How to Set Up an ARK: Survival Evolved Server on Ubuntu OS

DZone 's Guide to

How to Set Up an ARK: Survival Evolved Server on Ubuntu OS

Playing on Cloud 9. If you're familiar with this action-adventure game, check out how to play it with others on this Ubuntu server in the cloud.

Free Resource

ARK: Survival Evolved is an adventure-action genre video game. It is my personal favorite and one of the most played games worldwide. You can play as a single-player or play with your friends on a server in multiplayer mode. There are a few ways to host a multiplayer server: buying a dedicated gaming server, using a third-party service, or creating your own on Alibaba Cloud!

As a gamer and developer, I prefer to have more flexibility when it comes to creating dedicated gaming servers. One major benefit of using a cloud provider, such as Alibaba Cloud, is that I do not have to worry about maintaining or upgrading the hardware in my server. It is also elastic, which means that I can easily scale my resources based on demands.

In this tutorial, I will be using an Ubuntu 16.04 server on Alibaba Cloud Elastic Compute Service (ECS). You could also use other operating systems (OS); however, the steps may differ slightly from this tutorial. To setup your own ARK: Survival Evolved server, follow the tutorial below.

Prerequisites:

  1. You must have an Alibaba Cloud ECS instance activated. If you are a new user, you can get free $300 credit in your Alibaba Cloud account. If you don't know how to setup your instance, you can refer to this tutorial or the quick-start guide.
  2. You must have a copy of the game client from https://www.playark.com to use your ARK: Survival Evolved server.
  3. You should set up your server's hostname.

Minimum Requirements for ARK: Survival Evolved Server:

  1. Ubuntu 16.04 (64 bit) installed on your Alibaba Cloud ECS
  2. 6 GB RAM required (8 GB Recommended)
  3. Fast Internet (you can purchase bandwidth on ECS for internet access)

Setting Up Ubuntu for SteamCMD

After completing the prerequisites, you will need to set up Ubuntu correctly on your ECS instance.

Login as root user with your root username & password via SSH client (e.g. Putty – You can get Putty from https://www.putty.org ). You can also connect directly using the Alibaba Cloud console.

You will have to update & upgrade your Ubuntu to latest packages using the following commands:

# sudo apt-get update && sudo apt-get upgrade


When you see the following message, type 'Y' and press Enter key.

Select “install the package maintainer's version” option and then select OK.

Installing SteamCMD

To install SteamCMD in Ubuntu, follow the steps below:

You will have to open the sources.list in nano editor using the following command:

# sudo nano /etc/apt/sources.list


2. Write the following lines in opened sources.list file as shown below:

deb http://archive.ubuntu.com/ubuntu xenial main universe multiverse
deb http://archive.ubuntu.com/ubuntu xenial-updates main universe multiverse

deb http://archive.ubuntu.com/ubuntu xenial-security main universe multiverse

After you have done writing, press Ctrl + X, type 'Y' and press Enter key. Now, type the following command in your terminal:

# sudo dpkg --add-architecture i386


Now you will need to update your package again using the following command:

# sudo apt-get update


Now type the following command to proceed towards the installation of SteamCMD:

# sudo apt-get install steamcmd


If the above command gives any error, then you may use the following command:

# sudo apt-get -f install steamcmd


After the execution of above command, you will see the following screen. Type 'Y' and press Enter key.

During the installation of SteamCMD, a screen will appear to ask regarding terms and agreements. Select the OK option and then select I AGREE to accept these terms and agreements and select OK.

Adding a New User in Ubuntu

To avoid any security issues, you will have to add another user to your server.

To add user, use the following command:

# adduser ark


Note: ark can be any username of your choice.

