1.0 Overview (The Case for Flow Variables)

I came across an exam question in Mule pertaining to the relationship of flow variables and batch jobs. You need to pay attention to questions like this if you are to pass the Mule certification exams. When I try to Google the answer, there is no article that has been written about it. Not in the Mule documentation, not anywhere on the web. So, read on and get an understanding of how each type of Mule variables behaves in the context of a batch job (Mule construct).

The question is something like this: given the following batch job,

Figure 1.0a.

And given the following input payload, what would flowVar.aCounter be at the end of On Complete?

[
  {
    "ID":"001",
    "OriginNum":"1"
  },
  {
    "ID":"002",
    "OriginNum":"2"
  }
]

If at the beginning of the batch flowVars.aCounter starts with one (1), then theoretically, flowVars.aCounter would have a total of 5 at the end of “On Complete” phase of the batch job, right? Wrong! That notion is totally wrong! The following is the XML Mule configuration of the batch job. This is how your thinking process would be: the payload has an array of two elements, which means one instance of the batch job would run and both batch_step_1 and batch_step_2 would be executed two times (one time for each record).

    <batch:job name="batchjob_withnoInput">
        <batch:input>
            <logger message="Batch Job Input: #[payload]" level="INFO" doc:name="Logger"/>
            <set-variable variableName="aCounter" value="#[1]" doc:name="flowVars.aCounter = 0"/>
        </batch:input>
        <batch:process-records>
            <batch:step name="Batch_Step_1">
                <scripting:component doc:name="flowVars.aCounter add 1">
                    <scripting:script engine="Groovy"><![CDATA[flowVars.aCounter = flowVars.aCounter + 1]]></scripting:script>
                </scripting:component>
                <logger message="Batch Step 1 flowVars.aCounter: #[flowVars.aCounter]" level="INFO" doc:name="Logger"/>
            </batch:step>
            <batch:step name="Batch_Step_2" >
                <scripting:component doc:name="flowVars.aCounter add 1">
                    <scripting:script engine="Groovy"><![CDATA[flowVars.aCounter = flowVars.aCounter + 1]]></scripting:script>
                </scripting:component>
                <logger message="Batch Step 2 flowVars.aCounter: #[flowVars.aCounter]" level="INFO" doc:name="Logger"/>
            </batch:step>
        </batch:process-records>
        <batch:on-complete>
            <logger message="oncomplete flowVars.aCounter : #[flowVars.aCounter]" level="INFO" doc:name="Logger"/>
        </batch:on-complete>
    </batch:job>

A batch job is not a flow but it can reference and execute a flow. Each step in the batch job executes as an independant flow, so the scope of the flow variable is really constrained to the individual steps, after execution leaves a batch step the flowVars is gone.

2.0 The Real Answer

The following is the logs collected if you run the batch job in Figure 1.0a:

[[batchplayground].HTTP_Listener_Configuration.worker.01] com.mulesoft.module.batch.engine.DefaultBatchEngine: Starting input phase
[[batchplayground].HTTP_Listener_Configuration.worker.01] org.mule.api.processor.LoggerMessageProcessor: Batch Job Input: [{OriginNum=1, ID=001}]
[[batchplayground].HTTP_Listener_Configuration.worker.01] com.mulesoft.module.batch.engine.DefaultBatchEngine: Input phase completed
[[batchplayground].HTTP_Listener_Configuration.worker.01] com.mulesoft.module.batch.engine.queue.BatchQueueLoader: Starting loading phase for instance '67b3a840-974e-11e7-956a-b62d20524153' of job 'batchjob_withnoInput'
[[batchplayground].HTTP_Listener_Configuration.worker.01] com.mulesoft.module.batch.engine.queue.BatchQueueLoader: Finished loading phase for instance 67b3a840-974e-11e7-956a-b62d20524153 of job batchjob_withnoInput. 1 records were loaded
[[batchplayground].HTTP_Listener_Configuration.worker.01] com.mulesoft.module.batch.engine.DefaultBatchEngine: Started execution of instance '67b3a840-974e-11e7-956a-b62d20524153' of job 'batchjob_withnoInput'
[batch-job-batchjob_withnoInput-work-manager.01] org.mule.api.processor.LoggerMessageProcessor: Batch Step 1 flowVars.aCounter: 2
[batch-job-batchjob_withnoInput-work-manager.01] com.mulesoft.module.batch.DefaultBatchStep: Step Batch_Step_1 finished processing all records for instance 67b3a840-974e-11e7-956a-b62d20524153 of job batchjob_withnoInput
[batch-job-batchjob_withnoInput-work-manager.03] org.mule.api.processor.LoggerMessageProcessor: Batch Step 2 flowVars.aCounter: 2
[batch-job-batchjob_withnoInput-work-manager.03] com.mulesoft.module.batch.engine.DefaultBatchEngine: Starting execution of onComplete phase for instance 67b3a840-974e-11e7-956a-b62d20524153 of job batchjob_withnoInput
[batch-job-batchjob_withnoInput-work-manager.03] org.mule.api.processor.LoggerMessageProcessor: oncomplete flowVars.aCounter : 1
[batch-job-batchjob_withnoInput-work-manager.03] com.mulesoft.module.batch.engine.DefaultBatchEngine: Finished execution of onComplete phase for instance 67b3a840-974e-11e7-956a-b62d20524153 of job batchjob_withnoInput
[batch-job-batchjob_withnoInput-work-manager.03] com.mulesoft.module.batch.engine.DefaultBatchEngine: Finished execution for instance '67b3a840-974e-11e7-956a-b62d20524153' of job 'batchjob_withnoInput'.
                                                                                                      Total Records processed: 1. Successful records: 1. Failed Records: 0
[batch-job-batchjob_withnoInput-work-manager.03] com.mulesoft.module.batch.engine.DefaultBatchEngine:
[batch-job-batchjob_withnoInput-work-manager.03] com.mulesoft.module.batch.DefaultBatchStep: Step Batch_Step_2 finished processing all records for instance 67b3a840-974e-11e7-956a-b62d20524153 of job batchjob_withnoInput

