Tutorial: Using Runtime Statistics with Amazon FreeRTOS V10

Want to learn more about how to use the runtime statistics feature on your Amazon FreeRTOS V10? Check out this tutorial to learn more.

By
Erich Styger user avatar
Erich Styger
·
Aug. 13, 18 · Tutorial
Likes (2)
Comment
Save
Tweet
Share
9.0K Views

Join the DZone community and get the full member experience.

Join For Free

FreeRTOS includes a nice feature that provides information about how much time every task is spent running on the system:

Image title

FreeRTOS Runtime Information

This tutorial explains how to use the FreeRTOS runtime statistics feature and how it can be turned on and used.

Software and Tools

In this article, I’m using the following:

  • MCUXpresso IDE 10.2.1
  • FRDM-K64F board
  • Amazon FreeRTOS V10.0.1 from MCUXpresso SDK 2.4.0

But, of course, any other tools/IDEs or FreeRTOS version could be used (FreeRTOS should be at least version 9.0.0 or later).

Using the steps below, it is possible to update an existing project with the FreeRTOS task runtime information gathering.

How it Works

FreeRTOS uses a user/application specific timer to measure the task execution time. For this, every task descriptor inside the RTOS has a cumulative counter, which adds the timer ticks spent for that task. The current timer tick count is memorized when a task gets the CPU time and, again, when the RTOS switches out that task. That delta time, which corresponds the task execution time, is then added to the task execution time counter.

I need to configure the FreeRTOS with the following macro set to 1 to perform runtime analysis:

#define configGENERATE_RUN_TIME_STATS 1


Additionally, the following two macros need to be provided:

portCONFIGURE_TIMER_FOR_RUN_TIME_STATS()
portGET_RUN_TIME_COUNTER_VALUE()


These are used by the RTOS to configure the runtime counter timer and to get the timer value.

The runtime counter is stored as a 32bit value inside each task descriptor, which means that my RAM requirements for the system will go up four bytes for each task:

Image title

ulRunTimeCounter in FreeRTOS TCB

Assuming a 10 kHz (0.1 ms) counter period, this means that the variable will overflow after about five days.

Additionally, the RTOS maintains to extra global variables in task.c:

#if ( configGENERATE_RUN_TIME_STATS == 1 )
    PRIVILEGED_DATA static uint32_t ulTaskSwitchedInTime = 0UL; /*< Holds the value of a timer/counter the last time a task was switched in. */
    PRIVILEGED_DATA static uint32_t ulTotalRunTime = 0UL;       /*< Holds the total amount of execution time as defined by the run time counter clock. */
#endif


The first variable is used to remember the time when a task is switched in, and the second one is the total runtime of the system. This is what happens at task switch time (Kernel function vTaskSwitchContext):

/* Add the amount of time the task has been running to the
accumulated time so far.  The time the task started running was
stored in ulTaskSwitchedInTime.  Note that there is no overflow
protection here so count values are only valid until the timer
overflows.  The guard against negative values is to protect
against suspect run time stat counter implementations - which
are provided by the application, not the kernel. */
if( ulTotalRunTime > ulTaskSwitchedInTime )
{
    pxCurrentTCB->ulRunTimeCounter += ( ulTotalRunTime - ulTaskSwitchedInTime );
}
else
{
    mtCOVERAGE_TEST_MARKER();
}
ulTaskSwitchedInTime = ulTotalRunTime;


Typically, a periodic timer interrupt is used to count the execution time, and that timer frequency should be about 10x the time of the tick interrupt frequency (say ‘hello’ to “Nyquist-Shannon” sampling theorem ). This means that if my tick interrupt is 1 kHz, my runtime analysis timer frequency should be 10 kHz.

