Design and Create VPC in AWS

This article will help design and create Virtual Private Network using the VPC designer tool and cloud formation template. It also describes VPC components in detail.

KONDALA RAO PATIBANDLA user avatar by
KONDALA RAO PATIBANDLA
·
Nov. 10, 22 · Tutorial
Like (3)
Save
Tweet
Share
5.80K Views

Join the DZone community and get the full member experience.

Join For Free

This article describes the design and creation of Amazon Virtual Private Network (VPC) using the VPC Designer tool and Cloud Formation templates. It also provides details of VPC Components such as Subnets, Route tables, Security Groups, Internet Gateway, NAT Gateway, VPC endpoints, Network Interfaces,  Network Access Control Lists (ACLs), and VPC Peering.

Amazon Virtual Private Cloud (VPC) enables you to create your own dedicated, logically isolated virtual private network in your AWS account. This virtual network closely resembles a traditional network that you operate in your own data center (on-premises).  It provides the ability to define and have full control over the virtual network environment, including security, connectivity, and resource deployment. VPC spans multiple availability zones in an AWS Region.

An Amazon VPC is primarily focused on the following capabilities:

  • Isolating your own AWS resources from other AWS Accounts.
  • Protecting your AWS resources deployed in VPC from network Threats.
  • Routing network traffic to and from your resources deployed in VPC.

Illustration of a Virtual Private Cloud with Subnets.

                                            Illustration of a Virtual Private Cloud with Subnets.

VPC Components

The fundamental VPC components are:

  • VPC CIDR Block
  • Subnets
  • Security Groups
  • Network Access Control Lists (ACLs)
  • Gateways (Internet, NAT)
  • Route Table

VPC CIDR Block

VPCs and Subnets are associated with an IP address range that is a part of a Classless Inter-Domain Routing (CIDR) block, which will be used to allocate private IP addresses for the resources deployed in VPC. You can create a VPC by assigning either an IPv4 or IPv6 address.

Subnets

A subnet is associated with a CIDR block that is a subset of the '/16 CIDR block' of its VPC.  A subnet must reside in a single availability zone. You can deploy AWS resources in a VPC after adding subnets to it.

Security Groups

A security group is considered the first-level defense and acts as a firewall for AWS resources deployed in a subnet to control incoming and outgoing traffic. Inbound rules control the incoming traffic to the instances, whereas outbound rules control the outbound traffic from the instances within the VPC.

Network Access Control Lists (ACLs)

An NACL is considered the second-level defense and acts as a firewall to the subnet that controls incoming and outgoing traffic.  We can create rules to allow or deny network traffic to specific protocols through specific ports and specific IP address ranges. Network ACLs are stateless and have separate inbound and outbound rules.

Gateways

A Gateway connects a VPC to another network. The AWS resources residing in a VPC require connectivity outside of the AWS network, i.e., to the internet. A VPC must be attached to the Internet Gateway to access the Internet. NAT Gateway is used to enable the resources residing in a private subnet to connect to the Internet or other AWS services.

Route Table

A Route Table contains a set of rules, called routes, that determine where network traffic from a subnet or gateway needs to be directed. A Route Table is always associated with a subnet.

VPC Peering

A VPC peering connection is a networking connection between two VPCs that enables you to route traffic between them using private IPv4 addresses or IPv6 addresses.  We can create a VPC peering connection between our own VPCs or a VPC in another AWS account.  Instances in either VPC can communicate with each other as if they are within the same network. The VPCs can be in different Regions i.e., also known as an inter-Region VPC peering connection.

Prerequisites

We have provided a sample solution along with this article. To deploy this solution, we must have the following:

  • An AWS account.
  • AWS CLI with administrator permissions.
  • Basic knowledge of CloudFormation templates.

Design a VPC Using VPC Design Tool

Amazon VPC supports both IPv4 and IPv6 addresses. Here, we will use IPv4 to design a VPC. When we create a VPC, we must specify an IPv4 address for the VPC. The acceptable address block will be between a '/16 netmask' (65,536 IP address) and a '/28 netmask' (16 IP  address). AWS recommends that we specify the CIDR block from the private address ranges specified in RFC 1918.

RFC 1918 range Example CIDR block
10.0.0.0 - 10.255.255.255 (10/8 prefix) 10.0.0.0/16
172.16.0.0 - 172.31.255.255 (172.16/12 prefix) 172.31.0.0/16
192.168.0.0 - 192.168.255.255 (192.168/16 prefix) 192.168.0.0/20

                                        RFC 1918 Standard

Let us discuss more IPv4 addresses.

An IPv4 address is 32 bits. An IP Address is shown as four decimal numbers representing 4 bytes (each byte is 8 bits, i.e. 8 * 4 = 32 bits).

 IPv4 address

Example of an IP CIDR Range :
CIDR RANGE Explanation
10. 9 . 0 . 0 /16
 8 + 8
CIDR  / 16, first two digits will not change in this IP address range.
10 . 9 . (0 - 255) . (0 - 255) = 256 * 256 = 65536 private IP addresses are available for usage.
10. 9 . 0 . 0 /18

8 + 8 +2


CIDR  / 18, first two digits will not change in this IP address, and the third digit allows a range between    0 through 63.
10 . 9 . (0 - 63) . 0  = 64 * 256 = 16384 private IP addresses are available for usage.
10. 9 . 0 . 0 /22
 8  +8 +6

CIDR / 18, first two digits will not change in this IP address, and the third digit allows a range between  0 through 3.
10 . 9 . (0 - 3) . 0  = 4 * 256 = 1024 private IP addresses are available for usage.
10. 9 . 0 . 0/24

8  + 8  + 8
CIDR  / 24, first three digits will not change in this IP address.
10 . 9 . 0 . 0 - 255 = 256 private IP addresses are available for usage.
10. 9 . 0. 0 /26    8+8+8+2    CIDR / 18, first three digits will not change in this IP address, and fourth
digit will allow a range between 0 through 63.
10 . 9 . 0 . (0 - 63)  = 64  private IP addresses are available for usage.
10.  9 . 0 . 0/32
 8  + 8 + 8+ 8
CIDR  / 32, all the four digits will not change in this IP address.
10 . 9 . 0 . 0 = 1 private IP address is available for usage.


Let us now design a VPC and its subnets with an IP CIDR range. Please ensure the VPC CIDR range we use does not overlap with existing IP address ranges currently in use in your organization.

I am using a VPC designer tool to design subnets in a VPC.

VPC CIDR Range: 10.9.0.0/22

VPC CIDR Range

There are 1024 IP addresses available to allocate to our subnets.

 1024 IP addresses availableLet us design two subnets in a VPC, one public and another private. This example takes three availability zones into consideration. We allocate 256 IP addresses for each private subnet using a 'CIDR /24' range. We then allocate 64 IP addresses for the first two public subnets using a 'CIDR /26' range. We then assign not 64, but 128 IP addresses to the last public subnet using a 'CIDR /25' range. This is possible as we would be left with 64 unused IP addresses, which we can assign to our third public subnet.

Refer to the screenshot below to understand how the allocation works.

 how the allocation works.


VPC Creation

Let us now create a VPC using the information provided above from the VPC designer tool and design the CIDR range for our public and private subnets using the CloudFormation template.

YAML

AWSTemplateFormatVersion: "2010-09-09"
Description: This template deploys a VPC with a pair of public and private subnets spread across three Availability Zones. It deploys an internet gateway, defining routes to public subnets. It deploys three NAT gateways (one in each AZ), and routes them to private subnets. It also creates NACls for each Public and Private subnet.