So if you ever get a question like this during any of your MuleSoft exams, and if the question asks you to state the value of a flow variable at the “On Complete” phase, then the answer is 1 if the flow variable was initialized with 1 (or zero if the flow variable’s initialized value is zero). From the logs, you can see that the state of the flow variable flowVars.aCounter is not persisted when it traverses through the batch steps, but the state of the flow variable when it was first initialized is being carried through to each phase and batch step. In short, the flow variable flowVars.aCounter will always start with 1 in each batch step, regardless if the batch step tries to increment its value. And finally, the “On Complete” phase still shows a flowVars.aCounter with the value of 1, which was what the variable was initialized with at the Input phase.

3.0 The Case for Record Variables

Figure 3.0a.

Record variable is definitely inaccessible in the On Complete phase. Users cannot declare record variable in the input phase, the reason behind this is that records only exist after the implicit load and dispatch phase. Figure 3.0a summarizes the availability of record variables, but they are a bit fuzzy about the actual scope/lifetime of the record variable.

To illustrate to you the life time of the record variable I have created the following flow. You can only start setting a record variable in a batch step, I have done it in Batch_step_1 (as per figure 3.0b).

Figure 3.0b.

Notice that I have used the expression message processor instead of the Groovy message processor to set the recordVars.rACounter, the reason being is that the Groovy shell in Mule does not recognize recordVars (take note, so that you don't have to spend hours trying to figure out why).

You cannot access a record variable at the On Complete phase else it will give you a runtime exception. The following is the full batch job XML to show how to correctly use record variables.

    <batch:job name="batchjob_withnoInput">
        <batch:input>
            <logger message="Batch Job Input: #[payload]" level="INFO" doc:name="Logger"/>
            <set-variable variableName="aCounter" value="#[1]" doc:name="flowVars.aCounter = 1"/>
        </batch:input>
        <batch:process-records>
            <batch:step name="Batch_Step_1">
                <batch:set-record-variable variableName="rACounter" value="#[1]" doc:name="recordVars.rACounter = 1"/>
                <scripting:component doc:name="flowVars.aCounter add 1">
                    <scripting:script engine="Groovy"><![CDATA[flowVars.aCounter = flowVars.aCounter + 1]]></scripting:script>
                </scripting:component>
                <expression-component doc:name="recordVars.rACounter add 1"><![CDATA[recordVars.rACounter = recordVars.rACounter + 1]]></expression-component>
                <logger message="Batch Step 1 flowVars.aCounter: #[flowVars.aCounter + &quot;\n&quot;] Batch Step 1 recordVars.rACounter: #[recordVars.rACounter + &quot;\n&quot;]" level="INFO" doc:name="Logger"/>
            </batch:step>
            <batch:step name="Batch_Step_2" >
                <scripting:component doc:name="flowVars.aCounter add 1">
                    <scripting:script engine="Groovy"><![CDATA[flowVars.aCounter = flowVars.aCounter + 1]]></scripting:script>
                </scripting:component>
                <expression-component doc:name="recordVars.rACounter add 1"><![CDATA[recordVars.rACounter = recordVars.rACounter + 1]]></expression-component>
                <logger message="Batch Step 2 flowVars.aCounter: #[flowVars.aCounter + &quot;\n&quot;] Batch Step 2 recordVars.rACounter: #[recordVars.rACounter + &quot;\n&quot;]" level="INFO" doc:name="Logger"/>
            </batch:step>
        </batch:process-records>
        <batch:on-complete>
            <logger message="oncomplete flowVars.aCounter : #[flowVars.aCounter + &quot;\n&quot;]" level="INFO" doc:name="Logger"/>
        </batch:on-complete>
    </batch:job>

Listing 3.0a.

