In the last few years, Prometheus has gained huge popularity as a tool for monitoring distributed systems. It has a simple yet powerful data model and query language, however, it can often pose a bit of a challenge when it comes to high availability as well as for historical metric data storage. Adding more Prometheus replicas can be used to improve availability, but otherwise, Prometheus does not offer continuous availability.

For example, if one of the Prometheus replicas crashes, there will be a gap in the metric data during the time it takes to failover to another Prometheus instance. Similarly, Prometheus’s local storage is limited in scalability and durability given its single-node architecture. You will have to rely on a remote storage system to solve the long-term data retention problem. This is where the CNCF sandbox project Thanos comes in handy.

Thanos is a set of components that can be composed into a highly available metrics system with unlimited storage capacity on GCP, S3, or other supported object stores, and runs seamlessly on top of existing Prometheus deployments. Thanos allows you to query multiple Prometheus instances at once and merges data for the same metric across multiple instances on the fly to produce a continuous stream of monitoring logs. Even though Thanos is an early-stage project, it is already used in production by companies like Adobe and eBay.

Because YugabyteDB is a cloud native, distributed SQL database, it can easily interoperate with Thanos and many other CNCF projects like Longhorn, OpenEBS, Rook, and Falco.

What’s YugabyteDB? It is an open source, high-performance distributed SQL database built on a scalable and fault-tolerant design inspired by Google Spanner. Yugabyt is PostgreSQL wire compatible.

In this blog post, we’ll show you how to get up and running with Thanos so that it can be used to monitor a YugabyteDB cluster, all running on Google Kubernetes Engine (GKE).

Thanos Architecture

At a high level, Thanos has several key components worth understanding how they work.

  • First, a sidecar is deployed alongside the Prometheus container and interacts with Prometheus.
  • Next, an additional service called Thanos Query is deployed. It is configured to be aware of all instances of the Thanos Sidecar. Instead of querying Prometheus directly, you query the Thanos Query component.
  • Thanos Query communicates with the Thanos Sidecar via gRPC and de-duplicates metrics across all instances of Prometheus when executing a query. Thanos Query also delivers a graphical user interface for querying and administration, plus exposes the Prometheus API.

An illustration of the components is shown below. You can learn more about the Thanos architecture by checking out the documentation.

Thanos arhitecture

Why Thanos and YugabyteDB

Because YugabyteDB already integrates with Prometheus, Thanos can be used as a  resilient monitoring platform for YugabyteDB clusters that can also store the metric data long term. It ensures the continuous availability of YugabyteDB metric data by aggregating the data from multiple Prometheus instances into a single view.

Prerequisites

Here is the environment required for the setup:

Setting Up a Kubernetes Cluster on Google Cloud Platform

Assuming you have a Google Cloud Platform account, the first step is to set up a Kubernetes cluster using GKE.

The usual defaults should be sufficient. For the purposes of this demo, I chose Machine type: n-1-standard-4 (4 vCPU, 15 GB memory).

Selecting nodes

Install YugabyteDB on GKE With Helm

Once your Kubernetes cluster is up and running, log into the shell, and work through the following commands to get a YugabyteDB cluster deployed using Helm 3.

Create a Namespace

Shell





x



1
$ kubectl create namespace yb-demo



Add the Charts Repository

Shell





xxxxxxxxxx
1



1
$ helm repo add yugabytedb https://charts.yugabyte.com



Fetch Updates From the Repository

Shell





xxxxxxxxxx
1



1
$ helm repo update



Install YugabyteDB

We are now ready to install YugabyteDB. In the command below, we’ll be specifying values for a resource constrained environment.

