Monitor Your Microservices Architecture With the Elastic Stack

Check it out!

By
Jimena Garbarino user avatar
Jimena Garbarino
·
Nov. 13, 19 · Analysis
Likes (9)
Comment
Save
Tweet
Share
23.9K Views

Join the DZone community and get the full member experience.

Join For Free


Image title

Check out this stack of elastics!


Having a centralized tool for monitoring a microservice architecture is very crucial. It gives development teams the ability to inspect system health and receive feedback after deployment. Through this post, we will learn how to monitor a microservice architecture with Elastic (formerly ELK) Stack.

You may also like: Logging With the Elastic Stack

We will cover how to use JHipster to build a microservice architecture and add OpenID Connect to it for authentication. We’ll also learn how to install and enable JHipster Console and ELK Stack in Docker containers to observe microservice infrastructure.

The Evolution of the Elastic Stack

The acronym ELK stands for Elasticsearch, Logstash, and Kibana, three open-source projects that form a powerful stack for log ingestion and visualization, log search, event analysis, and helpful visual metrics for monitoring applications.

Elasticsearch is the heart of the stack: a JSON-based search and analytics engine, distributed and scalable. It was built on top of Apache Lucene and provides a JSON REST API, cluster management, high availability, and fault tolerance.

Logstash is an ETL (extract, transform, load) tool to enrich documents, run data processing pipelines. These pipelines ingest data from multiple sources, transform and send it to Elasticsearch.

Kibana provides the visualization front-end, a window into the Elastic Stack. With dashboards and visualization elements, the data stored in Elasticsearch can be explored, aggregated, and analyzed.

From version 7 on, the ELK Stack was renamed to Elastic Stack and added Beats to the stack. Beats is a family of lightweight data shippers that work with Elasticsearch and Logstash.

Set Up the Elastic Stack

Elastic has published a Docker Compose configuration, to demonstrate the stack components on a single machine. Install Docker and Docker Compose and follow these steps to start up the stack:

Windows users must configure two environment variables, check out the instructions on the stack-docker github repository.

Allow at least 4GB of RAM for the containers, also check out instructions for your environment.

1. Clone the stack-docker repository.

 git clone https://github.com/elastic/stack-docker.git


2. Setup the stack with Docker Compose.

 cd stack-docker
 docker-compose -f setup.yml up


When the setup completes, it will output the password for the elastic user. On a slow connection, this can take up to 20 minutes. When it completes, you will see the following logs:

 setup_1  | Setup completed successfully. To start the stack please run:
 setup_1  |  docker-compose up -d
 setup_1  |
 setup_1  | If you wish to remove the setup containers please run:
 setup_1  | docker-compose -f docker-compose.yml -f docker-compose.setup.yml down --remove-orphans
 setup_1  |
 setup_1  | You will have to re-start the stack after removing setup containers.
 setup_1  |
 setup_1  | Your 'elastic' user password is: Z8GFVXu9UVsBrM6nup5fHw==
 stack-docker_setup_1 exited with code 0


3. Launch the stack.

Start the stack in the foreground to watch the containers logs:

 docker-compose up


When you see Kibana log the response to health check requests sent by the Beats family and you see at least one heartbeat entry in the logs, you can try the login (step 4 below):

You may notice exceptions in the log output. For this demonstration, they can be safely ignored. If you run into any issues with docker, you can start fresh with:

 docker container ls -a | cut -c1-12 | xargs docker container rm --force
 docker images | cut -c69-80 | xargs docker rmi
 docker system prune -a


NOTE: This will destroy all docker containers, images, and networks, so use at your own risk.

4. Go to http://localhost:5601 to log into Kibana.

Once you log in (using the elastic user and the password you captured above), explore the installed dashboards from the Dashboards section via the menu on the left. Heartbeat is one of the Beat services that monitors the uptime of your service from a provided list of URLs. Open the dashboard Heartbeat HTTP monitoring and see the power of the stack for data visualization.

Heartbeat HTTP Monitoring

The JHipster Console

The Jhipster Console, an awesome monitoring solution based on the Elastic Stack, allows the visualization and analysis of JHipster application metrics over time. The Console provides pre-configured dashboards to monitor microservices infrastructure. You can review the complete list of features in JHipster Console’s documentation.

One of the easier ways to start with the JHipster Console is to deploy the applications and enable monitoring with the docker-compose sub-generator. You’ll use this to:

  • Create a microservices architecture with JHipster.
  • Enable monitoring with JHipster Console.
  • Configure OpenID Connect for authentication to microservices.

Create a Java Microservices Architecture With JHipster

To install a version of JHipster that will work here, you need to install Node.js.