  1. Select the password of your choice:
  2. Enter your information like Full Name, Phone Number, etc.
  3. Confirm your information is correct by typing 'Y' and press Enter.
  4. To assign admin rights to user, use the following command:
# adduser ark sudo


Configure Open Files Limit:

Use the following command to open /etc/sysctl.conf file:

# sudo nano /etc/sysctl.conf


Add the following line:

fs.file-max=100000




Press Ctrl + X, write "Y" and press Enter. Then run:

# sysctl -p /etc/sysctl.conf



Use the following command to open /etc/security/limits.conf file:

# sudo nano /etc/security/limits.conf


Update the following lines to the lines below in the opened file and use Ctrl + X, then type 'Y' and press Enter to save the settings:

* softnofile1000000
* hardnofile1000000


Use the following command to open /etc/pam.d/common-session file:

# sudo nano /etc/pam.d/common-session


Add the following line in the opened file as shown in the screenshot below and use Ctrl + X, then type 'Y' and press Enter to save the settings:

# session required pam_limits.so


The above changes are necessary for tuning. Otherwise, the consumption of system resources would be higher.

Installing ARK Server

Now, let's proceed towards the installation of the ARK server.  Firstly, you will have to create a server directory that contains the files of your ARK server. To create a directory, execute the following commands in your terminal:

# mkdir server


The argument server is the name of directory.

Now, let's create a symlink from the location /usr/games/steamcmd to steamcmd in your user's directory. In my case, the username is ark, so mine would be ark user's directory. To do this, use the following command:

# ln -s /usr/games/steamcmd steamcmd


Use the following command to run streamcmd for the installation of the ARK server.

# steamcmd +login anonymous +force_install_dir /home/ark/server +app_update 376030 +quit


Now, you can see that your app has been successfully installed.

Creating a systemd Unit for ARK Server

When the system is restarted or rebooted, we will create a systemd unit file to automatically start the ARK server. For this purpose, we will log in again from our root account or we can simply switch user to root by using the following command:

Command to switch user to root:

# su -

Now to create a new systemd file, execute the following command:

# nano /lib/systemd/system/ark.service


Type the following lines in opened file in nano editor. Use Ctrl + X, type 'Y' and press Enter key to save the file.

[Unit]
Description=ARK Survival Evolved
[Service]
Type=simple
Restart=on-failure
RestartSec=5
StartLimitInterval=60s
StartLimitBurst=3
User=ark
Group=ark
ExecStartPre=/home/ark/steamcmd +login anonymous +force_install_dir /home/ark/server +app_update 376030 +quit
ExecStart=/home/ark/server/ShooterGame/Binaries/Linux/ShooterGameServer TheIsland?listen?SessionName=example -server -log
ExecStop=killall -TERM srcds_linux
[Install]
WantedBy=multi-user.target


Execute the following command to apply your updated changes.

# systemctl daemon-reload


Execute the following commands to enable systemd unit and run/start your ARK server.

# systemctl enable ark.service


# systemctl start ark


Configuring ARK Server

Now, after the successful execution of the commands above, you will need to configure your server by editing settings in GameUserSettings.ini file. You can set up the password for the users and admin in this file. You can also leave the user's password blank when you want your users to connect with your server without any password. The admin password is required while issuing game commands. To do this, you can follow the commands below:

Open the GameUserSettings.ini file.

# nano /home/ark/server/ShooterGame/Saved/Config/LinuxServer/GameUserSettings.ini


2. Now, add the following lines given below in opened nano editor and use Ctrl + X, type 'Y' and press Enter to save the settings.

Setting Up Firewalls for ARK Server

You can protect your ARK server from unauthorized access by setting up firewalls. To do this, follow the following instructions.

If you have activated firewalls, you will have to define a rule in Alibaba Cloud security group for your cloud server to add an exception for port 27015, 7777, 7778, and 27020. By default, these ports are blocked by the firewalls.

Connecting to Your ARK Survival Server

After successfully completing all the previous steps, you should be able to connect to your ARK server. To do this, you just need to perform three steps.

  1. Open your ARK Survival client and click Join ARK.
  2. Use the Server Name Filter and select your server.
  3. Enter the password and click Accept.

Conclusion

If you follow all the steps correctly, you should have a fully functional and dedicated ARK gaming server. If you are interested to know how to host a Minecraft server on Alibaba Cloud, you should definitely check out my Minecraft tutorial!

I will be writing more tutorials on gaming in the near future. If you are interested in writing, feel free to check out the Tech Share program. Be sure to stay up to date with the official Alibaba Cloud Blog!