The code snippet at listing 3.0a will generate the following output:

[[batchplayground].HTTP_Listener_Configuration.worker.01] com.mulesoft.module.batch.engine.DefaultBatchEngine: Created instance a3e26950-9758-11e7-956a-b62d20524153 for batch job batchjob_withnoInput
[[batchplayground].HTTP_Listener_Configuration.worker.01] com.mulesoft.module.batch.engine.DefaultBatchEngine: Starting input phase
[[batchplayground].HTTP_Listener_Configuration.worker.01] org.mule.api.processor.LoggerMessageProcessor: Batch Job Input: [{OriginNum=1, ID=001}]
[[batchplayground].HTTP_Listener_Configuration.worker.01] com.mulesoft.module.batch.engine.DefaultBatchEngine: Input phase completed
[[batchplayground].HTTP_Listener_Configuration.worker.01] com.mulesoft.module.batch.engine.queue.BatchQueueLoader: Starting loading phase for instance 'a3e26950-9758-11e7-956a-b62d20524153' of job 'batchjob_withnoInput'
[[batchplayground].HTTP_Listener_Configuration.worker.01] com.mulesoft.module.batch.engine.queue.BatchQueueLoader: Finished loading phase for instance a3e26950-9758-11e7-956a-b62d20524153 of job batchjob_withnoInput. 1 records were loaded
[[batchplayground].HTTP_Listener_Configuration.worker.01] com.mulesoft.module.batch.engine.DefaultBatchEngine: Started execution of instance 'a3e26950-9758-11e7-956a-b62d20524153' of job 'batchjob_withnoInput'
[batch-job-batchjob_withnoInput-work-manager.02] org.mule.api.processor.LoggerMessageProcessor: Batch Step 1 flowVars.aCounter: 2
                                                                                                Batch Step 1 recordVars.rACounter: 2
[batch-job-batchjob_withnoInput-work-manager.02] com.mulesoft.module.batch.DefaultBatchStep: Step Batch_Step_1 finished processing all records for instance a3e26950-9758-11e7-956a-b62d20524153 of job batchjob_withnoInput
[batch-job-batchjob_withnoInput-work-manager.01] org.mule.api.processor.LoggerMessageProcessor: Batch Step 2 flowVars.aCounter: 2
                                                                                                Batch Step 2 recordVars.rACounter: 3
[batch-job-batchjob_withnoInput-work-manager.01] com.mulesoft.module.batch.engine.DefaultBatchEngine: Starting execution of onComplete phase for instance a3e26950-9758-11e7-956a-b62d20524153 of job batchjob_withnoInput
[batch-job-batchjob_withnoInput-work-manager.01] org.mule.api.processor.LoggerMessageProcessor: oncomplete flowVars.aCounter : 1
[batch-job-batchjob_withnoInput-work-manager.01] com.mulesoft.module.batch.engine.DefaultBatchEngine: Finished execution of onComplete phase for instance a3e26950-9758-11e7-956a-b62d20524153 of job batchjob_withnoInput
        _withnoInput-work-manager.01] com.mulesoft.module.batch.engine.DefaultBatchEngine: Finished execution for instance 'a3e26950-9758-11e7-956a-b62d20524153' of job 'batchjob_withnoInput'. Total Records processed: 1. Successful records: 1. Failed Records: 0
[batch-job-batchjob_withnoInput-work-manager.01] com.mulesoft.module.batch.engine.DefaultBatchEngine:
[batch-job-batchjob_withnoInput-work-manager.01] com.mulesoft.module.batch.DefaultBatchStep: Step Batch_Step_2 finished processing all records for instance a3e26950-9758-11e7-956a-b62d20524153 of job batchjob_withnoInput

4.0 How About Session Variables in Batch Jobs?

If you observe both the values of “flowVars.aCounter” and the “recordVars.rACounter,” you will see that only the record variable can transfer its state across batch steps, but once it is outside of the batch process area (where all the batch step is defined), it is no longer accessible by the execution context.

Figure 4.0a.

Figure 4.0a shows that I have included the session variable with the fully qualified name of “sessionVars.SaCounter.” Its behavior is the same as a flow variable. In a batch job, the notion of the context of scope for both flow variable and session variables does not work as if they are in a flow.

If you observe the log file closely, the clues to why it is behaving that way are really obvious:

Figure 4.0b.

From the logs, you get to know that there are essentially three threads running. The setting of the flow and session variable happens in a thread named “[batchplayground].HTTP_Listener_Configuration.worker.01.” This is the receiver thread from the flow “batchplaygroundFlow,” because this flow has an inbound endpoint of HTTP, it would automatically be a flow with a synchronous processing strategy. The other two threads, “batch-job-batchjob_withnoInput-work-manager.01” and “batch-job-batchjob_withnoInput-work-manager.02,” are disparate threads allocated by the Mule runtime to run both batch step 1 and batch step 2. In this multithreading environment, both flow variable and session variables are not synchronized; only the record variables are synchronized.

5.0 Conclusion

When using batch jobs, it always runs asynchronously and it always executes its batch steps in multithreading mode. Remember, batch jobs are built for high throughput processing. If you want the behaviors of your batch job to be predictable, always use only record variables because they are synchronized between each batch steps.
