Streaming Data with Spring Boot RESTful Web Service

Streaming data is a radical new approach to sending data to web browsers which provides for dramatically faster page load times. Quite often, we need to allow users to download files in web applications. When the data is too large, it becomes quite a challenge to provide a good user experience.

Spring offers support for asynchronous request processing via StreamingResponseBody. In this approach, an application can write data directly to the response OutputStream without holding up the Servlet container thread. There are a few other methods in Spring to handle asynchronous request processing.

In this article, we are going to look at an example to download files using StreamingResponseBody. In this approach, data is processed and written in chunks to the OutputStream.

Setting Up Spring Boot Project

Create a sample Spring Boot application. Here is my sample project structure. I have created the project manually, but you could also create using Spring Intializer.

Let us add some basic dependencies to Maven POM.

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>

    <groupId>com.techshard.streamingresponse</groupId>
    <artifactId>springboot-download</artifactId>
    <version>1.0-SNAPSHOT</version>

    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.1.4.RELEASE</version>
        <relativePath />
    </parent>

    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-actuator</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-security</artifactId>
        </dependency>
        <dependency>
            <groupId>org.slf4j</groupId>
            <artifactId>slf4j-api</artifactId>
        </dependency>
        <dependency>
            <groupId>org.apache.commons</groupId>
            <artifactId>commons-io</artifactId>
            <version>1.3.2</version>
        </dependency>
    </dependencies>
</project>

We will now create a controller and add an API endpoint for download. Here is my complete controller.

package com.techshard.download.controller;

import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.http.HttpStatus;
import org.springframework.http.MediaType;
import org.springframework.http.ResponseEntity;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;
import org.springframework.web.servlet.mvc.method.annotation.StreamingResponseBody;

import javax.servlet.http.HttpServletResponse;
import java.io.*;
import java.util.zip.ZipEntry;
import java.util.zip.ZipOutputStream;

@RestController
@RequestMapping ("/api")
public class DownloadController {

    private final Logger logger = LoggerFactory.getLogger(DownloadController.class);

    @GetMapping (value = "/download", produces = MediaType.APPLICATION_JSON_VALUE)
    public ResponseEntity<StreamingResponseBody> download(final HttpServletResponse response) {

        response.setContentType("application/zip");
        response.setHeader(
                "Content-Disposition",
                "attachment;filename=sample.zip");

        StreamingResponseBody stream = out -> {

            final String home = System.getProperty("user.home");
            final File directory = new File(home + File.separator + "Documents" + File.separator + "sample");
            final ZipOutputStream zipOut = new ZipOutputStream(response.getOutputStream());

            if(directory.exists() && directory.isDirectory()) {
                try {
                    for (final File file : directory.listFiles()) {
                        final InputStream inputStream=new FileInputStream(file);
                        final ZipEntry zipEntry=new ZipEntry(file.getName());
                        zipOut.putNextEntry(zipEntry);
                        byte[] bytes=new byte[1024];
                        int length;
                        while ((length=inputStream.read(bytes)) >= 0) {
                            zipOut.write(bytes, 0, length);
                        }
                        inputStream.close();
                    }
                    zipOut.close();
                } catch (final IOException e) {
                    logger.error("Exception while reading and streaming data {} ", e);
                }
            }
        };
        logger.info("steaming response {} ", stream);
        return new ResponseEntity(stream, HttpStatus.OK);
    }
}

In this API endpoint, we are reading multiple files from a directory and creating a zip file. We are executing this process within  StreamingResponseBody. It writes data directly to an OutputStream before passing that written information back to the client using aResponseEntity. This means that the download process will start immediately on the client, while the server is processing and writing data in chunks.

Start the server and test this endpoint using http://localhost:8080/api/download.

When using StreamingResponseBody, it is highly recommended to configure TaskExecutor used in Spring MVC for executing asynchronous requests. TaskExecutor is an interface that abstracts the execution of a Runnable.

package com.techshard.download;

import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.aop.interceptor.AsyncUncaughtExceptionHandler;
import org.springframework.aop.interceptor.SimpleAsyncUncaughtExceptionHandler;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.core.task.AsyncTaskExecutor;
import org.springframework.scheduling.annotation.AsyncConfigurer;
import org.springframework.scheduling.annotation.EnableAsync;
import org.springframework.scheduling.annotation.EnableScheduling;
import org.springframework.scheduling.concurrent.ThreadPoolTaskExecutor;
import org.springframework.web.context.request.NativeWebRequest;
import org.springframework.web.context.request.async.CallableProcessingInterceptor;
import org.springframework.web.context.request.async.TimeoutCallableProcessingInterceptor;
import org.springframework.web.servlet.config.annotation.AsyncSupportConfigurer;
import org.springframework.web.servlet.config.annotation.WebMvcConfigurer;

import java.util.concurrent.Callable;

@Configuration
@EnableAsync
@EnableScheduling
public class AsyncConfiguration implements AsyncConfigurer {

    private final Logger log = LoggerFactory.getLogger(AsyncConfiguration.class);

    @Override
    @Bean (name = "taskExecutor")
    public AsyncTaskExecutor getAsyncExecutor() {
        log.debug("Creating Async Task Executor");
        ThreadPoolTaskExecutor executor = new ThreadPoolTaskExecutor();
        executor.setCorePoolSize(5);
        executor.setMaxPoolSize(10);
        executor.setQueueCapacity(25);
        return executor;
    }

    @Override
    public AsyncUncaughtExceptionHandler getAsyncUncaughtExceptionHandler() {
        return new SimpleAsyncUncaughtExceptionHandler();
    }

    /** Configure async support for Spring MVC. */
    @Bean
    public WebMvcConfigurer webMvcConfigurerConfigurer(AsyncTaskExecutor taskExecutor, CallableProcessingInterceptor callableProcessingInterceptor) {
        return new WebMvcConfigurer() {
            @Override
            public void configureAsyncSupport(AsyncSupportConfigurer configurer) {
                configurer.setDefaultTimeout(360000).setTaskExecutor(taskExecutor);
                configurer.registerCallableInterceptors(callableProcessingInterceptor);
                WebMvcConfigurer.super.configureAsyncSupport(configurer);
            }
        };
    }

    @Bean
    public CallableProcessingInterceptor callableProcessingInterceptor() {
        return new TimeoutCallableProcessingInterceptor() {
            @Override
            public <T> Object handleTimeout(NativeWebRequest request, Callable<T> task) throws Exception {
                log.error("timeout!");
                return super.handleTimeout(request, task);
            }
        };
    }
}
