Automatic Partition Maintenance in MariaDB

Learn how to write stored procedures that can call stored procedures on a desired schedule and create stored procedures that automatically add new partitions.

Geoff Montee

Sep. 09, 17 · Tutorial

Likes (1)

Comment

Save

10.5K Views

A MariaDB Support customer recently asked how they could automatically drop old partitions after six months. MariaDB does not have a mechanism to do this automatically out-of-the-box, but it is not too difficult to create a custom stored procedure and an event to call the procedure on the desired schedule. In fact, it is also possible to go even further and create a stored procedure that can also automatically add new partitions.

In this blog post, I will show you how to write stored procedures that perform these tasks.

Partitioned Table Definition

For this demonstration, I'll use a table definition based on one from MySQL's documentation on range partitioning, with some minor changes:

DROP TABLE IF EXISTS db1.quarterly_report_status;

CREATE TABLE db1.quarterly_report_status (
   report_id INT NOT NULL,
   report_status VARCHAR(20) NOT NULL,
   report_updated TIMESTAMP NOT NULL DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP
) ENGINE=InnoDB
PARTITION BY RANGE ( UNIX_TIMESTAMP(report_updated) ) (
   PARTITION p_first VALUES LESS THAN ( UNIX_TIMESTAMP('2016-10-01 00:00:00')),
   PARTITION p201610 VALUES LESS THAN ( UNIX_TIMESTAMP('2016-11-01 00:00:00')),
   PARTITION p201611 VALUES LESS THAN ( UNIX_TIMESTAMP('2016-12-01 00:00:00')),
   PARTITION p201612 VALUES LESS THAN ( UNIX_TIMESTAMP('2017-01-01 00:00:00')),
   PARTITION p201701 VALUES LESS THAN ( UNIX_TIMESTAMP('2017-02-01 00:00:00')),
   PARTITION p201702 VALUES LESS THAN ( UNIX_TIMESTAMP('2017-03-01 00:00:00')),
   PARTITION p201703 VALUES LESS THAN ( UNIX_TIMESTAMP('2017-04-01 00:00:00')),
   PARTITION p201704 VALUES LESS THAN ( UNIX_TIMESTAMP('2017-05-01 00:00:00')),
   PARTITION p201705 VALUES LESS THAN ( UNIX_TIMESTAMP('2017-06-01 00:00:00')),
   PARTITION p201706 VALUES LESS THAN ( UNIX_TIMESTAMP('2017-07-01 00:00:00')),
   PARTITION p201707 VALUES LESS THAN ( UNIX_TIMESTAMP('2017-08-01 00:00:00')),
   PARTITION p201708 VALUES LESS THAN ( UNIX_TIMESTAMP('2017-09-01 00:00:00')),
   PARTITION p_future VALUES LESS THAN (MAXVALUE)
);

The most significant change is that the partition naming scheme is based on the date. This will allow us to more easily determine which partitions to remove.

Stored Procedure Definition (Create New Partitions)

The stored procedure itself contains some comments that explain what it does, so I will let the code speak for itself, for the most part. One noteworthy item to point out is that we are not doing ALTER TABLE ... ADD PARTITION. This is because the partition p_future already covers the end range up to MAXVALUE, so we actually need to do ALTER TABLE ... REORGANIZE PARTITION instead.

DROP PROCEDURE IF EXISTS db1.create_new_partitions;

DELIMITER $$
CREATE PROCEDURE db1.create_new_partitions(p_schema varchar(64), p_table varchar(64), p_months_to_add int)
   LANGUAGE SQL
   NOT DETERMINISTIC
   SQL SECURITY INVOKER
BEGIN
   DECLARE done INT DEFAULT FALSE;
   DECLARE current_partition_name varchar(64);
   DECLARE current_partition_ts int;

   -- We'll use this cursor later to check
   -- whether a particular already exists.
   -- @partition_name_to_add will be
   -- set later.
   DECLARE cur1 CURSOR FOR
   SELECT partition_name
   FROM information_schema.partitions
   WHERE TABLE_SCHEMA = p_schema
   AND TABLE_NAME = p_table
   AND PARTITION_NAME != 'p_first'
   AND PARTITION_NAME != 'p_future'
   AND PARTITION_NAME = @partition_name_to_add;

   -- We'll also use this cursor later
   -- to query our temporary table.
   DECLARE cur2 CURSOR FOR
   SELECT partition_name, partition_range_ts
   FROM partitions_to_add;

   DECLARE CONTINUE HANDLER FOR NOT FOUND SET done = TRUE;

   DROP TEMPORARY TABLE IF EXISTS partitions_to_add;

   CREATE TEMPORARY TABLE partitions_to_add (
      partition_name varchar(64),
      partition_range_ts int
   );

   SET @partitions_added = FALSE;
   SET @months_ahead = 0;

   -- Let's go through a loop and add each month individually between
   -- the current month and the month p_months_to_add in the future.
   WHILE @months_ahead <= p_months_to_add DO
      -- We figure out what the correct month is by adding the
      -- number of months to the current date
      SET @date = CURDATE();
      SET @q = 'SELECT DATE_ADD(?, INTERVAL ? MONTH) INTO @month_to_add';
      PREPARE st FROM @q;
      EXECUTE st USING @date, @months_ahead;
      DEALLOCATE PREPARE st;
      SET @months_ahead = @months_ahead + 1;

