How to Run HA MongoDB on Kubernetes

DZone's Guide to

How to Run HA MongoDB on Kubernetes

Learn how to easily run an HA MongoDB container on Kubernetes using Portworx for replication, snapshots, backups, volume resizing, and even encryption.

· Database Zone ·
Free Resource

Discover Tarantool's unique features which include powerful stored procedures, SQL support, smart cache, and the speed of 1 million ACID transactions on a single CPU core!

Thanks to advances in the container ecosystem recently (Kubernetes Stateful Sets, PVCs, etc.), getting started running MongoDB in a container is easy. But running MongoDB in production still requires a lot of forethought and planning. Here are some of the things you need to think about when running MongoDB on Kubernetes in production:

  • How do I automatically deploy a new MongoDB instance in the cloud or on-prem data center?
  • How do I failover a MongoDB pod to another availability zone or rack if my MongoDB instance goes down?
  • How do I resize my MongoDB volume if I am running out of space?
  • How do I snapshot and back up MongoDB for disaster recovery?
  • How do I test upgrades?
  • Can I take my MongoDB deployment and run it in any environment if needed (whether that is AWS, GCE, Azure, VMWare, OpenStack, or bare metal)?

This post will show you how you can run MongoDB in production on Kubernetes so you can easily answer these questions. After reading through the following steps, you will understand how to run an HA MongoDB cluster in production using Kubernetes.

The Essential Steps to Run HA MongoDB on Kubernetes

This post will walk you step-by-step through how to deploy and manage an HA MongoDB cluster on Kubernetes. Before getting into all that detail, let’s summarize.

There are five basic steps to run HA MongoDB:

  1. Chose a multi-cloud container orchestration platform like Kubernetes.
  2. Install multi-cloud container storage solution like Portworx.
  3. For small clusters up to three nodes, turn off MongoDB replication and set px replication to repl: "3".
  4. For larger clusters, keep MongoDB replication on to spread reads out among more hosts but keep px replication to repl: "3" for faster failover.
  5. Optionally, set io_priority: "high" to schedule MongoDB instance on fast storage medium for better IO performance.

Read on for more details about running an HA MongoDB cluster on Kubernetes. Follow this link to launch the MongoDB Kubernetes Katacoda tutorial.

Achieving HA With MongoDB

MongoDB can run in a single node configuration and in a clustered configuration using replica sets (not to be confused with Kubernetes Stateful Sets). A replica set is a group of MongoDB instances that maintain the same dataset. A replica set contains several data bearing nodes and optionally one arbiter node. Of the data bearing nodes, one and only one member is deemed the primary node, while the other nodes are deemed secondary nodes. This is documented here and illustrated by the following:

MongoDB replication architectureFigure 1: Three-node MongoDB replica set

Important: The documentation states the following.

“In this configuration the failover process generally completes within a minute. For instance, it may take 10-30 seconds for the members of a replica set to declare a primary inaccessible. One of the remaining secondaries holds an election to elect itself as a new primary. The election itself may take another 10-30 seconds.”

Using Portworx Volumes to Replicate MongoDB Data

For small MongoDB clusters, Portworx replicated volumes offer a simpler solution to running HA MongoDB on Kubernetes. With Portworx, you can have a single MongoDB instance that leverages a replicated volume provided by Portworx. This is far less complex to manage and configure and requires one-third of the MongoDB Pods and therefore one-third of the CPU and memory because Portworx is already running on your Kubernetes cluster and synchronously replicates data for all of your applications with great efficiency and scale. It also means that there is less network traffic, as you eliminate a hop from master to secondary on your way to writing the data to an underlying disk, which is often network attached itself.

Our configuration will look something like this:

mongodb deployment kubernetes

Figure 2: MongoDB Running on Portworx Replicated Volume

HA MongoDB Config MongoDB Pods Required Volumes Required
Without Portworx replication 3 3
With Portworx replication 1 (1/3 the pods for the same reliability!) 3

Table 1: Resource utilization with Portworx replication versus with MongoDB replica set

In Figure 1, we define a Kubernetes Storage Class object that declaratively defines how we want to handle storage for MongoDB:

kind: StorageClass
apiVersion: storage.k8s.io/v1beta1
  name: px-ha-sc
provisioner: kubernetes.io/portworx-volume
  repl: "3"
  io_profile: "db"
  io_priority: "high"

Along with the repl: "3", io_profile: "db", and io_priority: "high" settings, we can add Kubernetes snapshot schedules and encryption policies directly into this storage class definition. This declarative style of configuration is exactly what modern cloud-native infrastructure is all about. No more snowflakes — you can recreate whole environments from source code, including the automation of your common data management tasks.

