How Does JVM Handle Polymorphism Internally

DZone 's Guide to

How Does JVM Handle Polymorphism Internally

Find out how JVM utilizes method overloading and method overriding.

· Performance Zone ·
Free Resource

Gecko on a branch

How does JVM handle Polymorphism.
You may also like:  Everything About Method Overloading vs. Method Overriding

In my previous article, Everything About Method Overloading vs. Method Overriding, I discussed method overloading and overriding, their rules and differences.

In this article, we will see How Does JVM Handle Method Overloading And Overriding Internally, how JVM identifies which method should get called.

Let’s take the example of a parent class Mammal and a child Human classes from our previous blog to understand it more clearly.

public class OverridingInternalExample {

    private static class Mammal {
        public void speak() { System.out.println("ohlllalalalalalaoaoaoa"); }
    }

    private static class Human extends Mammal {

        @Override
        public void speak() { System.out.println("Hello"); }

        // Valid overload of speak
        public void speak(String language) {
            if (language.equals("Hindi")) System.out.println("Namaste");
            else System.out.println("Hello");
        }

        @Override
        public String toString() { return "Human Class"; }

    }

    //  Code below contains the output and and bytecode of the method calls
    public static void main(String[] args) {
        Mammal anyMammal = new Mammal();
        anyMammal.speak();  // Output - ohlllalalalalalaoaoaoa
        // 10: invokevirtual #4 // Method org/programming/mitra/exercises/OverridingInternalExample$Mammal.speak:()V

        Mammal humanMammal = new Human();
        humanMammal.speak(); // Output - Hello
        // 23: invokevirtual #4 // Method org/programming/mitra/exercises/OverridingInternalExample$Mammal.speak:()V

        Human human = new Human();
        human.speak(); // Output - Hello
        // 36: invokevirtual #7 // Method org/programming/mitra/exercises/OverridingInternalExample$Human.speak:()V

        human.speak("Hindi"); // Output - Namaste
        // 42: invokevirtual #9 // Method org/programming/mitra/exercises/OverridingInternalExample$Human.speak:(Ljava/lang/String;)V
    }
}


We can answer this answer in two ways, Logical way and Physical way, let's take a look at the logical way.

Logical Way

Logically we can say, during the compilation phase calling method is considered from the reference type. But at execution time method will be called from the object which the reference is holding.

For Example on humanMammal.speak(); line compiler will say Mammal.speak() is getting called because humanMammal is of type Mammal. During execution, JVM knows that humanMammal is holding a Human's object so Human.speak() will get called.

Well, it is pretty simple until we keep it at the conceptual level only. Once we get the doubt that how JVM is handling all this internally? or how JVM is calculating which method it should call.

Also, we know that overloaded methods are not called polymorphic and get resolved at compile time and this is why sometimes method overloading is also known as compile-time polymorphism or early/static binding.

But overridden methods get resolved at runtime time because the compiler does not know that, the object which we are assigning to our reference has overridden the method or not.

Physical Way

In this section, we will try to find out physical proof of all aforementioned statements and to find them we will read the bytecode of our program which we can do by executing javap -verbose OverridingInternalExample. By using -verbose option we will get the descriptive bytecode the same as our Java program.

Above command shows the bytecode in two sections

1. Constant Pool: Holds almost everything necessary for our program’s execution e.g. method references (#Methodref), Class objects ( #Class ), string literals ( #String ), please click one image to zoom.

java-method-area-or-constant-pool-or-method-table

2. Program’s Bytecode: executable bytecode instructions, please click one image to zoom.

method-overloading-overriding-internals-byte-code

Why Method Overloading Is Called Static Binding

In the above mention code humanMammal.speak() compiler will say speak() is getting called from Mammal but at execution time it will be called from the object which humanMammal is holding, which is the object of the Human class.

By looking at the above code and images we can see that the bytecodes of humanMammal.speak(), human.speak(), and human.speak("Hindi") are totally different because the compiler can differentiate between them based on the class reference.

So in the case of method overloading compiler can identify the bytecode instructions and method’s address at compile time and that is why it is also known as static binding or compile-time polymorphism.

