Making Elasticsearch in Docker Swarm Truly Elastic

DZone's Guide to

Making Elasticsearch in Docker Swarm Truly Elastic

Running a truly elastic Elasticsearch cluster on Docker Swarm is hard. Here's how to get past Elasticsearch and Docker's pitfalls with IP addresses, networking, and more.

· Big Data Zone
Free Resource

Effortlessly power IoT, predictive analytics, and machine learning applications with an elastic, resilient data infrastructure. Learn how with Mesosphere DC/OS.

Running on Elasticsearch on Docker sounds like a natural fit – both technologies promise elasticity. However, running a truly elastic Elasticsearch cluster on Docker Swarm became somewhat difficult with Docker 1.12 Swarm mode. Why? Since Elasticsearch gave up on multicast discovery (by moving multicast node discovery into a plugin and not including it by default) one has to specify IP addresses of all master nodes to join the cluster.  Unfortunately, this creates the chicken or the egg problem in the sense that these IP addresses are not actually known in advance when you start Elasticsearch as a Swarm service!  It would be easy if we could use the shared Docker bridge or host network and simply specify the Docker host IP addresses, as we are used to it with the “docker run” command. However,  “docker service create” rejects the usage of bridge or host network. Thus, the question remains: How can we deploy Elasticsearch in a Docker Swarm cluster?

Luckily, using a few tricks it is possible to create an Elasticsearch cluster on Docker Swarm and have it automatically create additional Elasticsearch node on each Docker Swarm node as they join the Swarm cluster!

We assume you already have a working Docker Swarm cluster. If not, simply run “docker swarm init” on the master node, and then run docker swarm join on worker nodes.

Let’s see how we can resolve these two problems.

Elasticsearch Problem: Node Discovery Without Explicit IP Addresses for Zen Discovery

We use an overlay network (a virtual network between containers, available on all Swarm nodes) with DNS round robin setup.  We also specify the Elasticsearch service name “escluster” for the Zen discovery.  This means each new Elasticsearch container will ask the “Elasticsearch node” named “escluster” to discover other Elasticsearch nodes. Swarm DNS round robin setup means that each time the IP address returned will be an IP of a different/random Elasticsearch node.  Using this trick we enable Elasticesearch nodes to eventually discover all other nodes and form the cluster.

Docker Problem: Connecting Closed Overlay Network With Outside Network

This gets us over one hurdle, but it leaves us facing the next Docker networking problem: Docker does not allow outside connections into overlay networks with DNS round robin setup. This is done by design, though some see it as a bug (see Docker SwarmKit issue #1693, which simplifies the network setup in the future).

However you see it, this means that while the Elasticsearch cluster is able to find other nodes in the overlay network with DNS round robin trick that solved our original problem, now we are faced with the second problem — it is not possible to connect to port 9200 and talk to Elasticsearch from any other network.

This Elasticsearch cluster can be used only from containers that share the overlay network! To solve this issue, we need a proxy service to connect the outside network to our Elasticsearch network. With such a proxy, we can reach the Elasticsearch cluster from the “outside” world. We use jwilder’s wildly popular jwilder/nginx-proxy, which can discover the target service by using VIRTUAL_HOST and VIRTUAL_PORT tags, which we have to set as environment variables in the Elasticsearch Docker Swarm service. Because we had no DNS configured during this setup, we simply used a public wildcard DNS (see xip.io for more info) for the virtual hostname. The following diagram shows how everything is connected.

Image title

Elasticsearch on Docker Swarm: Setting Up

Now that we’ve described the problems and our solutions for them, let’s actually set up Elasticsearch on Docker Swarm.

First, let’s create networks by executing these commands on Swarm master nodes:

docker network create -d overlay elasticsearch-backend

docker network create -d overlay elasticsearch-frontend

Next, we’ll deploy NGINX proxy:

docker service create --mode global \

--name proxy -p 80:80 \

--network elasticsearch-frontend \

--network elasticsearch-backend  \

--mount type=bind,src=/var/run/docker.sock,target=/tmp/docker.sock:ro \


Now we can create the global Elasticsearch service. The NGINX proxy will automatically discover every Elasticsearch container created by this service:

docker service create \

   --name escluster \

   --network elasticsearch-backend \

   --mode global \

   --endpoint-mode dnsrr \

   --update-parallelism 1 \

   --update-delay 60s \


   -e VIRTUAL_PORT=9200 \

   --mount type=bind,source=/tmp,target=/data \

 elasticsearch:2.4 \

   elasticsearch \

   -Des.discovery.zen.ping.multicast.enabled=false \

   -Des.discovery.zen.ping.unicast.hosts=escluster \

   -Des.gateway.expected_nodes=3 \

   -Des.discovery.zen.minimum_master_nodes=2 \

   -Des.gateway.recover_after_nodes=2 \


Let’s check on the status of our Elasticsearch cluster:

> docker service ps escluster

ID                         NAME           IMAGE              NODE                DESIRED STATE  CURRENT STATE          ERROR

30uq0ru7hc0suj500hiu9ojw1  escluster      elasticsearch:2.4  docker-1gb-nyc2-02  Running        Running 6 seconds ago

7v55bb2l2g5f2gbzqn58nzr2o   \_ escluster  elasticsearch:2.4  docker-1gb-nyc2-03  Running        Running 6 seconds ago

72le8cee81d03p2u211k7n8m7   \_ escluster  elasticsearch:2.4  docker-1gb-nyc2-04  Running        Running 6 seconds ago

14mbvsx4su038mw9y3apv4k31   \_ escluster  elasticsearch:2.4  docker-1gb-nyc2-01  Running        Running 6 seconds ago

Now we can query the list of nodes from Elasticsearch and use Elasticsearch from any other client:

> curl 6 21 0.30 d * Tethlam 8 21 0.01 d m Thornn 6 21 0.90 d m Sphinx

Elasticity in Action

Now let’s get back to the original problem — making Elasticsearch clusters deployed in Docker Swarm truly elastic. With everything we’ve done so far, when we need additional Elasticsearch nodes we can simply create a new server and have it join the Swarm cluster:

> ssh root@ docker swarm join \

--token SWMTKN-1-54ld5e3nz31wloghribbwt8m0px4z5a1qeg17iazm7p2j7g7ke-6zccu9643j0dj7bhwmhqtwh46

> This node joined a swarm as a worker.

At this point, the new Elasticsearch node and the nginx-proxy get automatically deployed to the new Swarm node and the new Elasticsearch node automatically joins the Elasticsearch cluster:

> ssh root@ docker ps

CONTAINER ID        IMAGE                        COMMAND                  CREATED             STATUS                  PORTS                NAMES

2fc12ed5f1db        jwilder/nginx-proxy:latest   "/app/docker-entrypoi"   3 seconds ago       Up Less than a second   80/tcp, 443/tcp      proxy.0.3gw46kczaiugioc6gdo0414ws

4b4999a6c7b4        elasticsearch:2.4            "/docker-entrypoint.s"   3 seconds ago       Up 1 seconds            9200/tcp, 9300/tcp

To see the Elasticsearch cluster in action, we deployed Sematext Docker Agent to collect container metrics in the Swarm cluster and then we indexed large log files in short batch jobs using Logagent:

> cat test.log | logagent --elasticsearchUrl --index logs

In our little setup, Logagent was able to ship up to 60,000 events per second with up to 150 HTTP sockets to the five-node cluster without indicating any network problem or request rejections from Elasticsearch.

The following chart shows that the load of indexing got evenly distributed to all Elasticsearch containers:


Balanced CPU load on Elasticsearch nodes during indexing jobs

The nginx-proxy did show small CPU spikes at the same time — because it just forwarded the indexing requests from the “elasticsearch-frontend” network to the the “elasticsearch-backend” network, and the load was distributed over all proxy containers.


Balanced CPU load on NGINX proxies during indexing jobs

container metrics overview

Container metrics overview in SPM for Docker

Missing features in Elasticsearch (e.g. removed multicast-discovery since version 2.3) and Docker networking made it challenging to deploy Elasticsearch as a Docker Swarm service. We hope new features in Elasticsearch and Docker will simplify such setups in the future.

We demonstrated that there are workarounds to overcome Elasticsearch discovery issues using DNS round robin in the overlay network in Swarm and made the Elasticsearch cluster available to external applications that don’t share the same overlay network. The result is a setup that can scale Elasticsearch automatically with the number of Swarm nodes, while all requests remain balanced across the cluster.
