How to Crash the Java Virtual Machine With a Race Condition

DZone's Guide to

How to Crash the Java Virtual Machine With a Race Condition

A look at what kind of errors you'll see if the JVM crashes thanks to using race conditions.

· Java Zone ·
Free Resource

Atomist automates your software deliver experience. It's how modern teams deliver modern software.

This is a how-to guide for crashing the Java virtual machine. It gives you an introduction to race conditions and shows you what errors can happen if your code contains such bugs.

Create a Race Condition

Let us start with the following method:

public class DataRaceTest implements Runnable
{
    private Type[] instance;
    @Override public void run()
    {
      if (instance == null)
       {
         Type[] ts = new Type[1];
         ts[0] = Object.class; instance = ts;
       }
       instance[0].getTypeName();
    }
}

If this method is executed by multiple threads it leads to a race condition. More specifically, it leads to a data race. Data races are defined in the Java memory model as access to a shared field without correct synchronization.

According to the Java memory model, data races lead to platform dependent undefined behavior. Without correct synchronization, very strange, confusing, and counterintuitive behaviors are possible.

If the code is executed in the given order, everything is O.K. But if some component reorders the statements, the array might not be completely initialized. One such component is the cache system of the CPU.

Intel Processors, for example, have a cache system with strong memory guarantees. The cache system makes sure that the values written by the cores are almost always seen in the same order as they have been written by the other cores. But ARM-compatible processors like in smartphones or the Raspberry Pi do not have this guarantee.

Create a Nullpointer Exception

To see what is happening, I'll execute the method multiple times by multiple threads. To do this, I use a tool to reproduce race conditions called stress test. I run it with the following command line options:

java -cp stress-test-0.0.1-SNAPSHOT-jar-with-dependencies.jar
  com.vmlens.StressTest -i 5 -w 16
  com.vmlens.stressTest.examples.dataRace.DataRaceTestSetup

Using the following test setup class:

public class DataRaceTestSetup implements TestSetup
{
  @Override
  public Runnable createTest()
  {
    return new DataRaceTest();
  }
}

This runs the DataRaceTest method for 5 iterations. Each iteration consists of 16,000 tests run by 16 threads.

If I run this on my Intel i5 workstation, I could not create an exception. If I run this on my Raspberry Pi, I see the following Nullpointer Exception for every 2000 tests:

java.lang.NullPointerException
  at com.vmlens.stressTest.examples.dataRace.DataRaceTest.run(DataRaceTest.java:78)
  at com.vmlens.stressTest.internal.TestCall.call(TestCall.java:36)
  at com.vmlens.stressTest.internal.TestCall.call(TestCall.java:7)
  at com.vmlens.stressTest.internal.WorkerThread.run(WorkerThread.java:22)

Crash the Java Virtual Machine

Now let us add some native calls. Let us clone the array:

 @Override public void run()
 {
   if (instance == null)
   {
     Type[] ts = new Type[1];
     ts[0] = Object.class; instance = ts;
   }
   Type[] clonedInstance = instance.clone();
   clonedInstance[0].getTypeName();
 }

This time I'll run the test until I see at least one error. This is done by using the -e option:

java -cp stress-test-0.0.1-SNAPSHOT-jar-with-dependencies.jar
  com.vmlens.StressTest -e 1 -w 16
  com.vmlens.stressTest.examples.dataRace.DataRaceTestSetup

If I run this code on a Raspberry Pi, I'll see the Java virtual machine crash after some time. It takes between half an hour and a day:

#
# A fatal error has been detected by the Java Runtime Environment:
#
# SIGSEGV (0xb) at pc=0x741ab340, pid=26364, tid=1682633824
#
# JRE version: Java(TM) SE Runtime Environment (8.0_65-b17) (build 1.8.0_65-b17)
# Java VM: Java HotSpot(TM) Client VM (25.65-b01 mixed mode linux-arm )
# Problematic frame:
# J 38 C1 com.vmlens.stressTest.internal.TestSetupCall.call()Lcom/vmlens/stressTest/internal/Result; (45 bytes) @ 0x741ab340 [0x741ab250+0xf0]

Conclusion

Data races are hard to reproduce. You need different types of hardware, and even then it takes time until you see an error occur.

That is the reason I developed vmlens, a tool to detect data races in the execution trace of an application.
