Tutorial: MCUXpresso SDK With Linux, Part 3: RAM and XiP Code on i.MX RT1064

Check out this third installment on using the MCUXpresso SDK with Linux.

Erich Styger user avatar by
Erich Styger
·
May. 22, 19 · Tutorial
Like (2)
Save
Tweet
Share
6.93K Views

Join the DZone community and get the full member experience.

Join For Free

In my previous articles, I have used the command line on Linux to build and debug NXP MCUXpresso SDK applications. In this article, I’m running code on NXP i.MX RT1064 in RAM or FLASH.

i.MXRT1064 board with LPC845-BRK as debug probe

i.MXRT1064 board with LPC845-BRK as debug probe

Outline

In this tutorial, I’m going to run code in RAM and FLASH (XiP, eXecute in Place) on the i.MX RT1064. For getting started with the MCUXpresso SDK on Linux, I recommend to have a read at my previous articles:

  • Tutorial: MCUXpresso SDK with Linux, Part 1: Installation and Build with Make
  • Tutorial: MCUXpresso SDK with Linux, Part 2: Commandline Debugging with GDB

I’m using the command line on purpose in this article. The MCUXpresso IDE is available on Linux too and is usually a better and easier starting point for development.

I’m using Linux in an Oracle VM (Ubuntu) with the NXP MCUXpresso SDK for the i.MX RT1064 EVK board (see First Steps with the NXP i.MX RT1064-EVK Board).

NXP i.MX RT1064 Board

The board has different memory areas available:

  1. internal ITC SRAM, base address: 0x0000’0000, size 0x2’0000 (128 KByte)
  2. internal DTC SRAM, base address: 0x2000’0000, size 0x2’0000 (128 KByte)
  3. internal OC SRAM, base address: 0x2020’0000, size 0xC’0000 (768 KByte)
  4. internal SPI FLASH: base address: 0x7000’0000, size: 0x40’0000 (4 MByte)
  5. external SDRAM,base address 0x8000’0000, size 0x200’0000 (32 MByte)

There is an extra 64-MByte Hyperflash available on the board, but this requires adding/removing resistors on the backside of the board.

i.MX RT1064-EVK Board

i.MX RT1064-EVK Board

Running From FLASH (XiP)

The i.MX RT does not have FLASH memory integrated with the MCU, as it is the case for most microcontrollers. Instead, it uses a serial (SPI) FLASH memory, which usually is an external memory chip. In the case of the i.MX RT1064, there is a 4-MByte FLASH wired to the device internally. Technically, it is the same as having it externally, except that the needed board space is smaller. Because the CPU does not know about the FLASH, the FLASH need a special header programmed at the start of the memory which is read by the CPU. For this, the following defines need to be turned on:

XIP_EXTERNAL_FLASH=1
XIP_BOOT_HEADER_ENABLE=1


The SPI FLASH memory is not used for data as it usually is used on microcontrollers. Instead, the processor can execute code in it, which is called XiP or ‘eXecute in Place’.

The next thing is the linker file: The following file places that header, code, constants, and vector table into the external FLASH starting at address 0x7000’0000. The Data-Tightly-Coupled (DTC) RAM is used for the heap and stack.

GROUP (
  "libcr_nohost_nf.a"
  "libcr_c.a"
  "libcr_eabihelpers.a"
  "libgcc.a"
)

MEMORY
{
  /* Define each memory region */
  PROGRAM_FLASH (rx) : ORIGIN = 0x70000000, LENGTH = 0x400000 /* 4M bytes (alias Flash) */
  SRAM_DTC (rwx) : ORIGIN = 0x20000000, LENGTH = 0x20000 /* 128K bytes (alias RAM) */
  SRAM_ITC (rwx) : ORIGIN = 0x0, LENGTH = 0x20000 /* 128K bytes (alias RAM2) */
  SRAM_OC (rwx) : ORIGIN = 0x20200000, LENGTH = 0xc0000 /* 768K bytes (alias RAM3) */
  BOARD_SDRAM (rwx) : ORIGIN = 0x80000000, LENGTH = 0x2000000 /* 32M bytes (alias RAM4) */
}

