JDBC Connection Pool In Payara Using phpMyAdmin (MySQL)

Introduction

In this article, we will learn how to create a JDBC connection pool in phpMyAdmin.

Step:1

Go to the database and create a new database. (I have created a database and table for your reference, you can use your own database and tables.)

Step:2

In StudentDB, create a table tblStudent.

Step:3

Generate the structure of the table.

Step:4

For opening the Payara server, we have two options.

1) Go to netbeans>Services>Payara server>View Domain Admin Console

2) Go to any web browser (chrome, firefox, etc.)>Enter URL>http://localhost:4848/

(By default, the port number for Payara is 4848. If you have changed the port number of Payara Server, then use that port number)

Step:5

Once Payara is open, go to Resources>JDBC>JDBC connection pool>New

Step:6

Pool Name: You can provide any name.

For Resource type and Database Driver Vendor, you need to check the version: MySQL-connector-java.

A path for MySQL -connector-java: (path where you have installed the payara) >payara5>glassfish>domains>domain1>lib

If a version of MySQL-connector-java is less than 8, then use:

Resource Type: javax.sql.DataSource

Database Driver Vendor: MySql

If the version of MySQL-connector java is 8 or higher then use:

Resource Type: javax.sql.PoolDataSource

Database Driver Vendor: MySql

Once you click next, the second textbox of Database Driver Vendor will become writable.

In second textbox of DatabaseDriver Vendor write: com.mysql.cj.jdbc.MysqlDataSource.

Don't forget to check Introspect. It will give a long list of the property, but not checking introspect will give an error during ping.

Step:7

Click next and scroll down. There will be a long list of properties for which you have to set the following property.

We need to add one property:

1) driverClass: com.mysql.jdbc.Drive.

You can sort property for faster access using two triangles. (Highlighted in the screenshot).

2) Password: It is your phpMyAdmin password (Setting password is compulsory. If your phpMyAdmin has a null password, set a password of phpMyAdmin.)

3) User: It is a username of phpMyAdmin.

4) Port: Port number of phpMyAdmin. In most cases, it is 3306.

5) ServerName: It is phpMyAdmin serverName.

6) DatabaseName: Provide a database name for which you are creating a connection pool.

7) URL: You can manually specify a URL or, as an alternative, you can perform steps 8 and 9.

Step: 8 (Optional)

Go to netbeans>services>Database>MysqlServer>Right click>connect

Step: 9 (Optional)

Select the database>Right click>connect.

One URL for a specific database will be created.

Copy until the name of the database and paste it into the URL, Url, url property.

Step:10

Once all properties are set, click finish.

Click Save>New value successfully saved message will be shown.

Click ping>Ping succeeded.

Ping succeeded means a connection pool is created successfully.

Step:11

Once the connection pool has succeeded, create a new JDBC resource>new.

Step:12

JNDI Name: Provide any JNDI name. Pool Name: Select the pool we have created. Click OK.

A connection pool has been created! If you have any doubts or questions, feel free to ask in the comments section!
