Using the Microsoft Service Bus Connector With Mulesoft

The service bus connector in Mule enables message integration with Windows Service Bus on-premise as well as with Azure Service Bus on the cloud.

By
Jitendra Bafna user avatar
Jitendra Bafna
DZone Core CORE ·
Updated May. 10, 17 · Tutorial
Likes (5)
Comment
Save
Tweet
Share
10.2K Views

Join the DZone community and get the full member experience.

Join For Free

This connector supports the communication with queues, topics, and EventHubs through AMQP 1.0.

Features of Service Bus Connector

  • Send messages to queues, topics, and EventHubs with the support of AMQP.

  • Receive from queues and topic asynchronously.

  • Supports Windows Service Bus on-premise as well as Azure Service Bus on the cloud.

  • Rest management API like CRUD for queues, topics, subscriptions, and rules.

First, go through my article on how to create a service bus with Windows Azure. This article will give you a brief idea on how to create queues and topics in Azure cloud.

Now, we will walk through how to send and receive messages from the Windows Azure Service Bus queue.

Send Messages to the Windows Azure Service Bus Queue

Place the HTTP listener into the canvas and click to open the Properties console.

Click the green + and configure as follows:

  • Host: localhost.

  • Port: 8081.

  • Method: POST.

  • Path: servicebus.

Image title

Search and drag the Microsoft Service Bus Connector into the canvas. If the Microsoft Service Bus Connector is not found, then install it from Anypoint Exchange.

Click on the green + to configure the Microsoft Service Bus Connector.

Image title

Select Microsoft Service Bus: Azure Service Bus.

Image titleProvide Service Name, Shared Access Key Name, and Shared Access Key. Then, you can get it from the Windows Azure Service Bus connection information.

Image title

Perform the test connection and press OK.

Select Operation Queue send and provide the destination queue name.

Image title

Test the Application

You can use Postman to send the request to Mule flow and Mule flow will send a message to the Azure Service Bus queue. The URL is http://localhost:8081/servicebus.

Image titleYou can verify in the Azure Service Bus queue whether the message was received.

Image title

Code:

<?xml version="1.0" encoding="UTF-8"?>
<mule
xmlns:http="http://www.mulesoft.org/schema/mule/http"
xmlns:microsoftservicebus="http://www.mulesoft.org/schema/mule/microsoftservicebus"
xmlns="http://www.mulesoft.org/schema/mule/core"
xmlns:doc="http://www.mulesoft.org/schema/mule/documentation"
xmlns:spring="http://www.springframework.org/schema/beans"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans-current.xsd
http://www.mulesoft.org/schema/mule/core http://www.mulesoft.org/schema/mule/core/current/mule.xsd
http://www.mulesoft.org/schema/mule/http http://www.mulesoft.org/schema/mule/http/current/mule-http.xsd
http://www.mulesoft.org/schema/mule/microsoftservicebus http://www.mulesoft.org/schema/mule/microsoftservicebus/current/mule-microsoftservicebus.xsd">
<microsoftservicebus:azureConfig name="Microsoft_Service_Bus__Azure_Service_Bus" namespace="" userName="" password="" doc:name="Microsoft Service Bus: Azure Service Bus"/>
<http:listener-config name="HTTP_Listener_Configuration" host="0.0.0.0" port="8081" doc:name="HTTP Listener Configuration"/>
<flow name="servicebusflowFlow">
<http:listener config-ref="HTTP_Listener_Configuration" path="/servicebus" allowedMethods="POST" doc:name="HTTP"/>
<microsoftservicebus:queue-send config-ref="Microsoft_Service_Bus__Azure_Service_Bus" destinationQueue="muletestqueue" doc:name="Microsoft Service Bus"/>
<set-payload value="Message Sent to Queue" doc:name="Set Payload"/>
</flow>
</mule>

Receive Messages From the Windows Azure Service Bus Queue

Search and drag the Microsoft Service Bus Connector in the message source area of the canvas. Configure in the same way as we have done above.

Select Operation Queue receive and provide the source queue.

Image title

This is how you can receive a message from the Azure Service Bus queue:

<?xml version="1.0" encoding="UTF-8"?>
<mule
xmlns:file="http://www.mulesoft.org/schema/mule/file"
xmlns:http="http://www.mulesoft.org/schema/mule/http"
xmlns:microsoftservicebus="http://www.mulesoft.org/schema/mule/microsoftservicebus"
xmlns="http://www.mulesoft.org/schema/mule/core"
xmlns:doc="http://www.mulesoft.org/schema/mule/documentation"
xmlns:spring="http://www.springframework.org/schema/beans"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans-current.xsd
http://www.mulesoft.org/schema/mule/core http://www.mulesoft.org/schema/mule/core/current/mule.xsd
http://www.mulesoft.org/schema/mule/http http://www.mulesoft.org/schema/mule/http/current/mule-http.xsd
http://www.mulesoft.org/schema/mule/microsoftservicebus http://www.mulesoft.org/schema/mule/microsoftservicebus/current/mule-microsoftservicebus.xsd
http://www.mulesoft.org/schema/mule/file http://www.mulesoft.org/schema/mule/file/current/mule-file.xsd">
<microsoftservicebus:azureConfig name="Microsoft_Service_Bus__Azure_Service_Bus" namespace="" userName="" password="" doc:name="Microsoft Service Bus: Azure Service Bus"/>
<http:listener-config name="HTTP_Listener_Configuration" host="0.0.0.0" port="8081" doc:name="HTTP Listener Configuration"/>
<flow name="servicebusflowFlow">
<microsoftservicebus:queue-receive config-ref="Microsoft_Service_Bus__Azure_Service_Bus" sourceQueue="muletestqueue" doc:name="Microsoft Service Bus"/>
<file:outbound-endpoint path="src/test/resources/out" responseTimeout="10000" doc:name="File"/>
</flow>
</mule>

Similarly, you can configure the service bus topic to receive and send messages.

Now, you know how to send and receive messages from Azure Service Bus queue with Mulesoft.

Here is the video tutorial.