ENTRY(ResetISR)

SECTIONS
{
    /* Image Vector Table and Boot Data for booting from external flash */
    .boot_hdr : ALIGN(4)
    {
        FILL(0xff)
        __boot_hdr_start__ = ABSOLUTE(.) ;
        KEEP(*(.boot_hdr.conf))
        . = 0x1000 ;
        KEEP(*(.boot_hdr.ivt))
        . = 0x1020 ;
        KEEP(*(.boot_hdr.boot_data))
        . = 0x1030 ;
        KEEP(*(.boot_hdr.dcd_data))
        __boot_hdr_end__ = ABSOLUTE(.) ;
        . = 0x2000 ;
    } >PROGRAM_FLASH

    /* MAIN TEXT SECTION */
    .text : ALIGN(4)
    {
        FILL(0xff)
        __vectors_start__ = ABSOLUTE(.) ;
        KEEP(*(.isr_vector))
        /* Global Section Table */
        . = ALIGN(4) ;
        __section_table_start = .;
        __data_section_table = .;
        LONG(LOADADDR(.data));
        LONG(    ADDR(.data));
        LONG(  SIZEOF(.data));
        LONG(LOADADDR(.data_RAM2));
        LONG(    ADDR(.data_RAM2));
        LONG(  SIZEOF(.data_RAM2));
        LONG(LOADADDR(.data_RAM3));
        LONG(    ADDR(.data_RAM3));
        LONG(  SIZEOF(.data_RAM3));
        LONG(LOADADDR(.data_RAM4));
        LONG(    ADDR(.data_RAM4));
        LONG(  SIZEOF(.data_RAM4));
        __data_section_table_end = .;
        __bss_section_table = .;
        LONG(    ADDR(.bss));
        LONG(  SIZEOF(.bss));
        LONG(    ADDR(.bss_RAM2));
        LONG(  SIZEOF(.bss_RAM2));
        LONG(    ADDR(.bss_RAM3));
        LONG(  SIZEOF(.bss_RAM3));
        LONG(    ADDR(.bss_RAM4));
        LONG(  SIZEOF(.bss_RAM4));
        __bss_section_table_end = .;
        __section_table_end = . ;
        /* End of Global Section Table */

        *(.after_vectors*)

    } > PROGRAM_FLASH

    .text : ALIGN(4)
    {
       *(.text*)
       *(.rodata .rodata.* .constdata .constdata.*)
       . = ALIGN(4);
    } > PROGRAM_FLASH
    /*
     * for exception handling/unwind - some Newlib functions (in common
     * with C++ and STDC++) use this.
     */
    .ARM.extab : ALIGN(4)
    {
        *(.ARM.extab* .gnu.linkonce.armextab.*)
    } > PROGRAM_FLASH

    __exidx_start = .;

    .ARM.exidx : ALIGN(4)
    {
        *(.ARM.exidx* .gnu.linkonce.armexidx.*)
    } > PROGRAM_FLASH
    __exidx_end = .;

    _etext = .;

    /* DATA section for SRAM_ITC */

    .data_RAM2 : ALIGN(4)
    {
        FILL(0xff)
        PROVIDE(__start_data_RAM2 = .) ;
        *(.ramfunc.$RAM2)
        *(.ramfunc.$SRAM_ITC)
        *(.data.$RAM2*)
        *(.data.$SRAM_ITC*)
        . = ALIGN(4) ;
        PROVIDE(__end_data_RAM2 = .) ;
     } > SRAM_ITC AT>PROGRAM_FLASH
    /* DATA section for SRAM_OC */