With our Storage Class defined, we will create a Read/Write Once Persistent Volume Claim (PVC) and assign a maximum size to our volume of 10GB:

kind: PersistentVolumeClaim
apiVersion: v1
  name: px-mongo-pvc
    volume.beta.kubernetes.io/storage-class: px-ha-sc
    - ReadWriteOnce
    storage: 10Gi

And finally, we will pass in the defined PVC as a parameter for our MongoDB Helm chart:

helm install --name px-mongo --set “persistence.size=1, auth.adminUser=admin, \ auth.adminPassword=password, persistence.existingClaim=px-mongo-pvc” \

Failover MongoDB Container

Now, let’s walk through a failover scenario. In the tutorial, we will simulate a node failure by cordoning the Kubernetes nodes where MongoDB is running and then deleting the MongoDB pod.

Once Kubernetes identifies that the pod needs to be rescheduled, it will work with Portworx’s Kubernetes scheduler extender, STORK, to identify which node is best suited to host the restarted pod. In our small environment, any of the two remaining nodes will do because we have a copy of the data on all three nodes. In reality, you will likely have much larger clusters — and that’s when STORK will benefit you by making sure the pod starts on a node where a copy of the data is locally stored. In the unlikely event that your pod cannot be started on one of those nodes, it will be able to start on any of the cluster nodes and access its data seamlessly through the Portworx storage fabric.

This failover should all happen within a very short time window, which is very similar to the MongoDB replication configuration described above. This failover is depicted in the figure below:

mongodb failover kubernetes

Figure 3: MongoDB failover

MongoDB Operations

So, it seems that just for reliability and high availability alone, it would be worth running MongoDB on Kubernetes and Portworx. But there is a lot more that you can do. So many of the data management operations that are error-prone and time-consuming are now going to be fully automated the same way in any cloud environment. First, we’ll show how volumes can be dynamically expanded without reconfiguring or restarting MongoDB, and then we will show how Snapshots can be easily restored.

Resize MongoDB Volume

Data management tasks like these need to be predictable and automatable when it makes sense to do so. The MongoDB Kubernetes KataCoda tutorial video at this bottom of this post will show how a simple command run from your Kubernetes command line interface, kubectl, can expand the MongoDB volume with zero downtime. Since Portworx volumes are virtual and carved out of your aggregate storage pool on your cluster, we thinly provision the volumes so that the expansion doesn’t immediately require you to add more storage capacity to your cluster. For information about expanding MongoDB storage capacity, view our docs.

Snapshot MongoDB

Snapshots can be scheduled as part of your storage class definition by using the Portworx command line interface (pxctl) or can be taken on demand by using STORK. STORK uses the external-storage project from kubernetes-incubator to add support for snapshots. The Katacoda tutorial will show how to use Stork with this simple YAML file to create a snapshot on demand:

apiVersion: volumesnapshot.external-storage.k8s.io/v1
kind: VolumeSnapshot
  name: px-mongo-snapshot
  namespace: default
  persistentVolumeClaimName: px-mongo-pvc

To learn more about MongoDB snapshot schedules, please refer to our docs page. In the Katacoda tutorial, you will also learn how to start a new MongoDB instance from a snapshot for point-in-time recovery of your data.

Using K8s Stateful Sets to Configure MongoDB Replica Sets

There are cases where running a single MongoDB instance is not going to cut it and we will want to spread our reads to the secondary nodes that are part of our MongoDB replica set. For these scenarios, you can leverage Kubernetes Stateful Sets to handle all the replica set configuration for you and still get all the agility benefits from Portworx by using the storage class for Portworx in the same way as before. There is a Helm chart available for this and it can very easily be used with Portworx as follows:

helm install --name px-mongo --set “persistence.size=1, auth.adminUser=admin, \ auth.adminPassword=password, persistentVolume.storageClass=px-ha-sc” \

Note here that what we are passing into the Helm configuration is the storage class for Portworx and not the PVC. This is because the Stateful Set comes with a template for creating new PVCs as you scale the number of nodes in your set. Kubernetes and Portworx will dynamically create the PVCs for members of your replica set and you will still benefit from the same declarative data management capabilities for all the volumes.

You can choose to turn off Portworx replication in this case but we recommend that you set it to a replication factor of 2 so that when nodes go away and restart the synchronization process is much faster. When one of the MongoDB instances gets restarted, it doesn’t have to rebuild the dataset from scratch because it can start with a copy of the volume that is consistent up to the time of the crash. This helps you reduce the instance outage window, which, in turn, can help you reduce the total size of your cluster while keeping similar uptime guarantees. This, in turn, allows you to save on your total compute, memory, and network utilization.


As we’ve just seen, you can easily run an HA MongoDB container on Kubernetes using Portworx for replication, snapshots, backups, volume resizing, and even encryption. Depending on the size of the cluster, you can either forego MongoDB replication and use Portworx replication for HA, or use both MongoDB replication (for spreading out writes) and Portworx replication (for faster failover). For more information about running HA MongoDB cluster on Kubernetes, watch the video below or explore our Katacoda tutorial for HA MongoDB on Kubernetes.
