Dataweave and the Reduce Operator: Part II

DZone's Guide to

Dataweave and the Reduce Operator: Part II

:array to :object transformations let us create maps from which a certain club's name can be easily looked up. However, they can't be done with the map operator.

· Integration Zone
Free Resource

Modernize your application architectures with microservices and APIs with best practices from this free virtual summit series. Brought to you in partnership with CA Technologies.

This post is a continuation of the series in which I am explaining the usage of the reduce operator of DataWeave.

In this post, I will be explaining how to perform :array to :object transformations.

Let's observe the following input payload and output payload required:

Input payload:

[{
"ClubID": "A1234",
"Name": "Barcelona FC",
"Country": "Spain"
}, {
"ClubID": "B1234",
"Name": "Chelsea FC",
"Country": "Spain"
}, {
"ClubID": "C1234",
"Name": "Arsenal FC",
"Country": "Englanda"
}]

Output payload: a map (An implementation of java.util.Map ) containing all the elements of the array with key as club ID and value as club name.

{
"A1234": "Barcelona FC",
"B1234": "Chelsea FC",
"C1234": "Arsenal FC"
}

This is basically an (:array to :object) transformation. This kind of transformation is very often required where we want to represent the data in terms of a unique ID from the payload, so that the data can be extracted conveniently using the ID. After creation of this map (when application/java mime type is used in output), a particular club's name can be easily looked up. For example, payload["A1234"] will give you  "Barcelona FC".

Transformation Details

Accumulator: {} (An empty object is chosen for addition of subsequent elements resulting from the lambda expression)

Aggregate operation: + (concatinate: to create a map by concatinating all elements resulting from the lambda, the aggregation will basically be a concatination of multiple objects).

Dataweave code:

payload reduce ((val, acc = {}) -> acc ++ (( { (val.ClubID) : ( val.Name ) } )))

If, however, the output required is : A map (e.g LinkedHashMap) of all the elements of the array with key as Club ID and value as rest of the club details.

{
"A1234": {
"Name": "Barcelona FC",
"Country": "Spain"
},
"B1234": {
"Name": "Chelsea FC",
"Country": "England"
},
"C1234": {
"Name": "Arsenal FC",
"Country": "England"
}
}

In this case, we just need to modify the lambda expression and keep the rest the same as the above transformation.

Dataweave code:

payload reduce ((val, acc = {}) -> acc ++ (( { (val.ClubID) : ( val - "ClubID" ) } )))

Advantage: Using the above transformation , we can easily look up all of the details of a particular club (when application/java mimetype is used in output). For example, to get all the Club details of the Club with ID "A1234," we can specify it like this: payload["A1234"]. This will result in :

{
"Name": "Barcelona FC",
"Country": "Spain"
}

This type of transformation is very often used in the merging of different payloads with a common Unique ID. I will be illustrating this in a later post.

The Integration Zone is proudly sponsored by CA Technologies. Learn from expert microservices and API presentations at the Modernizing Application Architectures Virtual Summit Series.

Topics:
dataweave ,mulesoft ,reduce ,integration ,tutorial