    .data_RAM3 : ALIGN(4)
    {
        FILL(0xff)
        PROVIDE(__start_data_RAM3 = .) ;
        *(.ramfunc.$RAM3)
        *(.ramfunc.$SRAM_OC)
        *(.data.$RAM3*)
        *(.data.$SRAM_OC*)
        . = ALIGN(4) ;
        PROVIDE(__end_data_RAM3 = .) ;
     } > SRAM_OC AT>PROGRAM_FLASH
    /* DATA section for BOARD_SDRAM */

    .data_RAM4 : ALIGN(4)
    {
        FILL(0xff)
        PROVIDE(__start_data_RAM4 = .) ;
        *(.ramfunc.$RAM4)
        *(.ramfunc.$BOARD_SDRAM)
        *(.data.$RAM4*)
        *(.data.$BOARD_SDRAM*)
        . = ALIGN(4) ;
        PROVIDE(__end_data_RAM4 = .) ;
     } > BOARD_SDRAM AT>PROGRAM_FLASH
    /* MAIN DATA SECTION */
    .uninit_RESERVED : ALIGN(4)
    {
        KEEP(*(.bss.$RESERVED*))
        . = ALIGN(4) ;
        _end_uninit_RESERVED = .;
    } > SRAM_DTC

    /* Main DATA section (SRAM_DTC) */
    .data : ALIGN(4)
    {
       FILL(0xff)
       _data = . ;
       *(vtable)
       *(.ramfunc*)
       *(NonCacheable.init)
       *(.data*)
       . = ALIGN(4) ;
       _edata = . ;
    } > SRAM_DTC AT>PROGRAM_FLASH

    /* BSS section for SRAM_ITC */
    .bss_RAM2 : ALIGN(4)
    {
       PROVIDE(__start_bss_RAM2 = .) ;
       *(.bss.$RAM2*)
       *(.bss.$SRAM_ITC*)
       . = ALIGN (. != 0 ? 4 : 1) ; /* avoid empty segment */
       PROVIDE(__end_bss_RAM2 = .) ;
    } > SRAM_ITC

    /* BSS section for SRAM_OC */
    .bss_RAM3 : ALIGN(4)
    {
       PROVIDE(__start_bss_RAM3 = .) ;
       *(.bss.$RAM3*)
       *(.bss.$SRAM_OC*)
       . = ALIGN (. != 0 ? 4 : 1) ; /* avoid empty segment */
       PROVIDE(__end_bss_RAM3 = .) ;
    } > SRAM_OC

    /* BSS section for BOARD_SDRAM */
    .bss_RAM4 : ALIGN(4)
    {
       PROVIDE(__start_bss_RAM4 = .) ;
       *(.bss.$RAM4*)
       *(.bss.$BOARD_SDRAM*)
       . = ALIGN (. != 0 ? 4 : 1) ; /* avoid empty segment */
       PROVIDE(__end_bss_RAM4 = .) ;
    } > BOARD_SDRAM

    /* MAIN BSS SECTION */
    .bss : ALIGN(4)
    {
        _bss = .;
       *(NonCacheable)
        *(.bss*)
        *(COMMON)
        . = ALIGN(4) ;
        _ebss = .;
        PROVIDE(end = .);
    } > SRAM_DTC

    /* NOINIT section for SRAM_ITC */
    .noinit_RAM2 (NOLOAD) : ALIGN(4)
    {
       *(.noinit.$RAM2*)
       *(.noinit.$SRAM_ITC*)
       . = ALIGN(4) ;
    } > SRAM_ITC

    /* NOINIT section for SRAM_OC */
    .noinit_RAM3 (NOLOAD) : ALIGN(4)
    {
       *(.noinit.$RAM3*)
       *(.noinit.$SRAM_OC*)
       . = ALIGN(4) ;
    } > SRAM_OC

    /* NOINIT section for BOARD_SDRAM */
    .noinit_RAM4 (NOLOAD) : ALIGN(4)
    {
       *(.noinit.$RAM4*)
       *(.noinit.$BOARD_SDRAM*)
       . = ALIGN(4) ;
    } > BOARD_SDRAM