Parameters:
  pVPCCIDRBlock:
    Description: Please enter the IP range for this VPC
    Type: String

  pPublicSubnet1CIDR:
    Description: Please enter the IP range for the public subnet in the first Availability Zone
    Type: String

  pPublicSubnet2CIDR:
    Description: Please enter the IP range for the public subnet in the second Availability Zone
    Type: String

  pPublicSubnet3CIDR:
    Description: Please enter the IP range for the public subnet in the third Availability Zone
    Type: String

  pPrivateSubnet1CIDR:
    Description: Please enter the IP range for the private subnet in the first Availability Zone
    Type: String

  pPrivateSubnet2CIDR:
    Description: Please enter the IP range for the private subnet in the second Availability Zone
    Type: String

  pPrivateSubnet3CIDR:
    Description: Please enter the IP range for the private subnet in the third Availability Zone
    Type: String

Resources:
 rVPC:
  Type: AWS::EC2::VPC
  Properties:
    CidrBlock: !Ref pVPCCIDRBlock
    EnableDnsSupport: true
    EnableDnsHostnames: true

 rPublicSubnet1:
  Type: AWS::EC2::Subnet
  Properties:
   CidrBlock: !Ref pPublicSubnet1CIDR
   VpcId: !Ref rVPC
   AvailailityZone: !Select [0, !GetAZs '']
   MapPublicIpOnLaunch: true
   Tags:
     - Key: Name
       Value: "Public Subnet (AZ1)"

 rPublicSubnet2:
  Type: AWS::EC2::Subnet
  Properties:
   CidrBlock: !Ref pPublicSubnet2CIDR
   VpcId: !Ref rVPC
   AvailailityZone: !Select [1, !GetAZs '']
   MapPublicIpOnLaunch: true
   Tags:
     - Key: Name
       Value: "Public Subnet (AZ2)"

 rPublicSubnet3:
  Type: AWS::EC2::Subnet
  Properties:
   CidrBlock: !Ref pPublicSubnet3CIDR
   VpcId: !Ref rVPC
   AvailailityZone: !Select [2, !GetAZs '']
   MapPublicIpOnLaunch: true
   Tags:
     - Key: Name
       Value: "Public Subnet (AZ3)"

 rPrivateSubnet1:
  Type: AWS::EC2::Subnet
  Properties:
   CidrBlock: !Ref pPrivateSubnet1CIDR
   VpcId: !Ref rVPC
   AvailailityZone: !Select [0, !GetAZs '']
   MapPublicIpOnLaunch: false
   Tags:
     - Key: Name
       Value: "Private Subnet (AZ1)"

 rPrivateSubnet2:
  Type: AWS::EC2::Subnet
  Properties:
   CidrBlock: !Ref pPrivateSubnet2CIDR
   VpcId: !Ref rVPC
   AvailailityZone: !Select [1, !GetAZs '']
   MapPublicIpOnLaunch: false
   Tags:
     - Key: Name
       Value: "Private Subnet (AZ2)"

 rPrivateSubnet3:
  Type: AWS::EC2::Subnet
  Properties:
   CidrBlock: !Ref pPrivateSubnet3CIDR
   VpcId: !Ref rVPC
   AvailailityZone: !Select [2, !GetAZs '']
   MapPublicIpOnLaunch: false
   Tags:
     - Key: Name
       Value: "Private Subnet (AZ3)"

 rPublicRouteTable:
  Type: AWS::EC2::RouteTable
  Properties:
   VpcId: !Ref rVPC
   Tags:
   	 - Key: Name
       Value: "Public Routes"

 rPublicSubnet1RouteTableAssociation:
   Type: AWS::EC2::SubnetRouteTableAssociation
   Properties:
     RouteTableId: !Ref rPublicRouteTable
     SubnetId: !Ref rPublicSubnet1

 rPublicSubnet2RouteTableAssociation:
   Type: AWS::EC2::SubnetRouteTableAssociation
   Properties:
     RouteTableId: !Ref rPublicRouteTable
     SubnetId: !Ref rPublicSubnet2