      -- Then we format the month in the same format used
      -- in our partition names.
      SET @q = 'SELECT DATE_FORMAT(@month_to_add, ''%Y%m'') INTO @formatted_month_to_add';
      PREPARE st FROM @q;
      EXECUTE st;
      DEALLOCATE PREPARE st;

      -- And then we use the formatted date to build the name of the
      -- partition that we want to add. This partition name is
      -- assigned to @partition_name_to_add, which is used in
      -- the cursor declared at the start of the procedure.
      SET @q = 'SELECT CONCAT(''p'', @formatted_month_to_add) INTO @partition_name_to_add';
      PREPARE st FROM @q;
      EXECUTE st;
      DEALLOCATE PREPARE st;

      SET done = FALSE;
      SET @first = TRUE;

      -- And then we loop through the results returned by the cursor,
      -- and if a row already exists for the current partition,
      -- then we do not need to create the partition.
      OPEN cur1;

      read_loop: LOOP
         FETCH cur1 INTO current_partition_name;

         -- The cursor returned 0 rows, so we can create the partition.
         IF done AND @first THEN
            SELECT CONCAT('Creating partition: ', @partition_name_to_add);

            -- Now we need to get the end date of the new partition.
            -- Note that the date is for the non-inclusive end range,
            -- so we actually need the date of the first day of the *next* month.

            -- First, let's get a date variable for the first of the partition month
            SET @q = 'SELECT DATE_FORMAT(@month_to_add, ''%Y-%m-01 00:00:00'') INTO @month_to_add';
            PREPARE st FROM @q;
            EXECUTE st;
            DEALLOCATE PREPARE st;

            -- Then, let's add 1 month
            SET @q = 'SELECT DATE_ADD(?, INTERVAL 1 MONTH) INTO @partition_end_date';
            PREPARE st FROM @q;
            EXECUTE st USING @month_to_add;
            DEALLOCATE PREPARE st;

            -- We need the date in UNIX timestamp format.
            SELECT UNIX_TIMESTAMP(@partition_end_date) INTO @partition_end_ts;

            -- Now insert the information into our temporary table
            INSERT INTO partitions_to_add VALUES (@partition_name_to_add, @partition_end_ts);
            SET @partitions_added = TRUE;
         END IF;

         -- Since we had at least one row returned, we know the
         -- partition already exists.
         IF ! @first THEN
            LEAVE read_loop;
         END IF;

         SET @first = FALSE;
      END LOOP;

     CLOSE cur1;
   END WHILE;

   -- Let's actually add the partitions now.
   IF @partitions_added THEN
      -- First we need to build the actual ALTER TABLE query.
      SET @schema = p_schema;
      SET @table = p_table;
      SET @q = 'SELECT CONCAT(''ALTER TABLE '', @schema, ''.'', @table, '' REORGANIZE PARTITION p_future INTO ( '') INTO @query';
      PREPARE st FROM @q;
      EXECUTE st;
      DEALLOCATE PREPARE st;

      SET done = FALSE;
      SET @first = TRUE;

      OPEN cur2;

      read_loop: LOOP
         FETCH cur2 INTO current_partition_name, current_partition_ts;

        IF done THEN
            LEAVE read_loop;
         END IF;

         -- If it is not the first partition,
         -- then we need to add a comma
         IF ! @first THEN
            SET @q = 'SELECT CONCAT(@query, '', '') INTO @query';
            PREPARE st FROM @q;
            EXECUTE st;
            DEALLOCATE PREPARE st;
         END IF;

         -- Add the current partition
         SET @partition_name =  current_partition_name;
         SET @partition_ts =  current_partition_ts;
         SET @q = 'SELECT CONCAT(@query, ''PARTITION '', @partition_name, '' VALUES LESS THAN ('', @partition_ts, '')'') INTO @query';
         PREPARE st FROM @q;
         EXECUTE st;
         DEALLOCATE PREPARE st;

         SET @first = FALSE;
      END LOOP;

      CLOSE cur2;

      -- We also need to include the p_future partition
      SET @q = 'SELECT CONCAT(@query, '', PARTITION p_future VALUES LESS THAN (MAXVALUE))'') INTO @query';
      PREPARE st FROM @q;
      EXECUTE st;
      DEALLOCATE PREPARE st;

      -- And then we prepare and execute the ALTER TABLE query.
      PREPARE st FROM @query;
      EXECUTE st;
      DEALLOCATE PREPARE st;
   END IF;

   DROP TEMPORARY TABLE partitions_to_add;
END$$
DELIMITER ;

Let's try running the new procedure:

MariaDB [db1]> SHOW CREATE TABLE db1.quarterly_report_status\G
*************************** 1. row ***************************
       Table: quarterly_report_status
Create Table: CREATE TABLE `quarterly_report_status` (
  `report_id` int(11) NOT NULL,
  `report_status` varchar(20) NOT NULL,
  `report_updated` timestamp NOT NULL DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP
) ENGINE=InnoDB DEFAULT CHARSET=latin1
/*!50100 PARTITION BY RANGE ( UNIX_TIMESTAMP(report_updated))
(PARTITION p_first VALUES LESS THAN (1475294400) ENGINE = InnoDB,
 PARTITION p201610 VALUES LESS THAN (1477972800) ENGINE = InnoDB,
 PARTITION p201611 VALUES LESS THAN (1480568400) ENGINE = InnoDB,
 PARTITION p201612 VALUES LESS THAN (1483246800) ENGINE = InnoDB,
 PARTITION p201701 VALUES LESS THAN (1485925200) ENGINE = InnoDB,
 PARTITION p201702 VALUES LESS THAN (1488344400) ENGINE = InnoDB,
 PARTITION p201703 VALUES LESS THAN (1491019200) ENGINE = InnoDB,
 PARTITION p201704 VALUES LESS THAN (1493611200) ENGINE = InnoDB,
 PARTITION p201705 VALUES LESS THAN (1496289600) ENGINE = InnoDB,
 PARTITION p201706 VALUES LESS THAN (1498881600) ENGINE = InnoDB,
 PARTITION p201707 VALUES LESS THAN (1501560000) ENGINE = InnoDB,
 PARTITION p201708 VALUES LESS THAN (1504238400) ENGINE = InnoDB,
 PARTITION p_future VALUES LESS THAN MAXVALUE ENGINE = InnoDB) */
1 row in set (0.00 sec)

MariaDB [db1]> CALL db1.create_new_partitions('db1', 'quarterly_report_status', 3);
+--------------------------------------------------------+
| CONCAT('Creating partition: ', @partition_name_to_add) |
+--------------------------------------------------------+
| Creating partition: p201709                            |
+--------------------------------------------------------+
1 row in set (0.01 sec)

+--------------------------------------------------------+
| CONCAT('Creating partition: ', @partition_name_to_add) |
+--------------------------------------------------------+
| Creating partition: p201710                            |
+--------------------------------------------------------+
1 row in set (0.02 sec)

+--------------------------------------------------------+
| CONCAT('Creating partition: ', @partition_name_to_add) |
+--------------------------------------------------------+
| Creating partition: p201711                            |
+--------------------------------------------------------+
1 row in set (0.02 sec)

Query OK, 0 rows affected (0.09 sec)

MariaDB [db1]> SHOW CREATE TABLE db1.quarterly_report_status\G
*************************** 1. row ***************************
       Table: quarterly_report_status
Create Table: CREATE TABLE `quarterly_report_status` (
  `report_id` int(11) NOT NULL,
  `report_status` varchar(20) NOT NULL,
  `report_updated` timestamp NOT NULL DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP
) ENGINE=InnoDB DEFAULT CHARSET=latin1
/*!50100 PARTITION BY RANGE ( UNIX_TIMESTAMP(report_updated))
(PARTITION p_first VALUES LESS THAN (1475294400) ENGINE = InnoDB,
 PARTITION p201610 VALUES LESS THAN (1477972800) ENGINE = InnoDB,
 PARTITION p201611 VALUES LESS THAN (1480568400) ENGINE = InnoDB,
 PARTITION p201612 VALUES LESS THAN (1483246800) ENGINE = InnoDB,
 PARTITION p201701 VALUES LESS THAN (1485925200) ENGINE = InnoDB,
 PARTITION p201702 VALUES LESS THAN (1488344400) ENGINE = InnoDB,
 PARTITION p201703 VALUES LESS THAN (1491019200) ENGINE = InnoDB,
 PARTITION p201704 VALUES LESS THAN (1493611200) ENGINE = InnoDB,
 PARTITION p201705 VALUES LESS THAN (1496289600) ENGINE = InnoDB,
 PARTITION p201706 VALUES LESS THAN (1498881600) ENGINE = InnoDB,
 PARTITION p201707 VALUES LESS THAN (1501560000) ENGINE = InnoDB,
 PARTITION p201708 VALUES LESS THAN (1504238400) ENGINE = InnoDB,
 PARTITION p201709 VALUES LESS THAN (1506830400) ENGINE = InnoDB,
 PARTITION p201710 VALUES LESS THAN (1509508800) ENGINE = InnoDB,
 PARTITION p201711 VALUES LESS THAN (1512104400) ENGINE = InnoDB,
 PARTITION p_future VALUES LESS THAN MAXVALUE ENGINE = InnoDB) */
1 row in set (0.00 sec)

We can see that it appears to be working as expected.

Stored Procedure Definition (Drop Old Partitions)

This additional stored procedure also contains some comments that explain what it does, so I will let the code speak for itself, for the most part. One noteworthy item to point out is that the stored procedure drops all old partitions individually with ALTER TABLE ... DROP PARTITION, and then it increases the range of the p_first partition with ALTER TABLE ... REORGANIZE PARTITION, so that it fills in the gap left behind.

DROP PROCEDURE IF EXISTS db1.drop_old_partitions;

DELIMITER $$
CREATE PROCEDURE db1.drop_old_partitions(p_schema varchar(64), p_table varchar(64), p_months_to_keep int, p_seconds_to_sleep int)
   LANGUAGE SQL
   NOT DETERMINISTIC
   SQL SECURITY INVOKER
BEGIN
   DECLARE done INT DEFAULT FALSE;
   DECLARE current_partition_name varchar(64);

   -- We'll use this cursor later to get
   -- the list of partitions to drop.
   -- @last_partition_name_to_keep will be
   -- set later.
   DECLARE cur1 CURSOR FOR
   SELECT partition_name
   FROM information_schema.partitions
   WHERE TABLE_SCHEMA = p_schema
   AND TABLE_NAME = p_table
   AND PARTITION_NAME != 'p_first'
   AND PARTITION_NAME != 'p_future'
   AND PARTITION_NAME < @last_partition_name_to_keep;

   DECLARE CONTINUE HANDLER FOR NOT FOUND SET done = TRUE;

   -- Now we get the last month of data that we want to keep
   -- by subtracting p_months_to_keep from the current date.
   -- Note that it will actually keep p_months_to_keep+1 partitions,
   -- since the current month is not complete.
   SET @date = CURDATE();
   SET @months_to_keep = p_months_to_keep;
   SET @q = 'SELECT DATE_SUB(?, INTERVAL ? MONTH) INTO @last_month_to_keep';
   PREPARE st FROM @q;
   EXECUTE st USING @date, @months_to_keep;
   DEALLOCATE PREPARE st;

   -- Then we format the last month in the same format used
   -- in our partition names.
   SET @q = 'SELECT DATE_FORMAT(@last_month_to_keep, ''%Y%m'') INTO @formatted_last_month_to_keep';
   PREPARE st FROM @q;
   EXECUTE st;
   DEALLOCATE PREPARE st;

   -- And then we use the formatted date to build the name of the
   -- last partition that we want to keep. This partition name is
   -- assigned to @last_partition_name_to_keep, which is used in
   -- the cursor declared at the start of the procedure.
   SET @q = 'SELECT CONCAT(''p'', @formatted_last_month_to_keep) INTO @last_partition_name_to_keep';
   PREPARE st FROM @q;
   EXECUTE st;
   DEALLOCATE PREPARE st;

   SELECT CONCAT('Dropping all partitions before: ', @last_partition_name_to_keep);

   SET @first = TRUE;

   -- And then we loop through all partitions returned by the cursor,
   -- and those partitions are dropped.
   OPEN cur1;

   read_loop: LOOP
      FETCH cur1 INTO current_partition_name;

      IF done THEN
         LEAVE read_loop;
      END IF;

      IF ! @first AND p_seconds_to_sleep > 0 THEN
         SELECT CONCAT('Sleeping for ', p_seconds_to_sleep, ' seconds');
         SELECT SLEEP(p_seconds_to_sleep);
      END IF;

      SELECT CONCAT('Dropping partition: ', current_partition_name);

      -- First we build the ALTER TABLE query.
      SET @schema = p_schema;
      SET @table = p_table;
      SET @partition = current_partition_name;
      SET @q = 'SELECT CONCAT(''ALTER TABLE '', @schema, ''.'', @table, '' DROP PARTITION '', @partition) INTO @query';
      PREPARE st FROM @q;
      EXECUTE st;
      DEALLOCATE PREPARE st;

      -- And then we prepare and execute the ALTER TABLE query.
      PREPARE st FROM @query;
      EXECUTE st;
      DEALLOCATE PREPARE st;

      SET @first = FALSE;
   END LOOP;

   CLOSE cur1;

   -- If no partitions were dropped, then we can also skip this.
   IF ! @first THEN
      -- Then we need to get the date of the new first partition.
      -- We need the date in UNIX timestamp format.
      SET @q = 'SELECT DATE_FORMAT(@last_month_to_keep, ''%Y-%m-01 00:00:00'') INTO @new_first_partition_date';
      PREPARE st FROM @q;
      EXECUTE st;
      DEALLOCATE PREPARE st;
      SELECT UNIX_TIMESTAMP(@new_first_partition_date) INTO @new_first_partition_ts;

      -- We also need to get the date of the second partition
      -- since the second partition is also needed for REORGANIZE PARTITION.
      SET @q = 'SELECT DATE_ADD(@new_first_partition_date, INTERVAL 1 MONTH) INTO @second_partition_date';
      PREPARE st FROM @q;
      EXECUTE st;
      DEALLOCATE PREPARE st;
      SELECT UNIX_TIMESTAMP(@second_partition_date) INTO @second_partition_ts;

      SELECT CONCAT('Reorganizing first and second partitions. first partition date = ', @new_first_partition_date, ', second partition date = ', @second_partition_date);

      -- Then we build the ALTER TABLE query.
      SET @schema = p_schema;
      SET @table = p_table;
      SET @q = 'SELECT CONCAT(''ALTER TABLE '', @schema, ''.'', @table, '' REORGANIZE PARTITION p_first, '', @last_partition_name_to_keep, '' INTO ( PARTITION p_first VALUES LESS THAN ( '', @new_first_partition_ts, '' ), PARTITION '', @last_partition_name_to_keep, '' VALUES LESS THAN ( '', @second_partition_ts, '' ) ) '') INTO @query';
      PREPARE st FROM @q;
      EXECUTE st;
      DEALLOCATE PREPARE st;

      -- And then we prepare and execute the ALTER TABLE query.
      PREPARE st FROM @query;
      EXECUTE st;
      DEALLOCATE PREPARE st;
   END IF;
END$$
DELIMITER ;

Let's try running the new procedure:

MariaDB [db1]> SHOW CREATE TABLE db1.quarterly_report_status\G
*************************** 1. row ***************************
       Table: quarterly_report_status
Create Table: CREATE TABLE `quarterly_report_status` (
  `report_id` int(11) NOT NULL,
  `report_status` varchar(20) NOT NULL,
  `report_updated` timestamp NOT NULL DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP
) ENGINE=InnoDB DEFAULT CHARSET=latin1
/*!50100 PARTITION BY RANGE ( UNIX_TIMESTAMP(report_updated))
(PARTITION p_first VALUES LESS THAN (1475294400) ENGINE = InnoDB,
 PARTITION p201610 VALUES LESS THAN (1477972800) ENGINE = InnoDB,
 PARTITION p201611 VALUES LESS THAN (1480568400) ENGINE = InnoDB,
 PARTITION p201612 VALUES LESS THAN (1483246800) ENGINE = InnoDB,
 PARTITION p201701 VALUES LESS THAN (1485925200) ENGINE = InnoDB,
 PARTITION p201702 VALUES LESS THAN (1488344400) ENGINE = InnoDB,
 PARTITION p201703 VALUES LESS THAN (1491019200) ENGINE = InnoDB,
 PARTITION p201704 VALUES LESS THAN (1493611200) ENGINE = InnoDB,
 PARTITION p201705 VALUES LESS THAN (1496289600) ENGINE = InnoDB,
 PARTITION p201706 VALUES LESS THAN (1498881600) ENGINE = InnoDB,
 PARTITION p201707 VALUES LESS THAN (1501560000) ENGINE = InnoDB,
 PARTITION p201708 VALUES LESS THAN (1504238400) ENGINE = InnoDB,
 PARTITION p_future VALUES LESS THAN MAXVALUE ENGINE = InnoDB) */
1 row in set (0.00 sec)

MariaDB [db1]> CALL db1.drop_old_partitions('db1', 'quarterly_report_status', 6, 5);
+--------------------------------------------------------------------------+
| CONCAT('Dropping all partitions before: ', @last_partition_name_to_keep) |
+--------------------------------------------------------------------------+
| Dropping all partitions before: p201702                                  |
+--------------------------------------------------------------------------+
1 row in set (0.00 sec)

+--------------------------------------------------------+
| CONCAT('Dropping partition: ', current_partition_name) |
+--------------------------------------------------------+
| Dropping partition: p201610                            |
+--------------------------------------------------------+
1 row in set (0.00 sec)

+---------------------------------------------------------+
| CONCAT('Sleeping for ', p_seconds_to_sleep, ' seconds') |
+---------------------------------------------------------+
| Sleeping for 5 seconds                                  |
+---------------------------------------------------------+
1 row in set (0.02 sec)

+---------------------------+
| SLEEP(p_seconds_to_sleep) |
+---------------------------+
|                         0 |
+---------------------------+
1 row in set (5.02 sec)

+--------------------------------------------------------+
| CONCAT('Dropping partition: ', current_partition_name) |
+--------------------------------------------------------+
| Dropping partition: p201611                            |
+--------------------------------------------------------+
1 row in set (5.02 sec)

+---------------------------------------------------------+
| CONCAT('Sleeping for ', p_seconds_to_sleep, ' seconds') |
+---------------------------------------------------------+
| Sleeping for 5 seconds                                  |
+---------------------------------------------------------+
1 row in set (5.03 sec)

+---------------------------+
| SLEEP(p_seconds_to_sleep) |
+---------------------------+
|                         0 |
+---------------------------+
1 row in set (10.03 sec)

+--------------------------------------------------------+
| CONCAT('Dropping partition: ', current_partition_name) |
+--------------------------------------------------------+
| Dropping partition: p201612                            |
+--------------------------------------------------------+
1 row in set (10.03 sec)

+---------------------------------------------------------+
| CONCAT('Sleeping for ', p_seconds_to_sleep, ' seconds') |
+---------------------------------------------------------+
| Sleeping for 5 seconds                                  |
+---------------------------------------------------------+
1 row in set (10.05 sec)

+---------------------------+
| SLEEP(p_seconds_to_sleep) |
+---------------------------+
|                         0 |
+---------------------------+
1 row in set (15.05 sec)

+--------------------------------------------------------+
| CONCAT('Dropping partition: ', current_partition_name) |
+--------------------------------------------------------+
| Dropping partition: p201701                            |
+--------------------------------------------------------+
1 row in set (15.05 sec)

+--------------------------------------------------------------------------------------------------------------------------------------------------------------+
| CONCAT('Reorganizing first and second partitions. first partition date = ', @new_first_partition_date, ', second partition date = ', @second_partition_date) |
+--------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Reorganizing first and second partitions. first partition date = 2017-02-01 00:00:00, second partition date = 2017-03-01 00:00:00                            |
+--------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (15.06 sec)

Query OK, 0 rows affected (15.11 sec)

MariaDB [db1]> SHOW CREATE TABLE db1.quarterly_report_status\G
*************************** 1. row ***************************
       Table: quarterly_report_status
Create Table: CREATE TABLE `quarterly_report_status` (
  `report_id` int(11) NOT NULL,
  `report_status` varchar(20) NOT NULL,
  `report_updated` timestamp NOT NULL DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP
) ENGINE=InnoDB DEFAULT CHARSET=latin1
/*!50100 PARTITION BY RANGE ( UNIX_TIMESTAMP(report_updated))
(PARTITION p_first VALUES LESS THAN (1485925200) ENGINE = InnoDB,
 PARTITION p201702 VALUES LESS THAN (1488344400) ENGINE = InnoDB,
 PARTITION p201703 VALUES LESS THAN (1491019200) ENGINE = InnoDB,
 PARTITION p201704 VALUES LESS THAN (1493611200) ENGINE = InnoDB,
 PARTITION p201705 VALUES LESS THAN (1496289600) ENGINE = InnoDB,
 PARTITION p201706 VALUES LESS THAN (1498881600) ENGINE = InnoDB,
 PARTITION p201707 VALUES LESS THAN (1501560000) ENGINE = InnoDB,
 PARTITION p201708 VALUES LESS THAN (1504238400) ENGINE = InnoDB,
 PARTITION p_future VALUES LESS THAN MAXVALUE ENGINE = InnoDB) */
1 row in set (0.00 sec)

We can see that our changes seem to be working as expected. In addition to old partitions being dropped, we can also see that p_first's date range was updated.

Stored Procedure Definition (Tie Other Procedures Together)

It is probably going to be preferable in most cases to perform all partition maintenance at the same time. Therefore, we can create another stored procedure that calls our other two stored procedures. This is fairly straight forward.

DROP PROCEDURE IF EXISTS db1.perform_partition_maintenance;

DELIMITER $$
CREATE PROCEDURE db1.perform_partition_maintenance(p_schema varchar(64), p_table varchar(64), p_months_to_add int, p_months_to_keep int, p_seconds_to_sleep int)
   LANGUAGE SQL
   NOT DETERMINISTIC
   SQL SECURITY INVOKER
BEGIN
   CALL db1.drop_old_partitions(p_schema, p_table, p_months_to_keep, p_seconds_to_sleep);
   CALL db1.create_new_partitions(p_schema, p_table, p_months_to_add);
END$$
DELIMITER ;

Let's reset our partitioned table to its original state, and then let's try running our new stored procedure.

MariaDB [db1]> SHOW CREATE TABLE db1.quarterly_report_status\G
*************************** 1. row ***************************
       Table: quarterly_report_status
Create Table: CREATE TABLE `quarterly_report_status` (
  `report_id` int(11) NOT NULL,
  `report_status` varchar(20) NOT NULL,
  `report_updated` timestamp NOT NULL DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP
) ENGINE=InnoDB DEFAULT CHARSET=latin1
/*!50100 PARTITION BY RANGE ( UNIX_TIMESTAMP(report_updated))
(PARTITION p_first VALUES LESS THAN (1475294400) ENGINE = InnoDB,
 PARTITION p201610 VALUES LESS THAN (1477972800) ENGINE = InnoDB,
 PARTITION p201611 VALUES LESS THAN (1480568400) ENGINE = InnoDB,
 PARTITION p201612 VALUES LESS THAN (1483246800) ENGINE = InnoDB,
 PARTITION p201701 VALUES LESS THAN (1485925200) ENGINE = InnoDB,
 PARTITION p201702 VALUES LESS THAN (1488344400) ENGINE = InnoDB,
 PARTITION p201703 VALUES LESS THAN (1491019200) ENGINE = InnoDB,
 PARTITION p201704 VALUES LESS THAN (1493611200) ENGINE = InnoDB,
 PARTITION p201705 VALUES LESS THAN (1496289600) ENGINE = InnoDB,
 PARTITION p201706 VALUES LESS THAN (1498881600) ENGINE = InnoDB,
 PARTITION p201707 VALUES LESS THAN (1501560000) ENGINE = InnoDB,
 PARTITION p201708 VALUES LESS THAN (1504238400) ENGINE = InnoDB,
 PARTITION p_future VALUES LESS THAN MAXVALUE ENGINE = InnoDB) */
1 row in set (0.00 sec)

MariaDB [db1]> CALL db1.perform_partition_maintenance('db1', 'quarterly_report_status', 3, 6, 5);
+--------------------------------------------------------------------------+
| CONCAT('Dropping all partitions before: ', @last_partition_name_to_keep) |
+--------------------------------------------------------------------------+
| Dropping all partitions before: p201702                                  |
+--------------------------------------------------------------------------+
1 row in set (0.00 sec)

+--------------------------------------------------------+
| CONCAT('Dropping partition: ', current_partition_name) |
+--------------------------------------------------------+
| Dropping partition: p201610                            |
+--------------------------------------------------------+
1 row in set (0.00 sec)

+---------------------------------------------------------+
| CONCAT('Sleeping for ', p_seconds_to_sleep, ' seconds') |
+---------------------------------------------------------+
| Sleeping for 5 seconds                                  |
+---------------------------------------------------------+
1 row in set (0.02 sec)

+---------------------------+
| SLEEP(p_seconds_to_sleep) |
+---------------------------+
|                         0 |
+---------------------------+
1 row in set (5.02 sec)

+--------------------------------------------------------+
| CONCAT('Dropping partition: ', current_partition_name) |
+--------------------------------------------------------+
| Dropping partition: p201611                            |
+--------------------------------------------------------+
1 row in set (5.02 sec)

+---------------------------------------------------------+
| CONCAT('Sleeping for ', p_seconds_to_sleep, ' seconds') |
+---------------------------------------------------------+
| Sleeping for 5 seconds                                  |
+---------------------------------------------------------+
1 row in set (5.03 sec)

+---------------------------+
| SLEEP(p_seconds_to_sleep) |
+---------------------------+
|                         0 |
+---------------------------+
1 row in set (10.03 sec)

+--------------------------------------------------------+
| CONCAT('Dropping partition: ', current_partition_name) |
+--------------------------------------------------------+
| Dropping partition: p201612                            |
+--------------------------------------------------------+
1 row in set (10.03 sec)