    /* DEFAULT NOINIT SECTION */
    .noinit (NOLOAD): ALIGN(4)
    {
        _noinit = .;
        *(.noinit*)
         . = ALIGN(4) ;
        _end_noinit = .;
    } > SRAM_DTC

    /* Reserve and place Heap within memory map */
    _HeapSize = 0x1000;
    .heap :  ALIGN(4)
    {
        _pvHeapStart = .;
        . += _HeapSize;
        . = ALIGN(4);
        _pvHeapLimit = .;
    } > SRAM_DTC

     _StackSize = 0x1000;
     /* Reserve space in memory for Stack */
    .heap2stackfill  :
    {
        . += _StackSize;
    } > SRAM_DTC
    /* Locate actual Stack in memory map */
    .stack ORIGIN(SRAM_DTC) + LENGTH(SRAM_DTC) - _StackSize - 0:  ALIGN(4)
    {
        _vStackBase = .;
        . = ALIGN(4);
        _vStackTop = . + _StackSize;
    } > SRAM_DTC

    /* Provide basic symbols giving location and size of main text
     * block, including initial values of RW data sections. Note that
     * these will need extending to give a complete picture with
     * complex images (e.g multiple Flash banks).
     */
    _image_start = LOADADDR(.text);
    _image_end = LOADADDR(.data) + SIZEOF(.data);
    _image_size = _image_end - _image_start;
}


Running From OC (On-Chip) RAM

It is possible to avoid external FLASH by linking things to the different RAM sections of the device. The following linker file runs everything from RAM:

GROUP (
  "libcr_nohost_nf.a"
  "libcr_c.a"
  "libcr_eabihelpers.a"
  "libgcc.a"
)

MEMORY
{
  /* Define each memory region */
  PROGRAM_FLASH (rx) : ORIGIN = 0x70000000, LENGTH = 0x400000 /* 4M bytes (alias Flash) */
  SRAM_OC (rwx) : ORIGIN = 0x20200000, LENGTH = 0xc0000 /* 768K bytes (alias RAM) */
  SRAM_ITC (rwx) : ORIGIN = 0x0, LENGTH = 0x20000 /* 128K bytes (alias RAM2) */
  SRAM_DTC (rwx) : ORIGIN = 0x20000000, LENGTH = 0x20000 /* 128K bytes (alias RAM3) */
  BOARD_SDRAM (rwx) : ORIGIN = 0x80000000, LENGTH = 0x2000000 /* 32M bytes (alias RAM4) */
}

  /* Define a symbol for the top of each memory region */
  __base_PROGRAM_FLASH = 0x70000000  ; /* PROGRAM_FLASH */
  __base_Flash = 0x70000000 ; /* Flash */
  __top_PROGRAM_FLASH = 0x70000000 + 0x400000 ; /* 4M bytes */
  __top_Flash = 0x70000000 + 0x400000 ; /* 4M bytes */
  __base_SRAM_OC = 0x20200000  ; /* SRAM_OC */
  __base_RAM = 0x20200000 ; /* RAM */
  __top_SRAM_OC = 0x20200000 + 0xc0000 ; /* 768K bytes */
  __top_RAM = 0x20200000 + 0xc0000 ; /* 768K bytes */
  __base_SRAM_ITC = 0x0  ; /* SRAM_ITC */
  __base_RAM2 = 0x0 ; /* RAM2 */
  __top_SRAM_ITC = 0x0 + 0x20000 ; /* 128K bytes */
  __top_RAM2 = 0x0 + 0x20000 ; /* 128K bytes */
  __base_SRAM_DTC = 0x20000000  ; /* SRAM_DTC */
  __base_RAM3 = 0x20000000 ; /* RAM3 */
  __top_SRAM_DTC = 0x20000000 + 0x20000 ; /* 128K bytes */
  __top_RAM3 = 0x20000000 + 0x20000 ; /* 128K bytes */
  __base_BOARD_SDRAM = 0x80000000  ; /* BOARD_SDRAM */
  __base_RAM4 = 0x80000000 ; /* RAM4 */
  __top_BOARD_SDRAM = 0x80000000 + 0x2000000 ; /* 32M bytes */
  __top_RAM4 = 0x80000000 + 0x2000000 ; /* 32M bytes */