Install JHipster

npm install -g generator-jhipster@6.3.1
jhipster --version


The version command should output something like this:

INFO! Using JHipster version installed globally
6.3.1


Create a directory for the project:

mkdir jhipster
cd jhipster


Create apps.jh to define store, blog, and gateway microservices in JHipster Domain Language (JDL). We are going to recreate a Java-based example of microservices architecture we have built before for this tutorial.

application {
  config {
    baseName gateway,
    packageName com.okta.developer.gateway,
    applicationType gateway,
    authenticationType oauth2,
    prodDatabaseType postgresql,
    serviceDiscoveryType eureka,
    testFrameworks [protractor]
  }
  entities Blog, Post, Tag, Product
}

application {
  config {
    baseName blog,
    packageName com.okta.developer.blog,
    applicationType microservice,
    authenticationType oauth2,
    prodDatabaseType postgresql,
    serverPort 8081,
    serviceDiscoveryType eureka
  }
  entities Blog, Post, Tag
}

application {
  config {
    baseName store,
    packageName com.okta.developer.store,
    applicationType microservice,
    authenticationType oauth2,
    databaseType mongodb,
    devDatabaseType mongodb,
    prodDatabaseType mongodb,
    enableHibernateCache false,
    serverPort 8082,
    serviceDiscoveryType eureka
  }
  entities Product
}

entity Blog {
  name String required minlength(3),
  handle String required minlength(2)
}

entity Post {
  title String required,
  content TextBlob required,
  date Instant required
}

entity Tag {
  name String required minlength(2)
}

entity Product {
  title String required,
  price BigDecimal required min(0),
  image ImageBlob
}

relationship ManyToOne {
  Blog{user(login)} to User,
  Post{blog(name)} to Blog
}

relationship ManyToMany {
  Post{tag(name)} to Tag{post}
}

paginate Post, Tag with infinite-scroll
paginate Product with pagination

microservice Product with store
microservice Blog, Post, Tag with blog


Now, in your jhipster folder, run the import-jdl generator.

jhipster import-jdl apps.jh


Deploy Monitoring Using Docker-Compose

In the project folder, create a subfolder for the docker-compose configuration and run the sub-generator.

mkdir docker-compose
cd docker-compose
jhipster docker-compose


The generator will ask you to define the following configurations:

  1. Type of application: Microservices application.
  2. Type of gateway: JHipster based on Zuul.
  3. Which applications to include: blog, gateway, store.
  4. If the database is clustered: no.
  5. if monitoring must be enabled: yes, with JHipster console.
  6. Additional technologies for monitoring: Zipkin.
  7. Password for JHipster Registry: default.

When the generator has almost finished, a warning shows in the output:

WARNING! Docker Compose configuration generated, but no Jib cache found
If you forgot to generate the Docker image for this application, please run:
To generate the missing Docker image(s), please run:
  ./mvnw package -Pprod verify jib:dockerBuild in /home/indiepopart/jhipster/blog
  ./mvnw package -Pprod verify jib:dockerBuild in /home/indiepopart/jhipster/gateway
  ./mvnw package -Pprod verify jib:dockerBuild in /home/indiepopart/jhipster/store


You can follow the instructions above for creating the microservices images or create an aggregator pom.xml and use just one command for building all the images, as described in our post on Java microservices.

Setup Okta OpenID Connect (OIDC) Authentication for Your Microservices

By default, the microservices architecture authenticates against Keycloak. Update the settings to use Okta as the authentication provider:

First of all, go to Okta for a free developer account.

Once you log in, click Your Org, and it will take you to the Developer Console. Go to the Applications section and add a new Web Application. Set the following authentication settings:

  • Name: give a name for your application.
  • Base URIs: http://localhost:8761 and http://localhost:8080
  • Login redirect URIs: http://localhost:8080/login/oauth2/code/oidc and http://localhost:8761/login/oauth2/code/oidc
  • Grant Type Allowed: Authorization Code and Refresh Token.

For simplicity, this tutorial only creates Web App, and its credentials will be used for all the services. In a real environment, each service must identify itself with its own credentials, and you should create one Web App or Service for each one of them in the Okta console.

Copy the Client ID and Client secret, as we will use it for the application’s setup. Find the Org URL at the top right corner in the Okta Dashboard.

Create a docker-compose/.env file with the following content:

OIDC_CLIENT_ID=<client_id>
OIDC_CLIENT_SECRET=<client_secret>
RESOURCE_ISSUER_URI=<org_url>/oauth2/default


Edit docker-compose/docker-compose.yml and update the SECURITY_* settings for the services blog-app, gateway-app, and store-app:

SPRING_SECURITY_OAUTH2_CLIENT_PROVIDER_OIDC_ISSUER_URI=${RESOURCE_ISSUER_URI}
SPRING_SECURITY_OAUTH2_CLIENT_REGISTRATION_OIDC_CLIENT_ID=${OIDC_CLIENT_ID}
SPRING_SECURITY_OAUTH2_CLIENT_REGISTRATION_OIDC_CLIENT_SECRET=${OIDC_CLIENT_SECRET}


The same authentication must be set up for the JHipster Registry. Edit docker-compose/jhipster-registry.yml and set the same values as the environment section of the gateway-app.

