Using Jena and SHACL to Validate RDF Data

DZone's Guide to

Using Jena and SHACL to Validate RDF Data

In this post, I will give a brief overview of how to use SHACL to validate RDF data using the Jena implementation of SHACL.

· Big Data Zone ·
Free Resource

Hortonworks Sandbox for HDP and HDF is your chance to get started on learning, developing, testing and trying out new features. Each download comes preconfigured with interactive tutorials, sample data and developments from the Apache community.

RDF enables users to capture data in a way that is intuitive to them. This means that data is often captured without conforming to any schema. It is often useful to know that an RDF dataset conforms to some (potentially partial) schema. This is where SHACL (SHApe Constraint Language), a W3C standard, comes into play. It is a language for describing and validating RDF graphs. In this post, I will give a brief overview of how to use SHACL to validate RDF data using the Jena implementation of SHACL.

A SHACL Example

We will use an example from the SHACL specification. Assume we have a file, person.ttl, that contains the following data:

@prefix ex: <http://example.com/ns#> .
@prefix owl: <http://www.w3.org/2002/07/owl#> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .

ex:Alice
  a ex:Person ;
  ex:ssn "987-65-432A" .

ex:Bob
  a ex:Person ;
  ex:ssn "123-45-6789" ;
  ex:ssn "124-35-6789" .

ex:Calvin
  a ex:Person ;
  ex:birthDate "1971-07-07"^^xsd:date ;
  ex:worksFor ex:UntypedCompany .

To validate this data we create a shape definition in personShape.ttl containing:

@prefix dash: <http://datashapes.org/dash#> .
@prefix ex: <http://example.com/ns#> .
@prefix owl: <http://www.w3.org/2002/07/owl#> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> .
@prefix sh: <http://www.w3.org/ns/shacl#> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .

ex:PersonShape
  a sh:NodeShape ;
  sh:targetClass ex:Person ;    # Applies to all persons
  sh:property [                 # _:b1
    sh:path ex:ssn ;           # constrains the values of ex:ssn
    sh:maxCount 1 ;
    sh:datatype xsd:string ;
    sh:pattern "^\\d{3}-\\d{2}-\\d{4}$" ;
  ] ;
  sh:property [                 # _:b2
    sh:path ex:worksFor ;
    sh:class ex:Company ;
    sh:nodeKind sh:IRI ;
  ] ;
  sh:closed true ;
  sh:ignoredProperties ( rdf:type ) .

A Code Example Using Jena

To validate our RDF data using our SHACL shape we will use the Jena implementation of SHACL. Start by adding the SHACL dependency to your Maven pom.xml. Note that you do not need to add Jena as well, as the SHACL pom already includes Jena.

<dependency>
  <groupId>org.topbraid</groupId>
  <artifactId>shacl</artifactId>
  <version>1.0.1</version>
</dependency>

In the code, we will assume the person.ttl and personShape.ttl files are in $Project/src/main/resources/. The code for doing the validation is the following then:

package org.shacl.tutorial;

import java.io.File;
import java.io.FileOutputStream;
import java.io.OutputStream;
import java.nio.file.Path;
import java.nio.file.Paths;

import org.apache.jena.rdf.model.Model;
import org.apache.jena.rdf.model.Resource;
import org.apache.jena.riot.RDFDataMgr;
import org.apache.jena.riot.RDFFormat;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.slf4j.Marker;
import org.slf4j.MarkerFactory;
import org.topbraid.shacl.validation.ValidationUtil;
import org.topbraid.shacl.vocabulary.SH;
import org.topbraid.spin.util.JenaUtil;

public class ShaclValidation {
  private static Logger logger = LoggerFactory.getLogger(ShaclValidation.class);
  // Why This Failure marker
  private static final Marker WTF_MARKER = MarkerFactory.getMarker("WTF");

  public static void main(String[] args) {
    try {
      Path path = Paths.get(".").toAbsolutePath().normalize();
      String data = "file:" + path.toFile().getAbsolutePath() +
        "/src/main/resources/person.ttl";
      String shape = "file:" + path.toFile().getAbsolutePath() +
        "/src/main/resources/personShape.ttl";

      Model dataModel = JenaUtil.createDefaultModel();
      dataModel.read(data);
      Model shapeModel = JenaUtil.createDefaultModel();
      shapeModel.read(shape);

      Resource reportResource =
          ValidationUtil.validateModel(dataModel, shapeModel, true);
      boolean conforms  = reportResource.getProperty(SH.conforms).getBoolean();
      logger.trace("Conforms = " + conforms);

      if (!conforms) {
        String report = path.toFile().getAbsolutePath() +
            "/src/main/resources/report.ttl";
        File reportFile = new File(report);
        reportFile.createNewFile();
        OutputStream reportOutputStream = new FileOutputStream(reportFile);

        RDFDataMgr.write(reportOutputStream, reportResource.getModel(), RDFFormat.TURTLE);
      }
    } catch (Throwable t) {
      logger.error(WTF_MARKER, t.getMessage(), t);
    }
  }
}

Running the Code

Running the code will cause a report.ttl file to be written out to $Project/src/main/resources/. We can determine that our data does not conform to this by checking the sh:conforms property. We have 4 violations of our ex:PersonShape:

  1. For ex:Alice the ex:ssn property does not conform to the pattern defined in the shape.

  2. ex:Bob has 2 ex:ssn properties.

  3. ex:Calvin works for a company that is not of type ex:Company.

  4. ex:Calvin has a property ex:birthDate that is not allowed by ex:PersonShape since it is close by sh:closed true.

A corrected version of our person data may look as follows:

@prefix ex: <http://example.com/ns#> .
@prefix owl: <http://www.w3.org/2002/07/owl#> .
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> .
@prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> .
@prefix xsd: <http://www.w3.org/2001/XMLSchema#> .

ex:Alice
  a ex:Person ;
  ex:ssn "987-65-4321" .

ex:Bob
  a ex:Person ;
  ex:ssn "124-35-6789" .

ex:ACECompany a ex:Company .

ex:Calvin
  a ex:Person ;
  ex:worksFor ex:ACECompany .

Conclusion

In this post, I gave a brief overview of how SHACL can be used to validate RDF data using the SHACL implementation of Jena. This code example is available on GitHub.
