JSON Web Token in Action With JAX-RS

DZone's Guide to

JSON Web Token in Action With JAX-RS

A quick introduction to JWT and how to use it with JAX-RS for authentication.

· Java Zone
Free Resource

Learn how to troubleshoot and diagnose some of the most common performance issues in Java today. Brought to you in partnership with AppDynamics.

This post is about using JSON Web Token (JWT) with JAX-RS.

It covers:

  • A quick intro to JWT.
  • How to use it with JAX-RS (for authentication) with an example.

Also:

Brief Intro to JWT

  • A standard defined by RFC 7519
  • Used to exchange claims
  • Has a pre-defined structure

Anatomy of a JWT

It consists of three parts

  • Header: Consists of info like signature mechanism, token type etc.
  • Body (Claims): The meat of the payload.
  • Signature: Signature of the contents to protect against tampered/malicious JWTs.

These three components come together to form the actual token:

//header

{
  "alg": "HS256",
  "typ": "JWT"
}

//payload/claims

{
  "sub": "1234567890",
  "name": "John Doe",
  "admin": true
}

//the formula

encoded_part = base64Of(header) + "." base64Of(payload)
signature = signedUsingHS256WithSecret(encoded_part) //assume that algo is HS256 and secret key is 'secret'
JWT = encoded_part + "." + sigature

//the JWT ( notice the separator/period --> "." )

eyJhbGciOiJIUzI1NiIsInR5cCI6IkpXVCJ9 //base-64 encoded header
.eyJzdWIiOiIxMjM0NTY3ODkwIiwibmFtZSI6IkpvaG4gRG9lIiwiYWRtaW4iOnRydWV9 //base-64 encoded payload
.TJVA95OrM7E2cBab30RMHrHDcEfxjoYZgeFONFh7HgQ //the signature

Benefits

  • Useful for implementing Stateless authentication.
  • Compact: less verbose compared to other counterparts like SAML).
  • Flexible: Although its backed by a standard, you are free to choose your signature, claim attributes etc.

Please Note That:

  • JWT is not only an authentication mechanism. It’s more about information exchange, and it’s usage is limited by your imagination.
  • It’s signed, notencrypted: its contents can be picked up over the wire if you do not secure your transport layer (e.g. using HTTPS).

Using JWT With JAX-RS

Let’s look at an example of how we might use JWT in a JAX-RS based application. As stated earlier, this sample uses JWT as a stateless authentication token. The process is split into distinct steps:

Getting Hold of the JWT

Why do we need a JWT in the first place? It is because the JAX-RS resource is protected and its access is dependent on the presence of a JWT token within the HTTP request (this is achieved by a JAX-RS filter)

Think of JWT as a proxy to the actual username/password (or any other authentication criteria) for your application. You need to actually authenticate using the method required by your application in order to get access to the JWT. In this example, a successfully executed HTTP Basic authentication is the gateway to the token

This is what happens

  1. The application executes a GET request to the URL http://<host&gt;:<port>/<context-root>/auth/token with the HTTP Authorization header containing user credentials
  2. HTTP Basic authentication kicks in. This is enforced by the web.xml (snippet below) which ensures that any request to the /auth/* is not allowed to pass unauthenticated
  3. In case of a successful authentication, the JWT is returned in the HTTP response header

Here is an excerpt form the web.xml

web_xml_snippet

Quick review of the JWT creation code and its result:

//exception handling excluded to avoid verbosity

RsaJsonWebKey rsaJsonWebKey = RsaKeyProducer.produce();

JwtClaims claims = new JwtClaims();
claims.setSubject("user1");

JsonWebSignature jws = new JsonWebSignature();
jws.setPayload(claims.toJson());
jws.setKey(rsaJsonWebKey.getPrivateKey());
jws.setAlgorithmHeaderValue(AlgorithmIdentifiers.RSA_USING_SHA256);

String jwt = jws.getCompactSerialization();

//the encoded JWT

eyJhbGciOiJSUzI1NiJ9
.eyJzdWIiOiJ1c2VyMSJ9
.HG9GCQPuC6w6pulbYE2uurCzpEwoWvz_8Ps5ZjgtfomyY4LWacDEzlHLnyMj9H7aqgcePC7_4l2wDXQV-S0BQRsIZfJeUUmWxlTlLzvKZr_2eEx00YZPPFZNoFCfwB-ajLHLLenROy4aSjPo_Vg9o7N-p0DZ1yZQoJhkvoVJgkhX9FeAf65kIZkbuJC9dmVkzXSOpVf4GZeCpNDJJYSo6IAnL3UEoWek6V9BtWgV-a4xvydp7vxkdDXmzmalGLYuWbuVG7rWcbWwSfsg38iEG-mqptqA_Kzk1VmjwWNo_BfvLuzjzuosqi732-5SRzBP-2zqGghBqMYsGgkqkH2n7A

//human readable format

{
  "alg": "RS256" //header
}

{
  "sub": "user1" //claim payload
}

JWT in Action

  • The JWT is sent by app in the subsequent request for the JAX-RS resource i.e.http:<host>:<port>/<context-root>/resources/books
  • The JAX-RS Container Request Filter kicks in – it checks for the presence of the JWT , verifies it. The verification process implicitly checks for presence of the required claim attributes as well as the signature validation
@Priority(Priorities.AUTHENTICATION)
public class JWTAuthFilter implements ContainerRequestFilter{
  @Override
  public void filter(ContainerRequestContext requestContext) throws IOException {
        String authHeaderVal = requestContext.getHeaderString("Authorization");

            //consume JWT i.e. execute signature validation
            if(authHeaderVal.startsWith("Bearer")){
            try {
                validate(authHeaderVal.split(" ")[1]);
            } catch (InvalidJwtException ex) {
                requestContext.abortWith(Response.status(Response.Status.UNAUTHORIZED).build());
            }
            }else{
                requestContext.abortWith(Response.status(Response.Status.UNAUTHORIZED).build());
            }
  }

JWT verification snippet:

//excpetion hanlding omitted for brevity

RsaJsonWebKey rsaJsonWebKey = getCachedRSAKey(); //should be the same as the one used to build the JWT previously

JwtConsumer jwtConsumer = new JwtConsumerBuilder()
                         .setRequireSubject() // the JWT must have a subject claim
                          .setVerificationKey(rsaJsonWebKey.getKey()) // verify the signature with the public key
                          .build(); // create the JwtConsumer instance

JwtClaims jwtClaims = jwtConsumer.processToClaims(jwt);
  • It allows the request to go through in case of successful verification. Otherwise, the filter returns a HTTP 401 Unauthorized response to the client.
  • A container response filter ensures that the JWT is added as a part of the response header again. It only does so when the JWT verification was successful. This is made possible using the contextual state/information sharing feature provided by JAX-RS Request Filters.
public class JWTResponseFilter implements ContainerResponseFilter {

    @Override
    public void filter(ContainerRequestContext requestContext, ContainerResponseContext responseContext) throws IOException {
        System.out.println("response filter invoked...");
        if (requestContext.getProperty("auth-failed") != null) {
            Boolean failed = (Boolean) requestContext.getProperty("auth-failed");
            if (failed) {
                System.out.println("JWT auth failed. No need to return JWT token");
                return;
            }
        }

        List<Object> jwt = new ArrayList<Object>();
        jwt.add(requestContext.getHeaderString("Authorization").split(" ")[1]);
        responseContext.getHeaders().put("jwt", jwt);
        System.out.println("Added JWT to response header 'jwt'");

    }
}

Other Considerations

Choice of Claim Attributes

In this example, we just used the standard sub (subject) attribute in the claim. You are free to use others. I would highly recommend reading section 4 of the JWT RFC for deeper insight:

jwt_rfc_doc_claims_section

JWT Expiration

One should also consider expiring the JWT token after a finite time. You would need to:

  • Make use of the exp claim attribute (standard).
  • Think about refreshing the JWT token (after expiry).

Revisiting the Stateless Paradigm...

Although the initial authentication was executed using HTTP Basic, the application does not rely on a Session ID for authorizing subsequent requests from the same user. This has the following implications:

  • There is no need to store the session ID on the server side.
  • There is no need to sync this session ID to multiple application nodes in a cluster.

As stated above, JWT is helping us with Stateless authentication (it is not very different from the HTTP protocol itself):

  • Our JWT contains all the required data (claim) for the conversation (in this case authentication).
  • We pass the token with each HTTP request (only to access resources which are protected by the JWT to begin with).
  • The application does not need to repetitively authenticate the user (via the username-password combo).

Now We Can Scale :-)

You can have multiple instances (horizontallyscaled across various nodes/clusters) of your JAX-RS service and yet you need not sync the state of the token between various nodes. If a subsequent request goes to different node than the previous request, the authentication will still happen (provided you pass the JWT token).

Using the Sample Project

If you want to play around with the example, please follow these steps:

  • Get the maven project and build it (same old maven clean install)
  • Deploy on a Java EE 7 container
  • Tweak your server security options to protect it using a realm named file and ensure that you include the members under the users group. Both these constraints are dictated by the web.xml descriptor (see above) – you can also choose to modify it as per your choice. Here is a snapshot from the Payara server:

test-jwt-snippet-3

  • Issue a HTTP GET to http://localhost:8080/jax-rs-with-jwt/auth/token
  • Copy the token in the HTTP response header (jwt):

test-jwt-snippet-1

  • Issue a GET request to http://localhost:8080/jax-rs-with-jwt/resources/books and include the JWT in the HTTP Authorization header (prepend it with Bearer):
  • test-jwt-snippet-2

    I am sure there are lots of other uses of JWT itself. Hopefully this gives a decent starting point to using them within your JAX-RS services.