The runtime statistics usually are presented with two numbers:

  • An absolute (time) number
  • A percentage

Below is a textual task list with the runtime information to the right:

TCB Static Handle     Name         State    Prio    Stack Beg  Stack End  Size    Stack Top            Unused  Runtime
1   no (0) 0x20000450 Shell        Running  (1,1)   0x20000440 0x20000060  1000 B 0x200001EC (  600 B)   392 B 0x00000000 ( <1%)
7   no (0) 0x20001E68 IDLE         Ready    (0,0)   0x20001E58 0x20001CD0   400 B 0x20001DFC (   96 B)   312 B 0x00007C35 ( 91%)
2   no (0) 0x20000740 Refl         Blocked  (4,4)   0x20000730 0x20000510   552 B 0x200006BC (  120 B)   384 B 0x00000C6E (  9%)
6   no (0) 0x20001C68 Main         Blocked  (1,1)   0x20001C58 0x20001A08   600 B 0x20001BDC (  128 B)   356 B 0x00000000 ( <1%)
3   no (0) 0x20001378 Radio        Blocked  (3,3)   0x20001368 0x20000F88  1000 B 0x200012F4 (  120 B)   680 B 0x00000001 ( <1%)
4   no (0) 0x20001658 Sumo         Blocked  (2,2)   0x20001648 0x20001458   504 B 0x200015C4 (  136 B)   360 B 0x00000000 ( <1%)
5   no (0) 0x20001948 Drive        Blocked  (3,3)   0x20001938 0x20001748   504 B 0x200018B4 (  136 B)   264 B 0x00000000 ( <1%)


The absolute number is the number of runtime timer ticks (ulRunTimeCounter in the TCB) and the percentage of this counter in relation to the total runtime (ulTotalRunTime in task.c).

For the IDLE task, it shows this:

TCB Static Handle Name State Prio Stack Beg Stack End Size Stack Top Unused Runtime
7 no (0) 0x20001E68 IDLE Ready (0,0) 0x20001E58 0x20001CD0 400 B 0x20001DFC ( 96 B) 312 B 0x00007C35 ( 91%)


0x7C35 is the timer counter using a 0.1 ms timer in this example, so it means that the IDLE task runs for about three seconds (0x7C35/10 => 3179 ms) and uses 91 percent of the runtime.

The question might be: what about the time spent in interrupts? The answer is that the RTOS does not know about the interrupts; it only knows about how much runtime timer ticks a task has used. Or, in other words, the runtime shows the FreeRTOS runtime counter and includes the time of interrupts.

Tutorial: Runtime Analysis With FreeRTOS

In these next sections, I show how to enable runtime analysis with FreeRTOS. The basic steps are:

  1. Create a new project (if one does not already exist)
  2. Update FreeRTOSConfig.h
  3. Initialize and configure the timer
  4. Add hooks/callbacks to the application

Create Project

Create a project for your board:

Image title

Board for Project Creation

Make sure FreeRTOS is included:

Image title

FreeRTOS option for the project

Add FreeRTOS Task

Next, you need to add a task that will look something like this:

#include "FreeRTOS.h"
#include "task.h"

static void MyTask(void *pvParameters) {
  for(;;) {
    vTaskDelay(pdMS_TO_TICKS(100));
  }
}


Inside  main(), create a task and start the scheduler:

/* create task */
 if (xTaskCreate(MyTask, "MyTask", 500/sizeof(StackType_t), NULL, tskIDLE_PRIORITY+1, NULL) != pdPASS) {
   for(;;){} /* error */
 }
 vTaskStartScheduler(); /* start RTOS */
 for(;;) {
     /* should not get here */
 }


Image title

Added FreeRTOS Task

Build and debug that project to make sure everything is working fine.

Image title

Debugging FreeRTOS Task

To show the FreeRTOS threads in the Debug view, see https://mcuoneclipse.com/2018/06/29/show-freertos-threads-in-eclipse-debug-view-with-segger-j-link-and-nxp-s32-design-studio/

But, the FreeRTOS task list (use the Menu FreeRTOS > Task List to show that view) does not show any runtime information:

Image title

FreeRTOS Task List with no Runtime Information

This is what we are going to add in the next steps.

Trace and Runtime Statistics

Inside FreeRTOSConfig.h, make sure the following defines are set to 1 (turned on):

#define configGENERATE_RUN_TIME_STATS 1 /* 1: generate runtime statistics; 0: no runtime statistics */
#define configUSE_TRACE_FACILITY      1 /* 1: include additional structure members and functions to assist with execution visualization and tracing, 0: no runtime stats/trace */

Image title

Enabled runtime stats and trace functionality

The configUSE_TRACE_FACILITY  is needed for the RTOS to have the additional data elements in the task descriptor present to store the runtime counter. The configGENERATE_RUN_TIME_STATS   turns the functionality on to record the task execution time.

