Hibernate Caching With Hazelcast: Basic Configuration

DZone's Guide to

Hibernate Caching With Hazelcast: Basic Configuration

In this post, we take a look at how to use Hazelcast as a second-level cache for Hibernate to lower the overhead of repeat database queries.

· Java Zone
Free Resource

Microservices! They are everywhere, or at least, the term is. When should you use a microservice architecture? What factors should be considered when making that decision? Do the benefits outweigh the costs? Why is everyone so excited about them, anyway?  Brought to you in partnership with IBM.

Previously we went through an introduction to JPA caching, including the mechanisms involved and what Hibernate offers.

What comes next is a Hibernate project using Hazelcast as a second-level cache.

We will use a basic Spring Boot project for this purpose with JPA. Spring Boot uses Hibernate as the default JPA provider. Our setup will be pretty close to the one of a previous post.
We will use PostgreSQL with Docker for our SQL database.

group 'com.gkatzioura'
version '1.0-SNAPSHOT'

buildscript {
    repositories {
        mavenCentral()
    }
    dependencies {
        classpath("org.springframework.boot:spring-boot-gradle-plugin:1.5.1.RELEASE")
    }
}

apply plugin: 'java'
apply plugin: 'idea'
apply plugin: 'org.springframework.boot'


repositories {
    mavenCentral()
}

dependencies {
    compile("org.springframework.boot:spring-boot-starter-web")
    compile group: 'org.springframework.boot', name: 'spring-boot-starter-data-jpa'
    compile group: 'org.postgresql', name:'postgresql', version:'9.4-1206-jdbc42'
    compile group: 'org.springframework', name: 'spring-jdbc'
    compile group: 'com.zaxxer', name: 'HikariCP', version: '2.6.0'
    compile group: 'com.hazelcast', name: 'hazelcast-hibernate5', version: '1.2'
    compile group: 'com.hazelcast', name: 'hazelcast', version: '3.7.5'
    testCompile group: 'junit', name: 'junit', version: '4.11'
}


By examining the dependencies carefully, we see the Hikari pool, the PostgreSQL driver, Spring Data JPA, and, of course, Hazelcast.

Instead of creating the database manually, we will automate it by utilizing the database initialization feature of Spring Boot.

We shall create a file called schema.sql under the resources folder.

create schema spring_data_jpa_example;

create table spring_data_jpa_example.employee(
    id  SERIAL PRIMARY KEY,
    firstname   TEXT    NOT NULL,
    lastname    TEXT    NOT NULL,
    email       TEXT    not null,
    age         INT     NOT NULL,
    salary         real,
    unique(email)
);

insert into spring_data_jpa_example.employee (firstname,lastname,email,age,salary)
values ('Test','Me','test@me.com',18,3000.23);


To keep it simple and avoid any further configurations, we shall put the configurations for the datasource, JPA, and caching inside the application.yml file.

spring:
  datasource:
    continue-on-error: true
    type: com.zaxxer.hikari.HikariDataSource
    url: jdbc:postgresql://172.17.0.2:5432/postgres
    driver-class-name: org.postgresql.Driver
    username: postgres
    password: postgres
    hikari:
      idle-timeout: 10000
  jpa:
    properties:
      hibernate:
        cache:
          use_second_level_cache: true
          use_query_cache: true
          region:
            factory_class: com.hazelcast.hibernate.HazelcastCacheRegionFactory
    show-sql: true


The configuration spring.datasource.continue-on-error is crucial, since once the application relaunches, there should be a second attempt to create the database, and thus a crash is inevitable.

Any Hibernate-specific properties reside in the spring.jpa.properties path. We enabled the second-level cache and the query cache.

Also, we set show-sql to true. This means that once a query hits the database, it will be logged through the console.

Then, we create our employee entity.

package com.gkatzioura.hibernate.enitites;

import javax.persistence.*;

/**
 * Created by gkatzioura on 2/6/17.
 */
@Entity
@Table(name = "employee", schema="spring_data_jpa_example")
public class Employee {

    @Id
    @Column(name = "id")
    @GeneratedValue(strategy = GenerationType.SEQUENCE)
    private Long id;

    @Column(name = "firstname")
    private String firstName;

    @Column(name = "lastname")
    private String lastname;

    @Column(name = "email")
    private String email;

    @Column(name = "age")
    private Integer age;

    @Column(name = "salary")
    private Integer salary;

    public Long getId() {
        return id;
    }

    public void setId(Long id) {
        this.id = id;
    }

    public String getFirstName() {
        return firstName;
    }

    public void setFirstName(String firstName) {
        this.firstName = firstName;
    }

    public String getLastname() {
        return lastname;
    }

    public void setLastname(String lastname) {
        this.lastname = lastname;
    }

    public String getEmail() {
        return email;
    }

    public void setEmail(String email) {
        this.email = email;
    }

    public Integer getAge() {
        return age;
    }

    public void setAge(Integer age) {
        this.age = age;
    }

    public Integer getSalary() {
        return salary;
    }

    public void setSalary(Integer salary) {
        this.salary = salary;
    }
}


Everything is set up. Spring Boot will detect the entity and create an EntityManagerFactory on its own. What comes next is the repository class for Employee.

package com.gkatzioura.hibernate.repository;

import com.gkatzioura.hibernate.enitites.Employee;
import org.springframework.data.jpa.repository.JpaRepository;
import org.springframework.data.repository.CrudRepository;

/**
 * Created by gkatzioura on 2/11/17.
 */
public interface EmployeeRepository extends JpaRepository<Employee,Long> {
}


And the last one is the controller:

package com.gkatzioura.hibernate.controller;

import com.gkatzioura.hibernate.enitites.Employee;
import com.gkatzioura.hibernate.repository.EmployeeRepository;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.PathVariable;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestParam;
import org.springframework.web.bind.annotation.RestController;

import java.util.List;

/**
 * Created by gkatzioura on 2/6/17.
 */
@RestController
public class EmployeeController {

    @Autowired
    private EmployeeRepository employeeRepository;

    @RequestMapping("/employee")
    public List<Employee> testIt() {

        return employeeRepository.findAll();
    }

    @RequestMapping("/employee/{employeeId}")
    public Employee getEmployee(@PathVariable Long employeeId) {

        return employeeRepository.findOne(employeeId);
    }

}


Once we issue a request at http://localhost:8080/employee/1, the console will display the query issued to the database:

Hibernate: select employee0_.id as id1_0_0_, employee0_.age as age2_0_0_, employee0_.email as email3_0_0_, employee0_.firstname as firstnam4_0_0_, employee0_.lastname as lastname5_0_0_, employee0_.salary as salary6_0_0_ from spring_data_jpa_example.employee employee0_ where employee0_.id=?


The second time we issue the request, since we have the second cache enabled, there won’t be a query issued on the database. Instead, the entity will be fetched from the second-level cache.

You can download the project from GitHub.
