Micro Frontends in Angular and React: A Deep Technical Guide for Scalable Front-End Architecture

Module Federation, Custom Elements, and orchestrators like Single-SPA enable independently evolving, maintainable applications with a seamless user experience.

By
Renjith Kathalikkattil Ravindran
·
Jan. 16, 26 · Analysis
Post on X (opens in a new tab) Share on LinkedIn (opens in a new tab)
4.3K Views

Join the DZone community Save articles, join the discussion, and download Refcards and Trend Reports with a free account.

Join for free Already a member? Log in

Micro-frontends allow large teams to build independent UI modules that ship autonomously. Angular and React both support micro-frontend architecture using Webpack Module Federation. Angular benefits from strong structure and RxJS-based shared services, while React provides lightweight, flexible federated components. A hybrid Angular-React MFE system typically follows a shell-and-remotes architecture, with shared libraries, version-safe dependencies, and independent deployments.

What Micro Frontends Are (and Why They Matter)

Micro frontends split a large UI into independently developed and deployed applications that compose together at runtime.

Problems They Solve

  • Long build & deployment pipelines for monolithic front-end apps
  • Cross-team dependency conflicts and tight coupling
  • Risky framework upgrades
  • Difficulty scaling engineering teams
  • Slow feature delivery due to centralized release cycles

Benefits

  • Independent deployments
  • Technology freedom (Angular + React = no problem)
  • Smaller, maintainable codebases
  • Domain ownership
  • Easier migrations

Macro Architecture Overview

JavaScript

                                 ┌───────────────────────────────────────┐
                                 │                SHELL                  │
                                 │  Global Nav, Routing, Auth, Layout    │
                                 └───────────────┬───────────────────────┘
                                                 │
   ┌─────────────────────────────────────────────┼────────────────────────────────────────┐
   │                                             │                                        │
   ▼                                             ▼                                        ▼
Angular MFE                              React MFE                               React/Angular MFE
/orders                                   /dashboard                              /profile
Module Federation                         Module Federation                        Custom Elements


Folder Structure for Enterprise-Scale MFEs

A poly-repo style (common in enterprises):

JavaScript

microfrontends/
│
├── shell/                       # Shell app (Angular or React)
│   ├── src/
│   ├── webpack.config.js
│   └── package.json
│
├── mfe-angular-orders/
│   ├── src/app/orders/
│   ├── src/app/app.module.ts
│   ├── webpack.config.js
│   └── package.json
│
├── mfe-react-dashboard/
│   ├── src/Dashboard.jsx
│   ├── webpack.config.js
│   └── package.json
│
└── mfe-react-profile/
    ├── src/Profile.jsx
    ├── webpack.config.js
    └── package.json


Monorepo with Nx

JavaScript

apps/
  shell/
  mfe-orders/
  mfe-dashboard/
  mfe-profile/
libs/
  shared-ui/
  auth/
  utils/


Nx simplifies dependency graphs, CI/CD, caching, and workspace generators.

Angular Micro Frontend Example (Module Federation)

Angular MFE (Orders App)

webpack.config.js

JavaScript

const ModuleFederationPlugin = require("webpack/lib/container/ModuleFederationPlugin");
const { share } = require("@angular-architects/module-federation/webpack");

module.exports = {
  output: {
    uniqueName: "orders",
  },
  plugins: [
    new ModuleFederationPlugin({
      name: "orders",
      filename: "remoteEntry.js",
      exposes: {
        "./OrdersModule": "./src/app/orders/orders.module.ts",
      },
      shared: share({
        "@angular/core": { singleton: true, strictVersion: true },
        "@angular/common": { singleton: true },
        "@angular/router": { singleton: true },
      }),
    })
  ],
};


Angular Shell Loads the Orders Module

shell/src/app/app-routing.module.ts

JavaScript

const routes: Routes = [
  {
    path: "orders",
    loadChildren: () =>
      loadRemoteModule({
        type: "module",
        remoteEntry: "http://localhost:4201/remoteEntry.js",
        exposedModule: "./OrdersModule",
      }).then(m => m.OrdersModule),
  },
];


Angular Orders Component Example

orders.component.ts

JavaScript

@Component({
  selector: 'app-orders',
  template: `
    <h2>Orders</h2>
    <ul>
      <li *ngFor="let order of orders">{{ order.id }} - {{ order.status }}</li>
    </ul>
  `
})
export class OrdersComponent {
  orders = [
    { id: 101, status: 'Shipped' },
    { id: 102, status: 'Processing' },
  ];
}


React Micro Frontend Example (Module Federation)

