Mule Message Encryption With JCE Keystore

The second post on Mule Message Encryption, this time using Keystore with the JCE.

· Security Zone ·
Free Resource


This is the second part of my previous post. In the previous post in the JCE Encrypter configuration I did not use Keystore. Here in this post I will create a Keystore and use it for encryption.

Getting Your Hands Dirty

First we will create a Keystore using Keytool that comes with JDK. After that we will create a simple project and use the generated keystore for message encryption.

Create Keystore

JDK comes with its inbuilt tool Keytool to create keystores. First let’s create a keystore using the native Keytool.

Let’s create a temporary directory. I have created a temporary directory named as encryption as shown below,

Temporary directory

Now let’s execute the following command:

keytool -genseckey -keystore aes-ackeystore.jck -storetype jceks -storepass acstorepass -keyalg AES -keysize 128 -alias ackey -keypass ackeypass

After execution of the command a keystore aes-ackeystore.jck is generated in the directory.Basic things to point out in the command are as follows,

Name of the keystore: aes-ackeystore.jck

Password of the keystore: acstorepass

Name of the key: ackey

Password of the key: ackeypass

These are the principal information that we need to configure our JCE Encrypter using keystore.

Create a Simple Mule Project

Please strongly refer to the post for Anypoint Enterprise Security module installation. Let’s create a simple Mule Maven project using Anypoint Studio. The most important point is to add the following repository in the pom.xml file.

   <name>MuleSoft Public Repository</name>

Please note that I have copied the generated keystore (in the previous step) to the resource folder of the project. Here is a screenshot of the project structure.

Project Structure

Creating a Simple Flow

Let’s create a simple flow. The scenario is as follows. We send some JSON data to an HTTP endpoint. Then the JSON data is encrypted using JCE Encryption Strategy and we log the encrypted data. After that we simply decrypt the encrypted data and log it. Here is diagram of the flow.

Simple Flow

Digging Into JCE Encryption

Step 1

First let’s configure a global Encryption element.

Global Encryption element configuration

Do mind it to select the Default Encryptor dropdown as JCE_ENCRYPTER. I have named the global element as JCE_Keystore.

Then select the JCE Encrypter tab and configure it as shown in the diagram,

Configure Keystore

Step 2

Now after configuring the global Encryption element in step 1 let’s configure the Encryption component (labeled as Encrypt in the flow. This is an Encryption palette found under the Security category of Mule palettes). Here is the screen shot,

Encryption palette configuration.

In the Connector Configuration please select the global encryption element(JCE_Keystore) that we have defined in step 1. In the Operation dropdown select Encrypt. In the Input Reference field I am putting the whole payload (JSON data) for encryption. Do remember that you can use MEL expression here to encrypt some part of the payload too. And that’s it. No more configuration is needed and you are ready to go.

Step 3

In the step 2 we have encrypted the message. Now let’s decrypt the encrypted message. Here we are going to configure the component labelled as Decrypt. It’s nothing but an Encryption palette found under the Security category of Mule palettes. Here is the configuration:

Decryption Configuration

The configuration is almost same as that for encryption. The only difference is the Operation: Decrypt.


Now let us run the project. After running the project, send a POST request with JSON payload. I am using Postman for this operation. On observing in the Anypoint console you can see the encrypted message as well as decrypted message.


Sample log in Anypoint console:

INFO  2016-12-10 21:23:26,602 [[springbeanexample].HTTP_8081.worker.01] org.mule.api.processor.LoggerMessageProcessor: XjeegDtusFQSovOSxqZgr1j5oCUYypD4/7X6NjworIQ=
INFO  2016-12-10 21:23:26,613 [[springbeanexample].HTTP_8081.worker.01] org.mule.api.processor.LoggerMessageProcessor: {

Please find the source code here.
