Tutorial: Blinky With the NXP LPC845-BRK Board

Learn how you can create your own blinky application using the MCUXpresso.

By
Erich Styger user avatar
Erich Styger
·
Feb. 14, 19 · Tutorial
Likes (3)
Comment
Save
Tweet
Share
10.3K Views

Join the DZone community and get the full member experience.

Join For Free

The NXP LPC845-BRK board is a sub-$6 breadboard-friendly development board with an ARM Cortex-M0+ on it. This tutorial is about developing a ‘blinky’ on it using MCUXpresso.

Binky on NXP LPC845-BRK Board

Binky on NXP LPC845-BRK Board

This tutorial goes through the tool installation and basics of implementing a blinky with MCUXpresso. It should give you a starting point for your own application on that board.

Installation

For this tutorial, we need:

  • NXP LPC845-BRK board (see Unboxing the NXP LPC845-BRK Board)
  • NXP MCUXpresso IDE (now V10.3.0, see New NXP MCUXpresso IDE V10.3.0 Release)
  • NXP MCUXpresso SDK for the LPC845

Download the NXP MCUXpresso IDE from http://www.nxp.com/mcuxpresso/ide and install it with the default options.

Go to http://mcuxpresso.nxp.com/ and select the LPC845 SDK (there is no SDK for the board available yet). I recommend that you configure the SDK with all available software components.

SDK for LPC845

SDK for LPC845

Start the IDE (you can use the default workspace) and import the SDK (zip file) with drag and drop into the ‘Installed SDKs’ view:

SDK for LPC845

SDK for LPC845

New Project

Create a new project:

Create New Project

Select the LPC845 and press Next:

LPC845

LPC845

Select the LPC845M301JBD48 for the Device package. Because we are going to use GPIO for the LEDs on the board, make sure that this driver is included. Then, press Finish:

SDK Wizard

SDK Wizard

With this, we have a blinky project:

Blinky Project Created

Blinky Project Created

LED Pins

Next, we configure the pins for the LED on the board. From the schematics, we get this information:

  • Green on PIO1_0
  • Blue on PIO1_1
  • Red on PIO1_2

GPIO RGB LED Pins on LPC845-BRK

GPIO RGB LED Pins on LPC845-BRK

The pins need to be muxed as GPIO output pins. Select the project and open the Pins tool:

Open Pins Tool

Open Pins Tool

Configure PIO1_0, PIO1_1, and PIO1_2 as GPIO pins. The easiest way is to double-click on the GPIO cell entries:

Configured LED GPIO Pins

Configured LED GPIO Pins

Add Identifiers to the pins, for example, LEDG, LEDB, and LEDR. We will use #defines created for the pins later in our code:

Identifiers for the Pins

Identifiers for the Pins

That’s it. Update the project sources with our changes:

Update Project

Update Project

It asks to confirm the changes. Press OK.

Updating Project

Updating Project

Switch back to the Develop Perspective (if not done automatically).

Develop Perspective

Develop Perspective

All the settings are stored in a .mex file. I can double-click on that file later to open the settings again:

MEX File

MEX File

Ungating Clocks

For the LEDs, we are using the GPIO port 1, for which we have to ungate the clocks first; otherwise, the GPIO pins won’t work.

Add the following to the includes:

#include "fsl_gpio.h"


Add the following line to ungate the clocks:

GPIO_PortInit(GPIO, 1);
/* ungate the clocks for GPIO_1 */


Ungating GPIO 1

Ungating GPIO 1

Configuring GPIO Pins

Next, we have to configure the GPIO pins as output pins with an initial HIGH (1) value. Add the following configuration to your code:

/* configuration for LOW active GPIO output pin */
static const gpio_pin_config_t configOutput = {
 kGPIO_DigitalOutput,  /* use as output pin */
 1,  /* initial value */
};


And initialize all the pins with that configuration:

/* initialize pins as output pins */
GPIO_PinInit(BOARD_INITPINS_LEDR_GPIO, BOARD_INITPINS_LEDR_PORT, BOARD_INITPINS_LEDR_PIN, &configOutput);
GPIO_PinInit(BOARD_INITPINS_LEDG_GPIO, BOARD_INITPINS_LEDG_PORT, BOARD_INITPINS_LEDG_PIN, &configOutput);
GPIO_PinInit(BOARD_INITPINS_LEDB_GPIO, BOARD_INITPINS_LEDB_PORT, BOARD_INITPINS_LEDB_PIN, &configOutput);


Notice that I’m using the Identifier (LEDG, LEDB, and LEDR) in the macros I defined previously in the Pins tool.

GPIO Init Pins

GPIO Init Pins

Delay

To slow down the LED blinky, add a delay function to the code:

static void delay(void) {
  for(int i=0;i<100000;i++) {
    __asm("nop");
  }
}


Delay

Delay

Blinky Code

Finally, add some blinky code to the application. The code below will turn on and off each led with a delay in between:

for(;;) { /* blinky, blinky, blinky! */
  /* red */
  GPIO_PortClear(BOARD_INITPINS_LEDR_GPIO, BOARD_INITPINS_LEDR_PORT, 1<<BOARD_INITPINS_LEDR_PIN); /* turn on */
  delay();
  GPIO_PortSet(BOARD_INITPINS_LEDR_GPIO, BOARD_INITPINS_LEDR_PORT, 1<<BOARD_INITPINS_LEDR_PIN);  /* turn off */

  /* green */
  GPIO_PortClear(BOARD_INITPINS_LEDG_GPIO, BOARD_INITPINS_LEDG_PORT, 1<<BOARD_INITPINS_LEDG_PIN); /* turn on */
  delay();
  GPIO_PortSet(BOARD_INITPINS_LEDG_GPIO, BOARD_INITPINS_LEDG_PORT, 1<<BOARD_INITPINS_LEDG_PIN);  /* turn off */

  /* blue */
  GPIO_PortClear(BOARD_INITPINS_LEDB_GPIO, BOARD_INITPINS_LEDB_PORT, 1<<BOARD_INITPINS_LEDB_PIN); /* turn on */
  delay();
  GPIO_PortSet(BOARD_INITPINS_LEDB_GPIO, BOARD_INITPINS_LEDB_PORT, 1<<BOARD_INITPINS_LEDB_PIN);  /* turn off */
}


Blinky Code

Blinky Code

Build and Debug

Time to build and then debug it with the board connected:

Build and Debug

Build and Debug

With the board connected to the host, the IDE automatically recognized the board:

Probes discovered

Probes discovered

Press OK and the debugger is loading the code:

Debugging the Board

Debugging the Board

Run it, and enjoy the blinky-blinky-blinky

Binky on NXP LPC845-BRK Board

Binky on NXP LPC845-BRK Board

Summary

Although there is no dedicated SDK for the LPC845-BRK board yet, it is very simple and easy to create a blinky application for it. Using the NXP MCUXpresso SDK, IDE, and Configuration tools, it only needs a few lines in the application code to use the LEDs or any GPIO pins on the board.

List of articles about the LPC845-BRK board:

  • Unboxing the NXP LPC845-BRK Board
  • Tutorial: Using external Debug Probes with NXP LPC845-BRK Board
  • Tutorial: Transforming the NXP LPC845-BRK into a CMSIS-DAP Debug Probe
  • Tutorial: Blinky with the NXP LPC845-BRK Board

Happy Transforming!

Helpful Links

  • LPC845-BRK Board web page
  • User Guide for LPC845-BRK Board
  • NXP LPC845
  • MCUXpresso SDK
  • MCUXpresso IDE
  • MCUXpresso IDE 10.3.0: New NXP MCUXpresso IDE V10.3.0 Release
  • List of community projects