React Dashboard MFE

mfe-react-dashboard/webpack.config.js

JavaScript

const ModuleFederationPlugin = require("webpack/lib/container/ModuleFederationPlugin");

module.exports = {
  plugins: [
    new ModuleFederationPlugin({
      name: "dashboard",
      filename: "remoteEntry.js",
      exposes: {
        "./Dashboard": "./src/Dashboard.jsx",
      },
      shared: ["react", "react-dom"],
    }),
  ],
};


React Dashboard Component

JavaScript

export default function Dashboard() {
  return (
    <div>
      <h2>Analytics Dashboard</h2>
      <p>Live metrics will appear here...</p>
    </div>
  );
}


Angular Shell Loading React Components

Step 1: React Render Wrapper

shell/src/app/react-renderer.ts

JavaScript

import React from "react";
import ReactDOM from "react-dom";

export function mountReact(Component: any, elementId: string) {
  ReactDOM.render(<Component />, document.getElementById(elementId));
}


Step 2: Wrapper Component in Angular

JavaScript

@Component({
  selector: 'app-dashboard-wrapper',
  template: `<div id="dashboard-root"></div>`
})
export class DashboardWrapper implements AfterViewInit {
  async ngAfterViewInit() {
    const Dashboard = (await import("dashboard/Dashboard")).default;
    mountReact(Dashboard, "dashboard-root");
  }
}


Step 3: Routing

JavaScript

{
  path: 'dashboard',
  component: DashboardWrapper
}


The result? Beautiful Angular + React harmony.


React Shell Consuming Angular MFE

Angular MFE can be delivered as a Custom Element.

Angular MFE Exports a Web Component

JavaScript

import { createCustomElement } from '@angular/elements';
import { OrdersComponent } from './orders.component';

const ordersElement = createCustomElement(OrdersComponent, { injector });
customElements.define('orders-widget', ordersElement);

React Shell Uses It Natively

JavaScript

function App() {
  return (
    <div>
      <h2>User Profile</h2>
      <orders-widget></orders-widget>
    </div>
  );
}


Communication Between Micro Frontends

Communication is challenging in MFEs because apps must stay decoupled.

Event Bus Pattern

Use browser events:

JavaScript

window.dispatchEvent(new CustomEvent("cart:updated", { detail: count }));

Listener:

JavaScript

window.addEventListener("cart:updated", (e) => console.log(e.detail));


Cross-MFE Shared Store (exposed via Module Federation)

React Exports:

JavaScript

exposes: { "./store": "./src/store.js" }

Angular Imports:

JavaScript

const store = await import("dashboard/store");
store.subscribe(value => ...);


URL-based Communication

The following are used by apps like Amazon to communicate state.

  • Route parameters
  • Query params
  • URL fragments

Deployment Patterns

Independent Deployments (Best Practice)

Every MFE deploys separately.

JavaScript

https://app.company.com/
https://orders.company.com/
https://dashboard.company.com/
https://profile.company.com/

Shell dynamically loads remoteEntry URLs.

CI/CD Workflow Example

  • Lint → Test → Build
  • Upload artifacts to S3 or CDN
  • Shell periodically fetches updated remoteEntry.json
  • Cache-busting via content hashes

Best Practices (Critical for Enterprise)

Keep MFEs small

Each app should represent a business domain.

Do not share too many libraries

This creates coupling.

Prefer runtime federation over build-time federation

Gives true deployment independence.

Add a versioning strategy for remotes

Prevent breaking shells.

Use monorepo (Nx) if teams share code

Use poly-repo if independence is priority.

Common Anti-Patterns

❌ Using iFrames for everything
❌ Sharing global state directly
❌ Hard-coding remote URLs in the shell
❌ Putting multiple business domains in one MFE
❌ Rebuilding the shell for every MFE change

When to Use Micro Frontends (and When Not To)

Use MFEs if:

✔ Your team is large (50+ engineers)
✔ Multiple frameworks are involved
✔ Release cycles must be independent
✔ You need long-term migration flexibility

Avoid MFEs if:

✘ You have a small app (< 10 engineers)
✘ You don’t have strong DevOps support
✘ Performance is a bigger priority than autonomy

Conclusion

Micro frontends offer a robust, scalable architecture for modern front-end development—especially for enterprise teams using Angular, React, or both. Using Module Federation, Custom Elements, and orchestrators like Single-SPA, companies can build maintainable, future-proof applications that evolve independently while delivering a seamless experience.

While Angular provides strong module boundaries and stable typing, React offers flexibility and a lightweight component-based architecture.

Combined, they form a powerful cross-framework ecosystem that supports large-scale innovation.