 rPublicSubnet3RouteTableAssociation:
   Type: AWS::EC2::SubnetRouteTableAssociation
   Properties:
     RouteTableId: !Ref rPublicRouteTable
     SubnetId: !Ref rPublicSubnet3

 rInternetGateway:
   Type: AWS::EC2::InternetGateway
     Properties:
     Tags:
     - Key: Name
       Value: "Internet Gateway"

 rInternetGatewayAttachment:
   Type: AWS::EC2::VPCGatewayAttachment
   Properties:
     InternetGatewayId: !Ref rInternetGateway
     VpcId: !Ref rVPC

 rNatGateway1EIP:
    Type: AWS::EC2::EIP
    DependsOn: rInternetGatewayAttachment
    Properties:
      Domain: vpc

 rNatGateway2EIP:
    Type: AWS::EC2::EIP
    DependsOn: rInternetGatewayAttachment
    Properties:
      Domain: vpc

 rNatGateway3EIP:
    Type: AWS::EC2::EIP
    DependsOn: rInternetGatewayAttachment
    Properties:
      Domain: vpc

 rNatGateway1:
    Type: AWS::EC2::NatGateway
    Properties:
      AllocationId: !GetAtt rNatGateway1EIP.AllocationId
      SubnetId: !Ref rPublicSubnet1

 rNatGateway2:
    Type: AWS::EC2::NatGateway
    Properties:
      AllocationId: !GetAtt rNatGateway2EIP.AllocationId
      SubnetId: !Ref rPublicSubnet2

 rNatGateway3:
    Type: AWS::EC2::NatGateway
    Properties:
      AllocationId: !GetAtt rNatGateway3EIP.AllocationId
      SubnetId: !Ref rPublicSubnet3

 rPrivateRouteTable1:
    Type: AWS::EC2::RouteTable
    Properties:
      VpcId: !Ref rVPC
      Tags:
        - Key: Name
          Value: "Private Routes (AZ1)"

 rPrivateRouteTable2:
    Type: AWS::EC2::RouteTable
    Properties:
      VpcId: !Ref rVPC
      Tags:
        - Key: Name
          Value: "Private Routes (AZ2)"

 rPrivateRouteTable3:
    Type: AWS::EC2::RouteTable
    Properties:
      VpcId: !Ref rVPC
      Tags:
        - Key: Name
          Value: "Private Routes (AZ3)"

 rPrivateSubnet1RouteTableAssociation:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      RouteTableId: !Ref rPrivateRouteTable1
      SubnetId: !Ref rPrivateSubnet1

 rPrivateSubnet2RouteTableAssociation:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      RouteTableId: !Ref rPrivateRouteTable2
      SubnetId: !Ref rPrivateSubnet2

 rPrivateSubnet3RouteTableAssociation:
    Type: AWS::EC2::SubnetRouteTableAssociation
    Properties:
      RouteTableId: !Ref rPrivateRouteTable3
      SubnetId: !Ref rPrivateSubnet3

 rPublicDefaultRoute:
 	Type: AWS::EC2::Route
    Properties:
      RouteTableId: !Ref rPublicRouteTable
      DestinationCidrBlock: 0.0.0.0/0
      GatewayId: !Ref rInternetGateway

 rPriaveteNATGatewayRoute1:
     Type: AWS::EC2::Route
     Properties:
        RouteTableId: !Ref rPrivateRouteTable1
        NatGatewayId: rNatGateway1
        DestinationCidrBlock: 0.0.0.0/0

 rPriaveteNATGatewayRoute2:
     Type: AWS::EC2::Route
     Properties:
        RouteTableId: !Ref rPrivateRouteTable2
        NatGatewayId: rNatGateway2
        DestinationCidrBlock: 0.0.0.0/0

 rPriaveteNATGatewayRoute3:
     Type: AWS::EC2::Route
     Properties:
        RouteTableId: !Ref rPrivateRouteTable3
        NatGatewayId: rNatGateway2
        DestinationCidrBlock: 0.0.0.0/0

 rPublicSubnetNacl:
    Type: AWS::EC2::NetworkAcl
    Properties:
    	VpcId: !Ref rVPC
        Tags:
        - Key: Name
          Value: "Public Subnet Nacl"

 rPrivateSubnetNacl:
    Type: AWS::EC2::NetworkAcl
    Properties:
    	VpcId: !Ref rVPC
        Tags:
        - Key: Name
          Value: "Private Subnet Nacl"

 rPublicSubnetInbound:
   Type: AWS::EC2::NetworkAclEntry
   Properties:
   	 NetworkAclId: !Ref rPublicSubnetNacl
     Egress: false
     RuleNumber: 10
     Protocol: 6
     RuleAction: 'allow'
     CidrBlock: '0.0.0.0/0'
     PortRange:
     	From: 1024
        To: 65535

 rPublicSubnetOutbound:
   Type: AWS::EC2::NetworkAclEntry
   Properties:
   	 NetworkAclId: !Ref rPublicSubnetNacl
     Egress: true
     RuleNumber: 10
     Protocol: -1
     RuleAction: 'allow'
     CidrBlock: '0.0.0.0/0'
     PortRange:
     	From: 22
        To: 65535

  rPublicSubnetInbound:
   Type: AWS::EC2::NetworkAclEntry
   Properties:
   	 NetworkAclId: !Ref rPrivateSubnetNacl
     Egress: false
     RuleNumber: 10
     Protocol: -1
     RuleAction: 'deny'
     CidrBlock: '0.0.0.0/0'
     PortRange:
     	From: 1024
        To: 65535

 rPublicSubnetOutbound:
   Type: AWS::EC2::NetworkAclEntry
   Properties:
   	 NetworkAclId: !Ref rPrivateSubnetNacl
     Egress: true
     RuleNumber: 10
     Protocol: 6
     RuleAction: 'allow'
     CidrBlock: '0.0.0.0/0'
     PortRange:
     	From: 1024
        To: 65535

 rNaclPublicSubnetAssociation1:
   Type: AWS::EC2::SubnetNetworkAclAssociation
   Properties:
     NetworkAclId: !Ref rPublicSubnetNacl
     Subnet: !Ref rPublicSubnet1

 rNaclPublicSubnetAssociation2:
   Type: AWS::EC2::SubnetNetworkAclAssociation
   Properties:
     NetworkAclId: !Ref rPublicSubnetNacl
     Subnet: !Ref rPublicSubnet2

 rNaclPublicSubnetAssociation3:
   Type: AWS::EC2::SubnetNetworkAclAssociation
   Properties:
     NetworkAclId: !Ref rPublicSubnetNacl
     Subnet: !Ref rPublicSubnet3

 rNaclPrivateSubnetAssociation1:
   Type: AWS::EC2::SubnetNetworkAclAssociation
   Properties:
     NetworkAclId: !Ref rPrivateSubnetNacl
     Subnet: !Ref rPublicSubnet1

 rNaclPrivateSubnetAssociation2:
   Type: AWS::EC2::SubnetNetworkAclAssociation
   Properties:
     NetworkAclId: !Ref rPrivateSubnetNacl
     Subnet: !Ref rPrivateSubnet2

 rNaclPrivateSubnetAssociation3:
   Type: AWS::EC2::SubnetNetworkAclAssociation
   Properties:
     NetworkAclId: !Ref rPublicSubnetNacl
     Subnet: !Ref rPrivateSubnet3

 Outputs:
  VPC:
    Description: "VPC Id"
    Value: !Ref VPC

  PublicSubnets:
    Description: "Public subnets"
    Value: !Join [ ",", [ !Ref rPublicSubnet1, !Ref rPublicSubnet2, !Ref rPublicSubnet3 ]]

  PrivateSubnets:
    Description: "Private subnets"
    Value: !Join [ ",", [ !Ref rPrivateSubnet1, !Ref rPrivateSubnet2, !Ref  rPrivateSubnet3]]


The above code snippet creates a VPC with public and private subnets, NACLs, Internet Gateway, NAT Gateway, and Route Tables.