ENTRY(ResetISR)

SECTIONS
{
    /* MAIN TEXT SECTION */
    .text : ALIGN(4)
    {
        FILL(0xff)
        __vectors_start__ = ABSOLUTE(.) ;
        KEEP(*(.isr_vector))
        /* Global Section Table */
        . = ALIGN(4) ;
        __section_table_start = .;
        __data_section_table = .;
        LONG(LOADADDR(.data));
        LONG(    ADDR(.data));
        LONG(  SIZEOF(.data));
        LONG(LOADADDR(.data_RAM2));
        LONG(    ADDR(.data_RAM2));
        LONG(  SIZEOF(.data_RAM2));
        LONG(LOADADDR(.data_RAM3));
        LONG(    ADDR(.data_RAM3));
        LONG(  SIZEOF(.data_RAM3));
        LONG(LOADADDR(.data_RAM4));
        LONG(    ADDR(.data_RAM4));
        LONG(  SIZEOF(.data_RAM4));
        __data_section_table_end = .;
        __bss_section_table = .;
        LONG(    ADDR(.bss));
        LONG(  SIZEOF(.bss));
        LONG(    ADDR(.bss_RAM2));
        LONG(  SIZEOF(.bss_RAM2));
        LONG(    ADDR(.bss_RAM3));
        LONG(  SIZEOF(.bss_RAM3));
        LONG(    ADDR(.bss_RAM4));
        LONG(  SIZEOF(.bss_RAM4));
        __bss_section_table_end = .;
        __section_table_end = . ;
        /* End of Global Section Table */

        *(.after_vectors*)

    } > SRAM_OC

    .text : ALIGN(4)
    {
       *(.text*)
       *(.rodata .rodata.* .constdata .constdata.*)
       . = ALIGN(4);
    } > SRAM_OC
    /*
     * for exception handling/unwind - some Newlib functions (in common
     * with C++ and STDC++) use this.
     */
    .ARM.extab : ALIGN(4)
    {
        *(.ARM.extab* .gnu.linkonce.armextab.*)
    } > SRAM_OC

    __exidx_start = .;

    .ARM.exidx : ALIGN(4)
    {
        *(.ARM.exidx* .gnu.linkonce.armexidx.*)
    } > SRAM_OC
    __exidx_end = .;

    _etext = .;

    /* DATA section for SRAM_ITC */

    .data_RAM2 : ALIGN(4)
    {
        FILL(0xff)
        PROVIDE(__start_data_RAM2 = .) ;
        *(.ramfunc.$RAM2)
        *(.ramfunc.$SRAM_ITC)
        *(.data.$RAM2*)
        *(.data.$SRAM_ITC*)
        . = ALIGN(4) ;
        PROVIDE(__end_data_RAM2 = .) ;
     } > SRAM_ITC AT>SRAM_OC
    /* DATA section for SRAM_DTC */

    .data_RAM3 : ALIGN(4)
    {
        FILL(0xff)
        PROVIDE(__start_data_RAM3 = .) ;
        *(.ramfunc.$RAM3)
        *(.ramfunc.$SRAM_DTC)
        *(.data.$RAM3*)
        *(.data.$SRAM_DTC*)
        . = ALIGN(4) ;
        PROVIDE(__end_data_RAM3 = .) ;
     } > SRAM_DTC AT>SRAM_OC
    /* DATA section for BOARD_SDRAM */