+---------------------------------------------------------+
| CONCAT('Sleeping for ', p_seconds_to_sleep, ' seconds') |
+---------------------------------------------------------+
| Sleeping for 5 seconds                                  |
+---------------------------------------------------------+
1 row in set (10.06 sec)

+---------------------------+
| SLEEP(p_seconds_to_sleep) |
+---------------------------+
|                         0 |
+---------------------------+
1 row in set (15.06 sec)

+--------------------------------------------------------+
| CONCAT('Dropping partition: ', current_partition_name) |
+--------------------------------------------------------+
| Dropping partition: p201701                            |
+--------------------------------------------------------+
1 row in set (15.06 sec)

+--------------------------------------------------------------------------------------------------------------------------------------------------------------+
| CONCAT('Reorganizing first and second partitions. first partition date = ', @new_first_partition_date, ', second partition date = ', @second_partition_date) |
+--------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Reorganizing first and second partitions. first partition date = 2017-02-01 00:00:00, second partition date = 2017-03-01 00:00:00                            |
+--------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (15.08 sec)

+--------------------------------------------------------+
| CONCAT('Creating partition: ', @partition_name_to_add) |
+--------------------------------------------------------+
| Creating partition: p201709                            |
+--------------------------------------------------------+
1 row in set (15.16 sec)

+--------------------------------------------------------+
| CONCAT('Creating partition: ', @partition_name_to_add) |
+--------------------------------------------------------+
| Creating partition: p201710                            |
+--------------------------------------------------------+
1 row in set (15.17 sec)

+--------------------------------------------------------+
| CONCAT('Creating partition: ', @partition_name_to_add) |
+--------------------------------------------------------+
| Creating partition: p201711                            |
+--------------------------------------------------------+
1 row in set (15.17 sec)

Query OK, 0 rows affected (15.26 sec)

MariaDB [db1]> SHOW CREATE TABLE db1.quarterly_report_status\G
*************************** 1. row ***************************
       Table: quarterly_report_status
Create Table: CREATE TABLE `quarterly_report_status` (
  `report_id` int(11) NOT NULL,
  `report_status` varchar(20) NOT NULL,
  `report_updated` timestamp NOT NULL DEFAULT CURRENT_TIMESTAMP ON UPDATE CURRENT_TIMESTAMP
) ENGINE=InnoDB DEFAULT CHARSET=latin1
/*!50100 PARTITION BY RANGE ( UNIX_TIMESTAMP(report_updated))
(PARTITION p_first VALUES LESS THAN (1485925200) ENGINE = InnoDB,
 PARTITION p201702 VALUES LESS THAN (1488344400) ENGINE = InnoDB,
 PARTITION p201703 VALUES LESS THAN (1491019200) ENGINE = InnoDB,
 PARTITION p201704 VALUES LESS THAN (1493611200) ENGINE = InnoDB,
 PARTITION p201705 VALUES LESS THAN (1496289600) ENGINE = InnoDB,
 PARTITION p201706 VALUES LESS THAN (1498881600) ENGINE = InnoDB,
 PARTITION p201707 VALUES LESS THAN (1501560000) ENGINE = InnoDB,
 PARTITION p201708 VALUES LESS THAN (1504238400) ENGINE = InnoDB,
 PARTITION p201709 VALUES LESS THAN (1506830400) ENGINE = InnoDB,
 PARTITION p201710 VALUES LESS THAN (1509508800) ENGINE = InnoDB,
 PARTITION p201711 VALUES LESS THAN (1512104400) ENGINE = InnoDB,
 PARTITION p_future VALUES LESS THAN MAXVALUE ENGINE = InnoDB) */
1 row in set (0.00 sec)

This stored procedure also seems to be working as expected.

Running the Procedure More Often Than Necessary

It should be noted that these stored procedures can be run more often than is necessary. If the procedures are run when no partitions need to be added or deleted, then the procedure will not perform any work. Let's reset our table definition and try it out.

MariaDB [db1]> CALL db1.perform_partition_maintenance('db1', 'quarterly_report_status', 3, 6, 5);
+--------------------------------------------------------------------------+
| CONCAT('Dropping all partitions before: ', @last_partition_name_to_keep) |
+--------------------------------------------------------------------------+
| Dropping all partitions before: p201702                                  |
+--------------------------------------------------------------------------+
1 row in set (0.00 sec)

+--------------------------------------------------------+
| CONCAT('Dropping partition: ', current_partition_name) |
+--------------------------------------------------------+
| Dropping partition: p201610                            |
+--------------------------------------------------------+
1 row in set (0.00 sec)

+---------------------------------------------------------+
| CONCAT('Sleeping for ', p_seconds_to_sleep, ' seconds') |
+---------------------------------------------------------+
| Sleeping for 5 seconds                                  |
+---------------------------------------------------------+
1 row in set (0.03 sec)

+---------------------------+
| SLEEP(p_seconds_to_sleep) |
+---------------------------+
|                         0 |
+---------------------------+
1 row in set (5.03 sec)

+--------------------------------------------------------+
| CONCAT('Dropping partition: ', current_partition_name) |
+--------------------------------------------------------+
| Dropping partition: p201611                            |
+--------------------------------------------------------+
1 row in set (5.03 sec)

+---------------------------------------------------------+
| CONCAT('Sleeping for ', p_seconds_to_sleep, ' seconds') |
+---------------------------------------------------------+
| Sleeping for 5 seconds                                  |
+---------------------------------------------------------+
1 row in set (5.06 sec)