JHipster applications require specific user roles ROLE_USER and ROLE_ADMIN as claims in the ID Token. In the Okta Developer Console, go to Users > Groups and create a group for each JHipster role, and add users to each group.

Now go to API > Authorization Servers, select the default server and Add Claim with the following settings:

  1. Name: groups
  2. Include in token type: ID Token, Always
  3. Value type: Groups
  4. Filter: Matches regex, set the Regex to .*

Enable Debug Logs and Zipkin

To send debug logs to the JHipster Console, let’s update the log level in the prod profile. Edit src/main/resources/config/application-prod.yml to set the level for each service (blog-app, store-app, and gateway-app) to DEBUG for the com.okta.developer.* logger. For example, in the blog’s application-prod.yml:

logging:
    level:
        com.okta.developer.blog: DEBUG


Also, for each service, update the LoggingAspectConfiguration to load when the prod profile is active. Change the @Profile annotation:

@Configuration
@EnableAspectJAutoProxy
public class LoggingAspectConfiguration {

    @Bean
    @Profile({JHipsterConstants.SPRING_PROFILE_DEVELOPMENT, JHipsterConstants.SPRING_PROFILE_PRODUCTION})
    public LoggingAspect loggingAspect(Environment env) {
        return new LoggingAspect(env);
    }
}


Zipkin is a distributed tracing system that helps to troubleshoot latency issues in microservices architectures. With a traceId propagated from service to service, calls to different services can be correlated and analyzed as a part of the same flow. The Zipkin server and UI are provided with the JHipster Console, and JHipster apps can integrate with Zipkin through Spring Cloud Sleuth. To enable Zipkin tracing, add the zipkin profile to blog-app, gateway-app, and store-app in docker-compose/docker-compose.yml.

- SPRING_PROFILES_ACTIVE=prod,swagger,zipkin


You also need to rebuild the Docker images with the zipkin profile, for blog-app, store-app, and gateway-app with the following Maven command:

./mvnw package -Pprod -Pzipkin verify jib:dockerBuild -DskipTests


ProTip: If you’re on a system with the bash shell, like Linux or macOS, you can do this from the jhipster folder to build each project at once:

for i in blog gateway store
do
cd $i
./mvnw package -Pprod -Pzipkin verify jib:dockerBuild -DskipTests
cd ..
done


Run the Monitored Microservices Architecture

Are you ready for the best? Go to the docker-compose folder and start the services with the following command:

docker-compose up


You will see a huge amount of logging while each service starts.

jhipster-registry_1           | ----------------------------------------------------------
jhipster-registry_1           | Application 'jhipster-registry' is running! Access URLs:
jhipster-registry_1           | Local: http://localhost:8761
jhipster-registry_1           | External: http://172.20.0.2:8761
jhipster-registry_1           | Profile(s): [composite, dev, swagger, oauth2]
jhipster-registry_1           | ----------------------------------------------------------


Log into the JHipster Registry at http://localhost:8761 with Okta user credentials and check the service’s health.

JHipster Registry

Once all the services are up, log in to the gateway application and create some blogs and posts to generate traffic. To do this, use the Entities menu at the top left of the application. The gateway home is at http://localhost:8080.

The fun part! Access the JHipster Console at http://localhost:5601. Go to the Dashboards section, and open the requests-dashboard. You should see some nice curves:

Requests Dashboard


Since you integrated the JHipster Console with Zipkin UI, in the traces-dashboard, you can find the longest traces duration on the left. If you click on a traceId on the right, it will open the trace in the UI and you will be able to examine the flow.

zipkin ui


Further Reading

ELK Stack Overview and Use Cases

Logging With Spring Boot and Elastic Stack

Installing Elastic Stack in a Single Click Using Docker Compose

microservice Architecture JHipster Docker (software) application Monitor (synchronization) Web Service Console (video game CLI) Spring Framework authentication

Published at DZone with permission of Jimena Garbarino, DZone MVB. See the original article here.

Opinions expressed by DZone contributors are their own.

Related

  • 7 Microservices Best Practices for Developers
  • Microservices With JHipster
  • How Your Application Architecture Has Evolved
  • How To Implement OAuth2 Security in Microservices

Partner Resources

×

Comments
Oops! Something Went Wrong

The likes didn't load as expected. Please refresh the page and try again.

ABOUT US

  • About DZone
  • Support and feedback
  • Community research
  • Sitemap

ADVERTISE

  • Advertise with DZone

CONTRIBUTE ON DZONE

  • Article Submission Guidelines
  • Become a Contributor
  • Core Program
  • Visit the Writers' Zone

LEGAL

  • Terms of Service
  • Privacy Policy

CONTACT US

  • 3343 Perimeter Hill Drive
  • Suite 100
  • Nashville, TN 37211
  • support@dzone.com

Let's be friends:

Likes
There are no likes...yet! 👀
Be the first to like this post!
It looks like you're not logged in.
Sign in to see who liked this post!
