Mule 3.9: Separate Mule Info and Error Logs via Log4J2 Configuration

In this article, I will explain how to separate the Mule application info and error logs into a separate log file.

Enrico Rafols Dela Cruz user avatar by
Enrico Rafols Dela Cruz
·
Aug. 31, 18 · Tutorial
Like (1)
Save
Tweet
Share
14.66K Views

Join the DZone community and get the full member experience.

Join For Free

In this article, I will explain how to separate the Mule application info and error logs into a separate log file. For instance, we have a Mule application that runs every 10 seconds to read an input file located on the local path /appdata/temp/input/persons.csv.

Image title

LOG4J2.XML Configuration

To separate the Mule INFO and ERROR logs, we need to define 2 separate RollingRandomAccessFile tags under Appenders in our log4j2.xml file located in src/main/resources. One for INFO logs and another for ERROR logs. We can set the filename of the log file as well as the log category (INFO, ERROR, WARN, DEBUG) that the file should contain which can be configured using ThresholdFilter Level. Lastly, we need to add the two RollingRandonAccessFile configuration to the loggers tag under AsyncRoot.

<?xml version="1.0" encoding="utf-8"?>
<Configuration>
    <Properties>
<Property name="baseDir">${sys:mule.home}${sys:file.separator}logs${sys:file.separator}${sys:hostName}</Property>
<Property name="infoFileName">mule-sample-interface-info</Property>
<Property name="errorFileName">mule-sample-interface-error</Property>
</Properties>


    <Appenders>
<RollingRandomAccessFile name="info_file"
fileName="${baseDir}-${infoFileName}.log" filePattern="${baseDir}-${infoFileName}-%d{yyyy-MM-dd}-%i.log">
<PatternLayout pattern="%d [%t] ${sys:hostName} %-5p %c - %m%n" />
<Policies>
<SizeBasedTriggeringPolicy size="30 MB" />
<TimeBasedTriggeringPolicy interval="1" modulate="true" />
</Policies>
<Filters>
<ThresholdFilter level="INFO" />
</Filters>
</RollingRandomAccessFile>
<RollingRandomAccessFile name="error_file"
fileName="${baseDir}-${errorFileName}.log" filePattern="${baseDir}-${errorFileName}-%d{yyyy-MM-dd}-%i.log">
<PatternLayout pattern="%d [%t] ${sys:hostName} %-5p %c - %m%n" />
<Policies>
<SizeBasedTriggeringPolicy size="30 MB" />
<TimeBasedTriggeringPolicy interval="1"
modulate="true" />
</Policies>
<Filters>
<ThresholdFilter level="ERROR" />
</Filters>
</RollingRandomAccessFile>
</Appenders>

    <Loggers>
<!-- Http Logger shows wire traffic on DEBUG -->
<AsyncLogger name="org.mule.module.http.internal.HttpMessageLogger" level="WARN"/>

<!-- JDBC Logger shows queries and parameters values on DEBUG -->
<AsyncLogger name="com.mulesoft.mule.transport.jdbc" level="WARN"/>

        <!-- CXF is used heavily by Mule for web services -->
        <AsyncLogger name="org.apache.cxf" level="WARN"/>

        <!-- Apache Commons tend to make a lot of noise which can clutter the log-->
        <AsyncLogger name="org.apache" level="WARN"/>

        <!-- Reduce startup noise -->
        <AsyncLogger name="org.springframework.beans.factory" level="WARN"/>

        <!-- Mule classes -->
        <AsyncLogger name="org.mule" level="INFO"/>
        <AsyncLogger name="com.mulesoft" level="INFO"/>

        <!-- Reduce DM verbosity -->
        <AsyncLogger name="org.jetel" level="WARN"/>
        <AsyncLogger name="Tracking" level="WARN"/>

        <AsyncRoot level="INFO">
            <AppenderRef ref="info_file" />
            <AppenderRef ref="error_file" />
        </AsyncRoot>
    </Loggers>
</Configuration>

Mule Application Code

<?xml version="1.0" encoding="UTF-8"?>

<mule xmlns:validation="http://www.mulesoft.org/schema/mule/validation" xmlns:scripting="http://www.mulesoft.org/schema/mule/scripting"
xmlns:file="http://www.mulesoft.org/schema/mule/file"
xmlns="http://www.mulesoft.org/schema/mule/core" xmlns:doc="http://www.mulesoft.org/schema/mule/documentation"
xmlns:spring="http://www.springframework.org/schema/beans"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://www.mulesoft.org/schema/mule/scripting http://www.mulesoft.org/schema/mule/scripting/current/mule-scripting.xsd
http://www.mulesoft.org/schema/mule/file http://www.mulesoft.org/schema/mule/file/current/mule-file.xsd
http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans-current.xsd
http://www.mulesoft.org/schema/mule/core http://www.mulesoft.org/schema/mule/core/current/mule.xsd
http://www.mulesoft.org/schema/mule/validation http://www.mulesoft.org/schema/mule/validation/current/mule-validation.xsd">
    <file:connector name="FILE_INBOUND_CONNECTOR_CONFIG" autoDelete="false" streaming="true" validateConnections="true"   doc:name="File" fileAge="30000"/>
    <validation:config name="Validation_Configuration" doc:name="Validation Configuration"/>
    <flow name="mule-sample-interfaceFlow">
        <poll doc:name="Run every 10 seconds">
            <fixed-frequency-scheduler frequency="10000"/>
            <logger message="#['\n'+message.rootId] - Start Of The Process" level="INFO" doc:name="Logger Start"/>
        </poll>
        <message-properties-transformer scope="invocation" doc:name="Message Properties Set Path and Filename Variable">
            <add-message-property key="targetPath" value="/appdata/temp/input/"/>
            <add-message-property key="targetFilename" value="persons"/>
        </message-properties-transformer>
               <scripting:transformer doc:name="Groovy Read File">
            <scripting:script engine="Groovy"><![CDATA[def filenameWildcard = flowVars.targetFilename + "*"
def endpointBuilder = muleContext.endpointFactory.getEndpointBuilder('file://'+flowVars.targetPath+'?connector=FILE_INBOUND_CONNECTOR_CONFIG')
endpointBuilder.addMessageProcessor(new org.mule.routing.MessageFilter(new org.mule.transport.file.filters.FilenameWildcardFilter(filenameWildcard)))
def inboundEndpoint = endpointBuilder.buildInboundEndpoint()
inboundEndpoint.request(60000)]]></scripting:script>
        </scripting:transformer>
        <validation:is-not-null config-ref="Validation_Configuration" message="No Input File on the source path." value="#[payload]" doc:name="Validation"/>
        <byte-array-to-string-transformer doc:name="Byte Array to String"/>
        <logger message="#['\nContent:\n'+payload]" level="INFO" doc:name="Logger File Content"/>
        <logger message="#['\n'+message.rootId] - End Of The Process" level="INFO" doc:name="Logger End"/>
    </flow>
</mule>

Test Result

The Mule Application was deployed and ran as expected.

Image title

Image title

2 log files were generated after the deployment of the Mule application.

Image title

The mule-sample-interface-info only contains info logs of the Mule application.

Image title

The mule-sample-interface-error has no error logs since there's no error occurring during the Mule application execution.

Image title

Removing the input file should cause an error and that will be logged in the mule-sample-interface-error file.

Image title

Image title

Image title
