If you're using MySQL before 5.7, shifting partitions can be a hassle. Fortunately, you can chain your moves together to shift your partition from one table to another.
Join the DZone community and get the full member experience.Join For Free
RavenDB vs MongoDB: Which is Better? This White Paper compares the two leading NoSQL Document Databases on 9 features to find out which is the best solution for your next project.
In this blog post, we’ll look at how to move a MySQL partition from one table to another, for MySQL versions before 5.7.
Up to version 5.7, MySQL had a limitation that made it impossible to directly exchange partitions between partitioned tables. Now and then, we get questions about how to import an .ibd for use as a partition in a table, as well as how to exchange partitions with another partitioned table. Below is step-by-step instructions on how to move a partition from one table to another.
In this example, one of our customers had two tables with the following structures:
CREATE TABLE live_tbl ( some_id bigint(20) NOT NULL DEFAULT '0', summary_date date NOT NULL, PRIMARY KEY (some_id,summary_date) ) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_unicode_ci /*!50500 PARTITION BY RANGE COLUMNS(summary_date) (PARTITION p201203 VALUES LESS THAN ('2012-04-01') ENGINE = InnoDB, PARTITION p201204 VALUES LESS THAN ('2012-05-01') ENGINE = InnoDB, PARTITION p201205 VALUES LESS THAN ('2012-06-01') ENGINE = InnoDB, PARTITION p201206 VALUES LESS THAN ('2012-07-01') ENGINE = InnoDB, PARTITION future VALUES LESS THAN (MAXVALUE) ENGINE = InnoDB) */;
CREATE TABLE archive_tbl ( some_id bigint(20) NOT NULL DEFAULT '0', summary_date date NOT NULL, PRIMARY KEY (some_id,summary_date) ) ENGINE=InnoDB DEFAULT CHARSET=utf8 COLLATE=utf8_unicode_ci /*!50500 PARTITION BY RANGE COLUMNS(summary_date) (PARTITION p201109 VALUES LESS THAN ('2011-10-01') ENGINE = InnoDB, PARTITION p201110 VALUES LESS THAN ('2011-11-01') ENGINE = InnoDB, PARTITION p201111 VALUES LESS THAN ('2011-12-01') ENGINE = InnoDB, PARTITION p201112 VALUES LESS THAN ('2012-01-01') ENGINE = InnoDB, PARTITION p201201 VALUES LESS THAN ('2012-02-01') ENGINE = InnoDB, PARTITION p201202 VALUES LESS THAN ('2012-03-01') ENGINE = InnoDB, PARTITION future VALUES LESS THAN (MAXVALUE) ENGINE = InnoDB) */;
And their (likely obvious) goal is to move (not copy) the oldest partition from live_tbl to archive_tbl. To achieve this, we came up with the following procedure:
For the following, we assume:
- The datadir is “/var/lib/mysql/”.
- MySQL Server is run by “mysql” Linux user.
- “p201203” is the partition name you want to move.
- “live_tbl is the source table from where you want to move the partition.
- “archive_tbl” is the destination table to where you want to move the partition.
- “dest_tbl_tmp” is the temporary table we will create, using the same CREATE TABLE criteria as in the live_tbl.
- “thedb” is the database name.
1. Copy the .ibd Data File From That Particular Partition
First, make sure you flush any pending changes to disk and that the table is locked, so that binary table copies can be made while the server is running. Keep in mind that the table will be locked while you copy the .ibd file. All reads/writes during that time will be blocked.
Important: Don’t close this session or the lock will be released.
mysql> USE thedb mysql> FLUSH TABLE live_tbl FOR EXPORT;
Open another session and copy the .ibd file to a temporary folder.
shell> cp /var/lib/mysql/thedb/live_tbl#P#<em>p201203</em>.ibd /tmp/dest_tbl_tmp.ibd
After you copy the .ibd file to the temporary folder, go back to the MySQL session and unlock the table so that all reads and writes to that particular table are allowed again.
2. Prepare a Temporary Table to Import the Tablespace
Create a temporary table exactly like the one into which you want to import the partition. Remove the partitioning on it and discard the tablespace so that it is ready for the .ibd import.
mysql> UNLOCK TABLES;
3. Import the Tablespace to the Temporary Table
Place the .ibd file in the appropriate folder, set the correct permissions and ownership and then import the tablespace to the temporary table.
mysql> CREATE TABLE dest_tbl_tmp LIKE archive_tbl; mysql> ALTER TABLE dest_tbl_tmp REMOVE PARTITIONING; mysql> ALTER TABLE dest_tbl_tmp DISCARD TABLESPACE;
4. Swap the Tablespace With the Destination Table’s Partition Tablespace
Partition according to your own schema. (This is just an example using date values. In our case, we have to REORGANIZE PARTITION to accommodate a new LESS THAN range before the MAXVALUE.)
mysql> ALTER TABLE archive_tbl REORGANIZE PARTITION future INTO ( PARTITION <em>p201203</em> VALUES LESS THAN ('2012-04-01'), PARTITION future VALUES LESS THAN (MAXVALUE) ); mysql> ALTER TABLE archive_tbl EXCHANGE PARTITION <em>p201203</em> WITH TABLE dest_tbl_tmp;
5.Check That the Partitions Are Correctly Exchanged Before Dropping the One From the Source Table
SELECT * FROM archive_tbl; SELECT * FROM dest_tbl_tmp; SELECT * FROM live_tbl; ALTER TABLE live_tbl DROP PARTITION <em>p201203</em>;
For more information on why these steps are needed, please check this documentation link for ALTER TABLE … EXCHANGE PARTITION.
In MySQL version 5.7, it is possible to exchange partitions without the unpartitioned table step, as described here.
There are bugs related to the steps in this guide that might be useful to take into consideration:
