Spring Boot: Integrating With Bootstrap and jQuery Using Web Jars

DZone's Guide to

Spring Boot: Integrating With Bootstrap and jQuery Using Web Jars

In this article, we'll learn how to add the dependencies for Bootstrap and jQuery web jars and create a simple JSP view using jQuery and Bootstrap.

· Integration Zone ·
Free Resource

The new Gartner Critical Capabilities report explains how APIs and microservices enable digital leaders to deliver better B2B, open banking and mobile projects.

This guide will help you create a simple web application with Spring Boot. We will add the dependencies for Bootstrap and jQuery web jars. We will create a simple JSP view using jQuery and Bootstrap.

You Will Learn

  • How to bootstrap a simple project with Spring Initializr.
  • How to initialize a basic web application for Spring Boot.
  • How to add a JSP to a web application.
  • How to add web jars to jQuery and Bootstrap.
  • How to create a simple view using jQuery and Bootstrap.

Tools You Will Need

  • Maven 3.0+ is your build tool.
  • Your favorite IDE. We use Eclipse.
  • JDK 1.8+

Overview of the Web application

We will build a static todo page (un-formatted) rendered using a JSP.

Files

A brief overview of all our files:

  • SpringBootWebApplicationBootstrapJqueryApplication.java - Spring Boot Application class. This initialized the Spring Boot application with auto-configuration.
  • WelcomeController.java - A Controller with a method to redirect to the view - JSP.
  • welcome.jsp - The view - uses Jquery and Bootstrap.
  • pom.xml - We will add the web jar dependencies for Bootstrap and jQuery to pom.xml.
  • application.properties - This is typically used to configure frameworks in Spring Boot. In this example, we will configure our view resolver in application.properties.

Complete project on GitHub

Bootstrapping a Web Application With Spring Initializr

Creating a web application with Spring Initializr is a cake walk.

Spring Initializr is a great tool to bootstrap your Spring Boot projects.

As shown in the image above, the following steps have to be done:

  • Launch Spring Initializr and choose the following:
    • Choose com.in28minutes.springboot.web.application as the Group.
    • Choose spring-boot-web-application-bootstrap-jquery as the Artifact.
    • Choose the following dependencies:
      • Web
      • Actuator
      • DevTools
  • Click Generate Project.
  • Import the project into Eclipse.

Project Dependencies

Spring Boot Starter Web provides all the dependencies and the auto-configuration needed to develop web applications. It is the first dependency we will use.

<dependency>
    <groupId>org.springframework.boot</groupId>
    <artifactId>spring-boot-starter-web</artifactId>
</dependency>

We want to use JSP as the view. The default embedded servlet container for Spring Boot Starter Web is Tomcat. To enable support for JSPs, we would need to add a dependency on tomcat-embed-jasper.

<dependency>
    <groupId>org.apache.tomcat.embed</groupId>
    <artifactId>tomcat-embed-jasper</artifactId>
    <scope>provided</scope>
</dependency>

Configuring a View Resolver

We would have our JSPs in /WEB-INF/jsp/. We would need to configure the view resolver with the prefix and suffix.

spring.mvc.view.prefix=/WEB-INF/jsp/
spring.mvc.view.suffix=.jsp

Controller

Let's add in a simple controller redirecting to the view:

/src/main/java/com/in28minutes/springboot/tutorial/basics/application/configuration/WelcomeController.java

@Controller
public class WelcomeController {
    @RequestMapping("/welcome")
    public String loginMessage(){
        return "welcome";
    }
}

The URL to this control method will be: http://localhost:8080/welcome.

Adding a View

Let's create a simple view with a basic HTML structure. We will create a basic table which we would want to format a little later.

/src/main/webapp/WEB-INF/jsp/welcome.jsp

<html>
<head>
    <title>Welcome</title>
</head>
<body>
    <div class="container">
        <table class="table table-striped">
            <caption>Your todos are</caption>
            <thead>
                <tr>
                    <th>Description</th>
                    <th>Target Date</th>
                    <th>Is it Done?</th>
                    <th>Edit</th>
                    <th>Delete</th>
                </tr>
            </thead>
            <tbody>
                    <tr>
                        <td>Todo 1</td>
                        <td>10/12/2017</td>
                        <td>No</td>
                        <td><a class="btn btn-warning" href="/edit-todo">Edit Todo</a></td>
                        <td><a class="btn btn-warning" href="/delete-todo">Delete Todo</a></td>
                    </tr>
            </tbody>
        </table>
        <div>
            <a class="btn btn-default" href="/add-todo">Add a Todo</a>

        </div>
    </div>
</body>
</html>

Webjars for jQuery and Bootstrap

Let's now add in the web jars to our pom.xml file:

<dependency>
    <groupId>org.webjars</groupId>
    <artifactId>bootstrap</artifactId>
    <version>3.3.6</version>
</dependency>

<dependency>
    <groupId>org.webjars</groupId>
    <artifactId>bootstrap-datepicker</artifactId>
    <version>1.0.1</version>
</dependency>

<dependency>
    <groupId>org.webjars</groupId>
    <artifactId>jquery</artifactId>
    <version>1.9.1</version>
</dependency>

Using Web Jars in View

Make sure that you restart the application and we are ready to use jquery and bootstrap in our project.

If you expand your dependencies you should see the dependencies.

Referring to bootstrap CSS:

<link href="webjars/bootstrap/3.3.6/css/bootstrap.min.css"
        rel="stylesheet">

Referring to Bootstrap JS:

<script src="webjars/bootstrap/3.3.6/js/bootstrap.min.js"></script>

Referring to jQuery JS:

<script src="webjars/jquery/1.9.1/jquery.min.js"></script>

Update the view using jQuery and Bootstrap as shown below.

/src/main/webapp/WEB-INF/jsp/welcome.jsp

<html>
<head>
    <title>Welcome</title>
    <link href="webjars/bootstrap/3.3.6/css/bootstrap.min.css"
        rel="stylesheet">
</head>
<body>
    <div class="container">
        <table class="table table-striped">
            <caption>Your todos are</caption>
            <thead>
                <tr>
                    <th>Description</th>
                    <th>Target Date</th>
                    <th>Is it Done?</th>
                    <th>Edit</th>
                    <th>Delete</th>
                </tr>
            </thead>
            <tbody>
                    <tr>
                        <td>Todo 1</td>
                        <td>10/12/2017</td>
                        <td>No</td>
                        <td><a class="btn btn-warning" href="/edit-todo">Edit Todo</a></td>
                        <td><a class="btn btn-warning" href="/delete-todo">Delete Todo</a></td>
                    </tr>
            </tbody>
        </table>
        <div>
            <a class="btn btn-default" href="/add-todo">Add a Todo</a>

        </div>
        <script src="webjars/jquery/1.9.1/jquery.min.js"></script>
        <script src="webjars/bootstrap/3.3.6/js/bootstrap.min.js"></script>
    </div>
</body>
</html>

Spring Boot will auto-configure the web jars resource mapping. So you DON'T need to do this anymore.

Complete Code Example

/pom.xml

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>

    <groupId>com.in28minutes.springboot.web.application</groupId>
    <artifactId>spring-boot-web-application-bootstrap-jquery</artifactId>
    <version>0.0.1-SNAPSHOT</version>
    <packaging>jar</packaging>

    <name>spring-boot-web-application-bootstrap-jquery</name>
    <description>Spring Boot Tutorial - Adding Bootstrap and jQuery to Web Application</description>

    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.0.0.M6</version>
        <relativePath /> <!-- lookup parent from repository -->
    </parent>

    <properties>
        <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
        <project.reporting.outputEncoding>UTF-8</project.reporting.outputEncoding>
        <java.version>1.8</java.version>
    </properties>

    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>

        <dependency>
            <groupId>org.webjars</groupId>
            <artifactId>bootstrap</artifactId>
            <version>3.3.6</version>
        </dependency>

        <dependency>
            <groupId>org.webjars</groupId>
            <artifactId>bootstrap-datepicker</artifactId>
            <version>1.0.1</version>
        </dependency>

        <dependency>
            <groupId>org.webjars</groupId>
            <artifactId>jquery</artifactId>
            <version>1.9.1</version>
        </dependency>

        <dependency>
            <groupId>org.apache.tomcat.embed</groupId>
            <artifactId>tomcat-embed-jasper</artifactId>
            <scope>provided</scope>
        </dependency>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-devtools</artifactId>
            <scope>runtime</scope>
        </dependency>

        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>
    </dependencies>

    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
            </plugin>
        </plugins>
    </build>

    <repositories>
        <repository>
            <id>spring-snapshots</id>
            <name>Spring Snapshots</name>
            <url>https://repo.spring.io/snapshot</url>
            <snapshots>
                <enabled>true</enabled>
            </snapshots>
        </repository>
        <repository>
            <id>spring-milestones</id>
            <name>Spring Milestones</name>
            <url>https://repo.spring.io/milestone</url>
            <snapshots>
                <enabled>false</enabled>
            </snapshots>
        </repository>
    </repositories>

    <pluginRepositories>
        <pluginRepository>
            <id>spring-snapshots</id>
            <name>Spring Snapshots</name>
            <url>https://repo.spring.io/snapshot</url>
            <snapshots>
                <enabled>true</enabled>
            </snapshots>
        </pluginRepository>
        <pluginRepository>
            <id>spring-milestones</id>
            <name>Spring Milestones</name>
            <url>https://repo.spring.io/milestone</url>
            <snapshots>
                <enabled>false</enabled>
            </snapshots>
        </pluginRepository>
    </pluginRepositories>


</project>

/src/main/java/com/in28minutes/springboot/tutorial/basics/application/configuration/SpringBootWebApplicationBootstrapJqueryApplication.java

package com.in28minutes.springboot.tutorial.basics.application.configuration;

import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;

@SpringBootApplication
public class SpringBootWebApplicationBootstrapJqueryApplication {

    public static void main(String[] args) {
        SpringApplication.run(SpringBootWebApplicationBootstrapJqueryApplication.class, args);
    }
}

/src/main/java/com/in28minutes/springboot/tutorial/basics/application/configuration/WelcomeController.java

package com.in28minutes.springboot.tutorial.basics.application.configuration;
import org.springframework.stereotype.Controller;
import org.springframework.web.bind.annotation.RequestMapping;

@Controller
public class WelcomeController {
    @RequestMapping("/welcome")
    public String loginMessage(){
        return "welcome";
    }
}

/src/main/resources/application.properties

spring.mvc.view.prefix=/WEB-INF/jsp/
spring.mvc.view.suffix=.jsp
logging.level.org.springframework.web=INFO

/src/main/resources/static/css/custom.css

body {
    background-color: lightblue;
}

/src/main/resources/static/js/custom.js

alert("I'm active");

/src/main/webapp/WEB-INF/jsp/welcome.jsp

<html>
<head>
    <title>Welcome</title>
    <link href="webjars/bootstrap/3.3.6/css/bootstrap.min.css"
        rel="stylesheet">
    <link href="css/custom.css"
        rel="stylesheet">
</head>
<body>
    <div class="container">
        <table class="table table-striped">
            <caption>Your todos are</caption>
            <thead>
                <tr>
                    <th>Description</th>
                    <th>Target Date</th>
                    <th>Is it Done?</th>
                    <th>Edit</th>
                    <th>Delete</th>
                </tr>
            </thead>
            <tbody>
                    <tr>
                        <td>Todo 1</td>
                        <td>10/12/2017</td>
                        <td>No</td>
                        <td><a class="btn btn-warning" href="/edit-todo">Edit Todo</a></td>
                        <td><a class="btn btn-warning" href="/delete-todo">Delete Todo</a></td>
                    </tr>
            </tbody>
        </table>
        <div>
            <a class="btn btn-default" href="/add-todo">Add a Todo</a>

        </div>
        <script src="webjars/jquery/1.9.1/jquery.min.js"></script>
        <script src="webjars/bootstrap/3.3.6/js/bootstrap.min.js"></script>
        <script src="js/custom.js"></script>
    </div>
</body>
</html>

/src/test/java/com/in28minutes/springboot/tutorial/basics/application/configuration/SpringBootWebApplicationBootstrapJqueryApplicationTests.java

package com.in28minutes.springboot.tutorial.basics.application.configuration;

import org.junit.Test;
import org.junit.runner.RunWith;
import org.springframework.boot.test.context.SpringBootTest;
import org.springframework.test.context.junit4.SpringRunner;

@RunWith(SpringRunner.class)
@SpringBootTest
public class SpringBootWebApplicationBootstrapJqueryApplicationTests {

    @Test
    public void contextLoads() {
    }

}

The new Gartner Critical Capabilities for Full Lifecycle API Management report shows how CA Technologies helps digital leaders with their B2B, open banking, and mobile initiatives. Get your copy from CA Technologies.

Topics:
bootstrap ,jquery ,spring boot ,integration

Published at DZone with permission of

Opinions expressed by DZone contributors are their own.

{{ parent.title || parent.header.title}}

{{ parent.tldr }}

{{ parent.urlSource.name }}
