Introduction

In general, we’re used to exposing APIs via annotated controllers like this:

    Java

   @GetMapping("/products")
public Flux<ProductDto> allProducts() {
    return this.productService.getAllProducts();
}

It’s simple and straightforward, and we always know what to expect.

WebFlux provides an alternative way to expose APIs, and it is a functional endpoint. The main logic of writing revolves around RouterFunction and HandlerFunction.

HandlerFunction is a functional interface that returns a generated response — Mono<ServerResponse> for each incoming request.
RouterFunction is the equivalent of the @RequestMapping annotation.

Here is an example:

    Java



   @Bean
  public RouterFunction<ServerResponse> route(ProductService productService) {
    return RouterFunctions.route()
        .GET("/products",
            req ->
                this.productService
                    .getAllProducts()
                    .as(productFlux -> ServerResponse.ok().body(productFlux, ProductDto.class)))
        .build();
  }


In fact, we will expose all our routing logic as beans in the functional style.

ServerRequest

Functional endpoints use ServerRequest to retrieve data from an HTTP request. This class provides methods to access all parts of the request: path variables, query params, headers, cookies, and the request body.

PathVariable

    Java

   String productId = request.pathVariable("id");

This method allows you to get data from parts of a URL. For example, from /products/{id} we got {id}.

Query Parameters

    Java

   String page = request.queryParam("page").orElse("0");

This method allows you to get data from the query string after the ? character.

Headers

    Java

   String contentType = request.headers()
                            .contentType()
                            .orElse(MediaType.APPLICATION_JSON).toString();

Body

    Java

   Mono<User> productMono = request.bodyToMono(Product.class);
Flux<User> productFlux = request.bodyToFlux(Product.class);

The request body can be converted to an object using the bodyToMono or bodyToFlux methods, depending on whether we expect a single object or a data stream.

ServerResponse

This is used to send an HTTP response to the client. There are many different methods to customize response status, headers, response body, and other aspects

Basic Methods of ServerResponse

1. Creating a simple response and setting the response status:

    Java

   Mono<ServerResponse> responseOk = ServerResponse.ok().build();
Mono<ServerResponse> responseNotFound = ServerResponse.notFound().build();
Mono<ServerResponse> responseConflict = ServerResponse.status(HttpStatus.CONFLICT).build();

2. Adding headers:

    Java



   Mono<ServerResponse> responseOkWithHeadersV1 =
        ServerResponse.ok()
            .header("Custom-Header1", "value1")
            .header("Custom-Header2", "value2")
            .build();

Mono<ServerResponse> responseOkWithHeadersV2 =
        ServerResponse.ok()
            .headers(httpHeaders -> {
              httpHeaders.add("Custom-Header1", "value1");

              httpHeaders.setBasicAuth("user", "password");
              httpHeaders.setBearerAuth("some-value");
            })
            .build();


Give preference to the second one, as httpHeaders already has many ready-made methods that will cover most of your business cases

3. Adding a body:

    Java

   Mono<ServerResponse> responseOkWithBodyValue =
        ServerResponse.ok().bodyValue(product);

Mono<ServerResponse> responseOkWithBodyMono =
        ServerResponse.ok().body(productMono);

The body and bodyValue methods are used to specify the body of the response. You can send the body as an object or as a data stream (reactive type).

Importance of Order in RouterFunction

The order of the routes is important — the first matching route will be called, as routes are processed from top to bottom.

    Java



   @Bean
public RouterFunction<ServerResponse> route() {
    return RouterFunctions.route()
            .GET("/products", this.requestHandler::allProducts)
            .GET("/products/{id}", this.requestHandler::getOneProduct)
            .GET("/products/paginated", this.requestHandler::pageProducts)
            .build();
  }


If you reverse the order, then GET /products/paginated will never be reached, as GET /products/{id} will intercept the request.

So you need to be careful when setting up endpoints.

Multiply RouterFunctions

If you have many endpoints, you can create several router functions and set them as beans. This approach is more understandable because we divide the code into logical blocks.

    Java



   @Configuration
public class RouteConfiguration {

  @Bean
  public RouterFunction<ServerResponse> productRoute(ProductHandler productHandler, ExceptionHandler exceptionHandler) {
    return RouterFunctions.route()
        .GET("/products", request -> productHandler.getAll())
        .GET("/products/{id}", productHandler::getOne)
        .POST("/products", productHandler::save)
        .PUT("/products/{id}", productHandler::update)
        .DELETE("/products/{id}", productHandler::delete)
        .onError(EntityNotFoundException.class, exceptionHandler::handleException)
        .build();
  }

  @Bean
  public RouterFunction<ServerResponse> orderRoute(OrderHandler orderHandler, ExceptionHandler exceptionHandler) {
    return RouterFunctions.route()
        .GET("/orders", orderHandler::getAllForUser)
        .GET("/orders/{id}", orderHandler::getOne)
        .POST("/orders", orderHandler::save)
        .PUT("/orders/{id}", orderHandler::update)
        .DELETE("/orders/{id}", orderHandler::delete)
        .onError(EntityNotFoundException.class, exceptionHandler::handleException)
        .build();
  }
}


If the endpoints for products and orders throw an EntityNotFoundException, then the error handler needs to be added to two routers.

Nested RouterFunction

If you don’t like to expose them as separate beans, then you can have one high-level router that can route to the child router functions. Let’s transform our RouteConfiguration using a nested router function:

    Java



   @Bean
  public RouterFunction<ServerResponse> nestedRoute(
      ProductHandler productHandler, OrderHandler orderHandler, ExceptionHandler exceptionHandler) {
    return RouterFunctions.route()
        .GET("/products", request -> productHandler.getAll())
        .GET("/products/{id}", productHandler::getOne)
        .POST("/products", productHandler::save)
        .PUT("/products/{id}", productHandler::update)
        .DELETE("/products/{id}", productHandler::delete)
        .path("orders", () -> orderRouteNested(orderHandler))
        .onError(EntityNotFoundException.class, exceptionHandler::handleException)
        .build();
  }

  private RouterFunction<ServerResponse> orderRouteNested(OrderHandler orderHandler) {
    return RouterFunctions.route()
        .GET(orderHandler::getAllForUser)
        .GET("/{id}", orderHandler::getOne)
        .POST(orderHandler::save)
        .PUT("/{id}", orderHandler::update)
        .DELETE("/{id}", orderHandler::delete)
        .build();
  }


In this case, error handling is needed in only one place.

WebFilters

It will also be possible to configure filters for implementing cross-cutting logic.

Filters can be added as we used to do it — implement WebFilter and override the method. We also have the ability to add filters to functional endpoints at the level of individual routers.

We will implement with you an authorization filter that will work only for /orders:

    Java



   @Component
public class SecurityFilter {

    public Mono<ServerResponse> adminRoleFilter(ServerRequest request, HandlerFunction<ServerResponse> next) {
        return SecurityFilter.requireRole("ADMIN", request.exchange())
                .flatMap(exchange -> next.handle(request))
                .onErrorResume(SecurityException.class, ex -> ServerResponse.status(HttpStatus.FORBIDDEN).build());
    }

    private static Mono<ServerWebExchange> requireRole(String role, ServerWebExchange exchange) {
        return ReactiveSecurityContextHolder.getContext()
                .flatMap(securityContext -> {
                    Authentication authentication = securityContext.getAuthentication();
                    if (authentication != null && authentication.isAuthenticated()) {
                        Object principal = authentication.getPrincipal();
                        if (principal instanceof UserDetails userDetails) {
                            if (userDetails.getAuthorities().stream()
                                    .anyMatch(grantedAuthority -> grantedAuthority.getAuthority().equals("ROLE_" + role))) {
                                return Mono.just(exchange);
                            }
                        }
                    }
                    return Mono.error(new SecurityException("Access Denied"));
                });
    }
}


Add in RouterFunction:

    Java



   private RouterFunction<ServerResponse> orderRouteNested(
      OrderHandler orderHandler, SecurityFilter securityFilter) {
    return RouterFunctions.route()
        .GET(orderHandler::getAllForUser)
        .GET("/{id}", orderHandler::getOne)
        .POST(orderHandler::save)
        .PUT("/{id}", orderHandler::update)
        .DELETE("/{id}", orderHandler::delete)
        .filter(securityFilter::adminRoleFilter) //<--- this
        .build();
  }


In this example, the filter will only work for /orders endpoints.

It is important to note that the order of adding filters is important, so if you need a strict sequence of filters, you should add them one by one:

    Java



   …
.filter(filter1) //will be executed first
.filter(filter2) //second
.filter(filter3) //third
…


RequestPredicate

Request predicates are used to define the conditions for routing requests to the appropriate handlers. They allow you to flexibly and accurately configure routes based on various characteristics of HTTP requests, such as method, path, headers, request parameters, etc.

    Java



   @Bean
  public RouterFunction<ServerResponse> nestedRoute(
      ProductHandler productHandler,
      OrderHandler orderHandler,
      ExceptionHandler exceptionHandler,
      SecurityFilter securityFilter,
      LoggingFilter loggingFilter) {
    return RouterFunctions.route()
        .GET(
            "/products",
            RequestPredicates.accept(MediaType.APPLICATION_JSON),
            request -> productHandler.getAll())
        .GET(
            "/products/{id}",
            RequestPredicates.headers(headers ->
                    null != headers.firstHeader("x-api-key")
                    && headers.firstHeader("x-api-key").equals("some-val")
            ),
            productHandler::getOne)
   ...


RequestPredicates is a class with a lot of auxiliary methods.

In this example:

/products – We can call it only if Accept = application/json, otherwise there will be an error that the path was not found.
/products/{id} – We will be able to call only when we have the x-api-key header and it is equal to some-val, otherwise there will be a 404.

You can also have the same path but route to different methods depending on the logic we put in predicates:

    Java



   private RouterFunction<ServerResponse> orderRouteNested(
      OrderHandler orderHandler, SecurityFilter securityFilter) {
    return RouterFunctions.route()
        .GET(isOperation("get-for-user"), orderHandler::getAllForUser)
        .GET(isOperation("get-for-all"), orderHandler::getAll)
        ...
        .build();
  }

  private RequestPredicate isOperation(String operation) {
    return RequestPredicates.headers(h -> operation.equals(h.firstHeader("operation")));
  }


Conclusion

We have discussed how to use functional endpoints in WebFlux in order to create APIs. By using RouterFunction and HandlerFunction to define routes and handlers in the code, this technique blends together routes with filters besides combining routing functions so as to enable us to produce scalable web applications

We managed to achieve this with the help of functional endpoints:

Flexibility and control. Dynamic route definition and combination improved control over request processing.
Readability and support. Separating logic into separate beans improved the code structure and simplified maintenance.
Modularity and flexibility. Creating multiple RouterFunctions for different parts of the application increased the modularity and flexibility of the code.

Here is the code.