All CIDR ranges of subnets in a VPC should be a subset of a VPC CIDR range. In this example, the VPC creates a '/22 CIDR block' (with 1024 IPs) with three availability zones, and each availability zone has a set of public and private subnets. All our public subnets will be created using the '/26 CIDR' block, and all our private subnets will be created using the '/24 CIDR' block.

Public Subnets

Each Public subnet has its own route table attached to route the internet traffic through the Internet gateway.  The resources deployed in EC2 Instances in public subnets can have their own public IPs or Elastic IPs (EIPs) that have a NAT attached to their Elastic Network Interface (ENI).

Public Subnets

Private Subnets

AWS resources deployed in the private subnets are assigned only private IPs, and these resources cannot directly access the internet. Infrastructure in a private subnet gets access to resources or users on the Internet through a NAT Gateway. An AWS NAT gateway is a fully managed and highly available service (in a given availability zone). To provide high availability across the availability zones (AZs), it is recommended to have a minimum of two NAT gateways in different AZs. In the event that one AZ should become unavailable, the design choice of having two NAT gateways in two different AZs allows us to switch to an available NAT gateway.

Private Subnets

Applications hosted on instances living within a private subnet can have different access requirements. Some services may require access to the Internet, whereas other services may require access to databases, applications, and users that are hosted on-premises. For this type of access, AWS provides two types of services: the Virtual Gateway and the Transit Gateway. The Virtual Gateway can only support a single VPC at a time, whereas the Transit Gateway is built to simplify the interconnectivity of tens of hundreds of VPCs, and then aggregate their connectivity to resources residing on-premises. Given that, we are looking at the VPC as a single unit of the network.

All diagrams below contain illustrations of the Virtual Gateway, which acts as a WAN concentrator for our VPC.

Virtual Gateway, which acts as a WAN concentrator for our VPC.

AWS provides two options for establishing private connectivity between our VPC and on-premises network: AWS Direct Connect and AWS Site-to-Site VPN.

AWS Site-to-Site VPN configuration leverages IPSec, with each connection providing two redundant IPSec tunnels. AWS supports both static routing and dynamic routing (through the use of BGP).

Note: BGP is recommended, as it allows dynamic route advertisement, high availability through failure detection, and failover between tunnels, in addition to decreased management complexity.

Conclusion

In this article, we learned how to design a VPC and subnets and defined their components. We ensured our VPC has internet and private network connectivity to the resources deployed within our VPC by defining an Internet Gateway, NAT Gateway, Virtual Gateway (VGW), and Direct Connect. We learned to describe components such as Route Table and NACLs. I hope this article helps you to understand, design, and define a virtual private cloud in simple and easy steps.

AWS Design Virtual private cloud

Opinions expressed by DZone contributors are their own.

Popular on DZone

  • Steel Threads Are a Technique That Will Make You a Better Engineer
  • Integrate AWS Secrets Manager in Spring Boot Application
  • Choosing the Right Framework for Your Project
  • Demystifying the Infrastructure as Code Landscape

Comments

Partner Resources

X

ABOUT US

  • About DZone
  • Send feedback
  • Careers
  • Sitemap

ADVERTISE

  • Advertise with DZone

CONTRIBUTE ON DZONE

  • Article Submission Guidelines
  • Become a Contributor
  • Visit the Writers' Zone

LEGAL

  • Terms of Service
  • Privacy Policy

CONTACT US

  • 600 Park Offices Drive
  • Suite 300
  • Durham, NC 27709
  • support@dzone.com
  • +1 (919) 678-0300

Let's be friends:
