ETL vs Pure SQL

Which one will come out on top? You should definitely check out the results so you can decide which one to use for your next project.

Mateusz Komendołowicz user avatar by
Mateusz Komendołowicz
·
Dec. 30, 16 · Big Data Zone · Opinion
Like (5)
Save
Tweet
6.00K Views

Join the DZone community and get the full member experience.

Join For Free

In this post I would like to compare the efficiency of upsert operation in ETL tools and SQL. This is one of the most commonly used operations when building ETLs and integrating systems. Developers should always ask themselves whether not to use custom written MERGE instead of creating jobs in selected ELT tool.

As an ETL example, I will use Talend Open Studio 6.1. An SQL example will be MERGE operation in SQL Server. We will start with building two tables, which will be used for upsert. Please note, that I will populate sourceTable with 1 000 000 rows and destinationTable with 500 000 rows using modified script from http://blogbi.pl/generating-milions-of-rows-in-sql-server/

CREATE TABLE sourceTable (
  id int PRIMARY KEY,
  number int );
CREATE TABLE destinationTable (
  id int PRIMARY KEY,
  number int );
-- mentioned script here
  SELECT COUNT(*) as [#sourceCount] FROM dbo.sourceTable;
SELECT COUNT(*) as [#destinationCount] FROM dbo.destinationTable;

Talend Open Studio upsert operation implementation

First, we will build job in Talend. Normally you can use three components: tMSSqlInput (for  sourceTable), tMSSqlOutput (for destinationTable) and obviously tMap. Then you would switch component action for data for (Insert or Update) for tMSSqlOutput. However this approach creates a flow, which transfers data with speed of dozens rows per second, so it is extremely poor. So, let me show you how to build a well-performing Talend upsert job.

talend upsert job

 I have used sourceTable and destinationTable as inputs for tMap. Then I have selected inner join between them to catch which rows are new and which are already in destination table. Based on that I will filter them and insert/update them.

 With such an approach the performance is better than built-in insert/update in Talend. It works in ~ 20 seconds.

SQL Server upsert operation implementation

Now let’s check out how MERGE works in comparison to Talend.

The SQL code for MERGE:

CREATE PROCEDURE dbo.MergeExample AS BEGIN
MERGE dbo.destinationTable AS target
USING dbo.sourceTable AS source
ON target.id = source.id
WHEN MATCHED THEN
UPDATE SET number = source.number
WHEN NOT MATCHED THEN
INSERT (id, number)
VALUES (source.id, source.number); END;

In Talend you can just use TMSSqlRow with SQL Query EXEC dbo.MergeExample.

Performance: ~2 s.

So SQL is 10 times faster than Talend in this case.

Summary

This simple theoretical test shows the same what practice taught me. Pure SQL is much faster than any ETL tool in case of many operations. With more data and more complicated transformations the advantage of SQL will be even bigger. I have seen cases where pure well written SQL is even 500 times faster than ETL tools.

Also, please note that when you have a lot of transformations, it is nearly always easier to write Table -> View – > Merge flow in SQL, then create complex jobs in ETL tool.

Therefore I would like to suggest you consider this option while developing your ETLs.

Extract, transform, load sql Database

Published at DZone with permission of Mateusz Komendołowicz, DZone MVB. See the original article here.

Opinions expressed by DZone contributors are their own.