Configuring the Timer

Next, we have to set up a timer to measure the task execution time. That timer should run at least 10x faster than the RTOS Tick timer.

In our example, the tick rate is 1 kHz:

#define configTICK_RATE_HZ ((TickType_t)1000)


This means that our runtime timer shall run with at least 10 kHz.
To configure such a timer, I can use the MCUXpresso Configuration Peripheral tool:

Peripherals Tool

Peripherals Tool

In the Peripheral Tool, we are picking the FTM0 timer (we could use any other timer too).

Adding FTM0

Adding FTM0

The timer gets configured for 10 kHz:

Timer output frequency

Timer output frequency

We will use the timer interrupt to increase a counter, so don’t forget to turn the interrupt on:

Timer Overflow Interrupt Enabled

Timer Overflow Interrupt Enabled

Then, click the button to update the project sources:

Updated Project

Updated Project

Now, lets switch back to the developer perspective.

Timer ISR

Next, we add the timer interrupt code to the application:

#include "fsl_ftm.h"
static uint32_t RTOS_RunTimeCounter; /* runtime counter, used for configGENERATE_RUNTIME_STATS */

void FTM0_IRQHandler(void) {
  /* Clear interrupt flag.*/
  FTM_ClearStatusFlags(FTM0, kFTM_TimeOverflowFlag);
  RTOS_RunTimeCounter++; /* increment runtime counter */
}


Adding Timer Drivers

The project won’t compile yet, because the necessary drivers are not part of the project yet. To add them, use the ‘Manage SDK Components’ button:

Manage SDK Components Button

Manage SDK Components Button

Then, check the FTM driver and press OK to get the extra driver sources added to the project.

FTM Driver

FTM Driver

Adding Timer to FreeRTOS: FreeRTOS Timer Macros for Runtime Statistics

Add the following lines to the FreeRTOSConfig.h:

extern void RTOS_AppConfigureTimerForRuntimeStats(void);
#define portCONFIGURE_TIMER_FOR_RUN_TIME_STATS()   RTOS_AppConfigureTimerForRuntimeStats()
extern uint32_t RTOS_AppGetRuntimeCounterValueFromISR(void);
#define portGET_RUN_TIME_COUNTER_VALUE()           RTOS_AppGetRuntimeCounterValueFromISR()


This tells FreeRTOS which function it shall use to initialize the timer and what function to use for getting the timer value.

Added Runtime Counter Settings to FreeRTOSConfig.h

Added Runtime Counter Settings to FreeRTOSConfig.h

FreeRTOS Callback for Timer

Now, we need to add the two callbacks that we have configured FreeRTOS to use.

void RTOS_AppConfigureTimerForRuntimeStats(void) {
  RTOS_RunTimeCounter = 0;
  EnableIRQ(FTM0_IRQn);
}

uint32_t RTOS_AppGetRuntimeCounterValueFromISR(void) {
  return RTOS_RunTimeCounter;
}


Running

The next step is to build and debug your application. If you stop now, the application and inspect the Task List shows the following runtime information:

Runtime information displayed

Runtime information displayed

No Eclipse? No Problem!

Above, I was using the Eclipse Task List view for FreeRTOS, which is something NXP did for their Eclipse-based IDE’s (MCUXpresso IDE, S32DS for ARM, and Kinetis Design Studio). But, it is possible to show that information directly from the application, e.g. on a terminal LCD display. The FreeRTOS on McuOnEclipse includes a shell/terminal interface that uses:

Task Runtime Information on Console

Task Runtime Information on Console

The code snippet below shows how that information is printed for each task:

#if configGENERATE_RUN_TIME_STATS
  ulTotalTime = portGET_RUN_TIME_COUNTER_VALUE(); /* get total time passed in system */
  ulTotalTime /= 100UL; /* For percentage calculations. */
#endif
...
#if configGENERATE_RUN_TIME_STATS && configUSE_TRACE_FACILITY
      /* runtime */
      UTIL1_strcpy(tmpBuf, sizeof(tmpBuf), (unsigned char*)"0x");
      UTIL1_strcatNum32Hex(tmpBuf, sizeof(tmpBuf), taskStatus.ulRunTimeCounter);
      if (ulTotalTime>0) { /* to avoid division by zero */
        /* What percentage of the total run time has the task used?
           This will always be rounded down to the nearest integer.
           ulTotalRunTime has already been divided by 100. */
        ulStatsAsPercentage = taskStatus.ulRunTimeCounter/ulTotalTime;
        if (ulStatsAsPercentage>0) {
          UTIL1_strcat(tmpBuf, sizeof(tmpBuf), (unsigned char*)" (");
          UTIL1_strcatNum16uFormatted(tmpBuf, sizeof(tmpBuf), ulStatsAsPercentage, ' ', 3);
          UTIL1_strcat(tmpBuf, sizeof(tmpBuf), (unsigned char*)"%)");
        } else {
          /* If the percentage is zero here then the task has consumed less than 1% of the total run time. */
          UTIL1_strcat(tmpBuf, sizeof(tmpBuf), (unsigned char*)" ( <1%)");
        }
      }
      buf[0] = '\0';
      UTIL1_strcatPad(buf, sizeof(buf), tmpBuf, ' ', PAD_STAT_TASK_RUNTIME);
      CLS1_SendStr(buf, io->stdOut);
#endif
      CLS1_SendStr((unsigned char*)"\r\n", io->stdOut);


Summary

FreeRTOS Runtime Statistics is a very useful feature — it shows me how much time is used for each task, including its interrupt time. All that I need is to set some FreeRTOS configuration macros and to set up a periodic timer interrupt. Of course, this does not come for free with an extra timer interrupt and the RAM and FLASH needed for that functionality, but it can be easily turned off for the final release if desired.

Happy runtime!

Helpful Links

  • Example project on GitHub: https://github.com/ErichStyger/mcuoneclipse/tree/master/Examples/MCUXpresso/FRDM-K64F/FRDM-K64F_SDK_FreeRTOS
  • Performance and Runtime Analysis with FreeRTOS
  • MCUXpresso IDE web page: http://www.nxp.com/mcuxpresso/ide
  • MCUXpresso IDE community: http://www.nxp.com/mcuxpresso/ide/forum
  • Better FreeRTOS Debugging in Eclipse
  • McuOnEclipse Library project: https://github.com/ErichStyger/McuOnEclipseLibrary/tree/master/lib/FreeRTOS/Source
  • ARM Cortex-M Cycle Counter: https://mcuoneclipse.com/2017/01/30/cycle-counting-on-arm-cortex-m-with-dwt/
  • Better FreeRTOS Debugging: https://mcuoneclipse.com/2017/03/18/better-freertos-debugging-in-eclipse/
  • FreeRTOS RuntimeStats: https://www.freertos.org/rtos-run-time-stats.html
FreeRTOS Task (computing) Statistics

Published at DZone with permission of Erich Styger, DZone MVB. See the original article here.

Opinions expressed by DZone contributors are their own.

Related

  • The Impact of AI Agents on Modern Workflows
  • A Developer’s Guide to Multithreading and Swift Concurrency
  • The Battle of Data: Statistics vs Machine Learning
  • Mastering AI Agents: How Agentic Design Patterns Make Agents Smarter

Partner Resources

×

Comments
Oops! Something Went Wrong

The likes didn't load as expected. Please refresh the page and try again.

ABOUT US

  • About DZone
  • Support and feedback
  • Community research
  • Sitemap

ADVERTISE

  • Advertise with DZone

CONTRIBUTE ON DZONE

  • Article Submission Guidelines
  • Become a Contributor
  • Core Program
  • Visit the Writers' Zone

LEGAL

  • Terms of Service
  • Privacy Policy

CONTACT US

  • 3343 Perimeter Hill Drive
  • Suite 100
  • Nashville, TN 37211
  • support@dzone.com

Let's be friends:

Likes
There are no likes...yet! 👀
Be the first to like this post!
It looks like you're not logged in.
Sign in to see who liked this post!