Why Method Overriding Is Called Dynamic Binding

Bytecode for anyMammal.speak() and humanMammal.speak() are same (invokevirtual #4 // Method org/programming/mitra/exercises/OverridingInternalExample$Mammal.speak:()V) because according to compiler both methods are called on Mammal reference.

So now the question comes if both method calls have the same bytecode then how does JVM know which method to call?

Well, the answer is hidden in the bytecode itself and it is invokevirtual instruction, according to JVM specification invokevirtual invokes an instance method of an object, dispatching on the (virtual) type of the object. This is the normal method dispatch in the Java programming language.

JVM uses the invokevirtual instruction to invoke Java equivalent of the C++ virtual methods. In C++ if we want to override one method in another class we need to declare it as virtual. But in Java, all methods are virtual by default (except final and static methods) because we can override every method in the child class.

Operation invokevirtual accepts a pointer to method reference call ( #4 an index into the constant pool)

invokevirtual #4   // Method org/programming/mitra/exercises
  //OverridingInternalExample$Mammal.speak:()V


That method reference #4 again refers to a method name and Class reference.

#4 = Methodref   #2.#27   // org/programming/mitra/exercises/OverridingInternalExample$Mammal.speak:()V
#2 = Class   #25   // org/programming/mitra/exercises/OverridingInternalExample$Mammal
#25 = Utf8   org/programming/mitra/exercises/OverridingInternalExample$Mammal
#27 = NameAndType   #35:#17   // speak:()V
#35 = Utf8   speak
#17 = Utf8


All these references combinedly used to get a reference to a method and class in which the method is to be found. This is also mentioned in the JVM Specification.

The Java virtual machine does not mandate any particular internal structure for objects 4.

The bookmarks four states.

In some of Oracle’s implementations of the Java virtual machine, a reference to a class instance is a pointer to a handle that is itself a pair of pointers: one to a table containing the methods of the object and a pointer to the Class object that represents the type of the object, and the other to the memory allocated from the heap for the object data.

It means every reference variable holds two hidden pointers.

  1. A pointer to a table which again holds methods of the object and a pointer to the Class object. e.g. [speak(), speak(String) Class object].
  2. A pointer to the memory allocated on the heap for that object’s data e.g. values of instance variables.

Again the question comes, how invokevirtual internally do this? Well, no one can answer this because it depends on JVM implementation and it varies from JVM to JVM.

From the above statements, we can conclude that an object reference indirectly holds a reference/pointer to a table which holds all the method references of that object. Java has borrowed this concept from C++ and this table is known by various names such as virtual method table ( VMT ), virtual function table (vftable), virtual table (vtable), dispatch table.

We can not sure how vtable is implemented in Java because it is JVM dependent, but we can expect that it will be following the same strategy as C++ where vtable is an array-like structure that holds method names and their references on array indices. Whenever JVM tries to execute a virtual method it always asks the vtable for its address.

There is only one vtable per class, which means it is unique and the same for all objects of a class similar to the Class object. I have discussed more on the Class object in articles "Why an Outer Java Class Can’t Be Static" and "Why Java is Purely Object-Oriented Language Or Why Not".

So there is only one vtable for Object class which contains all 11 methods (if we don't count registerNatives) and references to their respective method bodies.

vtable-of-object

When JVM loads the Mammal class into memory it creates a Class object for it and creates a vtable that contains all the methods from the vtable of Object class with the same references (because Mammal is not overriding any method from Object) and adds a new entry for speak method.

vtable-human

Now here comes the turn of Human class and now JVM will copy all entries from the vtable of Mammal class to the vtable of Human and adds a new entry for the overloaded version of speak(String).

JVM knows that the Human class has overridden two methods one is toString() from Object and the second is speck() from Mammal. Now instead of creating new entries for these methods with updated references. JVM will modify the references to the already present methods on the same index where they were present earlier and will keep the same method names.

The invokevirtual causes the JVM to treat the value at method reference number four, not as an address but as the name of a method to look up in the vtable for the current object.

I hope now it would have become a little bit clear that how the JVM mixes constant pool entries and vtable to conclude which method it is going to call.

You can find the complete code on this Github Repository and please feel free to provide your valuable feedback.