Shell





xxxxxxxxxx
1



1
$ helm install yb-demo yugabytedb/yugabyte \
2
--set resource.master.requests.cpu=0.5, \ resource.master.requests.memory=0.5Gi,\
3
resource.tserver.requests.cpu=0.5, \ resource.tserver.requests.memory=0.5Gi --namespace yb-demo



To check the status of the YugabyteDB cluster, execute the command below:

Shell





xxxxxxxxxx
1



1
$ helm status yb-demo -n yb-demo


Yugabyte cluster deployed

From the screenshot above we can see that the external IP is 35.239.35.3 and that the YSQL port is 5433. You can use this information to connect to YugabyteDB with your favorite database admin tool, like DBeaver, pgAdmin, and TablePlus. For more information, check out the third-party tools documentation.

Congrats! At this point, you have a three-node YugabyteDB cluster running on GKE.

Setting Up the Prometheus Operator

For the purposes of this blog, we will be using the Prometheus Operator deployed via Helm 3 to get Prometheus up and running.

Create a values.yaml File

By default, Helm charts install multiple components that are not required to run Thanos with Prometheus. Also, since our cluster has limited resources, we need to override the default configuration by creating a new values.yaml file and passing this file when we install the Prometheus Operator using Helm.

Shell





xxxxxxxxxx
1



1
$ touch values.yaml
2
$ vim values.yaml



The file’s contents should look like this:

YAML








Install Prometheus

Install the Prometheus Operator via Helm 3 as shown below.

Shell





xxxxxxxxxx
1


1
$ kubectl create namespace prometheus
2
$ helm repo add stable https://kubernetes-charts.storage.googleapis.com
3
$ helm repo update
4
$ helm install prometheus-operator stable/prometheus-operator \
5
 --namespace prometheus \
6
 --values values.yaml



You can verify that the Prometheus Operator is installed using the following command:

Shell





xxxxxxxxxx
1



1
$ kubectl get pods -n prometheus


To avoid the scenario of metrics being unavailable, either permanently or for a short duration of time, we can run a second instance of Prometheus. Each instance of Prometheus will run independent of the other, however each instance will still have the same configuration as set by the Prometheus Operator. You can see this implementation detail in the bolded section below where we specify 2 replicas.

Create a file called prometheus.yaml

Shell





xxxxxxxxxx
1



1
$ touch prometheus.yaml
2
$ vim prometheus.yaml



Add the following configuration:

YAML





xxxxxxxxxx
1
89



1
apiVersion: monitoring.coreos.com/v1
2
kind: Prometheus
3
metadata:
4
  name: prometheus
5
  namespace: prometheus
6
spec:
7
  baseImage: quay.io/prometheus/prometheus
8
  logLevel: info
9
  podMetadata:
10
    annotations:
11
      cluster-autoscaler.kubernetes.io/safe-to-evict: "true"
12
    labels:
13
      app: prometheus
14
  replicas: 2
15
  resources:
16
    limits:
17
      cpu: 100m
18
      memory: 2Gi
19
    requests:
20
      cpu: 100m
21
      memory: 2Gi
22
  retention: 12h
23
  serviceAccountName: prometheus-service-account
24
  serviceMonitorSelector:
25
    matchLabels:
26
      serviceMonitorSelector: prometheus
27
  storage:
28
    volumeClaimTemplate:
29
      apiVersion: v1
30
      kind: PersistentVolumeClaim
31
      metadata:
32
        name: prometheus-pvc
33
      spec:
34
        accessModes:
35
        - ReadWriteOnce
36
        resources:
37
          requests:
38
            storage: 10Gi
39
  version: v2.10.0
40
  securityContext:
41
    fsGroup: 0
42
    runAsNonRoot: false
43
    runAsUser: 0
44
---
45
apiVersion: v1
46
kind: ServiceAccount
47
metadata:
48
  name: "prometheus-service-account"
49
  namespace: "prometheus"
50
---
51
apiVersion: rbac.authorization.k8s.io/v1
52
kind: ClusterRole
53
metadata:
54
  name: "prometheus-cluster-role"
55
rules:
56
- apiGroups:
57
  - ""
58
  resources:
59
  - nodes
60
  - services
61
  - endpoints
62
  - pods
63
  verbs:
64
  - get
65
  - list
66
  - watch
67
- apiGroups:
68
  - ""
69
  resources:
70
  - nodes/metrics
71
  verbs:
72
  - get
73
- nonResourceURLs:
74
  - "/metrics"
75
  verbs:
76
  - get
77
---
78
apiVersion: rbac.authorization.k8s.io/v1
79
kind: ClusterRoleBinding
80
metadata:
81
  name: "prometheus-cluster-role-binding"
82
roleRef:
83
  apiGroup: rbac.authorization.k8s.io
84
  kind: ClusterRole
85
  name: "prometheus-cluster-role"
86
subjects:
87
- kind: ServiceAccount
88
  name: "prometheus-service-account"
89
  namespace: prometheus



Next, apply the promethus.yaml file to the Kubernetes cluster using the following command:

Shell





xxxxxxxxxx
1



1
$ kubectl apply -f prometheus.yaml



You can verify that the Prometheus Operator is installed using the following command:

Shell





xxxxxxxxxx
1



1
$ kubectl get pods -n prometheus



You should see output like that shown below with two Prometheus pods now running:

Two Prometheus pods running

Configuring Prometheus PVC

The Prometheus persistent volume claim (PVC) is used to retain the state of Prometheus and the metrics it captures in the event that it is upgraded or restarted. To verify that the PVC that has been created and bound to a persistent volume run the following command:

Shell





xxxxxxxxxx
1



1
$ kubectl get persistentvolumeclaim --namespace prometheus



You should see output like that shown below:

prometheus pods running

To access the Prometheus UI we need to first run the following command:

Shell





xxxxxxxxxx
1


1
$ kubectl port-forward service/prometheus-operated 9090:9090 --namespace prometheus



Now, go to Web preview in Google Console and select Change port > 9090. You should now see the Prometheus web UI, similar to the one shown below:

prometheus web ui

Configuring Prometheus to Monitor YugabyteDB

The next step is to configure Prometheus to scrape YugabyteDB metrics. Create a file named servicemonitor.yaml with the following content:

YAML





xxxxxxxxxx
1
18



1
apiVersion: monitoring.coreos.com/v1
2
kind: ServiceMonitor
3
metadata:
4
  labels:
5
    serviceMonitorSelector: prometheus
6
  name: prometheus
7
  namespace: prometheus
8
spec:
9
  endpoints:
10
  - interval: 30s
11
    targetPort: 7000
12
    path: /prometheus-metrics
13
  namespaceSelector:
14
    matchNames:
15
    - yb-demo
16
  selector:
17
    matchLabels:
18
      app: "yb-master"



We can now apply the servicemonitor.yaml configuration by running the following command:

Shell








Verify that the configuration has been applied by running the following command:

Shell





xxxxxxxxxx
1


1
$ kubectl get servicemonitor --namespace prometheus



You should see output similar to the one shown below.

prometheus pods running

Now, return to the Prometheus UI to verify that the YugabyteDB metric endpoints are available to Prometheus by going to Status > Targets.

Targets in Prometheus

Setting Up Thanos

Add the following Thanos specific configurations to the prometheus.yaml file under the spec section that starts at line 7:

YAML





xxxxxxxxxx
1
45



1
spec:
2
  baseImage: quay.io/prometheus/prometheus
3
  logLevel: info
4
  podMetadata:
5
    annotations:
6
      cluster-autoscaler.kubernetes.io/safe-to-evict: "true"
7
    labels:
8
      app: prometheus
9
      thanos-store-api: "true"
10
  replicas: 2
11
  thanos:
12
    version: v0.4.0
13
    resources:
14
      limits:
15
        cpu: 10m
16
        memory: 50Mi
17
      requests:
18
        cpu: 10m
19
        memory: 50Mi
20
  resources:
21
    limits:
22
      cpu: 100m
23
      memory: 2Gi
24
    requests:
25
      cpu: 100m
26
      memory: 2Gi
27
  retention: 12h
28
  serviceAccountName: prometheus-service-account
29
  serviceMonitorSelector:
30
    matchLabels:
31
      serviceMonitorSelector: prometheus
32
 externalLabels:
33
    cluster_environment: workshop
34
  storage:
35
    volumeClaimTemplate:
36
      apiVersion: v1
37
      kind: PersistentVolumeClaim
38
      metadata:
39
        name: prometheus-pvc
40
      spec:
41
        accessModes:
42
        - ReadWriteOnce
43
        resources:
44
          requests:
45
            storage: 10Gi



Finally, add the following Thanos deployment configuration to the end of the prometheus.yaml file:

YAML





xxxxxxxxxx
1
57



1
---
2
apiVersion: apps/v1
3
kind: Deployment
4
metadata:
5
  name: thanos-query
6
  namespace: prometheus
7
  labels:
8
    app: thanos-query
9
spec:
10
  replicas: 1
11
  selector:
12
    matchLabels:
13
      app: thanos-query
14
  template:
15
    metadata:
16
      labels:
17
        app: thanos-query
18
    spec:
19
      containers:
20
      - name: thanos-query
21
        image: improbable/thanos:v0.5.0
22
        resources:
23
          limits:
24
            cpu: 50m
25
            memory: 100Mi
26
          requests:
27
            cpu: 50m
28
            memory: 100Mi
29
        args:
30
        - "query"
31
        - "--log.level=debug"
32
        - "--query.replica-label=prometheus_replica"
33
        - "--store.sd-dns-resolver=miekgdns"
34
        - "--store=dnssrv+_grpc._tcp.thanos-store-api.prometheus.svc.cluster.local"
35
        ports:
36
        - name: http
37
          containerPort: 10902
38
        - name: grpc
39
          containerPort: 10901
40
        - name: cluster
41
          containerPort: 10900
42
---
43
apiVersion: v1
44
kind: Service
45
metadata:
46
  name: "thanos-store-api"
47
  namespace: prometheus
48
spec:
49
  type: ClusterIP
50
  clusterIP: None
51
  ports:
52
  - name: grpc
53
    port: 10901
54
    targetPort: grpc
55
  selector:
56
    thanos-store-api: "true"
57





We are now ready to apply the configuration by running the following command:

Shell





xxxxxxxxxx
1



1
$ kubectl apply -f prometheus.yaml



Verify that the pods are running by running the following command:

Shell





xxxxxxxxxx
1



1
$ kubectl get pods --namespace prometheus



Notice that we now have Thanos running.

Connect to the Thanos UI

Connect to Thanos Query by using port forwarding. You can do this by running the following command replacing the thanos-query pod name with your own:

Shell





xxxxxxxxxx
1


1
$ kubectl port-forward pod/thanos-query-7f77667897-lfmlb 10902:10902 --namespace prometheus



We can now access the Thanos Web UI, using the web preview with port 10902.

Thanos Web UI

Verify that Thanos is able to access both Prometheus replicas by clicking on Stores.

Verifying Thanos is able to access Prometheus

The YugabyteDB metric data is now available to Thanos through both Prometheus instances. A few examples are below:

Yugabyte metric data

Thanos metric data

Conclusion

That’s it! You now have a YugabyteDB cluster running on GKE that is being monitored by two Prometheus instances, which not only made highly available but also appear as one, with Thanos. For more information, check out the documentation on YugabyteDB metrics and integration with Prometheus.

Topics:
mongodb, open source, oracle, postgresql, prometheus, sql, yugabytedb

Published at DZone with permission of Jimmy Guerrero . See the original article here.

Opinions expressed by DZone contributors are their own.

{{ parent.title || parent.header.title}}

{{ parent.tldr }}

{{ parent.urlSource.name }}
