Optimizing Serverless Computing with AWS Lambda Layers and CloudFormation

Recent advancements in cloud computing and serverless architectures have already changed the way applications are created. Among the most widely acknowledged services for serverless computing is AWS Lambda, which enables the execution of code without managing any servers. On the other hand, a large-scale application generally contains many dependencies and maintainable configurations.

This article examines how AWS Lambda layers and CloudFormation can be used to develop scalable, efficient, and maintainable serverless systems.

What are AWS Lambda Layers?

Lambda Layers solve common issues faced in serverless development, such as management of common dependencies among functions, deployable package optimizations, and developer productivity. The advantages of Lambda layers are best seen in large applications built out of multiple functions that depend on internally developed utility libraries and commonly used third-party libraries.

Key advantages of using AWS Lambda layers can be summarized thus:

1. The ability to leverage existing competencies

Lambda layers promote compliance with the Don't Repeat Yourself (DRY) principle. Rather than having redundant dependencies or common logic as part of a given Lambda function, such elements are grouped together and encapsulated in a single layer to allow sharing across many functions. This benefits the elimination of duplicate code and promotes the consistent application of common libraries or logic. For example, an organization using the requests library for HTTP calls in 10 different Lambda functions can create a layer with that library and attach it to all relevant functions, rather than packaging requests in each one.

2. Small payload sizes

AWS Lambda has packaging size limits: maximum compressed size of 50 MB and a maximum unpacked size of 250 MB. Many dependencies, especially those relevant to data science like NumPy, Pandas, and SciPy, add to the larger sizes of packages. By using layers on such dependencies, it becomes easier to have a clean function package. Now that the package is used to purely focus on the core business logic.

3. Improved Evaluation and Maintenance

Lambda layers eliminate the need to update each function when changes are required to a common dependency. Only the layer has to be updated, then a new version is published, and then linked to the dependent functions.

4. Better version control

An pdate at the layer level causes a fresh version to be generated. This facilitates the selection of the particular version of the layer used by any specified function and hence offers full control of the deployment life cycle. Besides ensuring backward compatibility, the versioning model also makes it easier to implement test protocols as a precursor to mass deployments in all functions.

5. Custom Execution Contexts and Extra Functionality

Lambda layers make it possible to integrate personalized runtime environments, thus enabling developers to implement programming languages that the Lambda runtime doesn't support natively. Secondly, additional features like a custom Ruby or PHP runtime are enabled by these layers. Thirdly, Datadog and New Relic type monitoring solutions can also be integrated in order to increase overall observability.

6. Isolation and Security

Segregation of confidential configuration files, software development toolkits (SDKs), or tools into separate layers makes it easier for teams to manage their governance in terms of managing access. These layers are shareable across multiple accounts using the AWS Resource Access Manager (RAM) and restricted further using IAM permissions.

Lambda Layers with CloudFormation to Optimize

AWS Lambda layers integrate with CloudFormation for seamless deployment and infrastructure maintenance.

These are the steps towards optimizing serverless computing:

Step 1: Create a Lambda layer

1. Prepare the dependencies: Create a folder structure with all the dependencies within::

   Shell



   mkdir python
   pip install requests -t python/




2. Zip the layer content:

   Shell



   zip -r layer.zip python/




3. Upload the layer to AWS:

   Shell



   aws lambda publish-layer-version --layer-name MyLayer --zip-file fileb://layer.zip --compatible-runtimes python3.8




4. Save the layer ARN: Make a note of the ARN that AWS returns so it can be used with CloudFormation..

Step 2: Define the Lambda layer in CloudFormation

Resources:
  MyLayer:
    Type: AWS::Lambda::LayerVersion
    Properties:
      LayerName: MyLayer
      CompatibleRuntimes:
        - python3.8
      Content:
        S3Bucket: my-layer-bucket
        S3Key: layer.zip

Step 3: Using the Layer with a Lambda function

Resources:
  MyFunction:
    Type: AWS::Lambda::Function
    Properties:
      FunctionName: MyFunction
      Runtime: python3.8
      Handler: app.handler
      Code:
        S3Bucket: my-code-bucket
        S3Key: my-code.zip
      Layers:
        - !Ref MyLayer
      Role: !GetAtt MyLambdaExecutionRole.Arn

Step 4: Automate the deployment using CloudFormation

aws cloudformation deploy --template-file template.yaml --stack-name MyServerlessApp

Use Case: API Backend Optimization

Scenario: A serverless API has been developed where a number of Lambda functions depend on common dependencies like requests and boto3.

Problem: Repeated dependencies increase package size and slow deployment.

Solution:

• Put the common dependencies into a Lambda layer.
• Use CloudFormation for declaring layers and functions.
• Refer to one shared layer from multiple functions and avoid redundancy.



Best Practices of Lambda Layers with CloudFormation

• Version layers appropriately: Semantic versioning will allow for the tracking of updates.
• Optimize layer content: Include only the necessary dependencies, keeping in mind the size.
• Leverage S3 for large files: Store larger layers in S3 and reference them in CloudFormation.
• Test compatibility: Test the compatibility of the layers with AWS Lambda runtimes.
• Monitor usage: Monitoring through AWS CloudWatch will be helpful in observing the performance and requests per layer.

Benefits of Combining Lambda Layers and CloudFormation

• Efficiency: Providing smooth development and deployment processes.
• Scalability: Easily replicate architectures across environments.
• Cost Savings: Minimize storage and duplication of dependencies.
• Maintainability: Simplify updates and version management.

Conclusion

AWS Lambda layers and CloudFormation are indeed very powerful solutions that can be used to optimize serverless architecture. Decoupling dependencies with automated infrastructure provisioning will enable developers to build scalable, efficient, and maintainable applications. Be it small project development or enterprise system management, integration will certainly reduce the overhead while letting innovations begin.

Transform your serverless workflow by combining Lambda layers and CloudFormation today.
