascript called  import()  .

webpack already has an implementation for  import()  and treats it as a code split point, putting the requested module into a separate file when the bundle is created (a separate  chunk  , actually, but think of it as a separate file for now).

 import()  takes the file name as an argument and returns a promise. here's how we'd load our above module:

 main.js

javascript





xxxxxxxxxx
1



1
import(/* webpackchunkname: "async-component" */ './asynccomponent.js')
2
  .then((asynccomponent) => {
3
    console.log(asynccomponent.default.template);
4
    // output: <div>async component</div>
5
  });


note: if you're using babel, you'll need to add the  syntax-dynamic-import  plugin so that babel can properly parse this syntax.

now when you build your project you'll notice the module appears in its own file:

asset and chunk name

 asset and chunk name


another note: you can give a dynamically imported module chunk a name so its more easily identifiable; simply add a comment before the file name in the same way i've done in the above example.

dynamic component loading

bring the pieces together now: since  import()  returns a promise, we can use it in conjunction with vue's async component functionality. webpack will bundle  asynccomponent  separately and will dynamically load it into the app via ajax when the app calls it.

 main.js

javascript





xxxxxxxxxx
1
12



1
import vue from 'vue';
2


3
vue.component('async-component', (resolve) => {
4
  import('./asynccomponent.js')
5
    .then((asynccomponent) => {
6
      resolve(asynccomponent.default);
7
    });
8
});
9


10
new vue({
11
  el: '#app'
12
});



 index.html

html





xxxxxxxxxx
1



1
<div id="app">
2
  <p>this part is included in the page load</p>
3
  <async-component></async-component>
4
</div>
5
<script src="bundle.main.js"></script>



on the initial load the page will be rendered as:

html





xxxxxxxxxx
1



1
<div id="app">
2
  <p>this part is included in the page load</p>
3
</div>



when  main.js  runs it will initiate a request for the async component module (this happens automatically because webpack's  import()  implementation includes code that will load the module with ajax!).

if the ajax call is successful and the module is returned, the promise resolves and the component can be rendered, so vue will now re-render the page:

html





xxxxxxxxxx
1



1
<div id="app">
2
  <p>this part is included in the page load</p>
3
  <div>async component</div>
4
</div>



here's a diagram to help you visualize it:

asynccomponent workflow

 asynccomponent workflow


single file components

the idiosyncratic way to achieve code splitting in vue, however, is to use the beloved  single file component  . here's a refactor of the above code using an sfc.

 asynccomponent.vue

html





xxxxxxxxxx
1



1
<template>
2
  <div>async component</div>
3
</template>
4
<script>
5
  export default {
6
    props: [ 'myprop' ]
7
  }
8
</script>



this syntax for importing is even neater:

javascript





xxxxxxxxxx
1



1
new vue({
2
  el: '#app',
3
  components: {
4
    asynccomponent: () => import('./asynccomponent.vue')
5
  }
6
});



code splitting architecture

that's the technical part out of the way. the question, now, is how can you architect an app for code splitting?

the most obvious way is by  page  . for example, say you have two pages in your app, a home page and an about page. these pages can be wrapped inside components,  home.vue  and  about.vue,  and these can be the split points of the app.

but there are other ways, for example, you could split any components that are conditionally shown (tabs, modals, drop-down menus, etc.) or that are below the page fold.

for my next article, i'll explore some different code splitting architectures for a vue.js spa, so stay tuned!