+---------------------------+
| SLEEP(p_seconds_to_sleep) |
+---------------------------+
|                         0 |
+---------------------------+
1 row in set (10.06 sec)

+--------------------------------------------------------+
| CONCAT('Dropping partition: ', current_partition_name) |
+--------------------------------------------------------+
| Dropping partition: p201612                            |
+--------------------------------------------------------+
1 row in set (10.06 sec)

+---------------------------------------------------------+
| CONCAT('Sleeping for ', p_seconds_to_sleep, ' seconds') |
+---------------------------------------------------------+
| Sleeping for 5 seconds                                  |
+---------------------------------------------------------+
1 row in set (10.08 sec)

+---------------------------+
| SLEEP(p_seconds_to_sleep) |
+---------------------------+
|                         0 |
+---------------------------+
1 row in set (15.09 sec)

+--------------------------------------------------------+
| CONCAT('Dropping partition: ', current_partition_name) |
+--------------------------------------------------------+
| Dropping partition: p201701                            |
+--------------------------------------------------------+
1 row in set (15.09 sec)

+--------------------------------------------------------------------------------------------------------------------------------------------------------------+
| CONCAT('Reorganizing first and second partitions. first partition date = ', @new_first_partition_date, ', second partition date = ', @second_partition_date) |
+--------------------------------------------------------------------------------------------------------------------------------------------------------------+
| Reorganizing first and second partitions. first partition date = 2017-02-01 00:00:00, second partition date = 2017-03-01 00:00:00                            |
+--------------------------------------------------------------------------------------------------------------------------------------------------------------+
1 row in set (15.11 sec)

+--------------------------------------------------------+
| CONCAT('Creating partition: ', @partition_name_to_add) |
+--------------------------------------------------------+
| Creating partition: p201709                            |
+--------------------------------------------------------+
1 row in set (15.18 sec)

+--------------------------------------------------------+
| CONCAT('Creating partition: ', @partition_name_to_add) |
+--------------------------------------------------------+
| Creating partition: p201710                            |
+--------------------------------------------------------+
1 row in set (15.18 sec)

+--------------------------------------------------------+
| CONCAT('Creating partition: ', @partition_name_to_add) |
+--------------------------------------------------------+
| Creating partition: p201711                            |
+--------------------------------------------------------+
1 row in set (15.18 sec)

Query OK, 0 rows affected (15.28 sec)

MariaDB [db1]> CALL db1.perform_partition_maintenance('db1', 'quarterly_report_status', 3, 6, 5);
+--------------------------------------------------------------------------+
| CONCAT('Dropping all partitions before: ', @last_partition_name_to_keep) |
+--------------------------------------------------------------------------+
| Dropping all partitions before: p201702                                  |
+--------------------------------------------------------------------------+
1 row in set (0.01 sec)

Query OK, 0 rows affected (0.02 sec)

As we can see from the above output, the procedure did not perform any work the second time.

Event Definition

We want our stored procedure to run automatically every month, so we can use an event to do that. Before testing the event, we need to do two things:

We need to recreate the table with the original definition so that it has all of the original partitions.
We need to ensure that event_scheduler=ON is set, and if not, we need to set it.

MariaDB [(none)]> SHOW GLOBAL VARIABLES LIKE 'event_scheduler';
+-----------------+-------+
| Variable_name   | Value |
+-----------------+-------+
| event_scheduler | OFF   |
+-----------------+-------+
1 row in set (0.00 sec)

MariaDB [(none)]> SET GLOBAL event_scheduler=ON;
Query OK, 0 rows affected (0.00 sec)

MariaDB [(none)]> SHOW GLOBAL VARIABLES LIKE 'event_scheduler';
+-----------------+-------+
| Variable_name   | Value |
+-----------------+-------+
| event_scheduler | ON    |
+-----------------+-------+
1 row in set (0.00 sec)

And then we can run the following:

DROP EVENT db1.monthly_perform_partition_maintenance_event;

CREATE EVENT db1.monthly_perform_partition_maintenance_event
   ON SCHEDULE
   EVERY 1 MONTH
   STARTS NOW()
DO
   CALL db1.perform_partition_maintenance('db1', 'quarterly_report_status', 3, 6, 5);

However, there's another great change that we can make here. It might not be ideal to only run the procedure once per month, because if the procedure fails for whatever reason, then it might not get another chance to run again until the next month. For that reason, it might be better to run the procedure more often, such as once per day. As mentioned above, the procedure will only do work when partition maintenance is actually necessary, so it should not cause any issues to execute the procedure more often.

If we wanted to run the procedure once per day, then the event definition would become:

DROP EVENT db1.monthly_perform_partition_maintenance_event;

CREATE EVENT db1.monthly_perform_partition_maintenance_event
   ON SCHEDULE
   EVERY 1 DAY
   STARTS NOW()
DO
   CALL db1.perform_partition_maintenance('db1', 'quarterly_report_status', 3, 6, 5);

Conclusion

Thanks to the flexibility of stored procedures and events, it is relatively easy to automatically perform partition maintenance in MariaDB. Has anyone else implemented something like this?

Partition (database) MariaDB

Published at DZone with permission of Geoff Montee, DZone MVB. See the original article here.

Opinions expressed by DZone contributors are their own.

Related

Trending