    .data_RAM4 : ALIGN(4)
    {
        FILL(0xff)
        PROVIDE(__start_data_RAM4 = .) ;
        *(.ramfunc.$RAM4)
        *(.ramfunc.$BOARD_SDRAM)
        *(.data.$RAM4*)
        *(.data.$BOARD_SDRAM*)
        . = ALIGN(4) ;
        PROVIDE(__end_data_RAM4 = .) ;
     } > BOARD_SDRAM AT>SRAM_OC
    /* MAIN DATA SECTION */
    .uninit_RESERVED : ALIGN(4)
    {
        KEEP(*(.bss.$RESERVED*))
        . = ALIGN(4) ;
        _end_uninit_RESERVED = .;
    } > SRAM_OC

    /* Main DATA section (SRAM_OC) */
    .data : ALIGN(4)
    {
       FILL(0xff)
       _data = . ;
       *(vtable)
       *(.ramfunc*)
       *(.data*)
       . = ALIGN(4) ;
       _edata = . ;
    } > SRAM_OC AT>SRAM_OC

    /* BSS section for SRAM_ITC */
    .bss_RAM2 : ALIGN(4)
    {
       PROVIDE(__start_bss_RAM2 = .) ;
       *(.bss.$RAM2*)
       *(.bss.$SRAM_ITC*)
       . = ALIGN (. != 0 ? 4 : 1) ; /* avoid empty segment */
       PROVIDE(__end_bss_RAM2 = .) ;
    } > SRAM_ITC

    /* BSS section for SRAM_DTC */
    .bss_RAM3 : ALIGN(4)
    {
       PROVIDE(__start_bss_RAM3 = .) ;
       *(.bss.$RAM3*)
       *(.bss.$SRAM_DTC*)
       . = ALIGN (. != 0 ? 4 : 1) ; /* avoid empty segment */
       PROVIDE(__end_bss_RAM3 = .) ;
    } > SRAM_DTC

    /* BSS section for BOARD_SDRAM */
    .bss_RAM4 : ALIGN(4)
    {
       PROVIDE(__start_bss_RAM4 = .) ;
       *(.bss.$RAM4*)
       *(.bss.$BOARD_SDRAM*)
       . = ALIGN (. != 0 ? 4 : 1) ; /* avoid empty segment */
       PROVIDE(__end_bss_RAM4 = .) ;
    } > BOARD_SDRAM

    /* MAIN BSS SECTION */
    .bss : ALIGN(4)
    {
        _bss = .;
        *(.bss*)
        *(COMMON)
        . = ALIGN(4) ;
        _ebss = .;
        PROVIDE(end = .);
    } > SRAM_OC

    /* NOINIT section for SRAM_ITC */
    .noinit_RAM2 (NOLOAD) : ALIGN(4)
    {
       *(.noinit.$RAM2*)
       *(.noinit.$SRAM_ITC*)
       . = ALIGN(4) ;
    } > SRAM_ITC

    /* NOINIT section for SRAM_DTC */
    .noinit_RAM3 (NOLOAD) : ALIGN(4)
    {
       *(.noinit.$RAM3*)
       *(.noinit.$SRAM_DTC*)
       . = ALIGN(4) ;
    } > SRAM_DTC

    /* NOINIT section for BOARD_SDRAM */
    .noinit_RAM4 (NOLOAD) : ALIGN(4)
    {
       *(.noinit.$RAM4*)
       *(.noinit.$BOARD_SDRAM*)
       . = ALIGN(4) ;
    } > BOARD_SDRAM

    /* DEFAULT NOINIT SECTION */
    .noinit (NOLOAD): ALIGN(4)
    {
        _noinit = .;
        *(.noinit*)
         . = ALIGN(4) ;
        _end_noinit = .;
    } > SRAM_OC

    /* Reserve and place Heap within memory map */
    _HeapSize = 0x1000;
    .heap :  ALIGN(4)
    {
        _pvHeapStart = .;
        . += _HeapSize;
        . = ALIGN(4);
        _pvHeapLimit = .;
    } > SRAM_OC

     _StackSize = 0x1000;
     /* Reserve space in memory for Stack */
    .heap2stackfill  :
    {
        . += _StackSize;
    } > SRAM_OC
    /* Locate actual Stack in memory map */
    .stack ORIGIN(SRAM_OC) + LENGTH(SRAM_OC) - _StackSize - 0:  ALIGN(4)
    {
        _vStackBase = .;
        . = ALIGN(4);
        _vStackTop = . + _StackSize;
    } > SRAM_OC

    /* Provide basic symbols giving location and size of main text
     * block, including initial values of RW data sections. Note that
     * these will need extending to give a complete picture with
     * complex images (e.g multiple Flash banks).
     */
    _image_start = LOADADDR(.text);
    _image_end = LOADADDR(.data) + SIZEOF(.data);
    _image_size = _image_end - _image_start;
}


Mixing RAM and FLASH

Running code from RAM has a performance benefit. So, it makes sense to run ‘slower’ parts in normal XiP FLASH and run code in RAM where higher performance is needed.

To place a function into RAM, I add an attribute with the desired section name:

static void __attribute__((section (".ramfunc"))) blinkRAM(void) {
  if (g_pinSet) {
      GPIO_PinWrite(EXAMPLE_LED_GPIO, EXAMPLE_LED_GPIO_PIN, 0U);
      g_pinSet = false;
  } else  {
      GPIO_PinWrite(EXAMPLE_LED_GPIO, EXAMPLE_LED_GPIO_PIN, 1U);
      g_pinSet = true;
  }
}


With this, the function gets copied and placed in RAM. One thing to note is that, depending on the call distance, a veneer function might be used to reach the RAM address where the function is placed. More details on this topic in Execute-Only Code with GNU and gcc, which covers that topic from a different angle.

Summary

It is possible to place code and data either in FLASH or in RAM. All that is needed is the correct linker file for it. The placement is controlled by the linker file, and with using __attribute__ parts of the application can be in FLASH or RAM. If you are not familiar with the GNU linker file syntax, I recommend you start with the MCUXpresso IDE because it provides projects with working linker files.

Happy XiPing!

Helpful Links

  • Tutorial: MCUXpresso SDK with Linux, Part 1: Installation and Build with Make
  • Tutorial: MCUXpresso SDK with Linux, Part 2: Commandline Debugging with GDB
  • NXP MCUXpresso SDK web site: https://mcuxpresso.nxp.com
  • First Steps with the NXP i.MX RT1064-EVK Board
  • Regaining Debug Access to NXP i.MX RT1064-EVK executing WFI
  • Tutorial: Booting the NXP i.MX RT from Micro SD Card
  • NXP i.MX RT1064 Board: https://www.nxp.com/support/developer-resources/evaluation-and-development-boards/sabre-development-system/mimxrt1064-evk-i.mx-rt1064-evaluation-kit:MIMXRT1064-EVK
Software development kit Linux (operating system)

Published at DZone with permission of Erich Styger, DZone MVB. See the original article here.

Opinions expressed by DZone contributors are their own.

Popular on DZone

  • Quick Pattern-Matching Queries in PostgreSQL and YugabyteDB
  • Utilize OpenAI API to Extract Information From PDF Files
  • Taming Cloud Costs With Infracost
  • How and Why You Should Start Automating DevOps

Comments

Partner Resources

X

ABOUT US

  • About DZone
  • Send feedback
  • Careers
  • Sitemap

ADVERTISE

  • Advertise with DZone

CONTRIBUTE ON DZONE

  • Article Submission Guidelines
  • Become a Contributor
  • Visit the Writers' Zone

LEGAL

  • Terms of Service
  • Privacy Policy

CONTACT US

  • 600 Park Offices Drive
  • Suite 300
  • Durham, NC 27709
  • support@dzone.com
  • +1 (919) 678-0300

Let's be friends:
